EN(H4SO 2.5)(diag)-13
ENGINE (DIAGNOSTICS)
Electrical Component Location
3. SOLENOID VALVE, ACTUATOR, EMISSION CONTROL SYSTEM PARTS AND IGNITION
SYSTEM PARTS
(1)
Purge control solenoid valve
(3)
Tumble generator valve actuator
(EC, EK, EH, ER and K4 model)
(4)
Ignition coil and ignitor ASSY
(2)
EGR valve (EC, EK, EH, ER and
K4 model)
(5)
Fuel injector
EN-02452
(4)
(2)
(3)
(5)
(5)
(3)
(1)
