Scania Truck (2017 year). Spare parts and accessories - 10

146 |

2

 4 ser

ies

 ECAS solenoid valve

Connection

M22 x 1.5

Operating pressure max. 5-13 bar

Voltage

24 V

Protection class

IP6K9K

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

6001 343 254

WABCO 472 880 001 0

 ECAS solenoid valve

Operating pressure 5-13 bar

Voltage

24 V

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

0379 001 120

WABCO 472 900 112 0

 Compressed air

 ECAS path sensor

 for air suspension

Connection

Bayonet DIN 72585-A1-2.1-Sn/K2

Protection class IP6K9K
 Two versions possible: Please check on vehicle, whether 441 050 011 0 or 441 050 012 0 is installed.

Suitable for

Order no

Comparative no

124, 114, 94

0210 500 110

WABCO 441 050 011 0

| 147

2

 4 ser

ies

 Alternating check valve

Connection 1 M16 x 1.5 reserve

Connection 2 M16 x 1,5 outlet

Suitable for

Order no

Comparative no

124, 114, 94

3990 001 030

Knorr 295358

 Compressed air

 Brake hose

∅ 12 mm

Suitable for

Length

Order no

Comparative no

164, 144, 124, 114, 94

600 mm

1325 018 680

Scania 1123476

164, 144, 124, 114, 94

630 mm

1325 018 682

Scania 1123477

164, 144, 124, 114, 94

720 mm

1325 018 681

Scania 1123479

164, 144, 124, 114, 94

500 mm

6170 128 111

Scania 1356151

  This fi gure corresponds to   1325 018 682

 Speed sensor

Version

with cable

Installation side

Left

Cable length

2740 mm

Temperature range -40 to +150 °C

Standard

ISO 20653

Protection class

IP68

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

1325 189 552

Scania 1892048

 Speed sensor

 for ABS/EBS

Version angled
  Scope  of  supply

 With  bush

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

1325 092 051

Scania 1892051

 for ABS/EBS

148 |

2

 4 ser

ies

 Speed sensor

 for ABS/EBS

Length 3400 mm

Suitable for

Order no

164, 124, 114, 94

3510 096 330

 Speed sensor

 for EBS

Suitable for

Version

Length

Order no

164, 144, 124, 114, 94

straight

1745 mm

1325 092 057

164, 144, 124, 114, 94

straight

2675 mm

1325 021 634

164, 144, 124, 114, 94

angled

2060 mm

1325 021 628

164, 144, 124, 114, 94

angled

2650 mm

1325 021 626

  This fi gure corresponds to   8000 012 243

 Speed sensor

 for ABS

Suitable for

Version

Length

Order no

164, 144, 124, 114, 94

straight

2780 mm

1325 189 553

164, 144, 124, 114, 94

angled

1050 mm

1325 092 062

164, 144, 124, 114, 94

angled

1055 mm

1263 001 624

164, 144, 124, 114, 94

angled

2740 mm

1325 189 550

  This fi gure corresponds to   1325 189 553

 Compressed air

Compressed air

150 |

2

 4 ser

ies

 Indicator switch

Switch function Wipe, wash

Voltage

24 V

Length

245,9 mm

Cable length

430 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9225 000 010

Scania 1424970

 Relay

 for dipped beam

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

3600 048 450

Bosch 0 332 515 012

 Switch

 for split transmission

Thread M18 x 1,5

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

6000 160 174

Scania 1420005

Scania 1423971

Scania 1472739

 Pressure switch

Outer thread

M18 x 1,5/M27 x 1

Spanner size 27 mm

Length

35/44 mm

Material

brass

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9460 159 431

Scania 370710

  Application range

 Differential  lock  actuation

 Electrics

| 151

2

 4 ser

ies

 Indicator switch

Switch function Indicators, light switch-over function, cruise control

Voltage

24 V

Cable length

300 mm

Colour

black

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

3870 645 141

Valeo 645141

 Indicator switch

Switch function Wipe, wash

Voltage

24 V

Cable length

300 mm

Colour

black

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

3870 645 142

Valeo 645142

 Electrics

 Starter Motor

Voltage

24 V

Power

6,7 kW

Pinion teeth 11

Flange

3-hole

Suitable for

Order no

Comparative no

164, 124, 114

7063 002 352

Bosch 0 986 017 760

 Starter Motor

Voltage

24 V

Power

5,5 kW

Pinion teeth 12

Flange

3-hole

Suitable for

Order no

Comparative no

124, 114, 94

7063 002 461

Bosch 0 986 021 480

152 |

2

 4 ser

ies

 Starter Motor

Voltage

24 V

Power

6,7 kW

Version

clockwise direction of rotation

Pinion teeth

11

Mounting slope 25°

Dwell angle

146°

