SCANIA INDUSTRIAL ENGINES (specification) - part 11

Engine speed (rpm)

Rating

1200

1500

1800

2100

Gross power (kW)

IFN

285

361

368

Gross power (hp, metric)

IFN

388

491

500

Gross torque (Nm)

IFN

2270

2298

1952

1673

Spec fuel consumption. Full load (g/kWh)

193

194

200

213

Spec fuel consumption. 3/4 load (g/kWh)

197

196

200

213

Spec fuel consumption. 1/2 load (g/kWh)

199

200

207

220

Reductant consumption. Full load (g/kWh)

IFN – Intermittent service: Rated output available 1 h/6 hours period.
Unlimited h/year service time at a load factor of 80%.

Note!
The fuel consumption values are valid when the engine uses fully warm after treatment system and
in warm conditions. Fuel efficiency will be reduced during warm up and with colder ambient tempe-
rature, escpecially in combination with un-efficient thermal insulation of after treatment system.

SCANIA INDUSTRIAL ENGINES

DC13 085A. 368 kW (500 hp)

EU Stage IV, US Tier 4f

Standard equipment
•  Scania Engine Management System, EMS
•  Extra high pressure fuel injection system, XPI
•  Turbocharger (VGT)
•  Fuel filter and extra pre-filter with water

separator

•  Fuel heater
•  Oil filter, full flow
•  Centrifugal oil cleaner
•  Oil cooler, integrated in block
•  Oil filler, in valve cover
•  Deep front oil sump
•  Oil dipstick, in block
•  Magnetic drain plug for oil draining
•  Starter, 1-pole 6.0 kW
•  Alternator, 1-pole 100A
•  Flywheel, for use with friction clutch
•  Silumin flywheel housing, SAE 1 flange
•  Front-mounted engine brackets
•  SCR system
•  EGR system
•  Open crankcase ventilation
•  Operator’s manual

Optional equipment
•  Cooling package
•  Puller and pusher fans
•  Fan ring with sealing
•  Hydraulic pump
•  Air compressor
•  AC compressor
•  Side-mounted PTO
•  Front-mounted PTO
•  Exhaust connections
•  Electrical base system
•  Control and instrument panels
•  Accelerator position sensor
•  Engine heater
•  Flywheels: SAE11.5”, SAE14”, DANA15/16”,

ZF WG260

•  Stiff rubber engine suspension
•  Air cleaner
•  Closed crankcase ventilation
•  Studs in flywheel housing
•  External thermostat for extra oil cooler
•  Low coolant level reaction
•  Variable idle speed setting
•  Low oil sump
•  Oil level sensor

The industrial engines from Scania are based on a robust design with a strength
optimised cylinder block containing wet cylinder liners that can easiliy be exchanged.
Individual cylinder heads with 4 valves per cylinder promotes repairability and fuel
economy.
  The engine is equipped with a Scania developed Engine Management System,
EMS, in order to ensure the control of all aspects related to engine performance.
The injection system is Scania’s XPI (Extra High Pressure Injection), a common rail
system that in combination with SCR (Selective Catalytic Reduction) and EGR (Exhaust
Gas Recirculation) gives low exhaust emissions with good fuel economy and a high
torque. The engine can be fitted with many accessories such as air cleaners, silencers,
PTOs and flywheels in order to suit a variety of installations.

This specification may be revised without notice.

SCANIA INDUSTRIAL ENGINES

SE 151 87 Södertälje, Sweden

Telephone +46 8 553 810 00

Telefax +46 8 553 829 93

www.scania.com

engines@scania.com

DC13 085A. 368 kW (500 hp)

EU Stage IV, US Tier 4f

Edition 08 © Scania CV AB, SE-151 87 Södertälje, Sweden

Engine description

No of cylinders

6 in-line

Working principle

4-stroke

Firing order

1 - 5 - 3 - 6 - 2 - 4

Displacement

12.7 litres

Bore x stroke

130 x 160 mm

Compression ratio

17.5:1

Weight

1075 kg (excl oil and coolant)

