POWER STEERING

STAVIC - 2004.09

32

4G

- Layout of high and low pressure pipe

Front

Rear

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

POWER STEERING

STAVIC - 2004.09

33

4G

TROUBLE DIAGNOSIS

Lack of lubrication

Abnormal wear or binding of steering ball joint

Damaged or faulty steering gear

Improper preload of steering pinion

Faulty steering shaft joint

Steering fluid leaks

Lack of fluid or air-in system

Faulty steering oil pump

Damaged or loosened pump drive belt

Clogging oil line

Damaged wheel or tire

Faulty suspension system

Damaged steering linkage

Damaged wheel and tire

Faulty brake system

Faulty suspension system

Worn steering gear

Worn or damaged steering ball joint

Loosened steering gearbox bolts

Damaged or binding steering ball joint

Improper preload of steering pinion

Damaged wheel or tire

Faulty suspension system

Damaged steering linkage

Loosened steering gearbox mounting bolt

Damaged or binding steering ball joint

Worn or damaged front wheel bearing

Damaged wheel or tire

Faulty suspension system

Loosened steering gearbox mounting bolt

Faulty steering gear

Steering column linterference

Loosened steering linkage

Damaged or loosened oil pump drive belt

Loosened oil pump bracket

Loosened oil pump mounting bolt

Air-in system

Faulty oil pump

Rubricate & Replace

Replace

Replace gear assembly

Adjust

Replace

Repair or replace

Replenish or bleed

Replace

Adjust or replace

Repair or replace

Repair or replace

Repair or replace

Repair

Repair or replace

Repair or replace

Repair or replace

Replace gear assembly

Replace

Retighten

Replace

Replace gear assembly

Repair or replace

Repair or replace

Replace

Retighten

Replace

Replace

Repair or replace

Repair or replace

Retighten

Replace gear assembly

Replace

Retighten

Adjust or replace

Retighten

Retighten

Bleed

Replace

Cause

Symptom

Hard steering

Steering pulls to one

side

Excessive wheel play

Poor return of steering
wheel

Steering wheel vibration

(Shimmy)

Abnormal noise from
steering system

Action

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

POWER STEERING

STAVIC - 2004.09

34

4G

Loosen steering column mounting nut or bad tightening

Worn or damage steering shaft bearing

Loosen inner shaft pinch bolt

Worn or damaged steering shaft bearing

Defective lock cylinder

Defective ignition key

Retighten

Replace steering column

Retighten

Replace steering column

Replace steering column

Replace ignition key

Cause

Symptom

Abnormal noise while
the operation

Excessive steering force

Ignition switch bad
turning

Action

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

POWER STEERING

STAVIC - 2004.09

35

4G

Name and Part Number

Application

661 589 13 33 00

Ball joint puller

Removal of the upper and lower
end assemblies of front
suspension

SPECIAL TOOLS AND EQUIPMENT
