Seat Toledo (2019 year). Manual in english

Vehicle maintenance

special questions or parts that are not listed.
Take he general considerations into account

›››

in Take special care with... on

page 270

Exterior cleaning

Windscreen wipers

Problem

Solution

Dirt

Soft cloth with wipers

Headlights / Tail lights

Problem

Solution

Dirt

Soft sponge with neutral soap

solution

Neutral soap solution: two tablespoons maximum in

1 litre of water

Sensors / Camera lenses

Problem

Solution

Dirt

Sensors

: soft cloth with clean-

ing product which does not
contain solvents

Camera lenses

- soft cloth with

cleaning product with no alco-
hol content

Snow/ice

Hand brush/Anti frost spray
with no solvents

Wheels

Problem

Solution

Anti frost salt

Water

Brake abrasion

dust

Acid-free special cleaning

product

End exhausts

Problem

Solution

Anti frost salt

Water, if a steel cleaning prod-

uct is required

Covers / Trims

Problem

Solution

Dirt

Neutral soap solution

, if a

steel cleaning product is re-
quired

Neutral soap solution: two tablespoons maximum in

1 litre of water

Paint

Problem

Solution

Flaws in the paint

Check the paint's colour code
in an authorised service and re-

store with a touch-up pencil

Spilled fuel

Immediately rinse with water

Environmental rust
tank

Apply rust remover and then

apply hard wax. Go you your
specialised workshop if you
have any queries

Problem

Solution

Corrosion

Have your specialised work-
shop take care of this

The water does
not create drop-

lets on the clean

paint

Maintain with hard wax (at
least 2 times a year)

No shine de-
spite sober main-
tenance/paint

Treat with suitable wax and ap-

ply paint preservative after-
wards if the wax used does not
contain preservative ingredi-
ents

Tanks, e.g. insect

remains, bird
droppings, tree

sap, road salt

Immediately soften with water
and remove with a microfibre

cloth

Fat-based dirt,
e.g. cosmetic
products or
sunscreen

Delete immediately with a neu-
tral soap solution

and a soft

cloth

Neutral soap solution: two tablespoons maximum in

1 litre of water

Carbon fibre parts

Problem

Solution

Dirt

Clean the same way as pain-
ted parts

›››

page 265

267

Maintenance

Decoration slides

Problem

Solution

Dirt

Soft sponge with neutral soap

solution

Neutral soap solution: two tablespoons maximum in

1 litre of water

Interior cleaning

Windows

Problem

Solution

Dirt

Apply windscreen cleaner and
then dry with a cloth

Covers / Trims

Problem

Solution

Dirt

Neutral soap solution

Neutral soap solution: two tablespoons maximum in

1 litre of water

Plastic parts

Problem

Solution

Dirt

Damp cloth

Encrusted dirt

Neutral soap solution

, if pos-

sible solvent-free plastic clean-
er

Neutral soap solution: two tablespoons maximum in

1 litre of water

Displays/instrument panel

Problem

Solution

Dirt

Soft cloth with a liquid crystal

display cleaner

Control panels

Problem

Solution

Dirt

Soft brush, then soft cloth with
neutral soap solution

Neutral soap solution: two tablespoons maximum in

1 litre of water

Seat belts

Problem

Solution

Dirt

Neutral soap solution

, al-

lowed to dry before retracting

Neutral soap solution: two tablespoons maximum in

1 litre of water

Fabrics, artificial, Alcantara leather

Problem

Solution

Dirt particles ad-
hered to the sur-
face

Vacuum cleaner

Water-based dirt,
e.g. coffee, tea,

blood etc.

Absorbent cloth and neutral
soap solution

Problem

Solution

Grease-based
dirt, e.g. oil, make-
up, etc.

Apply a neutral soap solution

Absorb the dissolved grease
and paint particles drying with
an absorbent cloth, in case you

must treat it with water after-

wards

Special dirt, e.g.
pens, nail polish,
dispersion paint,
shoe cream etc.