Piston speed at 1500 rpm

8.0 m/s

Piston speed at 1800 rpm

9.6 m/s

Camshaft

High position alloy steel

Pistons

Steel pistons

Connection rods

I-section press forgings of alloy steel

Crankshaft

Alloy steel with hardened
and polished bearing surfaces

Oil capacity

34-45 dm

Electrical system

1-pole 24V

1398

493

472

691

428

All dimensions in mm

1:7248

1:7249

Test conditions Air temperature +25°C. Barometric pressure 100 kPa (750 mmHg). Humidity 30%. Diesel fuel
acc. to ECE R 24 Annex 6. Density of fuel 0.840 kg/dm

Viscosity of fuel 3.0 cSt at 40°C. Energy value 42700 kJ/kg.

Power test code ISO 3046. Power and fuel values +/-3%.

160

180

200

220

240

260

280

300

320

340

360

380

400

420

440

460

480

500

120

130

140

150

160

170

180

190

200

210

220

230

240

250

260

270

280

290

300

310

320

330

340

350

360

370

150

160

170

180

190

200

210

220

230

240

1470

1570

1670

1770

1870

1970

2070

2170

2270

2370

kpm

100

180

185

190

195

200

205

210

215

800

1000

1200

1400

1600

1900

2100

g/kWh
Reductant

g/kWh
Fuel

rpm

Reductant

Fuel

160

180

200

220

240

260

280

300

320

340

360

380

400

420

440

460

480

500

120

130

140

150

160

170

180

190

200

210

220

230

240

250

260

270

280

290

300

310

320

330

340

350

360

370

150

160

170

180

190

200

210

220

230

240

1470

1570

1670

1770

1870

1970

2070

2170

2270

2370

kpm

100

180

185

190

195

200

205

210

215

800

1000

1200

1400

1600

1900

2100

g/kWh
Reductant

g/kWh
Fuel

rpm

Reductant

Fuel

160

180

200

220

240

260

280

300

320

340

360

380

400

420

440

460

480

500

120

130

140

150

160

170

180

190

200

210

220

230

240

250

260

270

280

290

300

310

320

330

340

350

360

370

150

160

170

180

190

200

210

220

230

240

1470

1570

1670

1770

1870

1970

2070

2170

2270

2370

kpm

100

180

185

190

195

200

205

210

215

800

1000

1200

1400

1600

1900

2100

g/kWh
Reductant

g/kWh
Fuel

rpm

Reductant

Fuel

Output

Torque

Spec fuel and reductant consumption

SCANIA INDUSTRIAL ENGINES

SCR system

EU Stage IV, US Tier 4f

SCR (Selective Catalytic Reduction) technology is used on Scania’s engines for
EU Stage IV and US Tier 4f to reduce the NO

content in the exhaust gases.

A chemical process is started by injecting reductant, an urea and water
mixture, into the exhaust gas stream. During injection the water evaporates
and the urea breaks down to form ammonia. The ammonia then reacts with
the nitrogen gases in the catalytic converter and forms harmless products
such as nitrogen gas and water. Through the use of SCR the exhaust gases
are purged of poisonous levels of NO

in the best possible way. Scania is

making use of a system that is carefully developed and tested in our own
laboratory.

The reductant tank is available in different sizes and is heated by the engine’s
cooling system in order to avoid freezing of the urea solution; urea freezes at
-11°C. The tank and a pump module are delivered as a unit which is fitted to
brackets for an easy installation. The Scania system contains all mechanical
and electrical parts needed except from the exhaust piping which is to be
adapted according to the customers installation.

Standard

Optional

1 Evaporator module



2 Reductant pressure line

2.5 m

4 m, 5 m, 6.5 m

Coolant hose for tank and pump
heating

4 Coolant valve



5 Reductant fluid return line

2.5 m

4 m, 5 m, 6.5 m

6 Reductant tank

38 l

45 l, 60 l, 63 l, 70 l

Coolant hose, return from tank and
pump heating

8 NOx sensor with control unit



9 Oxidation catalytic converter

Engine-mounted

Separately

10 Temperature sensor



11 SCR catalyst



12 NO

sensor with control unit



Standard

Optional

1 Customer interface, SCR system



–

2 between engine and SCR control unit

3 m

4.5 m, 6 m

3 NO

sensor electrical cable

3 m

4.5 m, 6 m

4 Electrical interface, SCR system



5 Reductant doser electrical cable

3 m

4.5 m, 6 m

6 Temperature sensor electrical cable

3 m

4.5 m, 6 m, 9 m

7 NO

sensor electrical cable

3 m

4.5 m, 6 m, 9 m

The principle for Scania SCR system

This specification may be revised without notice.

