and, depending on the navigation

system fitted in the vehicle, on the infotain-
ment system as well

›››

Road sign detection system messages:

There are no traffic signs available

●

The system is in its start-up phase.

●

OR:

the camera has not recognized any

mandatory or prohibitive sign.

Error: Dynamic Road Sign Display

●

There is a fault in the system. Have the sys-

tem checked by a specialised workshop.

Speed warning currently unavailable

●

The speed warning function of the road

sign detection system is faulty. Have the sys-
tem checked by a specialised workshop.

Dynamic Road Sign Display: please
clean the windscreen.

●

The windscreen is dirty in the camera area.

Clean the windscreen.

Dynamic Road Sign Display currently
restricted.

●

The navigation system is not transmitting

data. Check if the navigation system has up-
dated maps.

●

OR:

the vehicle is in a region not included

on the navigation system's map.

No data available

●

The traffic sign detection system does not

work in the current country.

Activate and deactivate the road sign dis-
play on the instrument panel

The permanent traffic sign view on the instru-
ment cluster can be switched on or off in the
infotainment system using the function button



> Settings > Driver assistance

Display of traffic signs

When the traffic sign detection system is con-
nected, a camera located on the base of the
interior rear-view mirror records the traffic

signs in front of the vehicle. After checking
and evaluating the information from the cam-
era, the navigation system and the current
vehicle data, up to three valid road signs are
displayed,

›››



with their additional

signs.

The sign that is currently valid for the

driver is shown in the left side of the
screen For example, a maximum speed
limit of

130

km/h

(

100

mph

)

›››

A sign valid only in certain circum-

stances, e.g.

100

km/h

(

mph

) is shown

second, together with the additional rain
sign.

The supplementary panel

will display the circumstances (rain,
times of day, fog, etc.) under which the
displayed speed limit is in force.

Thirdly, a sign prohibiting overtaking is

partially displayed. If there is no condi-
tional speed limit and overtaking is pro-
hibited, the latter sign will be displayed
in second place

›››

Speed warning

If the system detects that the permitted
speed is exceeded, it may warn the driver
with a “gong” and visually with a message on
the dash panel display.

The speed warning can be set or completely
switched off in the infotainment system using
the function button



> Settings >

First:

Second:

Additional sign:

Third:

Instruments and warning/control lamps

Driver assistance

›››

. The

warning can be set to 0 km/h (0 mph), 5 km/h
(3 mph) or 10 km/h (5 mph) above the maxi-
mum permitted speed.

Trailer mode

In vehicles equipped with a towing bracket
device from the factory and a trailer that is
electrically connected to the vehicle, it is
possible to activate or deactivate the display
of specific traffic signs for vehicles with trailer,
such as speed limits or overtaking prohibi-
tions. It is switched on or off in the infotain-
ment system, using the function button



Settings > Driver assistance

›››

For trailer mode, the display of speed limits
applicable to the type of trailer or to the legal
provisions can be adjusted. The speed is ad-
justed in steps of 10 km/h (5 mph) within a
range of between 60 km/h (40 mph) and
130 km/h (80 mph). If it is adjusted to a speed
greater than that which is permitted in the
country in question for driving with a trailer,
the system automatically displays the usual
speed limits, e.g. in Germany 80 km/h
(50 mph).

If the speed warning for the trailer is deacti-
vated, the system displays the speed limits as
if there were no trailer hitched.

Limited operation

The traffic sign detection system has certain
limitations. The following cases may lead the
system to operate with limitations or not at
all:

●

In the case of poor visibility, e.g. in snow,

rain, fog or intense mist.

●

In cases of dazzling, e.g. caused by head-

on traffic or by the sun.

●

When driving at high speeds.

●

If the camera is covered or dirty.

●

If the traffic signs are out of the camera's

field of vision.

●

If the traffic signs are partially or totally

covered, e.g. by trees, snow, dirt or other vehi-
cles.

