Subaru Legacy III (2000-2003 year). Manual - part 51

ME(H4SO)-16

MECHANICAL

GENERAL DESCRIPTION

22771AA030

SELECT MONI-
TOR KIT

Troubleshooting for electrical systems.
• English: 22771AA030 (Without printer)
• German: 22771AA070 (Without printer)
• French: 22771AA080 (Without printer)
• Spanish: 22771AA090 (Without printer)

498267800

CYLINDER HEAD
TABLE

• Used for replacing valve guides.
• Used for removing and installing valve springs.

498277200

STOPPER SET

Used for installing automatic transmission assem-
bly to engine.

498457000

ENGINE STAND
ADAPTER RH

Used with ENGINE STAND (499817000).

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

ST22771AA030

ST-498267800

ST-498277200

ST-498457000

ME(H4SO)-17

MECHANICAL

GENERAL DESCRIPTION

498457100

ENGINE STAND
ADAPTER LH

Used with ENGINE STAND (499817000).

498497100

CRANKSHAFT
STOPPER

Used for stopping rotation of flywheel when loos-
ening and tightening crankshaft pulley bolt, etc.

498547000

OIL FILTER
WRENCH

Used for removing and installing oil filter.

398744300

(2000 cc model)

PISTON GUIDE

Used for installing piston in cylinder.

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

ST-498457100

ST-498497100

ST-498547000

ST-398744300

ME(H4SO)-18

MECHANICAL

GENERAL DESCRIPTION

498747300

(2500 cc model)

PISTON GUIDE

Used for installing piston in cylinder.

498857100

VALVE OIL SEAL
GUIDE

Used for press-fitting of intake and exhaust valve
guide oil seals.

499017100

PISTON PIN
GUIDE

Used for installing piston pin, piston and connect-
ing rod.

499037100

CONNECTING
ROD BUSHING
REMOVER &
INSTALLER

Used for removing and installing connecting rod
bushing.

499057000

TORX PLUS

Used for removing flywheel (Dual mass flywheel).

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

ST-498747300

ST-498857100

ST-499017100

ST-499037100

ST-499057000

ME(H4SO)-19

MECHANICAL

GENERAL DESCRIPTION

499587200

CRANKSHAFT
OIL SEAL
INSTALLER

• Used for installing crankshaft oil seal.
• Used with CRANKSHAFT OIL SEAL GUIDE
(499597100).

499587500

OIL SEAL
INSTALLER

Used for installing camshaft oil seal.

499587700

CAMSHAFT OIL
SEAL INSTALLER

Used for installing cylinder head plug.

499097700

PISTON PIN
REMOVER ASSY

Used for removing piston pin.

499207400

CAMSHAFT
SPROCKET
WRENCH

Used for removing and installing camshaft
sprocket. (RH side)

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

ST-499587200

ST-499587500

ST-499587700

ST-499097700

ST-499207400
