Subaru Legacy (2005 year). Manual - part 834

PS-7

POWER ASSISTED SYSTEM (POWER STEERING)

General Description

• Gearbox (LHD model)

(1)

Pipe C

(20)

Adapter

(39)

O-ring

(2)

Pipe D

(21)

Clamp

(40)

Bracket

(3)

Clamp plate

(22)

Cotter pin

(41)

Bushing

(4)

Universal joint

(23)

Castle nut

(42)

Lock washer

(5)

Dust seal

(24)

Dust cover

(43)

Back-up washer

(6)

Valve housing

(25)

Clip

(7)

Gasket

(26)

Tie-rod end

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(8)

Oil seal

(27)

Clip

T1: 6 (0.6, 4.3)

(9)

Bushing

(28)

Boot

T2: 3.9 (0.4, 2.9)

(10)

Seal ring

(29)

Band

T3: 85 (8.7, 62.7)

(11)

Pinion & valve ASSY

(30)

Tie-rod

T4: 13 (1.3, 9.6)

(12)

Oil seal

(31)

Pipe B

T5: 15 (1.5, 10.8)

(13)

Back-up washer

(32)

Pipe A

T6: 24 (2.4, 17.4)

(14)

Ball bearing

(33)

Steering body

T7: 25 (2.5, 18.4)

(15)

Snap ring

(34)

Oil seal

T8: 27 (2.75, 19.9)

(16)

Lock nut

(35)

Piston ring

T9: 60 (6.1, 44.1)

(17)

Adjusting screw

(36)

Rack

T10: 70 (7.1, 51.6)

(18)

Spring

(37)

Rack bushing

T11: 78 (8.0, 57.9)

(19)

Sleeve

(38)

Holder

T11

(2)

(3)

(22)

(20)

(23)

(24)

(25)

(26)

(27)

(28)

(29)

(30)

(38)

(37)

(32)

(36)

(35)

(30)

(28)

(27)

(26)

(25)

(24)

(7)

(8)

(9)

(10)

(11)

(22)

(23)

(5)

(6)

(4)

(1)

(3)

(12)

(13)

(15)

(42)

(14)

(33)

(19)

(18)

(17)

(16)

(21)

(34)

(31)

(39)

PS-00709

(29)

(40)

(41)

T10

(43)

PS-8

POWER ASSISTED SYSTEM (POWER STEERING)

General Description

• Gearbox (RHD model)

(1)

Universal joint

(18)

Band

(35)

Bushing

(2)

Dust cover

(19)

Tie-rod

(36)

Bracket

(3)

Plug

(20)

Holder (Turbo, 3.0 R model)

(37)

Holder (Except for turbo, 3.0 R
model)

(4)

O-ring

(21)

Bushing

(5)

Oil seal

(22)

Oil seal

(6)

Control valve

(23)

Oil seal

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(7)

Seal ring

(24)

O-ring

T1: 27 (2.75, 19.9)

(8)

Oil seal

(25)

Rack

T2: 85 (8.7, 62.7)

(9)

Adapter

(26)

Oil seal

T3: 20 (2.0, 14.5)

(10)

Clamp

(27)

Back-up washer

T4: 24 (2.4, 17.4)

(11)

Castle nut

(28)

Steering body

T5: 64 (6.5, 47.0)

(12)

Cotter pin

(29)

Pipe A

T6: 90 (9.2, 66.4)

(13)

Dust seal

(30)

Pipe B

T7: 60 (6.1, 44.1)

(14)

Clip

(31)

Lock nut

T8: 39 (4.0, 28.9)

(15)

Tie-rod end

(32)

Adjusting screw

T9: 75 (7.6, 55.3)

(16)

Clip

(33)

Spring

(17)

Boot

(34)

Sleeve

(1)

(2)

(3)

(4)

(5)

(7)

(6)

(9)

(10)

(11)

(12)

(13)

(14)

(15)

(16)

(17)

(18)

(19)

(21)

(22)

(23)

(24)

(25)

(26)

(27)

(28)

(29)

(30)

(31)

(32)

(33)

(34)

(35)

(36)

(8)

PS-00710

(20)

PS-9

POWER ASSISTED SYSTEM (POWER STEERING)

General Description

3. OIL PUMP

• H4 model

(1)

Oil pump

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(2)

Pulley

T1: 8 (0.8, 5.8)

(3)

Bracket

T2: 15.7 (1.6, 11.6)

(4)

Belt tension nut

T3: 22 (2.2, 15.9)

T4: 25 (2.5, 18.4)

T5: 37.3 (3.8, 27.5)

PS-00480

(3)

(2)

(1)

(4)

PS-10

POWER ASSISTED SYSTEM (POWER STEERING)

General Description

• H6 model

C: CAUTION

• Wear work clothing, including a cap, protective
goggles and protective shoes during operation.
• Before removal, installation or disassembly, be
sure to clarify the failure. Avoid unnecessary re-
moval, installation, disassembly and replacement.
• Be careful not to burn yourself, because each
part on the vehicle is hot after running.
• Use SUBARU genuine power steering fluid,
grease etc. or the equivalent.Do not mix fluid,
grease etc. with that of another grade or from other
manufacturers.
• Be sure to tighten fasteners including bolts and
nuts to the specified torque.
• Place shop jacks or rigid racks at the specified
points.
• Before securing a part on a vise, place cushion-
ing material such as wooden blocks, aluminum
plate or cloth between the part and the vise.

(1)

Oil pump

Tightening torque: N

⋅

m (kgf-m, ft-lb)

(2)

Pulley

T1: 15.7 (1.6, 11.6)

(3)

Bracket

T2: 25 (2.5, 18.4)

(4)

Belt tensioner

T3: 33 (3.4, 24.3)

T4: 37.3 (3.8, 27.5)

PS-00699

(2)

(3)

(1)

(4)