●

In the case of traffic signs that do not fulfil

the regulations.

●

In the case of damaged or bent traffic

signs.

●

In the case of variable messages on over-

head or gantry signs (LED-based variable
traffic signs or other lighting units).

●

If the maps on the navigation system are

not up-to-date.

●

In the case of adhesives affixed to vehicles

that depict traffic signs, e.g. speed limits on
lorries.

WARNING

The technology in the traffic sign detection
system cannot change the limits imposed
by the laws of physics and only works with-
in the system's limits. Do not let the extra
convenience afforded by the traffic sign
detection system tempt you into taking any
risks when driving. The system is not a re-
placement for driver awareness.

●

Adapt your speed and driving style to suit

visibility, weather, road and traffic condi-
tions.

●

Poor visibility, darkness, snow, rain and

fog may lead to the system failing to dis-
play traffic signs or not displaying them
correctly.

●

If the camera's field of vision is dirty, cov-

ered or damaged, system operation may
be impaired.

WARNING

The driving recommendations and traffic
indications shown on the traffic sign detec-
tion system may differ from the actual cur-
rent traffic situation.

●

The system may not detect or correctly

show all the traffic signs.

●

Traffic signs and traffic regulations have

priority over the recommendations and dis-
plays provided by the system.

Operation

WARNING

If messages are ignored, the vehicle may
stall in traffic and cause accidents and se-
vere injuries.

●

Never ignore the messages displayed.

●

Stop the vehicle at the next opportunity

and in a safe place.

Note

To avoid affecting the correct operation of
the system, take the following points into
consideration:

●

Regularly clean the area of vision of the

camera and keep it in a clean state, without
snow or ice.

●

Do not cover the field of vision of the

camera.

●

Always replace damaged or worn blades

when required to avoid lines on the cam-
era's field of vision.

●

Check that the windscreen is not dam-

aged in the area of the camera's field of vi-
sion.

●

The use of outdated maps on the naviga-

tion system may cause the system to show
traffic signs incorrectly.

●

In the waypoints mode of the navigation

system, the traffic sign detection system is
only partly available.

●

Failure to heed the control lamps and

corresponding text messages when they

light up may result in damage to the vehi-
cle.

Eco-efficient driving assistance

Fig. 58

Eco-efficient driving assistance indi-

cation (schematic representation).

Eco-efficient driving assistance helps you
drive with care and with low energy con-
sumption by following instructions superim-
posed in the digital cockpit, depending on the
situation.

When you approach places such as a junc-
tion, a roundabout or a section of road with a
speed limit, the symbol



is displayed along

with an event in the digital cockpit

›››

Fig. 58

As soon as you follow the indication and take
your foot off the accelerator, the vehicle
adapts, based on the selected driving profile

and distance to the incident, brake energy re-
cuperation and speed.

Eco-efficient driving assistance uses the trip
data from the infotainment system and the
sensors of some assist systems. If no destina-
tion guidance is active, the most likely route is
used.

Pressing the accelerator can cancel the in-
tervention of the assistance at any time.

Eco-efficient driving assistance can be
switched on and off in the infotainment sys-
tem, in the assist system settings

›››

page 91

Eco-efficient driving assistance is temporarily
switched off if:

●

The gear selector is in the

position.

●

The sport driving program is used.

●

Driving with adaptive cruise control (ACC)

or cruise control (GRA).

When these conditions no longer exist, the
assistance is reactivated if it is switched on in
the assist system settings.

Eco-efficient driving assistance is available
depending on the equipment, although not in
all countries.

WARNING

The system is not a replacement for driver
awareness.

Instruments and warning/control lamps

●

Adapt your speed and driving style at all

times to suit visibility, weather, road and
traffic conditions.

●

Traffic signs on the road and traffic regu-

lations have priority over eco-driving notes.

Note

●

The appearance of the symbols may vary

slightly depending on the equipment and
model. System updates may modify or ex-
pand the symbols.

