M162 ENGINE MECHANICAL 1B1-3
N
•••••
m
20 / +90°
40
72 - 88
20 / +90°
25 - 35
22.5 - 27.5
22.5 - 27.5
22.5 - 27.5
22.5 - 27.5
30
26 - 34
30
8 - 10
25
25
22.5 - 27.5
29 - 35
22.5 - 27.5
9 - 11
50
9 - 11
15
Application
Exhaust Camshaft Sproket Bolt
Chain Tensioner Screw Plug
Chain Tensioner Assembly
Exhaust Camshaft Sprocket to Camshaft
Oil Pump Sprocket Bolt
Tensioning Device Bolt
Water Pump Pulley
Upper Intake Manifold Bolt
Lower Intake Mainfold Bolt
Flange Bolt to Exhaust Mainfold
Exhaust Mainfold Nut to Stud Bolt
Rivet Nut in Exhuast Mainfold Hole
Pre-silencer Bolt
Oil Drain Plug
Oil Filter Cover
Oil Filter Bolt
Oil Pump Drive Sprocket Bolt
Oil Pump Mounting Bolt
Oil Strainer Bracket Bolt
Oil Pressure Relief Valve Screw Plug
Oil Dipstick Guide Tube Bolt
Oil Gallery Screw Plug
FASTENER TIGHTENING SPECIFICATIONS (Cont’d)
