SD CARD 1

SD CARD 2

*: SD memory

card

›››

USB

: External data storage device

connected to the USB port



›››

AUX

: External audio source connec-

ted to the AUX-IN multimedia socket

›››

BT AUDIO

: Bluetooth

audio

›››

Function button: function

SELECTION

Opens the track list. Depending on
the level, track list, folders or source.





Changes track in Media mode or fast
forward/rewind.



Playback stops. The



function but-

ton changes to





Playback is resumed. The



func-

tion button changes to



SETTINGS

Opens the

Media Settings

menu.



REPEAT

Repeat all tracks.

Repeats all the tracks that are on the
same memory level as the track be-

ing played at that moment. If in the

Media Settings

menu the



Mix/Repeat including subfolders

op-

tion is enabled, it also includes the

subfolders.



REPEAT

The current track will be repeated.

MIX



Random play.

Includes all the tracks that are on

the same memory level as the track

being played at that moment. If in
the

Media Settings

menu the



Mix/Repeat including subfolders

op-

tion is enabled, it also includes the
subfolders.

173

Infotainment System

Messages and symbols on the Media main
menu

Display: Meaning

Displays information about the artist
name, album name and song title (CD
text



, ID3 tag on compressed audio

files).

Audio CD: displays track information. If
no data is available, it only displays

Track

and the number corresponding to

the position it occupies on the data stor-

age device.

Album cover display: If there are various

covers within the same folder/album, the

system only displays one of them.

It prioritizes displaying the covers in the
following manner:

1. Cover embedded in the file(s).

2. Image in file folder.
3. Default icon of the connected device.

The playing time so far and time remain-

ing in minutes and seconds. In the case
of audio files with variable bit rates (VBR)
the remaining time may vary.

The TP function is active and can be
used: select

Radio > Settings >

Traffic programme (TP)



There are no traffic stations available:

select

Radio > Settings > Traf-

fic programme (TP).

Depends on the market and unit in question.

Note

●

When the media source is inserted, play-

ing will not start automatically; it is neces-
sary for the user to select the source. Nor
will the media source change when it is
ejected.

Changing the Media source

Fig. 193

MEDIA mode: change media source.

●

From the

Media

main menu, press the



Infotainment button repeatedly to cycle
through the available media sources.

●

OR:

From the

Media

main menu, press the

SOURCE

function button

›››

Fig. 193

and se-

lect the desired media source.

In the pop-up window, the Media sources not
selected are shown as deactivated (in grey).

When a Media source that has already been
played is selected again, playback is re-

sumed from the point at which it was stop-
ped.

Optional Media playback sources

Function button: media source

Internal CD drive

›››

SD CARD 1

SD memory card

›››

SD CARD 2

USB

External data storage device con-

nected to the USB port



›››

AUX

External audio source connected

to the AUX-IN multimedia socket

›››

BT AUDIO

Bluetooth

audio

›››

Note

The Media source can be changed in the

Track list

view: select

Media > View.

174

Operating modes

Insert or eject a CD

Not available for model: Media System

Touch/Colour

Fig. 194

Slots for data storage devices in the

glove compartment.

The driver should refrain from operating the
unit while the vehicle is in motion. Insert or
change the data storage device before mov-
ing off!

The CD drive can play audio CDs and audio
data CDs.

Inserting a CD

●

Hold the CD with the printed side facing up.

●

Push the CD into the slot

›››

Fig. 194

the point where it is drawn in automatically.

Ejecting a CD

●

Press button



●

The CD in the drive will be ejected and

must be removed within approximately
10 seconds.

Insert or eject a memory card

Depending on the features and the country,
the vehicle may have one or two slots for SD
cards.

Inserting a memory card

Insert the compatible memory card, bevelled
edge first and with the label face up (con-
tacts face down), into slot

›››

Fig. 194

›››

Fig. 171

, until properly inserted.

If a memory card cannot be inserted, make
sure it is positioned correctly and is compati-
ble with the unit.

Removing a memory card

The inserted memory cards

must

be pre-

pared for removal.