●

When the system is switched on, eco-ef-

ficient driving assistance can also increase
recuperation without any indication being
displayed. This can occur in situations such
as when the accelerator pedal is released
when a vehicle is driving in front. In this
case, energy recuperation is adapted
match the speed of the vehicle in front
without any indication being displayed.

Time

Setting the time on the infotainment sys-
tem

●

Press





Settings

●

Select the menu option

Time and date

set the time

›››

Revolution counter

The rev counter indicates the number of en-
gine revolutions per minute.

Together with the gear-change indicator, the
rev counter offers you the possibility of using
the engine of your vehicle at a suitable
speed.

The beginning of the red zone of the rev
counter indicates the maximum speed in any
gear after running-in and with the engine hot.
However, it is advisable to change up a gear
or move the selector lever to

(or lift your

foot off the accelerator) before the needle
reaches the red zone

›››

We recommend that you avoid high revs and
that you follow the recommendations on the
gear-change indicator. Consult the addition-
al information in

›››

page 236, Selecting the

optimal gear

CAUTION

●

To prevent damage to the engine, the rev

counter needle should only remain in the
red zone for a short period of time.

●

When the engine is cold, avoid high revs

and heavy acceleration and do not make
the engine work hard.

For the sake of the environment

Changing up a gear early will help you to
save fuel and minimise emissions and en-
gine noise.

Power meter

Valid for: hybrid vehicles

Fig. 59

Digital instrument panel: Power meter

The lower left hand side of the rev counter
has two colour coded areas:

Charge:

Charging zone. Indicates the

amount of charge generated and the
maximum charge.

Power %:

Electric traction zone. Indi-

cates the percentage of power used and

Green

Blue

Operation

the maximum amount of power currently
available.

The power meter shows the usage level of
the electric drive. The power meter bar shows
the current usage level.

A finer coloured border indicates how much
the propulsion can currently be used. De-
pending on the selected driving program and
the current availability of electrical power,
the boundaries of the different colours can
vary.

The following displays can be seen on the
Power meter:

›››

Fig. 59

The vehicle recovers electrical energy.
e-Mode electric driving.
The combustion engine must be running.
With the Boost function, the vehicle drives
for a short period of time with maximum
power from both the electric motor and
the combustion engine.

Battery level indicator

Valid for: hybrid vehicles

Fig. 60

Instrument panel: battery level indica-

tor.

The small arrow next to the battery symbol
indicates which side of the vehicle the charg-
ing cover is on.

Note

●

Never drive with the tank completely

empty. Under certain circumstances, the
energy stored in the high-voltage battery
may not be sufficient to reach the nearest
service station.

●

When the outside temperature is very

low, and therefore the high-voltage battery
is very cold, difficulties may arise in start-
ing the internal combustion engine and the
range in the electric driving mode may be
reduced.

Fuel gauge

Fig. 61

Digital instrument panel: fuel gauge.

Control lamps



It lights up, and in addition, the
lower diode lights up in red

Fuel tank almost empty. The fuel reserve level has
been reached

›››

. Refuel as soon as you have the

opportunity.
When the fuel level is very low, the lower diode flash-
es red.

The display only works when the ignition is
switched on.

The fuel range is displayed on the instrument
panel.

You can consult the tank capacity of your ve-
hicle in the

›››

page 382

section.

Instruments and warning/control lamps

WARNING

When driving with low fuel, the vehicle may
stall in traffic and cause accidents and se-
vere injuries.

●

If the fuel tank level is too low, fuel could

reach the engine irregularly, particularly
when driving up or down slopes.

●

The steering system and the driver assis-

tance systems and brakes do not work
when the engine is running irregularly or
switches off due to lack of fuel or an irregu-
lar supply thereof.

●

SEAT recommends always refuelling

when the tank is approximately one quarter
full, to prevent the vehicle from stopping
due to a lack of fuel.