Special stain remove: dry with

an absorbent cloth, if applica-
ble, apply neutral soap solution
afterwards

Neutral soap solution: two tablespoons maximum in

1 litre of water

Natural leather

Problem

Solution

Recent dirt

Cotton cloth with neutral soap

solution

Water-based dirt,

e.g. coffee, tea,
blood etc.

Recent stains: absorbent cloth

Dry stains: leather cleaner

Grease-based

dirt, e.g. oil, make-

up, etc.

Recent stains: absorbent cloth
and leather cleaner
Dry stains: grease dissolving

spray

Special dirt, e.g.
pens, nail polish,
dispersion paint,
shoe cream etc.

Stain remover suitable for

leather

268

Vehicle maintenance

Problem

Solution

Care

Apply preservative cream regu-
larly to protect from sunlight.
Use a colour preservative if re-
quired

Neutral soap solution: two tablespoons maximum in

1 litre of water

Carbon fibre parts

Problem

Solution

Dirt

Clean like plastic parts

Take special care with...

Headlights/tail lights

●

Do not clean the headlights/tail lights with

a dry cloth or sponge.

●

Do not use cleaning products that contain

alcohol. Risk of cracks!

Wheels

●

Do not use for paint wax or other abrasive

products.

●

If the protective coating on the paint of the

rim has been damaged due to stone impacts,
scratches, etc., the damage should be re-
paired immediately.

Camera lenses

●

Do not use hot or warm water to remove ice

or snow from the camera lenses. Risk of
cracking the lens!

●

To clean the camera lens, never use abra-

sive cleaning products or products with alco-
hol. Risk of scratches and cracks!

Windows

●

Remove snow and ice from windows and

exterior mirrors with a plastic scraper only. To
avoid scratches, the scraper should only be
pushed in one direction and not moved to
and fro.

●

Never remove snow or ice from windows

and rearview mirrors with warm or hot water.
Risk of cracks on the windows!

●

To prevent damage to the heating of the

rear window, do not put stickers over the
heating elements.

Covers/trims

●

Do not use cleaning products or chrome

based cleaning agents.

Paint

●

The vehicle must be free from dirt and dust

before applying wax or care products. Risk of
scratches!

●

Do not apply wax or care products if the

vehicle is exposed to direct sunlight. Risk of
damaging the paint job!

●

The ambient rust deposits must not be re-

moved through friction. Risk of damaging the
paint job!

●

Remove cosmetic products and sunlight

immediately. Risk of damaging the paint job!

Displays/instrument panel

●

The screens, the instrument panel and the

trim around it must not be cleaned dry. Risk of
scratches!

●

Make sure that the instrument panel is

switched off and cooled down before clean-
ing.

●

Make sure that no liquid leaks between the

instrument panel and the trim. Risk of dam-
age!

Control panels

●

Make sure that no liquid leaks into the con-

trol panels. Risk of damage!

Seat belts

●

Do not remove the seat belts to clean them.

●

Seat belts and their components must nev-

er be cleaned with chemical products, nor
should they be allowed to come into contact
with corrosive liquids, solvents or sharp ob-
jects. Risk of damaging the fabric!

●

If you find any damage to the belt webbing,

belt fittings, the belt retractor or the buckle,
ask your specialised workshop to replace the
belt in question.

269

Maintenance

Fabrics/artificial leather/Alcantara leath-
er

●

Do not treat artificial leather/Alcantara

leather with leather cleaning products, sol-
vents, wax polish, shoe cream, stain removers
or similar products.

●

If the stain is very hard to remove, take the

vehicle to a specialised workshop to have it
removed there. This will prevent damage.

●

Do not use steam cleaners, brushes, hard

sponges, etc. to clean.

●

Do not turn on seat heating* to dry the

seats.

●

Sharp objects on clothing, such as zips, riv-

ets or belts can damage the surface.

●

Open Velcro, e.g. on clothes can damage

the seat upholstery. Make sure that Velcro
fasteners are closed.

Natural leather

●

Never use solvents, wax polish, shoe cream,

spot removers or similar products on leather.

●

Sharp objects on clothing, such as zips, riv-

ets or belts can damage the surface.

●

Do not use steam cleaners, brushes, hard

sponges, etc. to clean.

