SCANIA industrial engines
dC16 076a. 425 kW (578 hp)
China Phase iii and india Bharat stage iii
Standard equipment
• Scania Engine Management System, EMS
• Unit injectors, PDE
• Turbocharger
• Fuel filter and extra pre-filter with water
separator
• Oil filter, full flow
• Centrifugal oil cleaner
• Oil cooler, integrated in block
• Oil filler, in valve cover
• Deep front oil sump
• Oil dipstick, in block
• Magnetic drain plug for oil draining
• Starter, 1-pole 7.0 kW
• Alternator, 1-pole 100A
• Flywheel, for use with friction clutch
• Silumin flywheel housing, SAE 1 flange
• Front mounted engine brackets
• Open crankcase ventilation
• Operator’s manual
Optional equipment
• Prepared for cooling package
• Puller and pusher fans
• Fan ring with sealing
• Hydraulic pump
• Air compressor
• AC compressor
• Side-mounted PTO
• Front-mounted PTO
• Exhaust connections
• Electrical base system
• Control and instrument panels
• Accelerator position sensor
• Engine heater
• Flywheel: SAE14”
• Stiff rubber engine suspension
• Air cleaner
• Closed crankcase ventilation
• Studs in flywheel housing
• External thermostat for extra oil cooler
• Low coolant level reaction
• Variable idle speed setting
• Low oil sump
The industrial engines from Scania are based on a robust design with a strength
optimised cylinder block containing wet cylinder liners that can easily be exchanged.
Individual cylinder heads with 4 valves per cylinder promotes repairability and fuel
economy.
The engine is equipped with a Scania developed Engine Management System,
EMS, in order to ensure the control of all aspects related to engine performance.
The injection system is based on electronically controlled unit injectors that gives low
exhaust emissions with good fuel economy and a high torque. The engine can be fitted
with many accessories such as air cleaners, silencers, PTOs and flywheels in order to
suit a variety of installations.
This specification may be revised without notice.
Engine speed (rpm)
Rating
1200
1500
1800
1900
Gross power (kW)
IFN
280
383
425
425
Gross power (hp, metric)
IFN
381
521
578
578
Gross torque (Nm)
IFN
2230
2440
2255
2136
Spec fuel consumption. Full load (g/kWh)
205
203
218
245
Spec fuel consumption. 3/4 load (g/kWh)
200
201
216
250
Spec fuel consumption. 1/2 load (g/kWh)
201
202
220
266
Heat rejection to coolant (kW)
136
144
173
205
IFN – Intermittent service: Rated output available 1 h/6 hours period.
Unlimited h/year service time at a load factor of 80%.
