SsangYong Musso. Manual - part 6

MUSSO-SPORTS 1A-21

SUPPLEMENT

KAA5A08A

COMPONENTS LOCATOR

EXTERIOR BODY PANNEL

9 PNL-Deck Side OTR

10 PNL-Deck Side INR

11 RR Wheel Guard

12 PNL-Deck W/House INR
13 PNL-Deck

SECTION A-A

SECTION B-B

SECTION C-C

SECTION C1-C1

1A-22 MUSSO-SPORTS

SUPPLEMENT

KAA5A300

ROOF PANNEL

1 Front Upper Rail
2 Front Lower Rail
3 No1. Rail of Roof Center

4 No2. Rail of Roof Center
5 Roof Pannel
6 Rear Roof Rail

MUSSO-SPORTS 1A-23

SUPPLEMENT

KAA5A300

1 C-Pannel of Pillar Inner
2 Reinforce C-Pillar Outer Pannel
3 C-Pannel of Pillar Outer
4 Front Center Outer Pannel
5 Outer Pannel of Front Wheel House
6 Outer Pannel of Front Center
7 Inner Pannel of Wheel House

8 Outer Pannel of Front Wheel House
9 Side Outer of Pannel Deck

10 Side Inner Pannel Deck

11 Rear Wheel Guard

12 Pannel-Deck Wheel House Inner
13 Deck Pannel

ROOF RAIL

SECTION A-A

SECTION B-B

SECTION C-C

1A-24 MUSSO-SPORTS

SUPPLEMENT

KAA5A300

3 Body No1. Upper Insulator
4 Lower Insulator
5 Washer and Tube Assembly
6 Washer of Plain Body Mounting
7 Bolt
8 Body No2. Washer and Tube Assembly
9 Upper Insulator

15 Body No3. Upper Insulator
16 Body No1. Wwasher and Tube Assembly
19 Body No4. Upper Insulator
20 Body No4. Wwasher and Tube
23 Bolt
24 Deck Mounting Insulator

FRAME AND UNDER BODY MOUNTINGS

VI EWFI ,G

V I E W F 2

크 로 스 멤 버

N o . 1

N o . 2

N o . 3

N o . 4

N o . 5

N o . 6

N o . 7

F1,2

G1,2

는 화물데크 고정마운팅용

Cross member

: For luggage deck mounting
