Scania Truck (2017 year). Spare parts and accessories

226 |

niv

sal v

ehicle par

ts f

or Scania T

ruc

Bulb

Bulb type T4W

Voltage

24 V

Power

4 W

Socket

BA 9 s

Application range

for clearance, interior and number plate lights

Version

Order no

8900 004 000

Heavy Duty

8900 030 080

Bulb

display bulb

Bulb type T2W

Voltage

24 V

Power

2 W

Socket

BA 9 s

Application range

for clearance light and interior light

Order no

8900 016 000

Bulb

Bulb type R5W

Voltage

24 V

Power

5 W

Socket

BA 15 s

Application range

for tail/licence plate/position and interior light

Version

Order no

8900 001 000

Heavy Duty

8900 011 000

Bulb

Bulb type R10W

Voltage

24 V

Power

10 W

Socket

BA 15 s

Application range

for tail, licence plate, position and interior lights

Version

Order no

8900 002 000

Heavy Duty

8900 012 000

Bulbs

| 227

niv

sal v

ehicle par

ts f

or Scania T

ruc

Halogen bulb

Bulb type H21W

Voltage

24 V

Power

21 W

Socket

BAY 9 s

Application range

for indicator, stop, rear fog, reversing and interior light

Order no

2750 004 356

Bulb

festoon bulb

Voltage 24 V

Socket

SV 8,5

∅

11 mm

Application range

for tail/licence plate/position and interior light

Bulb type

Power

Length

Order no

C5W

5 W

35 mm

8900 005 000

S (10W)

10 W

43 mm

8900 040 060

Bulb

Plastic base lamp

Bulb type

Bax

Voltage

24 V

Power

1,2 W

Socket

BAX 8,5 d

Housing colour grey
Application range

for instrument lighting

Order no

3610 004 068

Bulb

Glass-base bulb

Voltage 24 V
Application range

for instrument lighting, clearance and indicator lights

Bulb type

Power

Socket

∅

Length

Order no

WBT5

1,2 W

W2 x 4,6 d

5 mm

20 mm

3610 002 741

W3W

3 W

W2,1 x 9,5 d

10 mm

26,8 mm

3610 002 841

W5W

5 W

W2,1 x 9,5 d

10 mm

26,8 mm

8900 040 130

Bulbs

228 |

niv

sal v

ehicle par

ts f

or Scania T

ruc

Bulbs

Bulb type

Socket

Order no

D1R

PK 32 d-3

2740 475 033

D2S

P 32 d-2

2740 477 433

This fi gure corresponds to 2740 477 433

Gas discharge lamp

Xenon

Voltage 85 V

Power

35 W

Application range

for main headlights and spotlights

Bulb cupboard

Including bulb tester

Equipped with basic range, robust metal housing, lockable, with 2 handy drawers for signal lamps and business card holder
Dimensions 370 x 176 x 595 mm
Scope of supply

– 40 x H7 Halogen headlamp bulbs, 24 V (8900 001 030)

– 10 x H4 Halogen headlamp bulbs, 24 V (8900 006 000)

– 10 x H3 Halogen headlamp bulbs, 24 V (8900 009 000)

– 10 x H1 Halogen headlamp bulbs, 24 V (8900 040 100)

– 40 x bulbs, P21W, 24 V (8900 003 000)

– 10 x bulbs, P21/5W, 24 V (8900 013 000)

– 40 x bulbs, R10W, 24 V (8900 002 000)

– 40 x bulbs, R5W, 24 V (8900 001 000)

– 40 x bulbs, W5W, 24 V (8900 040 130)

– 10 x bulbs, T4W, 24 V (8900 004 000)