●

From the main

Media

menu, press the

SETTINGS

button to open the

Media Set-

tings

menu or press the infotainment button



and then press

Settings

to open menu

System settings

●

Press the

Remove safely

function button. A

dropdown menu appears with the following
options: SD1 Card, SD2 Card* and USB. After
correctly ejecting the memory card from the

system, the function button becomes inactive
(grey colour).

●

Press the inserted memory card. The mem-

ory card “jumps” to the eject position.

●

Remove the memory card.

Unreadable memory card

If a memory card is inserted and the data
cannot be read, the relevant warning ap-
pears.

External data storage device con-
nected to the USB port



Depending on the the features and the coun-
try, the vehicle may have a USB connection

›››

page 195

Audio files on an external data storage device
connected to the USB port



can be played

and controlled via the Infotainment system.

Where this manual refers to external data
storage devices, this means USB mass stor-
age devices containing supported audio files,
such as MP3 players, iPods™ and USB sticks.

Only supported audio files are displayed and
played. Other files are ignored.

Instructions and restrictions

Compatibility with Apple™ devices and other
media players depends on the unit.

175

Infotainment System

The USB port



supplies the usual USB volt-

age of 5 volts for a USB connection.

External hard disks with a capacity greater
than 32 GB must be reformatted for the FAT32
file system in some circumstances. You will
find the necessary software and information
on the Internet.

Take into account all other instructions and
limitations regarding requirements for media
sources.

Disconnecting

Any connected data storage devices

must

be prepared before their disconnection in or-
der to remove them.

●

From the main

Media

menu, press the

SETTINGS

button to open the

Media Set-

tings

menu or press the infotainment button



and then press

Settings

to open menu

System settings

●

Press the

Remove safely

function button. A

dropdown menu appears with the following
options: SD1 Card, SD2 Card* and USB. After
correctly ejecting the data storage device
from the system, the function button be-
comes inactive (grey colour).

●

Now the data storage device can be dis-

connected.

Note

●

Do not connect an external media player

at the same time to play music via Blue-
tooth

and via the USB port



with the In-

fotainment system, as this could cause
playback limitations.

●

If the external player is an Apple™ device,

it cannot be simultaneously connected by
USB and by Bluetooth

●

If a connected device is not recognised,

disconnect all the connected devices and
try connecting the device again.

●

Do not use memory card adaptors, USB

extension cords or USB hubs!

External audio source connected to
the AUX-IN multimedia socket



Depending on the equipment and country
there may be an AUX-IN multimedia socket

›››

page 195

The connected external audio source is
played over the vehicle speakers and

cannot

be controlled via the Infotainment system
controls.

The connection of an external audio source is
indicated by

AUX

on the screen.

Connecting an external audio source to
the AUX-IN multimedia socket

●

Lower the base volume on the Infotainment

system.

●

Connect the external audio source to the

AUX-IN multimedia socket.

●

Start playback on the external audio

source.

●

In the MEDIA main menu, press the

SOURCE

function button and select

AUX

Connecting an external audio
source via Bluetooth

Bluetooth

Audio mode allows you to listen to

audio files being played on a Bluetooth

au-

dio source (e.g., a mobile telephone) connec-
ted via Bluetooth

(audio playback by Blue-

tooth

) over the vehicle speakers.

Conditions

●

The Bluetooth

audio source must support

the A2DP Bluetooth

profile.

●

In the

Bluetooth Settings menu

the



Bluetooth Audio (A2DP/AVRCP) function

must

be on. Select

Phone > Settings > Blue-

tooth

176

Operating modes

Starting Bluetooth

audio transfer

●

Activate Bluetooth

visibility on the external

Bluetooth

audio source (e.g., mobile tele-

phone).

●

Lower the base volume on the Infotainment

system.

●

In the MEDIA main menu, press the

SOURCE

function button and select

BT audio

●

Press

Search for new device

in order to con-

nect an external Bluetooth

audio source for

the first time

›››

page 190

●

OR:

Select a Bluetooth

external audio

source from the list.

