SCANIA MARINE ENGINES (specification) - part 6
Standard equipment
• Scania Engine Management System, EMS
• Unit injectors, PDE
• Turbocharger
• Fuel pre-filter with water separator
• Fuel filter
• Oil filter, full flow
• Centrifugal oil cleaner
• Oil cooler, integrated in block
• Oil filler, in engine block
• Oil dipstick, in block
• Starter, 2-pole 7.0 kW
• Alternator, 2-pole 100A
• Flywheel SAE 14
• Silumin flywheel housing, SAE 1 flange
• Front-mounted engine brackets
• Protection covers
• Sea water pump
• Heat exchanger with expansion tank
• Closed crankcase ventilation
• Operator’s manual
Optional equipment
• Hydraulic pump
• Side-mounted PTO
• Front-mounted PTO
• Exhaust connections
• Electrical base system
• Control and instrument panels
• Accelerator position sensor
• Engine heater
• Power pack engine bracket
• Stiff rubber suspension
• Air cleaner
• Studs in flywheel housing
• Reversible fuel filter
• Low coolant level reaction
• Variable idle speed setting
• Low and extra low oil sump
• Long oil dipstick
• Oil level sensor
• Bilge pump
SCANIA MARINE ENgINEs
DI13 086M. 496 kW (675 hp)
Us Tier 3
The marine engines from Scania are based on a robust design with a strength
optimised cylinder block containing wet cylinder liners that can easily be exchanged.
Individual cylinder heads with 4 valves per cylinder promotes repairability and fuel
economy. The engines are type approved in all major classification societies.
The engine is equipped with a Scania developed Engine Management System,
EMS, in order to ensure the control of all aspects related to engine performance.
The injection system is based on electronically controlled unit injectors that gives low
exhaust emissions with good fuel economy and a high torque already at low revs.
The engine can be fitted with many accessories such as air cleaners, PTOs, transmis-
sions and type approved instrumentation in order to suit a variety of installations.
This specification may be revised without notice.
Engine speed (rpm)
Rating
1200
1500
1900
2300
Gross power, full load (kW)
Patrol
craft
short
262
423
482
496
Gross power, full load (hp, metric)
356
575
656
675
Gross power, propeller curve (kW)
98
170
308
496
Gross power, propeller curve (hp, metric)
133
232
418
675
Gross torque (Nm)
2085
2693
2423
2059
Spec fuel consumption. Full load (g/kWh)
209
198
194
216
Spec fuel consumption. 3/4 load (g/kWh)
194
199
208
213
Spec fuel consumption. 1/2 load (g/kWh)
193
206
219
214
Spec fuel consumption. Propeller curve (l/h)
23
43
78
128
Optimum fuel consumption (g/kWh)
192
Heat rejection to coolant (kW)
197
279
310
398
Patrol craft short: Intended for intermittent use where rated power is available 1 h/12 h.
Between full load operations engine rpm must be reduced at least 10% from max. obtained rpm.
Accumulated total service time max. 1200 h/year.