– Bulb tester

Version

Order no

250-piece

8900 019 000

230 |

niv

sal v

ehicle par

ts f

or Scania T

ruc

LED daytime running lights set

LEDayFlex, 2 x 5 LED light module

Version

with position lamp

Installation side left/right

Voltage

12/24 V

∅

30 mm

Form

round

Colour

clear

Order no

Comparative no

0010 458 811

HELLA 2PT 010 458-711

LED auxiliary driving lamp

with 6 main LEDs

sturdy aluminium casing, painted black
Version

with LED position light

Reference number

Ref. 17,5

Voltage

10-32 V

Lighting power

4500/3800 lm

Power consumption 60 W

∅

222,4 mm

Height

232 mm

Depth

79 mm

Protection class

IP67

Approved for electromagnetic compatibility (EMC)

Order no

1007 270 913

Lighting and electrics

H7 Spotlight

Version

with position lamp

Reference number

ECE Ref. 25

Voltage

12/24 V

Bulb type

H7/T10

Power consumption 55/70 W

∅

223 mm

Height

235 mm

Depth

122 mm

Protection class

IP56

Scope of supply

without bulbs

Lens colour

Fig.

Order no

Blue

1007 000 015

Clear

1007 000 016

232 |

niv

sal v

ehicle par

ts f

or Scania T

ruc

Lighting and electrics

H1 spotlight

Rallye 3003

with chrome ring
Version

with LED position light

Reference number ECE Ref. 25

Voltage

12/24 V

∅

222 mm

Height

242 mm

Depth

124 mm

Type

attachment

Colour

clear

Scope of supply

without bulb

Order no

Comparative no

0009 797 431

HELLA 1F8 009 797-431

H1 auxiliary driving lamp

Luminator-Chromium-Celis

Version

with LED position light

Reference number ECE Ref. 17,5

Installation side

left/right

Voltage

12/24 V

∅

224,5 mm

Height

232,5 mm

Depth

129,5 mm

Colour

clear

Type

surface-mounting

Scope of supply

without bulb

Order no

Comparative no

0007 560 211

HELLA 1F8 007 560-211

LED auxiliary driving lamp

with 40 LEDs

Reference number

Voltage

10-32 V

Lighting power

10800/3934 lm

Power consumption 120 W

Width

563 mm

Height

78,5 mm

Depth

86,5 mm

Protection class

IP67

EMC approval

Order no

1007 809 110

| 233

niv

sal v

ehicle par

ts f

or Scania T

ruc

Lighting and electrics

LED auxiliary driving lamp

Driving light bar, with 12 LEDs

Reference number

Voltage

10-32 V

Lighting power

3420/1403 lm

Power consumption 36 W

Width

206 mm

Height

78,5 mm

Depth

86,5 mm

Protection class

IP67

E approval

Order no

1007 809 111

LED reversing light

with 4 LEDs and bracket

Voltage

10-32 V

Lighting power

1080 lm

Width

83 mm

Height

75 mm

Depth

80 mm

Connection

DT connector

Type

surface-mounting

Protection class IP67K
EMC approval

Order no

1007 000 000

LED reversing light

with 9 LEDs

Voltage

12-36 V

Height

100 mm

Width

100 mm

Depth

74 mm

Overall height

140 mm

Cable length

1500 mm

Fastening

size M8

Protection class IP68
Approved for electromagnetic compatibility (EMC)

Order no

5129 000 009

234 |

niv

sal v

ehicle par

ts f

or Scania T

ruc

LED working fl oodlight

With reverse polarity protection, lens made of impact and scratch resistant plastic
Voltage

10-30 V

Width

100 mm

Height

100 mm

Depth

40 mm

Type

surface mounting

Material

aluminium casing

Protection class IP69K
Scope of supply

Mounting kit incl. 500 mm connection cable
EMC approval

Description

Version

Lighting power

Power consumption

Fig.

