Peugeot 5008 (2024 year). Manual in english

258

PEUGEOT Connect Nav

step. There's more information available in

"novice" mode. You can set the dialogue mode to

"expert" when you feel comfortable.

Global voice commands

Voice commands

Set dialogue mode as novice - expert

Select user 1 / Select profile John

Increase temperature

Decrease temperature

Help messages

There are lots of topics I can help you with.

You can say: "help with phone", "help with

navigation", "help with media" or "help with

radio". For an overview on how to use voice

controls, you can say "help with voice controls".

Say "yes" if I got that right. Otherwise, say "no"

and we'll start that again.

"Navigation" voice

commands

Voice commands

Navigate home

Navigate to work

Navigate to preferred address, Tennis club

Navigate to contact, John Miller

Navigate to address 11 regent street, London

Help messages

To plan a route, say "navigate to" followed by the

address, the contact name or an intersection. For

example, "navigate to address 11 Regent Street,

London", "navigate to contact, John Miller",

or "navigate to intersection of Regent Street,

London". You can specify if it's a preferred

address, or a Point of Interest. For example, say

"navigate to preferred address, Tennis club", or

"navigate to POI Heathrow Airport in London".

Or, you can just say, "navigate home". To see

Points of Interest on a map, you can say things

like "show POI hotels in Banbury". For more

information say "help with points of interest" or

"help with route guidance".

To choose a destination, say something like

"navigate to line three" or "select line two". If you

can't find the destination but the street's right,

say for example "select the street in line three".

To move around a displayed list, you can say

"next page" or "previous page". You can undo

your last action and start over by saying "undo",

or say "cancel" to cancel the current action.

Voice commands

Tell me the remaining distance

Tell me the remaining time

Tell me the arrival time

Stop route guidance

Help messages

You can say "stop" or "resume route guidance".

To get information about your current route, you

can say "tell me the remaining time", "remaining

distance" or "arrival time". To learn more

commands, try saying "help with navigation".

Voice commands

Show POI ''hotel'' at the destination

Show nearby POI petrol station

Navigate to POI Heathrow Airport in London

Navigate to POI petrol station along the route

Help messages

To see points of interest on a map, you can

say things like "show hotels in Banbury", "show

nearby parking", "show hotel at the destination"

or "show petrol station along the route". If you

prefer to navigate directly to a point of interest,

you can say "navigate to nearby petrol station".

If you feel you are not being well understood,

try to say the word "POI" in front of the point

of interest. For example say "navigate to POI

restaurant at the destination".

To choose a POI, say something like "select

line 2". If you've searched for a Point of Interest

and don't see the one you're after, you can filter

further by saying something like "select POI in

line 2", or "select the city in line 3". You can also

scroll through the list by saying "next page" or

"previous page".

Depending on the country, give

destination (address) instructions in the

language configured for the system.

259

PEUGEOT Connect Nav

"Radio Media" voice

commands

Voice commands

Turn on source radio - Streaming Bluetooth

- …

Help messages

You can select an audio source by saying "turn

on source" followed by the device name. For

example, "turn on source, Streaming Bluetooth",

or "turn on source, radio". Use the command

"play" to specify the type of music you'd like to

hear. You can choose between "song", "artist",

or "album". Just say something like "play artist,

Madonna", "play song, Hey Jude", or "play

album, Thriller".

Voice commands

Tune to channel BBC Radio 2

Tune to 98.5 FM

Tune to preset number five

Help messages

You can pick a radio station by saying "tune to"

and the station name or frequency. For example

"tune to channel Talksport" or "tune to 98.5

FM". To listen to a preset radio station, say for

example "tune to preset number five".

* This function is available only if the telephone connected to the system supports downloading of contacts and recent calls and the corresponding

download has been performed.

Voice commands

What's playing?

Help messages

To choose what you'd like to play, start by saying

"play" and then the item. For example, say "play

song Hey Jude", "play line 3" or "select line 2".

You can undo your last action and start over

by saying "undo", or say "cancel" to cancel the

current action.

Voice commands

Play song Hey Jude

Play artist Madonna

Play album Thriller

Help messages

I'm not sure what you'd like to play. Please say

"play" and then a song title, an album title, or

an artist name. For example, say "play song

Hey Jude", "play artist Madonna" or "play

album Thriller". To select a line number from the

display, say "select line two". To move around

a displayed list, you can say "next page" or

"previous page". You can undo your last action

and start over by saying "undo", or say "cancel"

to cancel the current action.

Media voice commands are available

only with a USB connection.

"Telephone" voice

commands

If there is no telephone connected by

Bluetooth, a voice message announces:

"Please first connect a telephone", and the

voice session is closed.