●

Do not turn on seat heating* to dry the

seats.

●

Avoid exposing leather to direct sunlight for

long periods, otherwise it may tend to lose
some of its colour. If the car is left for a pro-

longed period in the bright sun, it is best to
cover the leather.

WARNING

Do not use water-repellent coatings on the
windscreen. In bad visibility conditions
such as humid weather, darkness or when
the sun is in its lowest point, visibility may
be impacted. Risk of accident! Such coat-
ings can also cause the windscreen wiper
blades to make noise.

Note

●

Remains of insects can be removed much

more easily with previously treated paint.

●

Regular car care treatments can prevent

deposits of ambient rust.

Remove the vehicle from traffic

If you want to leave your vehicle stationary
for a long period of time, contact a qualified
workshop. They will gladly inform you about
the necessary measures, such as anti-corro-
sion protection, Service and storage.

Also take into account instructions regarding
the vehicle's battery

›››

page 251

270

Information for the user

Information for the user

Important information

Recycling of electrical or electron-
ic devices

All electrical or electronic devices (EED) that
are not permanently fitted in the vehicle must
be marked with the following symbol:



This symbol indicates that EED must not be
discarded as home waste but through selec-
tive waste collection.

Information about the EU Di-
rective 2014/53/EU

Simplified EU compliance declara-
tion

Your vehicle has different radioelectrical devi-
ces. The manufacturers of these devices de-
clare that they comply with Directive
2014/53/EU when legally required.

The full text of the EU compliance declaration
is available online at the following address:

www.seat.com/generalinfo



Table of correspondences

The table of correspondences will help you to
associate the name of the device in the dec-
laration of compliance with the features of
the vehicle and the terminology used in the
on-board documentation.

Features of the
vehicle

Name of the device
according to the dec-

laration of compli-
ance

Radiofrequency re-
mote control (vehicle)

FS09, FS12A, FS12P, FS1477,
FS94

Radio frequency re-

mote control (auxili-
ary heater)

Sender STH SEAT -
50000914

Telestart

Auxiliary heating

50000864 / D208L VW

Telestart

Bluetooth

MIB2 Entry

MIB Standard 2

MIB2 Main-Unit

A580 / A270

Features of the

vehicle

Name of the device
according to the dec-
laration of compli-

ance

Wireless hotspot

MIB2 Main-Unit

A580 / A270

Keyless Access Sys-
tem

MQB-B B

Radar sensors for as-

sistance systems

ARS4-B

MRRevo14F

BSD3.0

Central control unit

5WK50254

5WK50474

Infotainment system

MIB2 Entry

MIB Standard 2

MIB2 Main-Unit

A580 / A270

Wireless charging

WCH-183

WCH-185

5G0.980.611

Connection to the ex-
ternal antenna of the

car

UMTS/GSM-MMC

UMTS/GSM-MMC-AG2

271

Information for the user

Features of the

vehicle

Name of the device
according to the dec-
laration of compli-

ance

Instrument panel

eNSF

Immobilizer integrated in
dashboard module
instrument cluster

Antenna

FM/AM Antenna Base

Antennas MQB27 Small/Big

family

Antennas KSA Small Fam III

5Q0.035.507 Roof Antenna

GNSS Antenna VAG
720166002

8S7.035.503.B

Antenna amplifiers

6F0.035.225
6F9.035.225

3V5.035.577.A
7N0.035.552.J
7N0.035.552.K

7N0.035.552.Q
5F4.035.225

5F4.035.225.A
5F4.035.225.B
5F9.035.225
5F9.035.225.A
5F9.035.225.B

575.035.225
575.035.225.A

575.035.225.B

Addresses of the manufacturers

According to the Directive 2014/53/EU, all
relevant components must include the ad-
dress of the manufacturer.

The address of the manufacturers of compo-
nents that, due to their size or nature, cannot
include a sticker are listed below, as long as it
is legally required:

Radioelectrical
equipment fitted
in the vehicle

Addresses of the
manufacturers

Radiofrequency remote

control key

Hella KGaA Hueck & Co.