Order no

With 5 LEDs

near-fi eld illumination

850/600 lm

9 W

7001 000 002

With 9 LEDs

far-reaching illumination

1530/1210 lm

15 W

7001 000 008

LED working fl oodlight

with 5 LEDs

With reverse polarity protection, lens made of impact and scratch resistant plastic
Version

far-reaching illumination

Voltage

10-30 V

Lighting power

4500/2290 lm

Power consumption 50 W

Width

145 mm

Height

98 mm

Depth

79 mm

Type

surface mounting

Material

aluminium casing

Protection class

IP69K

Scope of supply

Mounting kit incl. 500 mm connection cable
EMC approval

Order no

7001 000 005

Lighting and electrics

| 235

niv

sal v

ehicle par

ts f

or Scania T

ruc

Lighting and electrics

LED working fl oodlight

with 9 LEDs

With reverse polarity protection, lens made of impact and scratch resistant plastic
Version

near-fi eld illumination

Voltage

12-55 V

Lighting power

1685/1300 lm

Power consumption 13,5 W

Width

100 mm

Height

100 mm

Depth

74 mm

Type

surface mounting

Material

plastic casing

Protection class

IP68

Scope of supply

Mounting kit incl. 1500 mm connection cable
EMC approval

Order no

5129 000 000

LED working fl oodlight

with 6 LEDs

With reverse polarity protection, lens made of impact and scratch resistant plastic
Version

far-reaching illumination

Voltage

10-30 V

Lighting power

1140/1061 lm

Power consumption 18 W

Width

160 mm

Height

46 mm

Depth

58 mm

Type

surface mounting

Material

aluminium casing

Protection class

IP69K

Scope of supply

Mounting kit incl. 500 mm connection cable
EMC approval

Order no

7001 000 007

236 |

niv

sal v

ehicle par

ts f

or Scania T

ruc

LED working fl oodlight

with 16 LEDs

With reverse polarity protection, lens made of impact and scratch resistant plastic
Version

far-reaching illumination

Voltage

10-30 V

Lighting power

2720/2200 lm

Power consumption 25 W

Width

108 mm

Height

108 mm

Depth

48 mm

Type

surface mounting

Material

aluminium casing

Protection class

IP69K

Scope of supply

Mounting kit incl. 1000 mm connection cable
EMC approval

Order no

7001 000 004

LED working fl oodlight

With reverse polarity protection, lens made of impact and scratch resistant plastic
Voltage

10-30 V

∅

107 mm

Depth

41,5 mm

Type

surface mounting

Material

aluminium casing

Protection class IP69K
Scope of supply

Mounting kit incl. 500 mm connection cable
EMC approval

Description

Version

Lighting power

Power consumption

Fig.

Order no

With 6 LEDs

near-fi eld illumination

1020/600 lm

9 W

7001 000 003

With 9 LEDs

far-reaching illumination

1530/1250 lm

15 W

7001 000 006

Lighting and electrics

| 237

niv

sal v

ehicle par

ts f

or Scania T

ruc

Lighting and electrics

LED working fl oodlight

with 12 LEDs

Support rotatable through 120°
Version

near-fi eld illumination

Voltage

10-33 V

Width

109 mm

Height

109 mm

Depth

90 mm

Connection

DT connector with 2 m cable

Protection class IP68
EMC approval

Lighting power

Power consumption

Order no

2400/1750 lm

17 W

1007 000 284

4000/3300 lm

38 W

1007 000 293

This fi gure corresponds to 1007 000 293

LED working light rail

Version

curved, combined illumination

Lighting power

16200/7012 lm

Voltage

10-30 V

Power

180 W

Connection

ATP connector

Width

818 mm

Height

78,5 mm

Depth

111,5 mm

Protection class IP67
ECE R10 approval, EMC tested

Order no

1007 000 006

LED working light rail

Voltage

10-30 V

Connection

DT connector

Height

74,5 mm

Depth

68,5 mm

Protection class IP67

Description

Version

Lighting power

Power consumption

Width

Order no

With 6 LEDs

spotlight illumination

2700/1746 lm

30 W

276 mm

1007 000 009

With 12 LEDs

combined illumination

4200/2986 lm

60 W

516 mm

1007 000 010

With 18 LEDs

combined illumination

8100/4508 lm

90 W

756 mm

1007 000 011

This fi gure corresponds to 1007 000 010

238 |

niv

sal v

ehicle par

ts f

or Scania T

ruc

Lighting and electrics

LED fl ashing beacon

with 9 LEDs and shock-proof lens

Version

with double fl ash function

Voltage

12/24 V

∅

145 mm

Protection class IP68
Approved for electromagnetic compatibility (EMC)

Fastening

Height

Cable length

Fig.

