Subaru Impreza 3 / Impreza WRX / Impreza WRX STI. Manual - part 13

PI-6

Pre-delivery Inspection

PRE-DELIVERY INSPECTION

(2) Operate the lever using a tool such as a

screwdriver to check that the rear gate is un-

locked normally.

8. FUEL LID OPENER LOCK RELEASE LE-

VER

Operate the fuel lid opener to check that the fuel lid

is unlocked normally. Check that the filler cap is se-

curely closed.

9. ACCESSORY

Check that the following accessories are provided.

• Owner’s manual

• Warranty booklet

• Maintenance note

• Spare key

• Tool set

• Towing hook (eyebolt)

• Spare tire

• Key No. plate

• Security ID plate

• Jack

• Jack handle

4 door model

5 door model

PI-00406

(A) Jack handle
(B) Tool set

(E) Towing hook (eyebolt)

(A) Jack
(B) Jack handle

PI-00436

(A)

(B)

(C)

(D)

(E)

PI-00664

(A)

(B)

(C)

(D)

PI-7

Pre-delivery Inspection

PRE-DELIVERY INSPECTION

10.FRONT HOOD LOCK RELEASE SYSTEM

Operate the front hood release knob to check that

the front hood will unlock properly.

Operate the lever (A) and check that the front hood

is opened normally.

11.BATTERY

Check the battery terminals to make sure that there

are no rust or corrosions due to fluid leaks. Check

that the battery caps are securely tightened.

12.BRAKE FLUID

Check the brake fluid amount. If the amount is in-

sufficient, carry out a brake line test to identify

brake fluid leaks and check the brake operation. Af-

ter that, refill the brake fluid tank with the specified

type of fluid.
CAUTION:

If the brake fluid is spilt over exhaust pipe, wipe

it off with cloth to avoid emitting smoke or

causing a fire.

PI-00433

PI-00413

(A)

(A) Cap
(B) Upper level

PI-00012

(A)

(B)

(C)

PI-8

Pre-delivery Inspection

PRE-DELIVERY INSPECTION

13.ENGINE OIL

Check the engine oil amount. If the amount of oil is

insufficient, check that no leaks are found. Then, add

the necessary amount of the specified engine oil.

CAUTION:

If any engine oil is spilled on the exhaust pipe,

under cover, wipe off completely to prevent

fires or emission of smoke.

14.TRANSMISSION GEAR OIL

5MT model
Check for leakage of the transmission gear oil. Re-

fer to “5MT” section for transmission gear oil in-

spection. <Ref. to 5MT-22, INSPECTION,

Transmission Gear Oil.>
CAUTION:

If gear oil is spilt over the exhaust pipe, wipe it

off with a cloth to avoid emitting smoke or

causing a fire.

6MT model
Check for leakage of the transmission gear oil.

15.REAR DIFFERENTIAL GEAR OIL

Check for leakage of gear oil from the rear differen-

tial.

16.ENGINE COOLANT

Check the coolant amount on the reservoir. If the

amount of engine coolant is insufficient, check that

no leaks are found. Then, add the necessary

amount of coolant with the specified concentration.
CAUTION:

If any engine coolant is spilled on the exhaust

pipe, wipe off completely to prevent fires or

emission of smoke.

17.CLUTCH FLUID

Check the clutch fluid amount. If the amount of fluid

is insufficient, check that no leaks are found. Then,

add the necessary amount of specified fluid.

CAUTION:

If any clutch fluid is spilled on the exhaust pipe,

wipe off completely to prevent fires or emission

of smoke.

18.WINDOW WASHER FLUID

Check the window washer fluid amount. If the

amount is insufficient, check that no leaks are

found. Then, add the necessary amount of washer

fluid.

(A) Oil level gauge
(B) Engine oil filler cap

(E) Approx. 1.0 L (1.1 US qt, 0.9 Imp qt)

(F) Notch mark

(A) Oil level gauge
(B) Upper level

(C)

(B)

(D)

(E)

(F)

(A)

PI-00460

(B)
(C)

(A)

PI-00564

(A) Reservoir tank
(B) MIN. level

(A)

(B)

(C)

PM-00076

PI-00409

PI-9

Pre-delivery Inspection

PRE-DELIVERY INSPECTION

19.FRONT HOOD LATCH

Close the front hood. Check that the front hood is

completely latched.

20.KEYLESS ENTRY SYSTEM

Check the keyless entry system operations as fol-

lows:

• Fully open all the door windows.

• Remove the key from the ignition switch and

close all the doors including rear gate.

• Press the “LOCK/ARM” button momentarily on

the keyless transmitter. Check that all the doors be-

come locked, the buzzer sounds once, and the

hazard lights flash once.

• Press the “UNLOCK/DISARM” button momen-

tarily on the keyless transmitter. Check that the

driver’s door is unlocked, the buzzer sounds twice,

and the hazard lights flash twice.

• Within 5 seconds, press the “UNLOCK/DISARM”

button momentarily on the keyless transmitter.

Check that all doors (including rear gate) are un-

locked.

• Lock all the doors including rear gate. Press the

rear gate unlock button to unlock the rear gate.

Check that the buzzer sounds twice, and the haz-

ard lights flash twice. Press the release button and

check that the rear gate opens. (Wagon model)

• Check that the buzzer sounds twice, and the

hazard lights flash twice, when the trunk lid unlock

button is held down to unlock the trunk lid. (Sedan

model)

• Press the “PANIC” button of the keyless trans-

mitter. Check that the panic mode (the horn keeps

sounding) is initiated. Also, check that this condi-

tion continues for 30 seconds or until when any of

the buttons on the keyless transmitter are pressed.

• Press the “LOCK/ARM” button momentarily on

the keyless transmitter with one of the doors (in-

cluding the rear gate) opened. Check that the buzz-

er sounds 5 times, and the hazard light flashes 5

times to notify the door not being fully closed. Next,

close all the doors including rear gate. Check if all

doors are locked and buzzer sounds once and the

hazard light flashes once.

• With one of the doors open (including the rear

gate), press the “LOCK” side of the power door lock

switch. Next, close all the doors including rear gate.

Check if all doors are locked and buzzer sounds

once and the hazard light flashes once.

• Driver’s side

PI-00357

PI-00358

PI-00503

PI-00502

PANIC

PI-00720