Rixbecker Straße 75
59552 Lippstadt,
GERMANY

Radio frequency re-

mote control (auxiliary
heater)

Digades gmbH
Äußere Weberstraße 20

02763 Zittau, GERMANY

Webasto Thermo &
Comfort SE

Friedrichshafener Str. 9

82205 Gilching, GERMANY

Radar sensors for as-

sistance systems

ADC Automotive Distance

Control Systems GmbH
Peter-Dornier-Straße 10

88131 Lindau, GERMANY

Robert Bosch GmbH
Postfach 16 61
71226 Leonberg,

GERMANY

272

Information for the user

Frequency bands, station power

Radioelectrical equipment

Frequency band

Max. station power

Valid for models

Radiofrequency remote control (vehicle)

433.05-434.78 MHz

10 mW (ERP)

All SEAT models

433.05-434.79 MHz

10 mW

868.0-868.6 MHz

25 mW

434.42 MHz

32 µW

Radio frequency remote control (auxiliary heater)

868.7-869.2 MHz (869.0 MHz)

0.24 mW, / –6.3 dBm e.r.p.

Ateca

868.0-868.6 MHz (868.3 MHz)

3.1 mW, / 4.8 dBm e.r.p.

Alhambra

Auxiliary heating

868.0-868.6 MHz (868.3 MHz)

23.5 mW, / 13.7 dBm e.r.p.

Alhambra

868.7-869.2 MHz (869.0 MHz)

23.5 mW, / 13.7 dBm e.r.p.

Ateca

Bluethooth

2402-2480 MHz

6 dBm

All SEAT models

2400-2483.5 MHz

10 dBm

Wireless hotspot

2400-2483.5 MHz

10 dBm

Leon and Ateca

Connection to the external antenna of the car

GSM 900: 880-915 MHz

33 dBm

Ibiza, Arona, Leon, Ateca and Alhambra

GSM 1800: 1710-1785 MHz

30 dBm

WCDMA FDD I: 1920-1980 MHz

24 dBm

WCDMA FDD lll: 1710-1785 MHz

24 dBm

Keyless Access

434.42 MHz

32 µW

Ibiza, Toledo, Arona, Leon and Ateca

Radar sensors for assistance systems

76 GHz-77 GHz

28.2 dBm

Toledo, Leon and Alhambra

35.0 dBm

Ibiza, Arona and Ateca

24050-24250 MHz

20 dBm

Arona, Ateca and Alhambra

Wireless charging

110-120 kHz

10 W

Ibiza, Arona, Leon and Ateca

273

Technical specifications

Technical data

Technical specifications

Important information

Important

The information in the vehicle documentation
always takes precedence over the informa-
tion in this Instruction Manual.

All technical specifications provided in this
documentation are valid for the standard
model in Spain.

The figures may be different depending
whether additional equipment is fitted, for dif-
ferent models, for special vehicles and for
other countries.

Abbreviations used in the Technical Speci-
fications section

Kilowatt, engine power measurement.

Pferdestärke (horsepower), formerly
used to denote engine power.

rpm

Revolutions per minute - engine speed.

Newton metres, unit of engine torque.

Cetane number, indication of the die-

sel combustion power.

RON

Research octane number, indication of
the knock resistance of petrol.

Vehicle identification data

Fig. 254

Chassis number.

VIN in the Easy Connect

●

Select:



button > function button

SET-

TINGS > Service > Chassis number

Chassis number

The VIN is located in the Easy Connect and
under the windscreen, on the driver side

›››

Fig. 254

. Additionally, the chassis number

is located in the engine compartment, on the
right-hand side. The number is engraved on
the top side rail, and is partially covered.

Type plate

The model plate is located at the bottom of
the B pillar, between the front and rear doors,
on the right-hand side.

The type plate indicates the following
weights:

●

Total permitted weight of the vehicle when

loaded

●

Maximum authorised weight of the vehicle

with a trailer, when the vehicle operates as a
tractor

●

Maximum permitted load of the front axle

●

Maximum permitted load of the rear axle

Weight in running order

The weight in running order only has one ap-
proximate value. This value corresponds to
the minimum operative weight of the vehicle
without additional equipment that increases
its weight, i.e. air conditioning, spare wheel,
towing bracket.