Suitable for

Order no

Comparative no

164, 124, 114

5240 860 305

Prestolite 860305

 Starter Motor

Voltage

24 V

Power

6 kW

Version

clockwise direction of rotation

Pinion teeth 11

Flange

3-hole

Suitable for

Order no

Comparative no

124, 114, 94

5240 903 545

Prestolite M90R3545SE

 Starter Motor

Voltage

24 V

Power

4 kW

Pinion teeth 9

Flange

3-hole

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

5240 857 472

Prestolite 857472GB

 Starter Motor

Voltage

24 V

Power

6,7 kW

Version

clockwise direction of rotation

Pinion teeth

11

Mounting slope 290°

Dwell angle

146°

Suitable for

Order no

Comparative no

164, 144, 114, 94

5240 860 614

Prestolite 860614

 Electrics

| 153

2

 4 ser

ies

 Starter Motor

 in exchange

Voltage

24 V

Power

4 kW

Pinion teeth 9

Version

clockwise direction of rotation

Flange

3-hole

Suitable for

Order no

Comparative no

144, 124, 114, 94

0726 253 001

HELLA 8EA 726 253-001

 Electrics

 Starter Motor

 in exchange

Voltage

24 V

Power

6,7 kW

Pinion teeth 11

Version

clockwise direction of rotation

Flange

3-hole

Suitable for

Order no

Comparative no

164, 124, 114

0737 403 001

HELLA 8EA 737 403-001

 Starter Motor

 in exchange

Voltage

24 V

Power

4 kW

Pinion teeth 9

Flange

3-hole

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

3698 601 128

Bosch 0 986 011 280

 Starter Motor

 in exchange

Voltage

24 V

Power

5,5 kW

Pinion teeth 12

Flange

3-hole

Suitable for

Order no

Comparative no

124, 114, 94

3561 381 480

Bosch 0 986 021 480

154 |

2

 4 ser

ies

 Alternator

Voltage

24 V

Charging current 65 A

Housing-∅

157 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

5240 860 557

Prestolite 860557

 Alternator

Voltage

24 V

Charging current 65 A

Version

without belt pulley

Housing-∅

157 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114

5240 150 115

Prestolite 20150115

 Alternator

Voltage

24 V

Charging current 100 A

Version

with belt pulley

Number of ribs

8

Suitable for

Order no

Comparative no

164, 124, 114

7063 002 117

Bosch 0 986 047 820

 Alternator

Voltage

24 V

Charging current 100 A

Version

clockwise rotation, with belt pulley

Flange

4-hole

Housing-∅

142 mm

Number of ribs

8

Suitable for

Order no

Comparative no

164, 124, 114, 94

5240 861 079

Prestolite 861079

 Electrics

156 |

2

 4 ser

ies

 Alternator

Voltage

24 V

Charging current 110 A

Version

clockwise rotation, with belt pulley

Housing-∅

154 mm

Number of ribs

8

Suitable for

Order no

Comparative no

164, 124, 114, 94

5240 860 805

Prestolite 860805GB

 Alternator

Voltage

24 V

Charging current 100 A

Version

with belt pulley

Suitable for

Order no

Comparative no

164, 144, 124, 114

1263 002 560

Scania 1777300

 Alternator

 in exchange

Voltage

24 V

Charging current 100 A

Version

with connection for tachometer

Number of ribs

8

Suitable for

Order no

Comparative no

164, 124, 114, 94

0738 211 571

HELLA 8EL 738 211-571

 Electrics

| 157

2

 4 ser

ies

 Alternator

 in exchange

Voltage

24 V

Charging current 100 A

Version

with connection for tachometer, without belt pulley

Suitable for

Order no

Comparative no

144, 124, 114, 94

0738 211 401

HELLA 8EL 738 211-401

 Alternator

 in exchange

Voltage

24 V

Charging current 90 A

Version

with connection for tachometer

Suitable for

Order no

Comparative no

144, 124, 114, 94

0737 452 001

HELLA 8EL 737 452-001

 Alternator

 as replacement

Voltage

24 V

Charging current 65 A

Version

without belt pulley

Flange

3-hole

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

8000 000 677

Bosch 0 986 039 490

 Electrics

158 |

2

 4 ser

ies

 Truck passenger seat

 Kingman High Performance

 Orthopaedic seat, controls on right-hand side of the seat, air suspension, automatic weight adjustment (electro-

pneumatic) 50-130 kg, height adjustment, longitudinal adjustment, integrated 3-point seatbelt, APS (automatic

positioning system), damper setting, fore/aft isolator, seat tilt adjustment, lumbar support, side contour

adjustment (air), backrest adjustment, quick lowering, integrated headrests
Version standard
  Application  range

 Suited to vehicles without an airbag
 Armrests must be ordered separately.

