CO(w/o STI)-21 Radiator COOLING 10) Connect the connector (A) to the main fan mo- tor and the connector (B) to the sub fan motor. 11) Install the under cover. <Ref. to EI-28, INSTAL- 12) Lower the vehicle. 13) Connect the battery ground terminal. 14) Fill engine coolant. <Ref. to CO(w/o STI)-13, FILLING OF ENGINE COOLANT, REPLACE- C: INSPECTION 1) Check that the radiator does not have deforma- tion, cracks or damage. 2) Check that the hose has no cracks, damage or loose part. 3) Remove the coolant filler tank cap, fill the cool- ant filler tank with engine coolant, then install the radiator cap tester to the filler neck of coolant filler tank. 4) Apply a pressure of 122 kPa (1.2 kg/cm 2 , 18 psi) to the radiator and check the following points: • Leakage from the radiator or its vicinity • Leakage from the hose or its connections • Inspection must be carried out at the side of coolant filler tank, not at the side of radiator. • Engine should be turned off. • Wipe engine coolant from check points in ad- vance. • Be careful not to deform the filler neck of the coolant filler tank when installing and removing the radiator cap tester. • Be careful of engine coolant from spurting out when removing the radiator cap tester. (A) CO-02727 (B) CO-02728 IN-00203 CO-02244 |
