M162 ENGINE MECHANICAL  1B1-11

12. Discharge the refrigerant from A/C system, and disconnect

the discharge pipe and suction pipe from the compressor.

14. Remove the fuel feed and return line.

Notice

Before removing the fuel lines, release the pressure in the
fuel system.

Installation Notice

13. Remove the acceleration control cable and automatic

transmission pressure cable.

11. Remove the hydraulic pipe of power steering.

Notice

Completely drain the oil.

Tightening  Torque

21 - 25 Nm

1B1-12  M162 ENGINE MECHANICAL

19. Disconnect the engine ground wire.

15. Remove the automatic transmission dipstick guide tube.

16. Disconnect the wire of alternator.

17. Disconnect the wire of starter motor and remove the starter

motor.

18. Disconnect the engine main harness ground.

M162 ENGINE MECHANICAL  1B1-13

20. Disconnect following sensors connector.

z

HFM sensor.

z

Coolant temperature sensor.

z

2 knock sensors.

z

Camshaft and crankshaft sensors.

21. After removing the ignition coil cover, disconnect the ignition

coil connector.

22. Remove the harness cover and disconnect the 6 injection

valve connectors. Disconnect the main harness

23. Separate the hose toward engine from canister purge

solenoid valve.

24. Remove the automatic transmission oil cooler line.

1B1-14  M162 ENGINE MECHANICAL

Tightening Torque

30 Nm

29. Remove the exhaust manifold and exhaust pipe.

Installation Notice

25. Separate the vacuum hose for brake booster.

26. Separate the other vacuum hoses.

27. Remove the propeller shaft from the front axle.

Installation Notice

28. By rotating the crankshaft from the front of engine, remove

the 6 torque converter mounting bolts from the engine
ring gear plate.

Tightening  Torque

81 - 89 Nm