Suitable for

Order no

series 4

9361 142 118

Description

Order no

Seat heating

9361 201 200

Neck cushion, with replaceable cover

9361 252 750

Storage net for upper seat section

9361 173 492

 Accessories

 Truck driver's seat

 Kingman High Performance, without belt pretensioner

 Air sprung, with external supply, spring defl ection 70 mm, height adjustment 100 mm, built-in headrest, length

adjustment, longitudinal horizontal suspension, pneumatic lumbar support, backrest adjustment, built-in 3-point

restraint system, quick lowering, side contour adjustment, seat angle adjustment, adjustable shock absorber
Version

standard

Suspension pneumatic

Width

545 mm

Track width

230 mm

Depth

630 mm

 Illustration shows special equipment!

Armrests must be ordered separately.

Suitable for

Order no

series 4

9361 503 140

Description

Order no

Arm rest, left

9361 029 136

Arm rest, right

9361 029 137

Seat heating

9361 201 200

Neck cushion, with replaceable cover

9361 252 750

Storage net for upper seat section

9361 173 492

 Accessories

 Cab

| 159

2

 4 ser

ies

 Truck driver's seat

 Kingman Comfort

 Length adjustment 150 mm
  Application  range

 Vehicles with already integrated 3-point belt, without belt pretensioner or vehicles specialised for this

Suitable for

Order no

164, 144, 124, 114, 94

9361 503 150

Description

Order no

Arm rest, left

9361 029 136

Arm rest, right

9361 029 137

Storage net for upper seat section

9361 173 492

 Accessories

  This fi gure corresponds to   9361 029 136

 Truck driver's seat

 Kingman Klima

 Height adjustment 100 mm, spring defl ection 70 mm, length adjustment 150 mm, backrest adjustment, seat

angle adjustment, quick lowering, integrated headrest, built-in 3-point restraint system, seat cushion depth

adjustment, longitudinal horizontal suspension, pneumatic lumbar support, side contour adjustment, active seat

air-conditioning including seat heating
  Application  range

 Vehicles with already integrated 3-point belt, without belt pretensioner or vehicles specialised for this

Suitable for

Order no

164, 144, 124, 114, 94

9361 188 599

Description

Order no

Installed console

9361 063 500

Retrofi t set XXL cushion reinforcement up to 160 kg

9360 072 266

 Accessories

 Cab

160 |

2

 4 ser

ies

 Wiper arm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

8000 011 950

Scania 1864620

 Wiper bearing

Thread M10

Suitable for

Installation side

Order no

Comparative no

164, 144, 124, 114, 94

left

8000 002 016

Scania 1525891

164, 144, 124, 114, 94

right

8000 002 015

Scania 1525892

 Cab

 Wiper rods

Length 766 mm
  Application  range

 for  RHD

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

3600 134 500

Scania 1525889

 Shock absorber

 for driver's seat

Version

adjustable

Fastening eye/eye

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9369 888 901

ISRI 98889-01

 Wiper rods

Suitable for

Installation side

Order no

Comparative no

164, 144, 124, 114, 94

left

8000 002 019

Scania 1525888

164, 144, 124, 114, 94

right

8000 002 017

Scania 1525890

| 161

2

 4 ser

ies

 Wiper motor

Voltage 24 V

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

8000 012 017

Scania 1392755

 Wiper blade

Length 700 mm
  Scope  of  supply

 With  4  adapters

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

7257 002 110

SWF 132.704

 (Illustration  similar)

 Wiper blade

 Visiofl ex

Version

with integrated wear warning contact, washing water nozzle, spoiler and pipe connector

Contents 1 piece

Length

700 mm

Suitable for

Order no

Comparative no

114, 94

7920 133 703

SWF 133.703

 Cab

 Washer fl uid pump

Installation location Cab

Version

electric

Voltage

24 V

  Application  range

 Windscreen  cleaning  system

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

9800 122 086

Scania 1548504

 Wiper blade

 with plug connection

Version with integrated washer nozzle

Length

700 mm

Suitable for

Order no

Comparative no

164, 144, 124, 114, 94

7920 132 705

SWF 132.705