Order no

Fixed mounting

126 mm

1500 mm

5129 000 014

With a magnet

126 mm

3000 mm

5129 000 015

Flexible pipe nozzle diameter 24 mm

204 mm

5129 000 016

LED working light rail

Version

far-reaching spotlight illumination

Voltage

10-32 V

Lighting power

16200 lm

Power consumption 180 W

Connection

ATP connector

Width

818 mm

Height

86,5 mm

Depth

78 mm

Protection class

IP67

EMC approval

Order no

1007 000 150

| 239

niv

sal v

ehicle par

ts f

or Scania T

ruc

Lighting and electrics

LED rotating beacon

With three different fl ashing patterns at choice
Voltage

12-24 V

Power consumption 20 W

Protection class

IP65

ECE-R65 approval

Fastening

∅

Height

Fig.

Order no

Fixed surface-mounting

142 mm

183 mm

1007 000 141

With a magnet

142 mm

183 mm

1007 000 143

Tube bracket

128 mm

235 mm

1007 000 142

LED rotating beacon

Low variant
Voltage

12-24 V

Power consumption 10 W

Protection class

IP65

ECE-R65/R10 approval

Fastening

∅

Height

Fig.

Order no

Fixed surface-mounting

210 mm

140 mm

1007 809 066

With a magnet

128 mm

130 mm

1007 809 068

Tube bracket

128 mm

210 mm

1007 809 067

240 |

niv

sal v

ehicle par

ts f

or Scania T

ruc

Lighting and electrics

LED fl ashing warning light

with 6 LEDs

with 18 different fl ashing patterns
Voltage

9-32 V

Power consumption 18 W

Width

128 mm

Height

28 mm

Depth

21 mm

Cable length

2500 mm

Type

surface-mounting

Protection class

IP65

ECE-R65 approval

Order no

1007 850 177

LED fl ashing warning light

9 different light options (also SOS, Morse code) switchable, 360° fi eld of view, brightness visible up to 800

metres, with magnet, very sturdy, waterproof
Version

replaceable CR123A battery

Light colour

light red

Housing colour

orange

Lighting duration up to 100 h

∅

105 mm

Height

35 mm

Protection class

IP65

Application range

For protection in the event of accidents, breakdowns and for personal safety

Order no

1007 000 004

LED warning system

Voltage

12-30 V

Cable length 600 mm

Width

Order no

1375 mm

1007 509 052

1829 mm

1007 509 053

WHEN PERFORMANCE

IS EVERYTHING.

THE LATEST LIGHTING TECHNOLOGY FOR PROFESSIONALS
WITH UNIQUE 3 YEAR FUNCTION WARRANTY

| 241

niv

sal v

ehicle par

ts f

or Scania T

ruc

Lighting and electrics

LED fl ashing warning light set

6 rechargeable LED fl ashing lights, each with 16 LEDs, 9 different light options (also SOS, morse code),

switchable, 360° fi eld of view, brightness visible up to 800 metres, with magnet, very sturdy, case with built-in

charger 12/24/230 V
Light colour

light red

Housing colour

orange

Lighting duration up to 100 h

∅

105 mm

Height

35 mm

Protection class

IP65

Application range

For protection in the event of accidents, breakdowns and for personal safety
CE tested

Version

Order no

6-piece

8000 001 020

WHEN PERFORMANCE

IS EVERYTHING.

THE LATEST LIGHTING TECHNOLOGY FOR PROFESSIONALS
WITH UNIQUE 3 YEAR FUNCTION WARRANTY

Scania Truck (2017 year). Spare parts and accessories - 15
