FUEL TANK (2/3)

Filling with fuel

Special case

With the ignition off, insert the nozzle to

When the vehicle has been stopped for

open valve 2 and insert it fully before

around three months, you must add

1

turning it on to fill the tank (risk of

fuel to prevent damage to the fuel

splashing).

pump.

2

Keep the nozzle in this position through-

To do this, with the ignition off, top-up

out the entire filling operation.

at least 1.10 gallons (5 litres) then start

When the pump cuts out automatically

the engine to operate the pump and

at the end of the filling procedure, a

renew the fuel in the circuit.

maximum of two further filling attempts

If it is not possible to add at least

may be made, as there must be suffi-

1.10 gallons (5 litres) of fuel due to the

cient space in the fuel tank to allow for

fuel level in the tank, drive the vehicle

expansion.

until the tank has capacity.

Make sure that no water enters the fuel

tank during filling. The cover 1 and its

It is essential to use unleaded petrol.

surround must remain clean.

The octane rating (RON) must comply

with the information given on the label

on the cover 1 ➥ 6.6.

To fill up with fuel, the engine

After locking the vehicle, if the flap 1

must be stopped (and not

is still open, you can close it but it

only on standby in the case

will not be locked.

of vehicles equipped with

To lock the flap 1, unlock the vehicle

the Stop and Start function): you

then lock it again.

must switch off the ignition ➥ 2.3.

1.120

FUEL TANK (3/3)

Using leaded petrol will damage the

antipollution system and may lead to a

loss of warranty.

To ensure that the fuel tank is not filled

with leaded petrol, the fuel tank filler

neck contains a restrictor fitted with a

foolproof system which only allows

the nozzle for unleaded petrol to be

used (at the pump).

Persistent fuel odour

If you notice a persistent

fuel odour you should:

- stop the vehicle as soon as traf-

fic conditions allow and switch off

No modifications what-

the ignition;

soever are permitted on

- switch on the hazard warning

any part of the fuel supply

lights and ask your passengers to

system (electronic units,

leave the vehicle and stay clear

wiring, fuel circuit, injectors, pro-

of the traffic;

tective covers, etc.) as this may be

- contact an approved Dealer.

dangerous (unless undertaken by

qualified Network personnel).

Fuel types that conform to European

standards with which the engines of

vehicles sold in Europe are compat-

ible: refer to the table ➥ 6.6.

1.121

STARTING, STOPPING THE ENGINE (1/4)

Special features

- If one of the conditions required

for starting is not met, the mes-

sage “Press brake pedal + START”

2

or “Press Clutch + START” or “Set

gearbox to P” will appear on the in-

strument panel;

- in some cases, it will be necessary

to move the steering wheel whilst

1

pressing the start button 2 to help

unlock the steering column; the

message “Turn Steering Wheel +

START” will warn you of this;

Starting

- on vehicles with a manual gearbox,

press the brake pedal and press

The card must be inserted in detection

the 2 button, then release the brake

zone 1.

pedal once the engine has started.

To start:

If a gear is engaged, also press the

- on vehicles equipped with an auto-

clutch pedal.

matic gearbox: in P position, press

the brake pedal, then press the

Depending on the vehicle, you may

button 2 and release the brake pedal

have a digital key that offers all the

once the engine starts. On E-Tech

functions of the card. However, if a

full hybrid vehicles, the READY mes-

card has been left inside the vehi-

sage illuminates on the instrument

cle and the doors have been locked

panel along with a sound signal. The

with a digital key, all of the card’s

message disappears when the vehi-

Before carrying out any op-

functions will be inhibited.

cle speed is above approximately

eration in the engine com-

3 mph (5 km/h);

For further information, please refer

partment, you must switch

to the “Digital key” section ➥ 1.21.

off the ignition.

2.3

STARTING, STOPPING THE ENGINE (2/4)

Starting (continued)

Note:

-

on vehicles equipped with a manual

gearbox, in the event of engine stall-

2

ing the “Press Clutch” message

will be displayed on the instrument

panel. Fully press the clutch pedal to

restart the engine;

3

4

-

on E-Tech full hybrid vehicles: the

engine unit will switch off automati-

cally after approximately 15 minutes

if the vehicle has remained station-

ary and the driver’s seat belt has not

been fastened. If necessary, you can

restart the engine by pressing

“Hands-free” starting with

The message “Place card on zone +

the 2 button once.

START” appears on the instrument

the tailgate open

panel.

In this case, the card should not be lo-

Press the brake or clutch pedal, then

cated in the luggage compartment, to

place the card 4 (button side) on the

prevent the risk of loss.

placement area 3. Press the 2 button

to start the vehicle. The message goes

Accessories function

out.

(switching on the ignition)

During a system update via the mul-

timedia system it will not be possible

Once you have gained access to your

to start the vehicle.

vehicle, you may use some of its func-

tions (radio, navigation, wipers, etc.).

Wait for the update to be completed

before starting the vehicle.

To use the other functions, with the

card in the passenger compartment,

For more information on system up-

press the 2 button without pressing the

dates, please refer to the multime-

pedals.

dia instructions.

2.4

STARTING, STOPPING THE ENGINE (3/4)

Operating faults

If the card is no longer in the passenger

compartment when you try to switch the

In certain cases, the hands-free card

engine off, the message: Card miss-

may not work:

ing: press and hold START appears on

- card battery flat, etc.;

the instrument panel: press button 2

2

for at least two seconds. If the card is

- near to appliances operating on the

no longer in the passenger compart-

same frequency as the card (mon-

ment, make sure you can retrieve it

itor, mobile phone, video game,

before pressing and holding the button.

phone charger, etc.);

Without the card, you will not be able

- vehicle located in a high electromag-

to start.

netic radiation zone.

With the engine switched off, any ac-

cessories being used (radio, etc.) will

continue to function for approximately

10 minutes.

When the driver’s door is opened, the

Conditions for stopping the

accessories stop working.

engine

The vehicle must be stationary, lever

in position P on vehicles with an auto-

matic gearbox. On E-Tech full hybrid

vehicles, the READY message is dis-

played on the instrument panel.

With the card in the vehicle, press

button 2: the engine stops. On E-Tech

full hybrid vehicles, the READY mes-

sage disappears from the instrument

panel.

The steering column is locked when a

door is opened or the vehicle is locked.

2.5

STARTING, STOPPING THE ENGINE (4/4)

Special case of E-Tech full

When you leave your vehi-

hybrid vehicles

cle, especially if you have

With the vehicle stationary in electric

your card with you, check

operating mode, the message “ACTIVE

that the engine is com-

ENGINE SWITCH OFF” appears on

pletely switched off.

the instrument panel accompanied by

a beep if:

- the driver’s seatbelt is not fastened;

Driver’s responsibility

when parking or stopping

- the bonnet is open;

the vehicle

- the driver’s door is open.

Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors, for example.

Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

Never switch off the igni-

RISK OF DEATH OR SERIOUS

tion before the vehicle has

INJURY.

stopped completely. Once

the engine has stopped, the

brake servo, power-assisted steer-

ing etc., and the passive safety de-

vices such as the airbags and pre-

tensioners will no longer operate.

2.6

FUNCTION STOP AND START (4/4)

Special feature of the automatic

Operating faults

engine re-start

When the “Check Stop & Start” mes-

Under certain conditions, the engine

sage appears on the instrument panel

can restart on its own in order to guar-

and the 1 switch is on, this indicates

antee your safety and comfort.

that the system is deactivated.

This can occur especially when:

Please consult an authorised dealer.

- the outdoor temperature is too low or

too high;

1

- the “Clear view” function is activated

➥ 3.7 ;

- the battery is not sufficiently charged;

- the vehicle speed is above 3 mph

(5 km/h) (downhill slope, etc.);

- repeated pressing on the brake

Deactivating, activating the

pedal or braking system require-

ment;

function

- ...

Press 1 to deactivate the function. The

message “Stop & Start deactivated” ap-

The

 warning light is displayed on

pears on the instrument panel and the

the instrument panel to notify you of au-

ignition warning light 1 appears.

tomatic engine restarting.

Pressing again will reactivate the

system. The message “Stop & Start

Activated” appears on the instrument

panel and the 1 switch disappears.

The system is automatically reactivated

each time the vehicle is started using

The engine MUST be

the start button. ➥ 2.3.

stopped (not put in standby)

before leaving the vehicle.

Special note: engine on standby,

➥ 2.3.

press switch 1 to automatically re-

start the engine.

2.10

AUTOMATIC TRANSMISSION (1/6)

1

2

Electronic selector lever 1

One-touch selector

R: reverse

Move the selector lever 1 one or two

notches upwards or downwards to

N: neutral

engage the desired position (R, N or D)

D: automatic mode

then release the lever and it will return

P : park, button 2

to the stable position.

The gear engaged is displayed on the

The position engaged lights up on the

instrument panel.

instrument panel.

If certain conditions prevent shifting

from one position to another, the cur-

rent position flashes on the instrument

panel.

2.13

AUTOMATIC TRANSMISSION (2/6)

To disengage position P

To engage neutral

With the vehicle stationary and the

With the vehicle stationary and the

engine running, press the brake pedal

engine running, to engage the N po-

2

and move the 1 selector lever upwards

sition, it is necessary to depress the

or downwards according to the position

brake pedal before moving the selec-

desired.

tor lever 1 one notch upwards or down-

wards.

If the brake pedal is not fully depressed,

the message “Press brake pedal” and

warning light are displayed

the

Ó

on the instrument panel.

To engage position P

With the vehicle at a standstill, engine

running or ignition on, press button 2 to

engage position P.

Check that the P warn-

ing light on the instrument

panel is activated before

leaving the vehicle.

Risk of loss of immobilisation of

the vehicle.

2.14

AUTOMATIC TRANSMISSION (4/6)

Driving in manual mode

(vehicles equipped with gear shift pad-

dles)

When driving in D position you can

switch to manual driving mode using

3

4

the 3 and 4 paddles on the steering

5

wheel. Depending on the vehicle, two

manual driving modes are available:

- the “temporary” manual mode

can be used to force gear shifting by

briefly pressing one of the two pad-

dles. the driving mode D and the

gear engaged appear on the instru-

ment panel.

Note: the gearbox adjusts itself to

Gear changing paddles 3

Note: depending on the vehicle, the

automatic mode D if the gear en-

return to automatic mode is carried

and 4

gaged is no longer optimal to vehi-

out by pressing and holding the right-

(except the E-Tech full hybrid version)

cle performance or if no action has

hand paddle or by moving the one-

been taken on a paddle for a certain

Depending on the vehicle, you can use

touch lever 1 one or two notches

amount of time.

paddles 3 and 4 to change gear when

downwards.

the lever is in position D.

- permanent manual mode is ac-

In all situations:

tivated by pressing and holding

3: change to a lower gear (-).

- to move down through the gears,

either of the paddles. Driving mode

4: change to a higher gear (+).

press the left-hand paddle;

M and the gear engaged will appear

P, N and R are not accessible using the

- to move up through the gears, press

on the 5 display on the instrument

paddles.

the right-hand paddle.

panel.

Note: the + and - indicators advise the

driver to shift to a higher or lower gear.

2.16

E-TECH FULL HYBRID VEHICLE SYSTEM: regenerative braking system (1/2)

1

2

3

Regenerative braking change

By releasing the accelerator, the vehi-

cle uses regenerative braking to slow

paddles 1 and 2

down the vehicle.

You can use paddles 1 and 2 to change

Some of this energy is converted to

the regenerative braking level when the

electricity to recharge the traction bat-

lever is in D position.

tery.

1:

Increasing regenerative brak-

ing (-).

2: Decreasing regenerative braking

(+).

The paddles can only be operated in

the D position.

The engine brake should

under no circumstances be

used as a substitute for the

brake pedal.

2.19

E-TECH FULL HYBRID VEHICLE SYSTEM: regenerative braking system (2/2)

If the traction battery is no longer able

to absorb energy (e.g. fully charged or

A

cold battery), the conventional braking

system replaces the regenerative brak-

ing system while maintaining its func-

tions.

B

However, the pedal may appear more

depressed and feel firmer. This is

normal.

C

To limit this effect, use the regenerative

braking levels A and B.

D

Regenerative braking levels

The 3 warning light informs you of the

regenerative braking level:

- A: “Free-wheel” level, for gentle,

economical driving. Requires driving

with anticipation;

- B: low regenerative braking level;

- C: average regenerative braking

level;

- D: maximum regenerative braking

level.

2.20

GEARSTICK

1

Gear lever

Vehicles with manual gearbox: refer

to the grid on the gear lever knob 1.

Vehicles with an automatic gearbox:

➥ 2.13.

An impact to the under-

side of the vehicle while

Selecting reverse gear

manoeuvring (e.g.: strik-

ing a post, raised kerb or

The reversing lights will come on as

other street furniture) may result in

soon as reverse gear is selected with

damage to the vehicle (e.g.: defor-

the ignition on.

mation of an axle).

To avoid any risk of accident, have

your vehicle checked by an ap-

proved Dealer.

2.21

ELECTRONIC PARKING BRAKE (1/4)

In all other instances, for example the

engine has stalled or is in standby

due to the Stop and Start ➥ 2.7,

1

the assisted parking brake is not ap-

plied automatically. Manual mode must

be used. For certain country-specific

model versions, the assisted brake ap-

2

plication function is not activated. Refer

to the information on “Manual opera-

tion”.

To confirm that the electronic park-

ing brake is applied, the

}

warn-

3

ing light on the instrument panel and 2

warning light on the switch 3 light up.

After the engine is switched off, indi-

Assisted operation

or

cator light 2 goes out several minutes

- when the driver’s door is opened;

after the electronic parking brake has

Applying the electronic parking

or

brake

- for vehicles fitted with an automatic

been applied and indicator light

}

gearbox, when position P is en-

With the vehicle stationary, the elec-

goes out when the vehicle is locked.

gaged.

tronic parking brake can be used to im-

mobilise the vehicle:

- by pressing the engine start/stop

button 1;

or

- when the driver’s seat belt is un-

fastened;

The electronic parking brake can be used to immobilise the vehicle. Before leaving the vehicle, check that the elec-

tronic parking brake is fully applied. Warning light 2 on switch 3 and warning light

} on the instrument panel light

up to show that the parking brake is applied but go out when the doors are locked. Depending on the vehicle, a sticker

is located on the upper section of the windscreen to remind you of this.

2.22

ELECTRONIC PARKING BRAKE (2/4)

Assisted operation

(continued)

Note: in some situations (electronic

parking brake failure, manual release of

the parking brake, etc.), a beep sounds

and the message “WARNING: Apply

Parking Brake” appears on the instru-

2

ment panel to warn you that the elec-

tronic parking brake has been released.

- with the engine running: when the

driver’s door is opened;

- with the engine switched off (e.g.

when the engine stalls): when a front

3

door is opened.

In this case, pull and release switch 3 to

apply the electronic parking brake.

Manual operation

The electronic parking

Assisted release of the parking

You can apply the electronic parking

brake can be used to im-

brake

brake manually.

mobilise the vehicle. Before

The parking brake is released:

leaving the vehicle, check

Manually applying the electronic

- once the vehicle starts to accelerate;

that the electronic parking brake

or

parking brake

is fully applied. Warning light 2 on

- when shifting from P position on ve-

Pull switch 3. Warning light 2 and warn-

hicles equipped with an automatic

switch 3 and warning light

}

ing light

} on the instrument panel

gearbox.

on the instrument panel light up to

light up.

show that the parking brake is ap-

plied but go out when the doors are

locked.

Depending on the vehicle, a sticker

is located on the upper section of

the windscreen to remind you of

this.

2.23

ELECTRONIC PARKING BRAKE (3/4)

To park the vehicle without applying the

electronic parking brake (if there is a

risk of freezing, for example):

1

-

engage position P: the drive wheels

will be mechanically locked by the

driveshaft;

2

-

stop the engine by pressing the

engine Start/Stop button 1;

-

release the driver’s seat belt;

–

open the driver’s door;

–

manually release the electronic park-

3

ing brake (please see the informa-

tion on “Manually releasing the elec-

tronic parking brake” on the previous

Manually releasing the electronic

Brief stop

page);

parking brake

To apply the electronic parking brake

-

depending on the vehicle, the park-

Press switch 1 without pressing the

manually (when stopping at a red light,

ing brake is applied automatically.

pedals to switch the ignition on. Press

or stopping when the engine is running,

You will have to release it manually.

the brake pedal then press switch 3: in-

etc.): pull and release the switch 3. The

dicator light 2 on the switch and indica-

brake is released as soon as the vehi-

cle is started up again.

tor light

} displayed on the instru-

ment panel go out.

Special cases

To park on a slope or while towing a

trailer, for example, pull switch 3 for

a few seconds to gain the maximum

braking.

2.24

“AUTOHOLD” FUNCTION (1/2)

Vehicle stopped (e.g. at a red light, an

intersection, a traffic jam, etc.), the func-

tion ensures braking force even when

the driver releases the brake pedal.

The braking force is released as soon

as the driver accelerates sufficiently

with a gear engaged.

1

Activation

Press the switch 1.

2

The switch warning light 1 illuminates

to confirm that the function is activated.

Upon each start-up, the function

Deactivation

If the braking force is maintained, the

continues the mode set at the time

Press the 1 switch, if your vehicle is

parking brake is applied automatically

the engine was last switched off.

maintained by braking force, also press

when:

the brake pedal.

- the driver opens the door;

The electronic parking

The switch warning light 1 turns off,

brake can be used to im-

or

confirming that the function is deacti-

mobilise the vehicle. Before

vated.

- the driver unbuckles their seat belt;

leaving the vehicle, check

that the electronic parking brake is

or

fully applied. The indicator light on

- the vehicle is immobilised for more

than approximately three minutes.

switch 2 and the warning light

}

on the instrument panel illuminate to

show that the parking brake is ap-

plied and switch off when the doors

are locked. Depending on the vehi-

cle, a sticker is located on the upper

section of the windscreen to remind

you of this.

2.26

DRIVING ADVICE, ECO DRIVING (2/7)

2

3

1

On the instrument panel

Gear change indicator 2

Driving style indicator 3

Informs you about the driving style

Depending on the vehicle, to obtain op-

Depending on the vehicle, you can cus-

adopted in real time.

timum consumption levels, a warning

tomise the instrument panel with differ-

You can display the driving style indica-

ent types of information.

light on the instrument panel lets you

tor by repeatedly pressing up/down on

know the best time to move up or down

the switch 1.

a gear:

The larger the 3 indicator circle is, the

better the management of speed, ac-

 upshift a gear;

celeration and anticipation.

 downshift a gear.

The smaller the 3 indicator circle is, the

worse the management of speed, ac-

If you regularly monitor this indicator

celeration and anticipation.

you will be able to reduce your vehicle’s

If you regularly monitor this indicator

fuel consumption.

you will be able to reduce your vehicle’s

fuel consumption.

2.30

DRIVING ADVICE, ECO DRIVING (3/7)

4

“Free wheel” mode

Depending on the vehicle, for vehicles

fitted with an automatic gearbox, in the

deceleration phases (with the foot fully

off the accelerator pedal), switching to

freewheeling (automatic neutral) de-

creases engine braking and allows you

to farther without accelerating in order

to save fuel.

The



warning light appears in

5

grey, then in green to indicate that the

vehicle is in “free-wheel” mode.

Note: pressing the brake pedal once

deactivates “free-wheel” mode.

On the multimedia screen

Journey record

When the engine is switched off, a no-

tification appears on the multimedia

screen 4 to provide information on your

driving during your last trip.

This notification provides direct access

to the “ECO driving” menu. This menu

provides more information on your driv-

ing and its effect on your fuel consump-

tion.

Please refer to the multimedia instruc-

When driving downhill, the “Free

tions for further information.

wheel” function is deactivated in

order to use the regenerative brak-

ing system and/or the engine brake,

depending on the vehicle.

2.31

DRIVING ADVICE, ECO DRIVING (4/7)

ECO mode

ECO mode is a function which opti-

mises fuel consumption. It affects the

vehicle behaviour (acceleration, gear

shifting, cruise control, deceleration,

etc.).

Limiting acceleration enables low fuel

consumption in urban and surrounding

areas.

6

5

Activating the function

To do this, press the accelerator pedal

firmly and fully.

You can access ECO mode:

ECO mode is reactivated when you

- from the multimedia screen 4;

take pressure off the accelerator pedal.

- using the steering wheel control 5.

Deactivating the function

The “ECO” indicator light 6 is displayed

on the instrument panel to confirm that

Please see the multimedia system user

it is activated.

manual for information on how to deac-

tivate ECO mode.

2.32

DRIVING ADVICE, ECO DRIVING (5/7)

Optimum use zone 7

B

Indicates nil consumption.

C

“Recommended consumption” B

green usage zone

In all-electric or E-Tech full hybrid

7

mode, the traction battery and/or the

combustion engine supply the energy

A

required to move the vehicle. This is

the ECO zone.

“Consumption not recommended” C

white usage zone

Indicates high energy consumption.

Power meter

Navigation system

Driving advice and ECO

(E-Tech full hybrid version)

driving

Use the information available on your

The power meter gives the driver a re-

navigation system (traffic information

Behaviour

al-time view of the vehicle’s electrical

etc.) to simplify your journey.

consumption.

- Drive carefully for the first few miles

until the engine reaches its normal

“Energy recovery” usage zone A

operating temperature, rather than

When driving, if you lift your foot off the

let it warm up while the vehicle is sta-

accelerator pedal or apply the brake,

tionary.

the motor generates electrical current

during deceleration, and this energy is

used to slow down the vehicle and re-

charge the traction battery. ➥ 2.19.

2.33

DRIVING ADVICE, ECO DRIVING (7/7)

- On vehicles equipped with non-au-

tomatic air conditioning, switch off

the air conditioning when it is not re-

quired.

Advice for reducing consumption

and therefore helping to preserve

the environment:

If the vehicle has been parked in the

sun, open the doors for a few moments

to let the hot air escape before starting

the engine.

- Do not leave an empty roof rack

fitted to the vehicle.

- It is better to fit a trailer for bulky ob-

jects.

Tyres

Advice on use

- When towing a caravan, fit a wind

– An underinflated tyre increases fuel

- Opt for ECO mode.

deflector and adjust it carefully.

consumption.

- Electricity is fuel; switch off all the

- Avoid using the car for door-to-door

- To optimise fuel consumption, set the

electrical components which are

calls (short journeys with long waits

highest speed tyre pressure or the

not really needed. However (safety

in between) because the engine

recommended pressure indicated on

first), keep your lights on when the

never reaches its normal operating

the edge of the driver’s door. ➥ 4.13.

visibility is bad (“see and be seen”).

temperature.

– The use of non-recommended tyres

- Use the air vents. Driving with the

can increase fuel consumption.

windows open at 60 mph (100 km/h)

will increase fuel consumption by

4%.

- Never fill the fuel tank right to the

brim to avoid overflow.

2.35

ECO PREDICTIVE DRIVING ASSISTANT (1/2)

Depending on the vehicle, using sub-

scription-based maps this function

Driving assistance

allows you to adopt a more economical

Predictive ECO driving assistant*

driving style.

Following distance

When approaching a driving situation

Blind spot warning

(roundabout, speed limit, etc.) the func-

Driver monitoring alert

tion informs the driver, via an indicator

Lane keeping system

displayed on the instrument panel, at

Speed management

which moment to release the acceler-

Advanced safety

ator pedal.

If the driver takes this action it enables

the vehicle to stop accelerating and to

*Renew your subscription to the connected ser-

limit the use of the brakes.

vices in the MY Renault application in order to

fully benefit from these assistance features

This enables a reduction in fuel con-

sumption and wear of the brake pads

and tyres.

Activation/deactivation

From the “Vehicle” mode, select

the “Driving assistance” menu, then

“Predictive ECO driving assistant”.

The predictive ECO driving assis-

tant service is subscription-based.

To manage the subscription,

please refer to the multimedia in-

structions.

2.37

ECO PREDICTIVE DRIVING ASSISTANT (2/2)

Operating principle

The function is not able to

When a driving situation is about to

detect the following:

occur, the 1 and 2 indicators are dis-

- slopes (uphill or downhill);

played on the instrument panel.

1

- intersections without a “Stop” sign or

The 2 indicator prompts the driver to re-

“Give way” sign;

lease the accelerator pedal.

- traffic jams.

The 1 indicator shows the imminent

driving situation.

When the driver releases the acceler-

ator pedal, the 2 indicator disappears

2

from the instrument panel. The 1 indi-

cator remains displayed on the instru-

ment panel until the situation occurs.

If the driver does not adjust their speed,

the 1 and 2 indicators remain displayed

Driving situations

on the instrument panel until the situa-

The following driving situations are de-

tion occurs.

tected:



road bend;



speed limit;



roundabout;



toll;



intersection with a “Stop” sign

or “Give way” sign.

2.38

TYRE PRESSURE LOSS WARNING (1/5)

1

2

1

When fitted to the vehicle, this system

Operating principle

notifies the driver if one or more tyres

This system detects a loss of pressure

lose pressure.

in one of the tyres by measuring the

The system can be identified by the 1

wheel speed while driving.

label in the vehicle.

In the event of insufficient tyre pressure

(deflation, puncture etc.), the 2



warning light is continuously displayed

to warn the driver.

2.39

TYRE PRESSURE LOSS WARNING (3/5)

3

Resetting procedure via the

multimedia screen 3

The resetting procedure must be car-

ried out while the vehicle is stationary

and the ignition is switched on. Please

refer to the multimedia instructions for

further information.

For your safety, the warning

light

®

requires you

to stop immediately as soon

as traffic conditions allow.

2.41

TYRE PRESSURE LOSS WARNING (4/5)

Readjustment of tyre

After each change of wheel/tyre, read-

just the tyre pressure and launch the

pressures

reset of the tyre pressure reference

The pressure of the four tyres must

value.

be set when cold (refer to the label lo-

4

cated on the edge of the driver’s door).

Emergency spare wheel

If tyre pressures cannot be checked

when the tyres are cold, the recom-

If fitted on the vehicle, readjust the tyre

mended pressures should be increased

pressure and launch the reinitialisation

by 0.2 to 0.3 bar (3 PSI).

of the tyre pressure reference value.

Never deflate a hot tyre.

After each reinflation or readjustment of

Tyre repair product and

the tyre pressure, launch the reinitiali-

inflation kit

sation of the tyre pressure reference

value.

Only use equipment approved by the

Network, otherwise the system may be

activated with a delay or operate incor-

Tyre pressure faults

Replacing wheels/tyres

rectly. ➥ 5.5. After using the tyre infla-

The table on the following page lists

Only use equipment approved by the

tion kit, readjust the tyre pressure and

the warning messages which appear

Network, otherwise the system may be

launch the resetting of the tyre pressure

on the instrument panel 4 when the

activated with a delay or operate incor-

reference value.

system detects a tyre pressure fault.

rectly. ➥ 5.12.

2.42

TYRE PRESSURE MONITOR (1/5)

Resetting the standard level

for the tyre pressures

This should be done:

1

- when the standard tyre pressure

needs to be changed to adapt to

usage conditions (empty, carrying a

load, motorway driving, etc.);

- after swapping a wheel (however

this practice is not recommended);

- after changing a wheel.

It should always be done after checking

the tyre pressure of all four tyres when

cold.

If the vehicle is equipped with the func-

Tyre pressures must correspond to the

tion, this system monitors the tyre pres-

current usage of the vehicle (empty,

sure.

carrying a load, motorway driving, etc.).

Operating principle

Each wheel has a sensor in the inflation

valve which periodically measures the

tyre pressure.

The system displays the current pres-

sures on the instrument panel 1 and

alerts the driver in the event of insuffi-

cient pressure.

If the vehicle is equipped with a nav-

igation system, the resetting proce-

dure may also be carried out using

the multimedia screen: please see

the equipment instructions.

2.44

TYRE PRESSURE MONITOR (2/5)

The flashing tyres symbol indicates

that the request to reset the reference

tyre pressure value has been acknowl-

edged.

1

Reset can take several minutes of driv-

3

ing.

If the reset is followed by short journeys,

the display of step 3 in the table on the

following page may remain displayed

after several successive restarts.

Note: the reference tyre pressure

2

cannot be less than that recommended

and indicated on the edge of the door.

Resetting procedure via the

Resetting procedure via the

instrument panel 1

multimedia screen 3

Ignition on, vehicle stopped:

The resetting procedure must be car-

ried out while the vehicle is stationary

- repeatedly press the switch upwards/

and the ignition is switched on. Please

downwards 2 as many times as nec-

refer to the multimedia instructions for

essary to reach the “Tyre pressure”

further information.

tab;

- press downwards and hold (for ap-

proximately three seconds) the 2

switch to start the reset.

For your safety, the warning

light

®

requires you

to stop immediately as soon

as traffic conditions allow.

2.45

TYRE PRESSURE MONITOR (3/5)

The table below shows the possible messages related to the tyre resetting procedure.

Steps

Displays

Readings

With the ignition on and the vehicle stationary, to start resetting the pressure of all four

1

tyres, press downwards and hold the 2 switch.

The “---” quote marks in front of each wheel will flash to indicate that the system has reg-

2

istered the tyre pressure reset for all four wheels.

The “---” quote marks in front of each wheel will remain lit. This system resets the tyre

pressure of all four tyres. You can now drive. The message may remain displayed during

3

short journeys.

Note: during the reset, tyre pressure monitoring remains in operation.

The pressure value of the four tyres is displayed: the resetting procedure is complete and

4

successful.

2.46

TYRE PRESSURE MONITOR (4/5)

Readjustment of tyre

Replacing wheels/tyres

pressures

Contact an Approved Dealer to replace

The pressure of the four tyres must

the tyres and to find out about acces-

be set when cold (refer to the label lo-

sories compatible with the system that

1

cated on the edge of the driver’s door).

are available from your dealer network:

If the tyre pressures cannot be checked

using any other accessory could affect

when the tyres are cold, the recom-

the correct operation of the system.

mended pressures should be increased

by 0.2 to 0.3 bar (3 PSI).

Never deflate a hot tyre.

Tyre repair product and

inflation kit

As the valves are specifically designed,

only use equipment approved by the

network. Please see the section on

➥ 5.5.

This function is an addi-

Tyre pressure faults

tional driving aid.

Changing a wheel

The function does not take

The table on the following page lists

The system may take sev-

the place of the driver. It

the warning messages which appear

eral minutes depending on

cannot, therefore, under any cir-

on the instrument panel 1 when the

use for the new wheel po-

cumstances replace the vigilance

system detects a tyre pressure fault.

sitions and pressures to be recog-

or the responsibility of the driver.

nised; check the tyre pressures after

Check the tyre pressures once a

all operations.

month.

2.47

TYRE PRESSURE MONITOR (5/5)

The information on the instrument panel signals any potential tyre pressure faults (e.g. deflated or punctured tyre). For

your safety, the warning light® requires you to stop immediately as soon as traffic conditions allow.

Indicator

Messages

Displays

Readings

lights

(depending on

the vehicle)

The wheel and associated pressure value are dis-

played in yellow.

Adjust Tyre Pressure

This indicates that tyre under-inflation has been de-



tected. Check and adjust the pressure of the four

tyres then reset the system.

This indicates that the tyre concerned is punctured

or severely underinflated. Adjust the pressure of the

Puncture

four tyres while cold and reset the system if the tyre

 +

®

is deflated. Replace the tyre (or have it replaced) if

it is punctured.

This indicates that at least one wheel is not fitted with

Check Tyre Pressure Sensors

a sensor or that the sensor is faulty. Consult an ap-

 +

©

proved dealer.

This indicates that the system has not been able to

determine the pressure of each tyre. This may be

Tyre Detection Failure

caused by the use of a sensor not recommended by



an approved dealer. The tyre pressure sensor moni-

toring system remains in operation.

2.48

DRIVER CORRECTION DEVICES AND AIDS (3/10)

Operating faults

The traction control system offers ad-

ditional safety. It is recommended that

When the system detects an operat-

you do not drive with the function disa-

ing fault the message “Check ESC”

bled. Correct this as soon as possible

and warning lights

©

and



by pressing the switch 1 again.

appear on the instrument panel. In

Note: traction control is automati-

this case, the ESC and traction control

cally reactivated when the ignition is

system are deactivated.

switched on.

Consult an approved dealer.

1

Activating, inhibiting the traction

control function

Activate the function by pressing the

switch 1.

If this is not required, it is possible to

deactivate the function by pressing

switch 1.

In this case, the



warning light

appears continuously on the instrument

panel accompanied by the message

“ESC OFF”.

2.51

DRIVER CORRECTION DEVICES AND AIDS (8/10)

- depending on the vehicle, from the

2

“Vehicle” mode 2, select “Dynamic

Dynamic chassis

4

chassis” 3 then press 4. the



warning light is displayed on the in-

strument panel. To deactivate the

Configure

function, press 4 again. The warning

light



goes out on the instru-

360° Camera

Parking assis-

Seats

Air quality

tance

ment panel.

Driving Eco

Driving assis-

Dynamic

Vehicle

tance

chassis

Starting the system

3

With the vehicle moving downhill, as

Settings

soon as sufficient gradient is detected,

4CONTROL

warning light turns to green.

the



During activation of the hill descent con-

Hill descent control (HDC)

Activating/deactivating the system

trol system, the descent speed can be

(depending on the vehicle)

There are several activation methods

increased using the accelerator pedal

This function enables the vehicle

available to access the system:

or decreased using the brake pedal.

speed to be limited without depressing

- via the “Hill Descent Control” widget

Note: this system does not work when

the brake pedal (when driving down a

(if configured by the customer);

the gear lever is in the P position of if

steep hill).

the vehicle is moving on a flat surface.

- via the “Favourites” function (if con-

Hill descent control operates between

figured by the customer) ➥ 1.91;

approximately 4 and 18 mph (6 and

30 km/h) in forward gear and 4 mph

(6 km/h) approximately in reverse gear.

Note: if the vehicle speed is above 37

mph (60 km/h), the system is disabled

and the



warning light goes out.

2.56

DRIVER CORRECTION DEVICES AND AIDS (10/10)

Operating faults

A

B

- If the

© warning light, together

with the message “Check power

steering”, is displayed on the instru-

ment panel: please contact an au-

thorised dealer.

- If the warning light

®

, together

with the message “WARNING:

Power Steering”, is displayed on the

instrument panel, this indicates a

fault in the system.

® requires you to stop

Rear wheel steering

When driving at higher speeds, the rear

as soon as traffic conditions

wheels steer in the same direction as

On equipped vehicles, this system,

allow. Contact an approved

the front wheels (figure B) to optimise

when the vehicle is being driven, steers

Dealer.

the vehicle’s stability. This is useful

the rear wheels according to driving

An impact to the underside of the

when changing lanes or when corner-

conditions: at low speed this system

vehicle (e.g.: striking a post, raised

ing etc.

offers manoeuvrability, at higher speeds

kerb or other street furniture) may

it optimises stability.

Note: the system configuration (re-

result in damage to the vehicle (e.g.:

sponsiveness etc.) depends on the

When driving at low speeds, the rear

deformation of an axle).

mode selected in the “MULTI-SENSE”

wheels steer in the opposite direction to

To avoid any risk of accident, have

menu ➥ 3.2.

the front wheels (figure A) to increase

your vehicle checked by an ap-

the vehicle’s manoeuvrability. This is

proved Dealer.

used when driving in towns, on winding

roads, during parking manoeuvres, etc.

2.58

LANE DEPARTURE WARNING (1/5)

Location of the camera 1

1

Make sure the windscreen is not ob-

scured (dirt, mud, snow, condensation

etc.).

Using information from the camera 1,

the function warns the driver if they

cross a (continuous or broken) line

without activating the direction indica-

tor lights.

This function is an addi-

tional driving aid. This func-

tion is not under any cir-

cumstances intended to

replace the due care and attention

of the driver, who should at all times

be in control of the vehicle.

The lane departure warning func-

tion does not correct the vehi-

cle’s trajectory.

2.59

LANE DEPARTURE WARNING (2/5)

To deactivate the function, press the 3

switch or deselect “Lane departure

warning” in the “Lane keeping system

“ menu.

2

Warning light

 goes out on the in-

strument panel.

If the lane departure warning was the

only side function selected, the switch

warning light 3 goes out and the mes-

sage “”Lane keeping system deacti-

3

vated “ is displayed.

If the “Lane crossing prevention“ func-

tion is activated, deselecting the lane

departure warning will not affect system

operation.

Activation/deactivation

Press the 3 switch to activate the func-

tion.

Before activating the function, from

the “Vehicle” mode on the multimedia

The message “Lane keeping system

screen 2, press the “Driving assistance”

activated” and the



warning

menu then the “Lane keeping system”

light are displayed on the instrument

menu and select “Lane departure warn-

panel and the 3 switch warning light il-

ing”.

luminates.

If no side function is selected in the

“Lane keeping system” menu, when

the 3 switch is pressed the message

“Lane keeping system not configured”

is displayed on the instrument panel.

Each time the vehicle is started,

the function continues the mode

saved the last time the engine was

stopped.

2.60

LANE DEPARTURE WARNING (3/5)

The function triggers an alert if a line

is crossed without the direction indica-

tors being activated.

The function alerts the driver:

- by a vibration in the steering wheel;

4

and

- the



warning light and 4 the in-

dicator for the crossed line turn red.

Operation

When the function is activated, the



warning light and the left and

right lines 4 are displayed in grey on the

instrument panel.

The function is set to notify the

driver if:

- the speed is between about 40 mph

(65 km/h) and 112 mph (180 km/h);

and

- the



warning light and left-

hand or right-hand line indicators 4

appear in white.

2.61

LANE DEPARTURE WARNING (4/5)

Temporarily not available

Conditions for non-activation

- Very fast lane departure;

of the system

- driving continuously on a line;

The system cannot be activated when:

- four seconds approximately after

- reverse gear is engaged;

2

changing lanes;

- the field of vision of the camera is ob-

structed;

- tight bends;

- impaired visibility;

- the

û warning light is displayed.

- activation of one of the direction indi-

cator lights;

The



warning light and the left/

- strong acceleration;

right line indicators turn to grey on the

instrument panel.

- the lane width changes;

- the active emergency braking

Adjustment

system is triggered.

- “Lane departure anticipation”: adjust

To access the multimedia screen func-

the line detection sensitivity level. To

When the function is not available, the

tion settings 2, refer to the multimedia

do this select:

 warning light and the left/right in-

instructions:

- “Late”: line detected when cross-

dicators turn to grey on the instrument

- “Alert vibration”: adjust the steering

ing;

panel.

wheel vibration level;

- “Standard”: line detected on ap-

proach;

- “Early”: line detected nearby.

Please refer to the multimedia instruc-

tions for further information.

2.62

LANE DEPARTURE PREVENTION (1/6)

Location of the camera 1

1

Make sure the windscreen is not ob-

scured (dirt, mud, snow, condensation

etc.).

Using information from the camera 1,

the function triggers a corrective action

on the vehicle steering system if a con-

tinuous or broken line is crossed with-

out the direction indicator lights having

been activated.

This function is an addi-

tional driving aid. This func-

tion is not under any circum-

stances intended to replace

the due care and attention of the

driver, who should at all times be

in control of the vehicle.

You can retake control of the ve-

hicle at any time by operating the

steering wheel.

2.64

LANE DEPARTURE PREVENTION (2/6)

If no side function is selected in the

“Lane keeping system” menu, when

the 3 switch is pressed the message

“Lane keeping system not configured”

is displayed on the instrument panel.

2

The 3 switch warning light remains

switched off.

To deactivate the function, press the 3

switch or deselect “Lane crossing pre-

vention” in the “Lane keeping system “

menu.

3

Warning light



goes out on the in-

strument panel.

The 3 switch warning light goes out and

Activation/deactivation

Press the 3 switch to activate the func-

the message “Lane keeping system

tion.

deactivated” is displayed on the in-

Before activating the function, from

strument panel when the 3 switch is

The message “Lane keeping system

the “Vehicle” mode on the multimedia

pressed or when all of the side func-

screen 2, press the “Driving assistance”

activated” and the

“



” warning

tions are deselected in the “Lane keep-

menu then the “Lane keeping system”

light are displayed on the instrument

ing system” menu.

menu and select “Lane crossing pre-

panel and the 3 switch warning light il-

vention”.

luminates.

When lane departure prevention is acti-

vated, it incorporates the function “Lane

departure warning”, even if it is not se-

lected on the multimedia screen

➥ 2.59.

Each time the vehicle is started,

the function continues the mode

saved the last time the engine was

stopped.

2.65

LANE DEPARTURE PREVENTION (3/6)

In these cases:

Special cases

– the function triggers an action on the

When using the function:

vehicle’s steering system to correct

-

if the system can no longer detect

the vehicle trajectory;

any action by the driver on the steer-

- the warning light



and the indi-

ing wheel, the



warning light

cator 4 on the side of the breached

appears in yellow on the instrument

4

line turns to yellow on the instrument

panel, accompanied by the message

panel.

“Keep control” and an audible warn-

ing.

Note: on bends, the function allows for

slightly cutting the bend.

The audible warning is emitted along

with the warning light and message

If the corrective action on the steer-

until the driver takes control;

ing system is not sufficient, the



-

if the system is active for too long, a

warning light and the indicator 4 on the

warning sound is emitted, the 4 indi-

Operation

side of the breached line turn to red on

cator light on the side of the line con-

When the function is activated, the

the instrument panel, accompanied by

a vibration on the steering wheel.

cerned flashes and the

 warn-



warning light and the left and

ing light appears in yellow until the

right lines 4 are displayed in grey on the

vehicle is taken control of again.

instrument panel.

The function is set to operate when

the vehicle speed is between approxi-

mately 40 mph (65 km/h) and 112 mph

(180 km/h) and if the



warning

light and left-hand and right-hand line

indicators 3 appear in white.

The function reacts when the vehi-

cle crosses a line without the indicator

lights having been activated.

You can interrupt the trajectory cor-

rection at any time by moving the

steering wheel.

2.66

LANE DEPARTURE PREVENTION (5/6)

Operating faults

- “Sensitivity”: adjust the sensitivity

2

level for line detection. To do this,

When the system detects an operating

select:

fault, the left-hand and right-hand line

- “Late”: line detected when cross-

ing;

indicators and the

 warning light

remain in grey on the instrument panel.

- “Standard”: line detected on ap-

proach;

In some cases, they are accompanied

by the following message:

- “Early”: line detected nearby.

- “Driving assist unavailable”;

Please refer to the multimedia instruc-

tions for further information.

or

- “Check Front camera”;

or

- “Driving assist unavailable”.

Adjustment

Depending on the vehicle, the mes-

sage is accompanied by the display of

To access the multimedia screen func-

tion settings 2, refer to the multimedia

the

© warning light on the instru-

instructions:

ment panel.

- “Vibration”: adjust steering wheel

Consult an approved dealer.

vibration for the “Lane Departure

Warning” function;

2.68

BLIND SPOT WARNING (1/6)

B

A

C

A

B

Using information from the sensors in-

Special feature

stalled on each side of the rear bumper

Ensure that the C area around the

(area C), the function warns the driver:

radars on each side of the rear bumper

- when another vehicle is in the blind

are not obstructed (by dirt, mud, snow

spot area A and travelling in the

The function does not notify the

etc.)

same direction as your vehicle;

driver if the other vehicles are not

If a radar is obscured, the message

moving.

and/or

“Side radars no visibility” will appear on

- when there is a risk of collision with a

the instrument panel. Clean the area

vehicle that is in the B area and driv-

This function is an addi-

where the sensors are located.

ing faster than you on an adjoining

tional driving aid. This func-

lane.

tion is not under any cir-

cumstances intended to

The function warns you when your ve-

replace the due care and attention

hicle is travelling at a speed above ap-

of the driver, who should at all times

proximately 9 mph (15 km/h).

be in control of the vehicle.

This system is reactivated each time

the ignition is switched on.

2.70

BLIND SPOT WARNING (2/6)

1

2

3

Activation/deactivation

Indicator 2

From the “Vehicle” World of your 1 mul-

An indicator light 2 is located on each

timedia screen, press the “Driving as-

rear view mirror 3.

sistance” menu.

Note:

Activate or deactivate the “Blind spot

- clean the rear view mirrors 3 regu-

warning” function.

larly, so that the indicator lights 2 can

be seen properly;

- if you overtake another vehicle, the 2

indicator will only come on if that ve-

hicle remains in your vehicle’s blind

spot A long enough.

The system’s detection range oper-

ates according to a standard lane

width. When driving in a narrow

lane, the function can warn you

when a vehicle is detected beyond

the adjacent lane.

2.71

BLIND SPOT WARNING (3/6)

Display E

Conditions for non-function

2

Direction indicator activated, the 2

- When driving on a road with tight

warning light flashes when the func-

bends;

tion detects a vehicle in the blind spot

- in reverse.

warning area and/or a vehicle is rapidly

D

approaching from the rear on the side

If the vehicle is equipped with a towbar

towards which you will turn the wheel.

recognised by the system, the “Trailer:

If you cancel the direction indicator, the

blind spot alert off” message displayed

function will return to the initial warning

on the instrument panel informs you

(display D).

that the function is not operational. For

information on the range of equipment

E

adapted to your vehicle, we advise you

to consult an approved Dealer.

Display D

First warning: direction indicator not

activated, the 2 warning light indicates

that a vehicle is detected in the blind

spot area and/or that a vehicle is rap-

idly approaching from the rear in an ad-

jacent lane.

2.72

SAFE DISTANCE ALERT (1/3)

Location of the camera 1

3

1

Make sure the windscreen is not ob-

scured (by dirt, mud, snow, condensa-

tion etc.).

Location of the radar 2

Ensure that the radar area is not ob-

structed (by dirt, mud, snow, a badly

fitted front number plate), impacted,

2

modified (including painting) or hidden

by any accessory fitted on the front of

the vehicle (on the grille or logo etc.).

Using the information from the radar 2

Activation/deactivation from

and camera 1, this function informs the

the multimedia screen 3

driver of the time interval between their

vehicle and the vehicle in front so that a

From the “Vehicle” World of your 3 mul-

safe stopping distance between the two

timedia screen, press the “Driving as-

vehicles can be maintained.

sistance” menu.

The function is activated when the ve-

Activate or deactivate the “Following

hicle speed is between about 19 and

distance” setting.

112 mph (30 and 180 km/h), depending

This function is an addi-

on the vehicle.

tional driving aid. This func-

tion is not under any cir-

cumstances intended to

replace the due care and attention

of the driver, who should at all times

be in control of the vehicle.

Each time the vehicle is started,

the function continues the mode

saved the last time the engine was

stopped.

2.76

SAFE DISTANCE ALERT (2/3)

- C (yellow): the time interval is be-

8

tween approximately 1 and 2 sec-

A

onds (insufficient distance between

the two vehicles);

- D (red): the time interval is less than

or equal to around one second (very

B

insufficient distance between the two

The measurement is dis-

vehicles).

played for information: the

If the interval between the two vehicles

system does not carry out

C

any action on the vehicle.

is less than around 0.5 seconds, notifi-

cation 8, display D, will remain lit red on

This function is not designed for use

the instrument panel.

in urban conditions or for a dynamic

D

Under certain conditions, the time inter-

driving style (sudden cornering, ac-

val may not be displayed:

celeration, braking, etc.), but rather

for stable driving conditions.

- while cornering;

Operation

The function does not interact with

- when changing lane;

With the function activated, the 8 in-

the braking system.

dicator is displayed on the instrument

- if the vehicle in front is sufficiently far

The radar and camera zones must

panel and informs the driver of the dis-

or outside the range of the radar or

be kept clean and free of any tam-

tance between their vehicle and the ve-

camera.

pering in order to ensure the proper

hicle in front:

operation of the system.

- A (grey): function not operational;

Any work carried out in the area

- A (green): no vehicle detected;

where the radar or camera is lo-

cated (repairs, replacements, wind-

- B (green): the time interval is greater

screen and/or bumper modifica-

than or equal to around two seconds

tions, etc.) must be carried out by a

(distance between the two vehicles

qualified professional.

adapted to your speed);

2.77

ADVANCED SAFETY (1/17)

The “Advanced Security” system con-

sists of:

1

- active emergency braking;

and

3

- emergency lane departure preven-

tion.

The “Advanced Safety” system uses in-

formation from the camera 1, the front

radar 2 and, depending on the vehicle,

the side radars 3.

2

Location of the camera 1

Location of the side radars 3

Make sure the windscreen is not ob-

Ensure that the radar area is not ob-

scured (by dirt, mud, snow, condensa-

structed (by dirt, mud, snow etc.), im-

tion etc.).

pacted or modified (including paintwork

etc.).

Location of the front radar 2

Ensure that the radar area is not ob-

structed (dirt, mud, snow, a badly

fitted/attached front number plate), im-

This system provides an

pacted, modified (including paintwork)

additional driving aid.

or hidden by any accessory fitted on

This system is not, under

the front of the vehicle (on the front

any circumstances, in-

bumper, logo, etc.)

Depending on the sensitivity set-

tended to replace the due care and

ting selected, the “Lane departure

attention of the driver, who should at

prevention” function may operate

all times be in control of the vehicle.

prior to operation of the “Advanced

Safety” system.

2.79

ADVANCED SAFETY (2/17)

4

Activating, deactivating the system

from the multimedia screen 4

From the “Vehicle” mode on your multi-

media screen 4, press the “Driving as-

sistance” menu, then “Advanced safety”

to activate/deactivate the function.

The



warning light appears in

yellow on the instrument panel when

the system is deactivated.

When the system is activated, the

warning light disappears.

This system is reactivated each time

the ignition is switched on.

2.80

ADVANCED SAFETY (3/17)

The system informs the driver if there

is a risk of head-on collision to enable

1

appropriate emergency manoeuvres

(pressing the brake pedal and/or turn-

ing the steering wheel).

Depending on the reactivity of the

driver, the system can assist with brak-

ing in order to limit damage or prevent

a collision.

2

Active emergency braking

The system uses information from the

radar 2 and the camera 1 to determine

the distance from your vehicle:

- from the vehicle ahead in the same

lane;

or

This function is an addi-

This system can apply maximum

- from any oncoming vehicles in the

tional driving aid.

braking to the vehicle until it is

context of a manoeuvre to change

This function is not under

completely stationary if necessary.

direction;

any circumstances in-

or

For safety reasons, always wear

tended to replace the due care

your seat belt when travelling in

- surrounding pedestrians and cy-

and attention of the driver, who

your vehicle and make sure that it

clists.

should at all times be in control of

is loaded so that no items can be

the vehicle.

thrown forward and hit the occu-

pants.

2.81

ADVANCED SAFETY (4/17)

Collision risk alert

Note: if the driver uses the vehicle con-

trols (steering wheel, pedals, etc.) the

The



red warning light or, de-

system may delay certain operations or

pending on the vehicle, the display 5

not activate.

and the “Brake” message appears on

the instrument panel, accompanied by

a beep and a haptic warning (micro

braking according to the sensitivity

5

level and speed).

If the driver presses the brake pedal

and the system still detects a risk of

collision, the brake force may be in-

creased.

Triggering of braking

If the driver fails to react following the

Active emergency braking

alert and collision becomes imminent.

(continued)

If active emergency braking has caused

Detection of vehicles

the vehicle to stop, the vehicle is kept

stationary for a short time. Beyond this

When driving, from approximately

time limit, the vehicle must be held sta-

5 mph (8 km/h), if there is a risk of col-

tionary by the driver keeping their foot

lision with the vehicle in front or with a

on the brake pedal.

vehicle moving in the opposite direc-

tion when changing direction or with a

stationary vehicle, the system will warn

In the event of emergency manoeu-

you of a risk of collision or may trigger

vre, you can stop braking at any

braking.

moment by:

- tapping the accelerator pedal;

or

- turning the steering wheel as a

collision avoidance manoeuvre.

2.82