1) Not DC13 085A or DC16.

Mechanical system

Electric system

SCANIA INDUSTRIAL ENGINES

SE 151 87 Södertälje, Sweden

Telephone +46 8 553 810 00

Telefax +46 8 553 829 93

www.scania.com

engines@scania.com

SCR system

EU Stage IV, US Tier 4f

Edition 09 © Scania CV AB, SE-151 87 Södertälje, Sweden

Evaporator module (DC9 and DC13)

Oxidation catalytic converter (not DC13 085A or DC16)

720

280

575

1:7265

Reductant tank - 38 litres
Total volume: 50 litres
Filling volume: 38 litres

This specification may be revised without notice.

Engine

Dimensions A (mm)

DC09 (202 kW - 257 kW)

786

DC09 (276 kW - 294 kW)

900

DC13 (257 kW - 331 kW)

900

DC13 (368 kW - 405 kW)

970

DC16

970

Evaporator module (DC16)

SCR catalyst

Other available sizes: 45 litres (total volume 62 litres)

60 litres (total volume 75 litres

63 litres (total volume 80 litres)

70 litres (total volume 88 litres)

720

280

671

1:7265

348.5

1:7357

Engine speed (rpm)

Rating

1200

1500

1800

2100

Gross power (kW)

IFN

297

368

405

356

Gross power (hp, metric)

IFN

404

500

551

484

Gross torque (Nm)

IFN

2363

2343

2149

1620

Spec fuel consumption. Full load (g/kWh)

192

194

202

213

Spec fuel consumption. 3/4 load (g/kWh)

197

195

200

213

Spec fuel consumption. 1/2 load (g/kWh)

199

200

205

221

Reductant consumption. Full load (g/kWh)

IFN – Intermittent service: Rated output available 1 h/6 hours period.
Unlimited h/year service time at a load factor of 80%.

SCANIA INDUSTRIAL ENGINES

DC13 085A. 405 kW (550 hp)

EU Stage IV, US Tier 4f

Standard equipment
•  Scania Engine Management System, EMS
•  Extra high pressure fuel injection system, XPI
•  Turbocharger (VGT)
•  Fuel filter and extra pre-filter with water

separator

ZF WG260

This specification may be revised without notice.

SCANIA INDUSTRIAL ENGINES

SE 151 87 Södertälje, Sweden

Telephone +46 8 553 810 00

Telefax +46 8 553 829 93

www.scania.com

engines@scania.com

DC13 085A. 405 kW (550 hp)

EU Stage IV, US Tier 4f

Edition 08 © Scania CV AB, SE-151 87 Södertälje, Sweden

Engine description

No of cylinders

6 in-line

Working principle

4-stroke

Firing order

1 - 5 - 3 - 6 - 2 - 4

Displacement

12.7 litres

Bore x stroke

130 x 160 mm

Compression ratio

17.5:1

Weight

1075 kg (excl oil and coolant)

Piston speed at 1500 rpm

8.0 m/s

Piston speed at 1800 rpm

9.6 m/s

Camshaft

High position alloy steel

Pistons

Steel pistons

Connection rods

I-section press forgings of alloy steel

Crankshaft

Alloy steel with hardened
and polished bearing surfaces

Oil capacity

34-45 dm

Electrical system

1-pole 24V

1398

493

472

691

428

All dimensions in mm

1:7248

1:7249

Test conditions Air temperature +25°C. Barometric pressure 100 kPa (750 mmHg). Humidity 30%. Diesel fuel
acc. to ECE R 24 Annex 6. Density of fuel 0.840 kg/dm

Viscosity of fuel 3.0 cSt at 40°C. Energy value 42700 kJ/kg.

Power test code ISO 3046. Power and fuel values +/-3%.

