1F-436 ENGINE CONTROLS
SSANGYONG Y158
KAA1F006
OXYGEN SENSOR (3.2L DOHC)
Removal and Installation Procedure
1. Disconnect the negative battery cable.
Notice: The Oxygen (O2) sensor uses a permanently
attached pigtail and connector. This pigtail should not be
removed from the O2 sensor. Damage or removal of the
pigtail or the connector could affect proper operation of the
O2 sensor. Do not drop the O2 sensor.
2. Disconnect the electrical connector.
3. Carefully remove the O2 from the exhaust pipe.
Installation Notice
Important: a special anti-seize compound is used on the
O2 sensor threads. This compound consists consists of a
liquid graphite and glass beads. The graphite will burn
away, but the glass beads will remain, making the sensor
easier to remove. New or serviced sensors will already
have the compound applied to the threads. If a sensor is
removed from any engine and is to be reinstalled, the
threads must have an anti-seize compound applied before
reinstallation.
4. Coat the threads of the O2 sensor with an anti-seize
compound, if needed.
5. Installation should follow the removal procedure in
the reverse order.
Tightening Torque
55 N•m (41 lb-ft)