●

Please refer to the instructions on the

screen of the Infotainment system and on the
Bluetooth

audio source regarding the rest of

the procedure.

You may still need to manually start playback
on the Bluetooth

source.

When playback on the Bluetooth

audio

source is stopped, the Infotainment system
remains in Bluetooth

Audio mode.

Controlling playback

The extent to which the Bluetooth

audio

source can be controlled via the Infotainment
system depends on the connected Blue-
tooth

audio source.

The available functions will depend on the
Bluetooth

Audio profile that the connected

external player supports.

With media players that support the AVRCP
Bluetooth

profile, playback on the Blue-

tooth

audio source can be automatically

started or stopped when the unit is switched
to Bluetooth

Audio mode or to a different au-

dio source. In addition, it is possible to view or
change the track via the Infotainment system.

Note

●

Due to the large number of possible Blue-

tooth

audio sources, it is not possible to

guarantee fault-free operation of all de-
scribed functions.

●

Do not connect an external media player

to play music via Bluetooth

and via the

USB port



›››

at the same time

with the Infotainment system, as this could
cause playback limitations.

●

If the external player is an Apple™ device,

it cannot be simultaneously connected by
USB and by Bluetooth

Images

Valid for the model: Media System Plus/Navi

System

Fig. 195

Images main menu.

Using the

Images

menu, image files can be

viewed (e.g. photos) individually or as a slide-
show.

The image files must be stored on a compati-
ble data storage device (e.g., a

or an

card

●

Press the Infotainment



button and

then select the

Images

context.

●

Press the

SOURCE

function button to select

the source where the pictures in question are
located.

Function button: function

SOURCE

Viewing and selecting the source.

SELECTION

Opens a list of image files.

177

Infotainment System

Function button: function



The image viewed was obtained via
GPS localisation and upon pressing

this function button, the navigator
menu opens to start a route to this

destination.





Rotate the view of the image to the
left or the right.



Reset the view of the image.



To stop the playback of a slideshow.
The



function button changes to



To continue the playback of a slide-
show. The



function button

changes to







To change to the

PREVIOUS

NEXT

image.

The same function can be per-

formed by sliding your finger hori-
zontally across the screen.

SETTINGS

Open the Image settings menu.

Enlarging or reducing the view

To enlarge or reduce the view of the image
displayed:

●

Turn the adjustment knob.

●

OR:

Stretch or reduce the image on the

screen using 2 fingers.

Rotating the view/image

To rotate an image, in addition to the buttons
provided for this (





), you can also press

on the screen (e.g. with your thumb) and,
while continuing to press with your thumb,
slide another finger (e.g. your index finger)
around it like a compass either clockwise (to
rotate the image to the right) or anti-clock-
wise (to turn the image to the left). This will ro-
tate the image 90° with respect to its current
position.

Requirements for viewing images

Image files

Maximum resolu-
tion

BMP

4MP

JPEG

4MP (Progressive Mode)

JPG

64MP

GIF

4MP

PNG

4MP

Navigation

Introduction

Fig. 196

Related video

General information

Using all the data available, the Infotainment
system calculates the optimum route to the
destination.

The destination is defined by entering an ad-
dress or a point of interest, e.g. a petrol sta-
tion or hotel. Traffic reports, if any, will also be
taken into account in the route calculation
(dynamic route guidance

›››

page 186

Spoken instructions and visual guidance on
the navigation unit and on the instrument
panel will direct you to your destination.

CAUTION

The navigation announcements played
may be inaccurate (e.g. due to out-of-date
navigation data).

Only available for the model: Navi System

178

Operating modes

Instructions for navigation

When the Infotainment system is unable to re-
ceive any data from GPS satellites (due to a
dense tree canopy, underground car park),
navigation can still continue using the vehicle
sensors.

Possible limitations in navigation

In areas that are not or are only partially digi-
tised on the data storage device, the Infotain-
ment system will still attempt to provide route
guidance.