CAUTION

Never run the fuel tank completely dry. An
irregular fuel supply can cause misfiring
and unburnt fuel could enter the exhaust
system. The catalytic converter or the par-
ticulate filter may get damaged!

Note

The small arrow on the fuel gauge next to
the fuel pump symbol points out towards
the side of the vehicle with the fuel tank
flap.

Coolant temperature indicator.

Fig. 62

Digital instrument panel: engine cool-

ant temperature indicator.

Cool zone.

The engine has not reached

operating temperature yet. Avoid high
speeds and stressing the engine if it has
not reached operating temperature.

Normal zone.

At high outside tempera-

tures and when making the engine work
hard, the diodes may continue lighting up
and reach the upper zone. This is no
cause for concern, provided the control
lamp does not light up



Warning area.

When the engine is work-

ing hard, especially at high outside tem-
peratures, the diodes may light up in the
warning area.

The coolant temperature gauge only works
when the ignition is switched on.

Control and warning lamp



It lights up red



Do not carry on driving!

Engine coolant level too low, coolant temperature too
high.



Flashes red

Fault in the engine coolant system.

●

Stop the vehicle, switch off the engine and

let it cool down.

●

Check the engine coolant level

›››

page 343

●

If the warning lamp does not switch off even

if the coolant level is correct, request assis-
tance from specialised personnel.

Control and warning lamps (valid for hy-
brid vehicles)



It lights up red



Do not carry on driving!

Engine or high-voltage system coolant level too low,
engine or high-voltage system coolant temperature

too high.



and



Flashes red



Do not carry on driving!

Failure in the high-voltage cooling circuit. Discon-
nect the drive system and seek professional assis-
tance.

Operation

●

Stop the vehicle, switch off the engine and

let it cool down.

●

Check the engine coolant level

›››

page 343

●

Check the coolant level in the high-voltage

cooling circuit

›››

page 344

. If the level is too

low

DO NOT add coolant

. Seek specialist

assistance immediately.

●

If the warning lamp does not switch off even

if the coolant level is correct, request assis-
tance from specialised personnel.

CAUTION

●

To ensure a long useful life for the engine,

avoid high revs, driving at high speed and
making the engine work hard for approxi-
mately the first 15 minutes when the engine
is cold. The phase until the engine is warm
also depends on the outside temperature. If
necessary, use the engine oil temperature

›››

page 73

as a guide.

●

Additional lights and other accessories in

front of the air inlet reduce the cooling ef-
fect of the coolant. At high outside temper-
atures and high engine loads, there is a risk
of the engine overheating.

●

The front spoiler also ensures proper dis-

tribution of the cooling air when the vehicle
is moving. If the spoiler is damaged this can
reduce the cooling effect, which could
cause the engine to overheat. Seek spe-
cialist assistance.

Service intervals

The service interval display appears on the
instrument cluster screen and in the infotain-
ment system.

There are different versions of instrument
panels and infotainment systems, so the ver-
sions and instructions on the screens may
vary.

SEAT distinguishes between services

with

en-

gine oil change (e.g. Oil change service) and
services

without

engine oil change (e.g. In-

spection).

In vehicles with

Services established by

time or mileage

, the service intervals are al-

ready pre-defined.

In vehicles with

LongLife Service

, the inter-

vals are determined individually. Thanks to
technological progress, maintenance work
has been greatly reduced. Because of the
technology used by SEAT, with this service
you only need to change the oil when the ve-
hicle so requires. To calculate this variation
(max. 2 years), the vehicle's conditions of use
and individual driving styles are considered.
The advance warning first appears 20 days
before the date established for the corre-
sponding service. The kilometres (miles) re-
maining until the next service are always
rounded up to the nearest 100 km (miles) and
the time is given in complete days. The cur-
rent service message cannot be viewed until

500 km after the last service. Prior to this, on-
ly lines are visible on the display.

