RS-19 General Diagnostic Table REAR SUSPENSION 10.General Diagnostic Table A: INSPECTION 1. IMPROPER VEHICLE POSTURE OR IMPROPER WHEEL ARCH HEIGHT 2. POOR RIDE COMFORT 1) Large rebound shock 2) Rocking of the vehicle continues too long after running over bump and hump. 3) Excessive shock in bumping 3. NOISE Possible cause Corrective action (1) Permanent distortion or damaged coil spring Replace. (2) Rough operation of strut or shock absorber Replace. (3) Improper installation of strut or shock absorber Replace with proper parts. (4) Installation of the wrong coil spring Replace with proper parts. Possible cause Corrective action (1) Damaged coil spring Replace. (2) Overinflation of tires Adjust. (3) Improper wheel arch height Replace the coil springs with new parts. (4) Fault in operation of strut or shock absorber Replace. (5) Damage or deformation of strut mount or shock absorber mount Replace. (6) Unsuitable length (maximum or minimum) of strut or shock absorber Replace with appropriate parts. (7) Deformation or loss of bushing Replace. (8) Deformation or damage of helper in strut assembly or shock absorber Replace. (9) Oil leakage from the strut or shock absorber Replace. Possible cause Corrective action (1) Wear or damage of strut or shock absorber component parts Replace. (2) Loosening of the suspension link installing bolt Tighten to the specified torque. (3) Deformation or loss of bushing Replace. (4) Unsuitable length (maximum or minimum) of strut or shock absorber Replace with appropriate parts. (5) Damaged coil spring Replace. (6) Wear or damage of the ball joint Replace. (7) Deformation of the stabilizer clamp Replace. |
