ME(H4SO)-8

MECHANICAL

GENERAL DESCRIPTION

3. VALVE ROCKER ASSEMBLY

(1) Intake valve rocker arm

(5) Rocker shaft support

Tightening torque: N·m (kgf-m, ft-lb)

(2) Valve rocker nut

(6) Intake rocker shaft

T1: 5 (0.5, 3.6)

(3) Valve rocker adjuster screw

(7) Exhaust rocker shaft

T2: 10 (1.0, 7.2)

(4) Spring

(8) Exhaust valve rocker arm

T3: 25 (2.5, 18.1)

( 3 )

( 3 )

( 3 )

( 3 )

ME-00187

T2

T1

T3

T1

T2

T3

T2

T2

( 1 )

( 2 )

( 4 )

( 4 )

( 5 )

( 1 )

( 2 )

( 6 )

( 1 )

( 2 )

( 2 )

( 4 )

( 4 )

( 5 )

( 1 )

( 7 )

( 3 )

( 3 )

( 2 )

( 2 )

( 8 )

ME(H4SO)-9

MECHANICAL

GENERAL DESCRIPTION

4. CYLINDER HEAD AND VALVE ASSEMBLY

(1) Exhaust valve

(4) Valve spring seat

(7) Retainer

(2) Intake valve

(5) Intake valve oil seal

(8) Retainer key

(3) Valve guide

(6) Valve spring

(9) Exhaust valve oil seal

ME-00188

( 2 )

( 2 )

( 3 )

( 4 )

( 6 )

( 7 )

( 8 )

( 1 )

( 1 )

( 9 )

( 3 )

( 4 )

( 5 )

( 6 )

( 7 )

( 8 )

ME(H4SO)-10

MECHANICAL

GENERAL DESCRIPTION

5. CYLINDER BLOCK

(1) Oil pressure switch

(14) Baffle plate

Tightening torque: N·m (kgf-m, ft-lb)

(2) Cylinder block (RH)

(15) Oil filter connector

T1: 5 (0.5, 3.6)

(3) Service hole plug

(16) Oil strainer

T2: 6.4 (0.65, 4.7)

(4) Gasket

(17) Gasket

T3: 10 (1.0, 7)

(5) Oil separator cover

(18) Oil pan

T4: 25 (2.5, 18.1)

(6) Water by-pass pipe

(19) Drain plug

T5: <Ref. to ME(H4SO)-72, INSTAL-

LATION, CYLINDER BLOCK.>

(7) Oil pump

(20) Metal gasket

(8) Front oil seal

(21) Oil level gauge guide

T6: 70 (7.1, 51)

(9) Rear oil seal

(22) Water pump sealing

T7: First 12 (1.2, 8.7)

Second 12 (1.2, 8.7)

(10) O-ring

(23) Oil filter

(11) Service hole cover

(24) Gasket

T8: 45 (4.6, 33)

(12) Cylinder block (LH)

(25) Water pump hose

T9: 44 (4.5, 33)

(13) Water pump

(26) Plug

T10: 25 (2.5, 18.1)

ME-00377

(14)

T6

T7

T2

T2

T4

T8

T4

T5

T2

T6

T6

T10

T1

T2

T8

T1

T3

T9

T2

T2

(9)

(8)

(7)

(6)

(10)

(10)

(10)

(26)

(22)

(11)

(12)

(13)

(19)

(18)

(20)

(17)

(16)

(24)

(10)

(25)

(5)

(4)

(4)

(4)

(3)

(3)

(3)

(2)

(1)

(21)

(15)

(23)

T5

T2

T5

T4

ME(H4SO)-11

MECHANICAL

GENERAL DESCRIPTION

MEMO:
