Seat Toledo (2019 year). Manual in english

Instruments and warning lamps

Button

Radio

Media (except AUX)

AUX

Telephone

Cycles through the audio source: FM/AM – CD – SD - USB - AUX - BT Audio (only those that are available).
This function can be used from any mode (audio, media, navigation, assistants, vehicle status, travel data).

Turn

Coloured instrument panel:

List of stations available (on-

ly if the instrument panel is in
audio menu).

Coloured instrument panel:

next track (only if the instru-

ment panel is in audio menu).

No function

– There is no active call:

List

of last calls.

– Active call:

access the call

options list (call on hold,
hang up, mute microphone,
private number, etc.).

– Active route:

access the

view to halt guidance to des-

tination.

– No active route:

list of previ-

ous destinations.

Press

Acts on the instrument panel or confirms the instrument panel menu option depending on the menu option.

According to the vehicle's equipment package.

This action can be performed when you are listening to the radio; there is no need to be in audio-radio mode.

These actions can be performed when you are listening to media; there is no need to be in audio-radio mode.

107

Operation

Opening and closing

Remote control

General notes

Read the additional information carefully

›››



page 11

The remote control key can

●

Lock and unlock the vehicle

●

Unlock or open the rear lid.

The remote control transmitter and the bat-
teries are integrated in the key. The receiver is
inside the vehicle. The remote control key has
a maximum range of 30 metres. The range is
reduced as the batteries start to lose power.

The key includes a foldaway part that can be
used to manually lock or unlock the vehicle
and to start the engine.

If a lost key is replaced or the receiver is re-
paired or changed, the remote control key
must be adapted by an authorised SEAT
dealer. Only then can the remote control key
be used again.

Note

●

The remote control is automatically de-

activated when the ignition is switched on.

●

The remote control function may be tem-

porarily limited by interference from other
transmitters near the vehicle that operate
on the same frequency (e.g. mobile phone,
television transmitter).

●

If the central locking system or the anti-

theft alarm only responds to the remote
control at a distance of less than 3 metres,
then the battery must be replaced

›››

page 110

●

If the driver door is open, the vehicle can-

not be locked using the remote control.

Unlocking and locking the vehicle

Fig. 117

Remote control key

Unlocking the vehicle



–

Press button

Locking the vehicle



–

Press button

Deactivating the Safe lock

–

Press button

twice in 2 seconds. Further

information

›››

page 110

Unlocking the rear lid



–

Press button

. Further information

›››

page 117

Unfolding the key shaft

–

Press button

Folding the key shaft

–

Press button

and fold the key shaft back

to its original position.

The turn signals will flash twice when the ve-
hicle is unlocked. If the vehicle is unlocked us-
ing button

and none of the doors or the

rear lid is opened in the following 30 seconds,
the vehicle will automatically relock and the
Safe lock or the anti-theft alarm will be acti-
vated. This function prevents the vehicle from
being unlocked by mistake.

Locking indication

The turn signals will flash if the vehicle has
been correctly locked.

108

Opening and closing

Should any of the doors or the rear lid remain
open when the vehicle is locked, the turn sig-
nals will only flash when they are closed.

WARNING

Do not leave people or animals in vehicles
locked from outside with the Safe lock acti-
vated: the doors and windows cannot then
be opened from the inside. Doors locked in
this manner could delay assistance in an
emergency. Risk of death!

Note

●

Only use the remote control when the

doors and the rear lid are locked and the
vehicle is within sight.

●

Do not press the lock button



on the re-

mote control before inserting the key in the
ignition, otherwise the vehicle could be
locked by mistake. Should this occur, press
the unlock button



on the remote control.

Remote control synchronisation

If the vehicle cannot be locked or unlocked
using the remote control, the key code may
not match that of the control unit. This can
occur when the remote control buttons are
frequently pressed outside the range of the
system or if the remote control battery has
been replaced.

In this case, it must be synchronised as fol-
lows:

●

Press any key on the remote control key.

●

Open the door using the key within the next

minute.

Keys

General notes

Fig. 118

Key with remote control/Key without

remote control.

Two keys are always supplied with the vehi-
cle. Depending on the model version, your

car may include keys without remote control

›››

Fig. 118



or with remote control

›››

Fig. 118



WARNING

●

Never leave the key inside whenever you

leave the vehicle - even if only for a mo-
ment. This is particularly important if chil-
dren are to remain in the vehicle. Children
might start the engine or some other elec-
trical component, e.g. electric windows.
Risk of injury!

●

Wait until the vehicle has completely

stopped before taking the key out of the ig-
nition. Otherwise the steering wheel may
lock suddenly. Risk of accident!

CAUTION

●

Each key contains electronic compo-

nents and must, therefore, be protected
from dampness and strong vibrations.

●

Keep the grooves in the key shaft clean.

Any dirt (fibre from clothing, dust, etc.) has
a negative impact on locks, ignition, etc.

Note

Should a key be lost, request a duplicate
key from an Authorised SEAT dealer.

109

Operation

Replacing the battery in the remote
control key

Fig. 119

Vehicle key: opening the battery com-

partment.

Fig. 120

Vehicle key: removing the battery.

SEAT recommends you ask a specialised
workshop to replace the battery.

The battery is located to the rear of the vehi-
cle key, under a cover.

Changing the battery

●

Unfold the vehicle key shaft.

●

Remove the cover from the back of the ve-

hicle key

›››

Fig. 119

in the direction of the ar-

row

›››

●

Extract the battery from the compartment

using a suitable thin object

›››

Fig. 120

●

Place the new battery in the compartment

as shown

›››

Fig. 120

, pressing in the opposite

direction to that shown by the arrow

›››

●

Fit the cover as shown

›››

Fig. 119

, pressing

it onto the vehicle key casing in the opposite
direction to that shown by the arrow until it
clicks into place.

CAUTION

●

If the battery is not changed correctly,

the vehicle key may be damaged.

●

Use of unsuitable batteries may damage

the vehicle key. For this reason, always re-
place the dead battery with another of the
same voltage, size and specifications.

●

When fitting the battery, check that the

polarity is correct.

For the sake of the environment

Please dispose of your used batteries cor-
rectly and with respect for the environ-
ment.

Note

If it is not possible to unlock or lock the ve-
hicle with the remote control key once the
battery has been replaced, it will need to
be re-synchronised

›››

page 109

Central locking system

General notes

All

of the doors, the rear lid and the fuel cap

flap

will unlock at the same time when the

central locking system is used.

Warning lamp on the driver door

Once the doors are locked, the warning lamp
will flash quickly for 2 seconds and then at a
slower rate.

If the vehicle is locked with Safe lock engag-
ed

›››

page 112

, the warning lamp on the

Valid for vehicles with a keyless fuel tank cap.

110

Opening and closing

driver door will flash quickly for 2 seconds be-
fore switching off for 30 seconds and then
flashing at a slower rate.

If the warning lamp flashes quickly for 2 sec-
onds and then remains switched on before
flashing at a slower rate after 30 seconds,
there is a fault in the interior monitor and tow-
away protection system

›››

page 117

. Go to a

technical service.

WARNING

●

Locking from the outside carelessly or

without good visibility may lead to bruising,
particularly in the case of children.

●

When locking a vehicle, never leave chil-

dren unaccompanied inside, as from the
outside it will be difficult to provide assis-
tance if required.

●

Having the doors locked prevents intrud-

ers from getting in, for example when stop-
ped at a traffic light.

Individualised settings

Unlocking single doors

This optional function unlocks the driver door
only. The other doors remain locked and are
only unlocked when the next command is giv-
en (unlock).

Automatic unlock and lock

The doors and the rear lid are locked auto-
matically when the vehicle reaches a speed
of about 15 km/h (9 mph).

The doors unlock automatically when the key
is removed from the ignition. Additionally, the
driver or front passenger can unlock the
doors by pressing the



›››

page 113

central

lock button or by pulling the front door han-
dle.

WARNING

Locking the doors prevents intruders from
getting into the car, e.g. while waiting at in-
tersections. However, it can also delay as-
sistance in the event of an accident. Risk of
death!

Note

●

Activation of the single door setting can

be requested at your SEAT dealer.

●

In the event of an accident in which the

airbags deploy, the doors will be automati-
cally unlocked for easier access and assis-
tance.

●

If the central locking system should fail to

work at any time, only the driver door can
be locked or unlocked using the key

›››

page 112

. All other doors and the rear lid

can be operated manually.

–

Manual release

›››



page 12

–

Manual release mechanism for the rear
lid

›››



page 12

Unlocking with key

Fig. 121

Key positions during vehicle locking

and unlocking.

–

Turn the key in the driver door in the forward
driving direction to its unlock position

›››

Fig. 121

–

Pull the handle and open the door.

●

All doors (driver door only on vehicles with

anti-theft alarm) are unlocked.

●

The rear lid is unlocked.

●

The fuel tank flap is unlocked

Valid for vehicles with a keyless fuel tank cap.

111

Operation

●

The courtesy lights switch on.

●

The Safe lock is deactivated.

●

The driver door warning lamp stops flash-

ing (on vehicles not equipped with an anti-
theft system)

›››

page 116

Note

If the vehicle is equipped with an anti-theft
alarm system, you have 15 seconds from
the time the door is opened to insert the
key in the ignition and start the vehicle. If,
during these 15 seconds, the vehicle is not
started, the alarm is triggered.

Locking with key

–

Turn the key in the driver door lock cylinder
in the reverse direction to its lock position

›››

Fig. 121

●

The doors, the rear lid and the fuel tank

flap

will be locked.

●

The courtesy lights switch off.

●

The Safe lock is immediately activated.

●

Warning lamp on the driver door starts to

flash.

Note

The vehicle doors cannot be locked if the
driver door is open.

Safe Lock

The central locking system is equipped with a

Safe lock

. If the vehicle is closed from out-

side, the door locks will automatically lock.
The warning lamp on the driver door will flash
quickly for about 2 seconds and then at a
slower rate. It is not possible to open any of
the doors from the inside or outside using the
handle. This limits the possibility of intruders
getting into the vehicle.

The Safe lock can be deactivated by press-
ing the lock button twice in less than 2 sec-
onds.

If Safe lock is out of service, the control lamp
on the driver door will flash quickly for about
2 seconds before switching off for 30 sec-
onds and then flashing at a slower rate.

The Safe lock is re-activated on unlocking
and locking the vehicle again.

If the vehicle is locked and the Safe lock is
deactivated, the vehicle can be opened from
inside by pulling on the door handle.

WARNING

Do not leave people or animals in locked
vehicles with Safe lock activated: the doors
and windows cannot then be opened from
the inside. Doors locked in this manner
could delay assistance in an emergency.
Risk of death!

Note

●

The anti-theft alarm switches on auto-

matically when the vehicle is locked, even
if the Safe lock is deactivated. The Vehicle
interior monitoring, however, is not activa-
ted.

●

Given that the Safe function will be acti-

vated on locking the vehicle,

CHECK DEAD-

LOCK

will be shown on the general instru-

ment panel display. On vehicles equipped
with an informative display,

Caution SAFE!

On-board documentation!

Valid for vehicles with a keyless fuel tank cap.

112

Opening and closing

Central locking button

Fig. 122

Central lock button.

If the vehicle has not been locked from out-
side, it is possible to lock and unlock the
doors from inside by pressing the

›››

Fig. 122

button, even without the key in the ignition.

Locking of all doors, the boot lid and the
fuel tank flap

–

Press the button



›››

Fig. 122

. The warning

lamp



on the button will light up.

Unlocking of all doors, the boot lid and the
fuel tank cap

–

Press the button



›››

Fig. 122

. The warning

lamp



on the button will switch off.

If the vehicle has been locked using the cen-
tral lock button.

●

The rear lid cannot be unlocked from the

outside (security measure, e.g. when stopped
at an intersection).

●

The doors can be unlocked individually by

pulling the handle.

●

The vehicle doors cannot be locked if any

of the doors are open.

●

In the event of an accident in which the air-

bags activate, doors locked from the inside
will be automatically unlocked for easier ac-
cess and assistance.

WARNING

The central locking system remains opera-
tive when the ignition is switched off. Never
leave children unattended in the vehicle, as
doors locked from the inside delay assis-
tance in an emergency. Risk of sustaining
fatal injuries!

Note

The handles and the central lock buttons
will not work if the Safe lock

›››

page 112

activated.

Unlocking and locking the vehicle
with Keyless Access

Fig. 123

Keyless Access locking and ignition

system: nearby areas.

Fig. 124

Locking and ignition system without

Keyless Access: sensor surface

for unlock-

ing inside the door handle and sensor surface

for locking on the exterior of the handle.

Valid for vehicles with a keyless fuel tank cap.

113

Operation

Keyless Access is a key-free locking and igni-
tion system to unlock and lock the vehicle
without actively using its key. For this, all that
is required is to have a valid vehicle key near

›››

Fig. 123

the vehicle and one of the sensor

surfaces on the door handles to be touched

›››

Fig. 124

General information

If a valid key is in the proximity of the car

›››

Fig. 123

, the Keyless Access locking and

starting system gives the key entry as soon as
one of the sensor surfaces on the door han-
dles is touched or the push button on the
boot hatch is operated. The following fea-
tures are then available without having to use
the vehicle key actively:

●

Keyless-Entry: unlocking of the vehicle with

the handles on the four doors or the button
located on the boot hatch.

●

Keyless-Go: engine ignition and driving. For

this to occur, there has to be a valid key inside
the vehicle and the ignition push button
needs to be pressed

›››

page 197

●

Keyless-Exit: unlocking of the vehicle with

one of the four door handle.

The central locking and locking systems op-
erate in the same way as a

normal

locking

and unlocking system. Only the controls
change.

Unlocking the vehicle is confirmed with a

double

flash of the indicator lights; locking by

single

flash.

The vehicle will lock again after a few sec-
onds if you unlock the vehicle but fail to open
any door or boot hatch.

Unlocking and opening the doors (Key-
less-Entry)

●

Grip the door handle. In doing this, the sen-

sor surface

›››

Fig. 124

(arrow) on the han-

dle is touched and the vehicle unlocks.

●

Open the door.

In vehicles without safety system “Safe”:
closing and locking the doors (Keyless-Ex-
it)

●

Switch the ignition off.

●

Close the driver's door.

●

Touch (

once

) the sensor surface

(arrow)

on the door handle. The door that is used
must be closed.

In vehicles with safety system “Safe”:
closing and locking the doors (Keyless-Ex-
it)

●

Switch the ignition off.

●

Close the driver's door.

●

Touch (

once

) the sensor surface

(arrow)

on the door handle. The vehicle locks with the

“Safe” security system

›››

page 112

. The door

that is used must be closed.

●

Touch (

twice

) the sensor surface

(arrow)

on the door handle to lock the vehicle without
the “Safe” security system

›››

page 112

Unlocking and locking the boot hatch

When the vehicle is locked, the hatch auto-
matically unlocks on opening if

›››

Fig. 123

there is a valid vehicle key in the proximity.

Open or close the hatch

normally

›››

page 117

After closing, the hatch locks automatically.
In the following instances, the rear lid does

not

lock automatically after closing:

●

If the entire vehicle is unlocked.

●

If the key used last is inside the vehicle. All

vehicle indicator lights flash

four times

. The

vehicle will lock again after a few seconds if
no door or boot hatch are opened.

Locking the vehicle with a second key

If there is a vehicle key inside the vehicle and
it is locked from the outside with a second ve-
hicle key, the key inside the vehicle is blocked
for engine ignition

›››

page 196

. In order to

enable engine ignition, the



button on the

key inside the vehicle needs to be pressed

›››

page 108

114

Opening and closing

Automatically disabling sensors

If the vehicle is not locked or unlocked for a
long period of time, the proximity sensor on
the passenger door is automatically disa-
bled.

If one of the sensor surfaces on the door han-
dles is often activated in an unusual manner
with the vehicle locked (e.g. by the branches
of a bush rubbing against it), all proximity
sensors are disabled for a time. If this only
happens with the exterior sensor on the driv-
er's door, only this sensor is disabled.

Sensors will again be enabled:

●

After a time.

●

OR:

if the vehicle is unlocked with the but-

ton



on the key.

●

OR:

if the boot is opened.

Keyless Access temporary disconnection
function*

You can deactivate the vehicle's Keyless Ac-
cess unlocking for a locking and unlocking
cycle.

●

Move the gear lever to position

(if the ve-

hicle has automatic gearbox), since other-
wise the vehicle cannot be locked.

●

Close the door.

●

Push the central locking button



on the re-

mote control and touch the locking sensor
surface

›››

Fig. 124

on the driver door han-

dle once within the following 5 seconds. Do
not grab the handle or the vehicle will not
lock. Deactivation is also possible if the vehi-
cle is locked through the driver’s door lock.

●

To check that the function has been deacti-

vated, wait at least 10 seconds, grip and pull
on the door handle. The door should not
open.

The next time the door can only be unlocked
via the remote control or the lock cylinder.
The next time the door is locked/unlocked,
Keyless Access will be active again.

Convenience functions

To close all electric windows, the sliding roof
and electric tilting panoramic roof

with the

convenience feature

, keep your finger on

the lock sensor surface

located on the ex-

terior part of the driver or passenger door
handle for a few seconds until the windows
and roof close.

The

doors opened

by touching the sensor

surface of the door handle depend on the
settings that have been activated in the Easy
Connect system with the



button and the

SETTINGS

and

Opening and closing

function

buttons.

CAUTION

The sensor surfaces on the door handles
could engage if hit with a water jet or high
pressure steam if there is a valid vehicle

key in the proximity. If at least one of the
windows is open and the sensor surface

on one of the handles is activated continu-
ously, all windows will close. If the water jet
or steam is briefly moved away from the
sensor surface

on one of the handles

and then pointed at it again, all the win-
dows will probably open

›››

page 115, Con-

venience functions

Note

●

If the vehicle battery has little or no

charge, or the vehicle key battery is almost
or entirely out of charge, you will probably
not be able to lock or unlock the vehicle
with the Keyless Access system. The vehi-
cle can be unlocked or locked manually

›››



page 11

●

If there is no valid key inside the vehicle

or the system fails to detect one, a warning
will display on the dash panel screen. This
could happen if any other radio frequency
signal interferes with the key signal (e.g.
from a mobile device accessory) or if the
key is covered by another object (e.g. an
aluminium case).

●

If the sensors are very dirty, e.g. have a

layer of salt, the correct functioning of the
sensors on the door handles may be affec-
ted. If this is the case, wash the vehicle

›››

page 265

●

If the vehicle is equipped with an auto-

matic gearbox, it may only be locked in the
gear stick is in position P.

115

Operation

●

To improve the safety of your vehicle, the

remote control of the system is equipped
with a position sensor. If this remote control
does not detect movement for a certain
length of time, the system will conclude
that the vehicle cannot be opened (e.g. on
a night table) so it will be disabled.

Child-proof locking

Fig. 125

Activating the childproof lock.

The childproof lock prevents the rear doors
from being opened from the inside. Doors can
only be opened from the outside.

The childproof lock is activated and deacti-
vated using the ignition key.

Activating the childproof lock

–

Turn the slot in the direction of the arrow

›››

Fig. 125

(in the other direction on the

right-hand door).

Deactivating the childproof lock

–

Turn the slot in the opposite direction of the
arrow (in the other direction on the right-
hand door).

Anti-theft alarm*

General notes

The anti-theft alarm system increases vehicle
protection from intruders. The system will ini-
tiate acoustic and optical warning signals
when your vehicle is tried to be forced.

Activating the alarm system

The anti-theft alarm switches on automati-
cally when the vehicle is locked using the re-
mote control key or inserting the key in the
driver door. The alarm is activated around 30
seconds after the vehicle is locked.

Deactivating the alarm system

The anti-theft alarm system is deactivated
when the remote control unlock button is
pressed. If the vehicle is not opened within 30
seconds after emitting the radio frequency
signal, the system will be reactivated.

If the vehicle is unlocked using by inserting
the key in the driver door, the ignition must be
switched on within 15 seconds. This deacti-

vates the alarm system. If, during these 15
seconds,

the vehicle is not started

the

alarm is triggered

When does the system trigger an alarm?

The following areas of the vehicle are moni-
tored:

●

Bonnet

●

rear lid;

●

Doors

●

Ignition

●

Tilt angle

›››

page 117, Vehicle interior

monitoring and anti-tow system

●

The interior

›››

page 117, Vehicle interior

monitoring and anti-tow system

●

Drop in voltage in the car systems

●

The factory-fitted towing bracket

The alarm is triggered immediately if one of
the battery cables is disconnected while the
alarm system is active.

How to turn OFF the alarm

To deactivate the alarm, press the unlock but-
ton on the remote control key or switch on the
ignition.

Note

●

The alarm horn power supply has a 5-

year useful life. Contact an Official Service
for more detailed information.

116

Opening and closing

●

To make sure that the anti-theft alarm is

fully operative when leaving the vehicle,
check that all the doors and windows are
closed.

●

Remote control and receiver unit coding

means that the remote control cannot be
used on other vehicles.

Vehicle interior monitoring and an-
ti-tow system

The Vehicle interior monitoring system is acti-
vated if movements are detected in the interi-
or of the vehicle.

Switching off the vehicle interior monitor-
ing and tow-away protection*

When the vehicle is locked, the alarm will be
triggered if movements are detected in the in-
terior (e.g. by animals) or if the vehicle's incli-
nation is changed (e.g. during transport). You
can prevent the alarm from being triggered
accidentally by switching off the vehicle inte-
rior monitoring and/or tow-away protection.

●

To switch off the interior monitoring and

tow-away protection, switch off the ignition
and, using the Infotainment system, select: In-
fotainment button





and then the

SET-

TINGS > Opening and closing > Cen-
tral locking > Vehicle interior mon-
itoring

button.

●

When the vehicle is locked now, the vehicle

interior monitoring and the tow-away protec-
tion are switched off until the next time the
door is opened.

If the anti-theft security system (Safe)*

›››

page 112

is switched off, the vehicle interi-

or monitoring and the tow-away protection
are automatically switched off.

WARNING

Observe the safety warnings

›››

in Gen-

eral notes on page 111

Note

●

The vehicle interior monitoring system

and the tow-away protection system must
be deactivated if there is a danger of the
alarm being triggered due to movements
by children or animals in the interior when
being transported (e.g. by boat or by train)
or towed.

●

The effectiveness of the Vehicle interior

monitoring system is reduced if the specta-
cle case is left open. Always close the stor-
age compartment before locking the vehi-
cle to ensure that this monitoring system
operates correctly.

Rear lid

Opening and closing

Fig. 126

Rear lid: opening from the outside.

Fig. 127

Close-up of the inside trim of the rear

lid: space for pulling.

Read the additional information carefully

›››



page 12

117

Operation

The rear lid opening system operates electri-
cally. It is activated by using the handle on
the boot lid.

This system may or may not be operative, de-
pending on the situation of the vehicle.

If the rear lid is locked then it cannot be
opened, however if it is unlocked then the
opening system is operative and the rear lid
may be opened.

To lock/unlock, press the



button or the



button on the remote control key.

A warning appears on the instrument panel
display if the boot lid is open or not properly
closed.* An audible warning is also given if
the boot lid is opened while the vehicle is
moving faster than 6 km/h (4 mph)*.

WARNING

●

Always close the rear lid properly. Risk of

accident or injury.

●

Do not close the rear lid by pushing it

down with your hand on the rear window.
The glass could smash. Risk of injury!

●

Ensure the rear lid is locked after closing

it. If not, it may open unexpectedly while
driving.

●

Never allow children to play in or around

the vehicle. A locked vehicle can be subjec-
ted to extremely high and low tempera-
tures, depending on the time of year, thus
causing serious injuries/illness. It could
even have fatal consequences. Close and

lock both the rear lid and all the other
doors when you are not using the vehicle.

●

Closing the rear lid without observing

and ensuring it is clear could cause serious
injury to you and to third parties. Make sure
that no one is in the path of the rear lid.

●

Never drive with the rear lid open or half-

closed, exhaust gases may penetrate into
the interior of the vehicle. Danger of poi-
soning!

●

If you only open the rear lid, do not leave

the key inside. The vehicle will not be
opened if the key is left inside.

Note

●

Once the rear lid is closed, its lock is en-

gaged and the alarm system is activated.
Only valid if the vehicle has been locked
before the rear lid is closed.

●

The release catch located at the top of

the registration plate recess is deactivated
on accelerating or at speeds of over 5
km/h (3 mph). The catch is reactivated
when the vehicle comes to a standstill and
a door is opened.

Rear lid automatic locking

Where the vehicle has been locked by press-
ing the



button on the remote control with

the rear lid open, the rear lid will lock auto-
matically when closed.

The automatic rear lid locking time extension
function can be activated. When this function
is activated and once the rear lid has been
unlocked by pressing the



button on the

remote control key

›››

page 108

, the boot lid

can be re-opened for a certain length of time.

Where required, the automatic boot lid lock-
ing time extension function can be activated
or deactivated at a SEAT Authorised Service,
which will provide all of the necessary infor-
mation.

Before the vehicle locks automatically, there
is a risk of intruders getting into the vehicle.
Therefore, we recommend you always lock
the vehicle by pressing the



button on the

remote control or by using the key without re-
mote control

›››

page 112

118

Opening and closing

Controls for the windows

Operation of the electric windows

Fig. 128

Detail of the driver door: controls for

the windows.

Read the additional information carefully

›››



page 14

The electric window opening and closing
system only works when the ignition is switch-
ed on.

Opening

–

Press gently on the respective button on
the door to open the window. The process
will stop when the button is released.

–

The driver door window can also be auto-
matically opened by pressing the button as
far as it will go (fully open). Press the button
again to immediately stop it.

Closing

–

Press the respective button gently to close
the window. The process will stop when the
button is released.

Safety button



Press the safety button

›››

Fig. 128

to de-

activate the controls on the rear doors. Press-
ing the safety button

again will reactivate

the controls on the rear doors.

If the rear door controls are deactivated, the
warning lamp



on the safety button

will

light up.

WARNING

●

When locking the vehicle from the out-

side, make sure that nobody is inside the
vehicle, as the windows cannot be opened
from the inside in an emergency.

●

For safety reasons, use the safety button

that deactivates the window switches

on the rear doors when children are travel-
ling in the rear seats.

CAUTION

●

Keep the windows clean to ensure the

system operates correctly.

●

Defrost

›››

page 269

any frozen windows

before using the electric windows. Other-
wise you run the risk of damaging the elec-
tric window riser mechanism.

●

Always make sure all of the windows are

closed on leaving the locked vehicle.

Note

●

The vehicle heating and ventilation sys-

tem should be used to ventilate the interior
while driving. Leaving the windows open
could allow dust and other dirt to enter the
vehicle and cause unpleasant noises at
certain speeds.

●

Do not leave the side windows open at

high speeds, as this will overly increase
fuel consumption.

Note

The electric window opening mechanism is
equipped with a thermostat switch. This
may overheat if the window is opened and
closed repeatedly. This causes the window
to lock temporarily. Once the thermostat
switch has cooled down, the window can
be operated once again.

Roll-back function on the electric
windows

The electric windows are equipped with a
roll-back system that reduces risk of injury
when closing windows.

119

Operation

If an obstacle is present, the closing mecha-
nism will stop and the window will roll back a
few centimetres.

If an obstacle prevents closing for the next 10
seconds, the closing mechanism will once
again stop and the window will roll back an-
other few centimetres.

If in the next 10 seconds you attempt to close
the window after it has rolled back the sec-
ond time, only the closing mechanism will be
stopped even if the obstacle is still present.
The roll-back function is still connected.

The roll-back function will only be disconnec-
ted if you once again attempt to close the
window in the following 10 seconds.

In this

case, the window will close at full force

If you wait for a further 10 seconds, the roll-
back function will be once again connected.

Lights and visibility

Lights

Introduction

Read the additional information carefully

›››



page 21

The location of the controls of

right-hand

drive

cars differs slightly from the location

shown here

›››

Fig. 129

›››

page 121

. Howev-

er, the symbols indicating the respective po-
sitions of the controls remain the same.

WARNING

Never drive with only the side lights on! The
side lights are not bright enough to illumi-
nate the road ahead and to ensure that
other road users are able to see you. Al-
ways use your dipped beam headlights if it
is dark or if visibility is poor.

CAUTION

●

Use the lights in line with local law.

●

However, drivers always remain responsi-

ble for correctly adjusting and using the
lights.

Note

●

An audible warning will be heard when

the light control is set to



and you remove

the ignition key and open the door. Once
the driver door is closed (ignition off), the
audible warning will stop, whereas the side
lights will remain on to light up the station-
ary vehicle in case this is necessary.

●

Depending on weather conditions (cold

or wet), the lights may mist up temporarily
on the inside. This is particularly the case in
the event of a difference in temperature
between the inside and in front of the light.
By switching on the lights, the area through
which the beam of light is projected will
quickly be demisted, although the edges
may remain misted. The real lights and turn
signals can mist up. This has no influence
on the useful life of the lighting system.

Control lamps



It lights up

Rear fog light switched on

›››

page 124



It lights up

Front fog lights* switched on

›››

page 124



It lights up

Left or right turn signal.
The control lamp flashes twice as fast when a turn

signal is faulty

›››

page 122

120

Lights and visibility



It lights up

Main beam on or flasher on

›››

page 122



It lights up

Bulb failure

›››

page 86

For example, the information display indicates:

Check front right dipped headlight!

Several warning and control lamps light up
for a few seconds when the ignition is switch-
ed on, signalling that the function is being
verified. They will switch off after a few sec-
onds.

WARNING

Observe the safety warnings

›››

in Con-

trol and warning lamps on page 103

Note

The rear side lights and number plate light
contain several bulbs. The control lamp



lights up only when there is a fault in all the
number plate bulbs or side light bulbs (of a
combined tail light). Therefore it is advisa-
ble to regularly check the bulb operation.

Side light and dipped beam head-
light

Fig. 129

Instrument panel: light panel.

Switching the side lights on

–

Turn the light switch

›››

Fig. 129

to position



Switching on dipped beam

–

Turn the light switch

›››

Fig. 129

to position



Switching off lights (except daytime driv-
ing lights)

–

Turn the light switch

›››

Fig. 129

to position

Headlight range control



Fig. 130

Instrument panel: light range control.

–

Turn the control

›››

Fig. 130

to set the lights

to the required setting.

Positions

The control positions roughly correspond to
the following vehicle load conditions.

Two front occupants, luggage compart-
ment empty.
All seats occupied, luggage compart-
ment empty.
All seats occupied, luggage compart-
ment fully loaded.
Driver only, luggage compartment fully
loaded.

CAUTION

Always adjust the range of the lights so
that:

121

Operation

●

your vehicle does not dazzle others, par-

ticularly oncoming traffic;

●

the range of the headlights is sufficient

for safe driving.

Note

Make sure you set the range of the main
lights when the dipped beam headlights
are switched on.

Daytime running lights

Daytime running lights are signalling devices
for improving road safety. The lights are built
into the headlights and come on each time
the ignition is turned on if the light switch is in
position





›››

Fig. 129

. It is automatical-

ly switched off when the side lights are turned
on.

Switching the daytime driving lights on

●

Remove the key from the ignition, move the

turn signal lever upward (right turn signal),
press it back to flash position and hold it
there.

●

Insert the key and switch on the ignition,

holding it in this position for 3 seconds. Then,
switch off the ignition. The daytime running
light is now activated and the corresponding
lights can come on.

Switching the daytime running light off

●

Remove the key from the ignition, press the

turn signal lever down (left turn signal), press
it back to flash position and hold it here.

●

Insert the key and switch on the ignition,

holding it in this position for 3 seconds. Then,
switch off the ignition. The daytime running
light is now deactivated and the correspond-
ing lights cannot come on.

OR:

activate and deactivate the daytime

lights using the Easy Connect system

›››



page 24

Automatic control of the dipped beam in
combination with the daytime running
lights

If the

dipped beam control

and the

daytime

running lights

are activated at the same time,

the dipped beams and the instrument panel
lighting will automatically come on as re-
quired (e.g. when entering a tunnel) and the
daytime running lights will switch off. When
the automatic dipped beam control switches
off the dipped beams (e.g. when coming out
of a tunnel), the daytime running lights come
back on.

WARNING

On vehicles with rear lights with bulbs,
when activating the daytime running light
the rear lights are not switched on. A vehi-
cle which does not have the rear lights on

may not be visible to other drivers in the
darkness, in the case of heavy rain or in
conditions of poor visibility.

Note

Please observe any relevant legal require-
ments which may apply in your country.

Turn signal and main beam head-
lights lever

Fig. 131

Turn signal and main beam lever.

The turn signal and main beam lever also op-
erates the parking lights and the headlight
flasher.

Right and left-hand



turn signal



●

Move the lever

›››

Fig. 131

or down

●

Keep the lever held down at the point of re-

sistance for the turn signals to flash for as

122

Seat Toledo (2019 year). Manual in english - page 7