150

170

190

210

230

250

270

290

310

330

350

370

390

410

430

450

470

490

510

530

550

110

130

150

170

190

210

230

250

270

290

310

330

350

370

390

410

150

160

170

180

190

200

210

220

230

240

1470

1570

1670

1770

1870

1970

2070

2170

2270

2370

kpm

100

180

185

190

195

200

205

210

215

800

1000

1200

1400

1600

1900

2100

g/kWh
Reductant

g/kWh
Fuel

rpm

Reductant

Fuel

150

170

190

210

230

250

270

290

310

330

350

370

390

410

430

450

470

490

510

530

550

110

130

150

170

190

210

230

250

270

290

310

330

350

370

390

410

150

160

170

180

190

200

210

220

230

240

1470

1570

1670

1770

1870

1970

2070

2170

2270

2370

kpm

100

180

185

190

195

200

205

210

215

800

1000

1200

1400

1600

1900

2100

g/kWh
Reductant

g/kWh
Fuel

rpm

Reductant

Fuel

150

170

190

210

230

250

270

290

310

330

350

370

390

410

430

450

470

490

510

530

550

110

130

150

170

190

210

230

250

270

290

310

330

350

370

390

410

150

160

170

180

190

200

210

220

230

240

1470

1570

1670

1770

1870

1970

2070

2170

2270

2370

kpm

100

180

185

190

195

200

205

210

215

800

1000

1200

1400

1600

1900

2100

g/kWh
Reductant

g/kWh
Fuel

rpm

Reductant

Fuel

Output

Torque

Spec fuel and reductant consumption

SCANIA INDUSTRIAL ENGINES

SCR system

EU Stage IV, US Tier 4f

SCR (Selective Catalytic Reduction) technology is used on Scania’s engines for
EU Stage IV and US Tier 4f to reduce the NO

content in the exhaust gases.

in the best possible way. Scania is

making use of a system that is carefully developed and tested in our own
laboratory.

Standard

Optional

1 Evaporator module



2 Reductant pressure line

2.5 m

4 m, 5 m, 6.5 m

Coolant hose for tank and pump
heating

4 Coolant valve



5 Reductant fluid return line

2.5 m

4 m, 5 m, 6.5 m

6 Reductant tank

38 l

45 l, 60 l, 63 l, 70 l

Coolant hose, return from tank and
pump heating

8 NOx sensor with control unit



9 Oxidation catalytic converter

Engine-mounted

Separately

10 Temperature sensor



11 SCR catalyst



12 NO

sensor with control unit



Standard

Optional

1 Customer interface, SCR system



–

2 between engine and SCR control unit

3 m

4.5 m, 6 m

3 NO

sensor electrical cable

3 m

4.5 m, 6 m

4 Electrical interface, SCR system



5 Reductant doser electrical cable

3 m

4.5 m, 6 m

6 Temperature sensor electrical cable

3 m

4.5 m, 6 m, 9 m

7 NO

sensor electrical cable

3 m

4.5 m, 6 m, 9 m

The principle for Scania SCR system

This specification may be revised without notice.

1) Not DC13 085A or DC16.

Mechanical system

Electric system

SCANIA INDUSTRIAL ENGINES

SE 151 87 Södertälje, Sweden

Telephone +46 8 553 810 00

Telefax +46 8 553 829 93

www.scania.com

engines@scania.com

SCR system

EU Stage IV, US Tier 4f

Evaporator module (DC9 and DC13)

Oxidation catalytic converter (not DC13 085A or DC16)

720

280

575

1:7265

Reductant tank - 38 litres
Total volume: 50 litres
Filling volume: 38 litres

This specification may be revised without notice.

Engine

Dimensions A (mm)

DC09 (202 kW - 257 kW)

786

DC09 (276 kW - 294 kW)

900

DC13 (257 kW - 331 kW)

900

DC13 (368 kW - 405 kW)

970

DC16

970

Evaporator module (DC16)

SCR catalyst

Other available sizes: 45 litres (total volume 62 litres)

60 litres (total volume 75 litres

63 litres (total volume 80 litres)

70 litres (total volume 88 litres)

720

280

671

1:7265

348.5

1:7357

Content .. 9 10 11 12 ..