Inspection reminder

If a service or an inspection has to be carried
out soon, a

service reminder

will be dis-

played when the ignition is switched on.

The figure displayed are the kilometres that
can still be travelled or the time until the next
service.

Service due

When

the time for a service

or an

inspec-

tion

comes, an audible warning will be emit-

ted when the ignition is switched on and the
fixed key symbol



may appear on the in-

strument panel for a few seconds, along with
one of the following messages:

●

Service now!

●

Please have your vehicle inspec-

ted.

●

Oil change service due!

●

Oil change service and inspection

due!

Consult a service notification

With the ignition switched on, the engine off
and the vehicle at a standstill, the current

service notification

can be read:

Instruments and warning/control lamps

Check the date of the current service on the
infotainment system

●

Press the function button



Data > Set-

tings > Service

;



> Vehicle sta-

tus

›››

●

Select the

Service

menu option to display

information about the services.

Resetting service interval display

If the service was

not

carried out by a SEAT

dealership, the display can be reset as fol-
lows:

●

The service interval display can only be re-

set through the Service menu

›››

page 72

Do not

restart the indicator between the

service intervals, otherwise the information
displayed will be incorrect.

If the oil change service is reset manually, the
service interval display changes to a fixed
service interval, also in vehicles with

Flexible

oil change service

Note

●

The service message disappears after a

few seconds, when the engine is started or
when the



button is pressed on the multi-

function steering wheel.

●

In vehicles with the LongLife system in

which the battery has been disconnected
for a long period of time, it is not possible to
calculate the date of the next service.

Therefore the service interval display may
not be correct. In this case, bear in mind the
maximum service intervals permitted

›››

page 364

●

If you reset the display manually, the next

service interval will be indicated as in vehi-
cles with fixed service intervals. For this
reason we recommend that the service in-
terval display be reset by a SEAT author-
ised Dealer.

Using the instrument panel

Introduction

With the ignition switched on, it is possible to
read the different functions of the display by
scrolling through the menus.

The multifunction display can only be con-
trolled from the buttons on the multi-function
steering wheel.

Some menu options can only be read when
the vehicle is at a standstill.

WARNING

Distracting the driver in any way can lead
to an accident and cause injuries.

●

Never use the menus on the instrument

panel display while the vehicle is in motion.

Note

After loading or changing the 12-volt bat-
tery, check the system settings. If the pow-
er supply is interrupted, the system settings
might be incorrect or deleted.

Operation using the multifunction
steering wheel

Fig. 63

Right side of the multifunction steering

wheel: buttons to the menus and information

displays on the instrument panel.

As long as a priority 1

›››

page 73

warning is

active, it will not be possible to access any
menu. Some warnings can be confirmed and
hidden with the button



of the multifunction

steering wheel

›››

Select a menu or an informative display

●

Switch the ignition on.

Operation

●

Customisation option: select a user.

●

If a message or vehicle symbol is displayed,

press the button



›››

; if necessary,

several times.

●

To change menus, use buttons





›››

●

To open the menu or the information dis-

played, press the button



›››

or wait

a few seconds until the menu or the informa-
tive display opens automatically.

Changing menu settings

●

In the menu displayed, turn the right thumb-

wheel of the multifunction steering wheel

›››

until the desired option of the menu

is highlighted. The option appears framed.

●

Press the button



›››

to make the

required modifications. A mark indicates that
the system or function is activated.

Back to menu selection

Press the button





›››

page 66, Instrument panel

Button for the driver assistance
systems

Fig. 64

On the turn signal and main beam lev-

er: button for driver assistance systems (de-

pending on versions).

Fig. 65

Left side of the multifunction steering

wheel: button for driver assistance systems

(depending on versions).

With the turn signal and main beam headlight
lever button, you can activate or deactivate

the driver assistance systems displayed in the

Assistance systems

menu .

Activating or deactivating a driver assis-
tance system using the turn signal lever
and main beam headlight

●

Briefly press the

›››

Fig. 64

button to

open the

Assistants

menu.