Voice commands

Call David Miller

Call voicemail

Display calls

Help messages

To make a phone call, say "call" followed by

the contact name, for example: "Call David

Miller". You can also include the phone type, for

example: "Call David Miller at home". To make

a call by number, say "dial" followed by the

phone number, for example, "Dial 107776 835

417". You can check your voicemail by saying

"call voicemail". To send a text, say "send quick

message to", followed by the contact, and then

the name of the quick message you'd like to

send. For example, "send quick message to

260

PEUGEOT Connect Nav

David Miller, I'll be late". To display the list of

calls, say "display calls". For more information on

SMS, you can say "help with texting".

To choose a contact, say something like "select

line three". To move around the list say "next

page" or "previous page". You can undo your last

action and start over by saying "undo", or say

"cancel" to cancel the current action.

"Text message" voice

commands

If there is no telephone connected by

Bluetooth, a voice message announces:

"Please first connect a telephone", and the

voice session is closed.

The "Text messages" voice commands

function allows you to dictate and send

an SMS.

Dictate the text, taking care to pause briefly

between each word.

When you have finished, the voice recognition

system will automatically generate an SMS.

Voice commands

Send quick message to Bill Carter, I'll be late

Help messages

* This function is available only if the telephone connected to the system supports downloading of contacts and recent calls and the corresponding

download has been performed.

From the list of quick messages, say the name of

the one you'd like to send. To move around the

list you can say "go to start", "go to end", "next

page" or "previous page". You can undo your last

action and start over by saying "undo", or say

"cancel" to cancel the current action.

Voice commands

Send SMS to John Miller, I'm just arriving

Send SMS to David Miller at the office, don't

wait for me

Help messages

Please say "call" or "send quick message to",

and then select a line from the list. To move

around a list shown on the display, you can

say "go to start", "go to end", "next page" or

"previous page". You can undo your last action

and start over by saying "undo", or say "cancel"

to cancel the current action.

Voice commands

Listen to most recent message

Help messages

To hear your last message, you can say "listen to

most recent message". When you want to send

a text, there's a set of quick messages ready for

you to use. Just use the quick message name

and say something like "send quick message to

Bill Carter, I'll be late". Check the phone menu

for the names of the supported messages.

The system only sends pre-recorded

"Quick messages".

Navigation

Choice of a destination

To a new destination

Intuitive method:

Press

Navigation

to display the main

page.

Press "

Search…

Enter an address or the key words for the

destination.

Press "

" to select the "

Guidance

criteria

Guided method:

In order to be able to use the navigation,

you must enter the "

City

", the "

Street

(suggestions are displayed automatically

when you begin typing), then enter the

Number

" using the virtual keypad, or select

261

PEUGEOT Connect Nav

an address from the "

Contact

" list or the

address "

History

If you do not confirm the number, the

navigation system will show one end of

the street.

Press the "

MENU

" button to access the

secondary page.

Select "

Enter address

Then

Select the "

Country

Select the keyboard “language”.

Change the keyboard "type" according to

the selected "language": ABCDE;

AZERTY; QWERTY or QWERTZ.

Enter the "

City

", the "

Street

" and the

Number

", and confirm by pressing on

the displayed suggestions.

Press "

" to select the "

Guidance

criteria

And/or

Select "

See on map

" to choose the

Guidance criteria

Press "

" to start guided navigation.

Zoom in/out using the touch buttons or

with two fingers on the screen.

To a recent destination

Press

Navigation

to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

My destinations

Select the "

Recent

” tab.

Select the address chosen in the list to display

the "

Guidance criteria

”.

Press "

" to start guided navigation.

Select "

Position

" to see the point of

arrival on the map.

To "Home" or "My work"

Press

Navigation

to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

My destinations

Select the "

Preferred

” tab.

Select "

Home

Select "

My work

Select a preset favourite destination.

To a contact

Press

Navigation

to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

My destinations

Select the "

Contact

” tab.

Select a contact in the list to start guided

navigation.

To points of interest (POI)

Guided method:

Points of interest (POI) are listed in different

categories.

Press

Navigation

to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

Points of interest

Select the "

Travel

", "

leisure

Commercial

", "

Public

" or "

Geographic

”

tab.

Select "

Search

" to enter the name and

address of a POI.

Press "

" to calculate the route.

Intuitive method:

262

PEUGEOT Connect Nav

You can only select this method of

using the service if a network connection

is active; this may be either a "network

connection provided by the vehicle", if you

use the Peugeot Connect Packs solution, or

else a "network connection provided by the

user" via a smartphone,

In both cases, the system is automatically

connected to the Internet, if network coverage

permits.

Press

Navigation

to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

Search

Press on the mode shown in the bottom right of

the screen (On-Board or Connected) to change

the "Database".

Select the "Database" in "On-Board"

mode (integrated into the map), or in

"Connected" mode (connected to the Internet).

Press the back arrow to confirm.

Enter an address or the key words for the

destination (POI).

Press "

" to start the search.