Navigation area and updating navigation
data

Roads and streets are subject to constant
change (e.g. new roads, changes to street
names and building numbers). Therefore, if
the navigation data is not updated, then er-
rors or inaccuracies may occur during guid-
ance.

SEAT recommends updating navigation data
on a regular basis. Up to date navigation data
can be downloaded from www.seat.com or
acquired at a SEAT dealer.

Updating and using navigation da-
ta from an SD card

The Infotainment system always requires the
navigation data that is currently valid for this
unit in order to allow all functions to be used
in full. Using an old version may lead to errors
during navigation.

Updating navigation data

The current navigation data can be downloa-
ded in the internet at www.seat.com and stor-
ed in a SD card compatible with the unit.

Suitable SD Cards can be acquired at SEAT
dealerships.

The procedure is described on the internet at
www.seat.com.

Using navigation data

●

Insert the memory card

›››

●

Do not remove the memory card while test-

ing. Wait for the testing icon to disappear.

If the inserted memory card contains valid
navigation data, the following message ap-
pears: “

The source contains a valid

navigation database

”. It is now possible to

navigate with the memory card data. When
the memory card is no longer needed by the
hardware, it will be prepared for removal

›››

Note

●

The inserted memory card must be pre-

pared before it is ejected

›››

●

Press the Infotainment button



; then

press

Settings

to open the

System set-

tings

menu.

●

Navigation is not possible without the SD

card.

●

Do not remove the memory card while

the navigation data is in use. This could
damage the memory card!

●

The navigation memory card may not be

used as memory for other files. The info-
tainment system will not recognise the files
saved.

●

SEAT recommends only using original

SEAT memory cards to use navigation data.
The use of other memory cards could limit
its operation.

179

Infotainment System

Navigation main menu

Fig. 197

Navigation main menu

The

Navigation

main menu allows you to se-

lect a new destination, call up a previously
used or stored destination and search for
points of interest.

Opening the main Navigation menu

●

Press the Infotainment system button



to open the last menu that was open in navi-
gation.

Function buttons and messages on the
main Navigation menu

Function button: function

The split screen is displayed

›››

page 185

Messages and function buttons on the map

display

›››

page 185

Function button: function

NEW DESTINATION

: To enter a new destination

›››

page 180

ROUTE

: During route guidance

›››

MY DESTS.

: To activate or manage stored destina-

tions

›››

POI

: Search for points of interest (car parks, fuel sta-

tions and restaurants) within a particular search area

›››

page 184

VIEW

To modify or activate or deactivate the split

screen and show POI

›››

Fig. 197

›››

page 184

SETTINGS

Open the

Navigation Settings

›››

Fig. 197

New destination (enter destina-
tion)

Fig. 198

Search screen.

●

In the

Navigation

main menu, press the

New destination

function button.

●

Press the

Options

function button and se-

lect the required type of destination (

Search

Address

POI on the route

On map

●

Using voice control*, if you say Town, street

and number, without pauses, and then the in-
struction “Start Route Guidance” a route to
the given destination will start.

Search for addresses and Points of Interest
using the keypad to enter them

›››

Fig. 198

For cities, post codes and points of interest,
the full details must be entered. You can also
search for points of interest by names or cat-
egories. When necessary, enter the name of
the city to refine the search.

›››

Fig. 198

Press to open the cursor buttons (





which allow you to move within the text.

Address

After entering a country and a town, you can
start navigating towards the centre of the se-
lected town.

When narrowing down the destination ad-
dress,

please note

that every entry restricts

the available range of subsequent selections.
For instance, if the street you are looking for is

180

Operating modes

not

in the postcode area you have selected

in a previous window, you will not be able to
find the street at the street selection stage.

Function button: function

Country

: To select the desired country.

City

: To enter the desired city or postcode.

Street

: To enter the desired street name.

House number

: To enter the desired house number.

Junction

: To select the desired intersection.

Last destinations

: Open the

My destinations

›››

Start

: Start route guidance to the selected address.

Using the map

●

Select the destination on the map or enter

it using GPS coordinates and confirm with

Function button: function

Save

: To save the selected point of interest in the

destination memory

›››