●

Select the driver assistance system and ac-

tivate or deactivate it

›››

page 83

. A mark in-

dicates that driver assistance system is
switched on.

●

Next, confirm the selection by pressing the



button on the multi-function steering

wheel.

Activating or deactivating a driver assis-
tance system using the multifunction
steering wheel

●

Press the button



›››

Fig. 65

to open the

Aids

menu.

●

Select the driver assistance system and ac-

tivate or deactivate it. A mark indicates that
driver assistance system is switched on.

●

Next, confirm the selection by pressing the



button on the multifunction steering wheel.

The driver assistance systems can also be
switched on and off in the infotainment sys-
tem, in the menu Vehicle settings

›››

page 91

Instruments and warning/control lamps

Control lamps

Control and warning lamps

The control and warning lamps are indicators
of warnings

›››

, faults or certain functions.

Some control and warning lamps come on
when the ignition is switched on, and switch
off when the engine starts running, or while
driving.

Depending on the model, additional text
messages may be viewed on the instrument
panel display. These may be purely informa-
tive or they may be advising of the need for
action

›››

Depending upon the equipment fitted in the
vehicle, instead of a warning lamp, some-
times a symbol may be displayed on the in-
strument panel.

When certain control and warning lamps are
lit, an audible warning is also heard.

Red warning lamps



Notification central lamp: additional infor-
mation on the instrument panel display



Parking brake on

›››

page 273



Fault in the brake system

›››

page 273



Fault in the steering system

›››

page 238



Driver or passenger has not fastened seat

belt

›››

page 17



Engine or high voltage system coolant

(hybrid vehicles)

›››

page 81



Engine oil pressure

›››

page 341



Anomaly in the alternator

›››

page 348

›››

page 349



Press the foot brake

›››

page 255



Drive system

›››

page 324



AdBlue level too low,

fault in the SCR

system

›››

page 333

Yellow warning lamps



Notification central lamp: additional infor-

mation on the instrument panel display



Front brake pads worn

›››

page 273



Fault in the ESC or the system caused it to

switch off;

ESC or ASR operating

›››

page 278



ASR switched off manually;

ESC in

Sport mode

›››

page 278



Fault in the ABS

›››

page 278



Rear fog light switched on

›››



Fault in the emission control system

›››



Pre-heating of the diesel engine;

fault

in the management of the diesel engine

›››



Fault in the petrol engine management

›››



Particulate filter blocked

›››



Fault in the steering system

›››

page 238



Drive system

›››

page 223



Vehicle sound

›››

page 223



Tyre pressure monitor system

›››

page 359



Fuel tank almost empty

›››

page 80



Adblue level low,

fault in the SCR sys-

tem

›››

page 333



Fault in airbag system and seat belt ten-
sioners

›››

page 27





Front passenger front airbag disabled

›››

page 27





Front passenger airbag switched on

›››

page 27



Defective active cruise control (ACC)

›››

page 260



Lane Assist (lane keeping system)

›››

page 263

Operation





Error in the lane assist warning system

›››

page 263



Travel Assist error

›››

page 267



Fault in the lighting of the vehicle

›››



Low engine oil level

›››

page 341



Fault in the gearbox

›››

page 235



Windscreen cleaning fluid too low

›››

page 346

Green indicator lamps



Turn lights or emergency lights on

›››



Trailer turn signals

›››



Auto Hold activated

›››

page 277



Press the foot brake

›››

page 229



Cruise control

›››

page 248



Speed limiter

›››

page 250



Adaptive cruise control (ACC)

›››

page 256



Lane assist active (Lane Assist) warning

›››

page 263



Travel Assist active

›››

page 266

Blue indicator lamps



Main beam on or flasher on

›››

Other warning lamps



Door(s), rear lid or bonnet open or not

properly closed

›››

page 70



Main beam assist (Light Assist)

›››