275

Technical data

The running order weight also includes 75 kg
of the weight of the driver and service fluids,
in addition to a fuel tank at 90% capacity.

From the difference between the total permit-
ted weight in running order the approximate
carrying capacity can be calculated

›››

The carrying capacity must include:

●

occupants,

●

all pieces of equipment and other weights,

●

roof loads including the roof rack,

●

equipment that is not included in the run-

ning order weight,

●

when using the towing bracket, the drawbar

load (max. 50 kg).

Calculating fuel consumption and CO

emissions according to the ECE regula-
tions and the EU specifications

Calculation of fuel consumption for urban
driving begins when cold-starting the engine.
Then, normal city driving is simulated.

In calculating extra-urban driving fuel con-
sumption, braking and acceleration is done in
all gears, as in daily use of the vehicle. Driving
speed varies within a range of 0 and 120
km/h (75 mph).

The consumption value in combined driving is
composed of 37% of the value of urban driv-
ing and 63% of the value of extra-urban driv-
ing.

WARNING

The maximum permitted weight values
must not be exceeded – Risk of an accident
and damage to the vehicle!

Note

●

If you wish to calculate the exact weight

of your vehicle please contact a SEAT
dealer.

●

Depending on the volume of equipment,

driving style, road conditions, weather con-
ditions and the condition of the vehicle,
consumption values can differ from the
theoretical values stated here.

Information on fuel con-
sumption

Fuel consumption

Approved consumption values are derived
from measurements performed or supervised
by certified EU laboratories, according to the
legislation in force at the time (for more infor-
mation, see the Publications Office of the Eu-
ropean Union on the EUR-Lex website: © Eu-
ropean Union, http://eur-lex.europa.eu/) and
apply to the specified vehicle characteristics.

The values relating to fuel consumption and
CO

emissions can be found in the documen-

tation provided to the purchaser of the vehi-
cle at the time of purchase.

Fuel consumption and CO

emissions de-

pend on the equipment/features of each indi-
vidual vehicle, as well as on the driving style,
road conditions, traffic conditions, environ-
mental conditions, load or number of passen-
gers.

Note

In practice, and considering all the factors
mentioned here, consumption values can
differ from those calculated in the current
European regulations.

Weights

Kerb weight refers to the basic model with a
fuel tank filled to 90% capacity and without
optional extras. The figure quoted includes 75
kg to allow for the weight of the driver.

Special versions, optional equipment fittings
or retro-fitting accessories will increase the
weight of the vehicle

›››

WARNING

●

Please note that the centre of gravity

may shift when transporting heavy objects;
this may affect vehicle handling and lead
to an accident. Always adjust your speed

276

Technical specifications

and driving style to suit road conditions
and requirements.

●

Never exceed the gross axle weight rat-

ing or the gross vehicle weight rating. If the
permissible axle load or the permissible to-
tal weight is exceeded, the driving charac-
teristics of the vehicle may change, which
could lead to accidents, injuries and dam-
age to the vehicle.

Driving with a trailer

Trailer weights

Trailer weight

The trailer weights and drawbar loads ap-
proved are selected in intensive trials accord-
ing to precisely defined criteria. The ap-
proved trailer weights are valid for vehicles in
the

for maximum speeds of 80 km/h (50

mph) (in certain circumstances up to 100
km/h (62 mph)). The figures may be different
in other countries. All data in the official vehi-
cle documentation takes precedence over
these data at all times

›››

Drawbar loads

The

maximum

permitted drawbar load on the

ball coupling of the towing bracket must not
exceed

50 kg

In the interest of road safety, we recommend
that you always tow approaching the maxi-
mum drawbar load. The response of the trail-
er on the road will be poor, if the drawbar
load is too small.

If the maximum permissible drawbar load
cannot be met (e.g. with small, empty and
light-weight single axle trailers or tandem
axle trailers with a wheelbase of less than 1
metre), a minimum of 4% of the actual trailer
weight is legally required for the drawbar
load.

WARNING

●

For safety reasons, you should not drive

at speeds above 80 km/h (50 mph) when
towing a trailer. This also applies in coun-
tries where higher speeds are permitted.

●

Never exceed the maximum trailer

weights or the drawbar load. If the permis-
sible axle load or the permissible total
weight is exceeded, the driving character-
istics of the vehicle may change, leading to
accidents, injuries and damage to the vehi-
cle.

Wheels

Tyre pressure, snow chains and
wheel bolts

Tyre pressure

The sticker with the tyre pressure values can
be found on the inside of the fuel tank flap.
The tyre pressure values given there are for

cold

tyres. Do not reduce the slightly raised

pressures of warm tyres

›››

The pressure for winter tyres is 0.2 bar
(2.9 psi / 20 kPa) higher than that of summer
tyres.

Snow chains

Snow chains may be fitted only to the

front

wheels

Consult the section “wheels” of this manual.

Wheel bolts

After the wheels have been changed, the

tightening torque

of the wheel bolts should

be checked as soon as possible with a torque
wrench

›››

. The tightening torque for steel

and alloy wheels is

120

Nm.

WARNING

●

Check the tyre pressure at least once per

month. Checking the tyre pressure is very
important. If the tyre pressure is too high or

277

Technical specifications

Engine data

Petrol engines

1.0 TSI Start-Stop

Power output in kW (PS) at 1/min

70 (95)/5,000-5,500

81 (110)/5,000-5,500

Maximum torque (Nm at 1/min)

160/1,500-3,500

200/2,000-3,500

No. of cylinders/displacement (cm

)

3/999

Fuel

Super 95 / Normal 91 (with a slight power loss) ROZ

Gearbox

manual

DSG

Top speed (km/h)

189 (4)

204 (5)

206 (6)

Acceleration from 0-80 km/h (seconds)

7.3

6.7

6.8

Acceleration from 0-100 km/h (seconds)

11.1

9.9

10.2

Maximum authorised weight (kg)

1,630

1,650

1,675

Weight in running order (with driver) (kg)

1,170

1,190

1,215

Maximum authorised weight on front axle (kg)

Maximum authorised weight on rear axle (kg)

Maximum trailer weight without brakes (kg)

580

590

600

Weight of trailer with brakes on gradients up to 8% (kg)

1,100

1,200

1,100

Weight of trailer with brakes on gradients up to 12% (kg)

1,000

1,100

1,000

Data not available as this edition goes to print.

279

Technical data

Petrol engines

1.4 TSI Start-Stop

1.4 TSI Ecomotive

1.6 MPI

Power output in kW (PS) at 1/min

92 (125)/5,000-6,000

81 (110)/5,800

Maximum torque (Nm at 1/min)

200/1,400-4,000

155/3,800-4,000

No. of cylinders/displacement (cm

)

4/1,395

4/1,598

Fuel

Super 95 / Normal 91 (with a slight power loss) ROZ

Gearbox

DSG

manual

automatic

Top speed (km/h)

208 (6)

191 (5)

191 (6)

Acceleration from 0-80 km/h (seconds)

6.3

6.4

6.7

7.7

Acceleration from 0-100 km/h (seconds)

10.3

11.5

Maximum authorised weight (kg)

1,696

1,687

1,635

1,675

Weight in running order (with driver) (kg)

1,236

1,227

1,175

1,215

Maximum authorised weight on front axle (kg)

880

820

860

Maximum authorised weight on rear axle (kg)

830

840

Maximum trailer weight without brakes (kg)

600

610

580

600

Weight of trailer with brakes on gradients up to 8% (kg)

1,200

1,100

Weight of trailer with brakes on gradients up to 12% (kg)

1,200

1,000

280

Technical specifications

Vehicle data

Dimensions

Fig. 255

Dimensions.

TOLEDO

A/B

Front and rear projection (mm)

876/1,004

Wheelbase (mm)

2,602

Length (mm)

4,482

E/F

Front/rear

track width (mm)

1,463/1,500

Width (mm)

1,715

Height at kerb weight (mm)

1,466

Turning radius (m)

10.2

This data will change depending on the type of wheel rim.

281

Seat Toledo (2019 year). Manual in english - page 17