Select the "

On the route

", "

Around the

vehicle

" or "

At destination

" tab to refine

your search.

Select the desired address to calculate the route.

To a point on the map

Press

Navigation

to display the main

page.

Explore the map by sliding a finger on the

screen.

Select the destination by pressing on the map.

Tap the screen to place a marker and

display the sub-menu.

Press this button to start guided

navigation.

Press this button to save the displayed

address.

A long press on a point opens a list of

nearby POIs.

To GPS coordinates

Press

Navigation

to display the main

page.

Explore the map by sliding a finger on the

screen.

Touch the screen with a finger to go to the next

image.

Press this button to display the world

map.

Using the grid, select the desired country or

region by zooming.

Press this button to display or enter the

GPS coordinates.

A marker is displayed in the middle of the

screen, with the "

Latitude

" and

Longitude

" coordinates.

Choose the type of coordinates:

DMS for: Degrees, Minutes, Seconds.

DD for: Degrees, Decimals.

Press this button to start guided

navigation.

Press this button to save the displayed

address.

Press this button to enter the "

Latitude

value using the virtual keypad.

And

Press this button to enter the "

Longitude

value using the virtual keypad.

TMC (Traffic Message

Channel)

Available in some countries.

TMC (Traffic Message Channel) messages

are based on a European standard for traffic

information broadcasting via the RDS system on

FM radio, sending traffic information in real time.

The TMC information is then displayed on a GPS

Navigation system map and taken into account

straight away when routes are calculated, to

avoid accidents, traffic jams and closed roads.

Danger zone alerts may or may not be

displayed, depending on the applicable

263

PEUGEOT Connect Nav

legislation and subscription to the

corresponding service.

Connected navigation

Connected navigation

connection

Depending on version, vehicle trim level and

subscription to online services and options.

Network connection provided by the

vehicle

With the Peugeot Connect Packs

solution, the system is automatically

connected to the Internet and connected

services, and does not require the user to

provide a connection via their smartphone.

Network connection provided by the

user

For the list of compatible smartphones,

visit the Brand's website in your country.

Activate and enter settings for sharing the

smartphone connection.

As processes and standards are

constantly changing, we recommend you

update the smartphone operating system

as well as the date and time on the

smartphone and system

, to ensure that the

communication process between the

smartphone and the system functions

correctly.

USB connection

Connect the USB cable.

The smartphone charges when

connected by the USB cable.

Bluetooth connection

Activate the Bluetooth function on the

telephone and ensure that it is visible to

all (see the "Connect-App" section).

Wi-Fi connection

Select a Wi-Fi network detected by the

system and connect to it.

This function is only available if it has

been activated either via the

"Notifications" or via the "Applications" menu.

Press "

Notifications

Select Wi-Fi to activate it.

Press

Connect-App

to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Wi-Fi network connection

Select the "

Secured

", "

Not secured

" or

Stored

” tab.

Select a network.

Using the virtual keypad, enter the "

Key

network Wi-Fi and the "

Password

Press "

" to establish a connection

between the smartphone and the

vehicle’s system.

Usage restrictions:

With CarPlay

, connection sharing is only

available with a Wi-Fi connection.

The quality of services depends on the quality

of the network connection.

Authorize sending

information

Press

Settings

to display the main page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

System configuration

Select the "

Private mode

" tab.

Press "

Notifications

Press "

Private mode

THEN

264

PEUGEOT Connect Nav

Activate or deactivate:

– "

No data sharing except for company

vehicles

– "

Only data sharing

– "

Sharing data and vehicle position

Settings specific to

connected navigation

Press

Navigation

to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

Settings

Select the "

Map

” tab.

Activate or deactivate:

– "

Allow declaration of danger zones

– "

Guidance to final destination on foot

These settings must be configured for each

profile.

Press “

OK”

to confirm your selection.

Select the "

Alerts

” tab.

Activate or deactivate:

– "

Advise of car park nearby

– "

Filling station alert

– “

Risk areas alert

" then press the warning icon

(triangle) to configure the alerts.

– "

Give an audible warning

– "

Advise proximity of POI 1

– "

Advise proximity of POI 2

Press “

OK”

to confirm your selection.

The "Notifications", located in the upper

bar, can be accessed at any time.

Danger zone alerts may or may not be

displayed, depending on the applicable

legislation and subscription to the

corresponding service.

When "TOMTOM TRAFFIC” appears, the

services are available.

The services offered with connected

navigation are as follows.

A Connected Services pack:

– Weather,

– Filling stations,

– Car park,

– Traffic,

– POI local search.

A Danger area pack (optional).

Declaration: "Risk areas

alert"

To send information about danger zones,

select the option:

Allow declaration of

danger zones

Press

Navigation

to display the main

page.

Press the "

Declare a new danger zone

button located in the side bars or the

upper bar of the touch screen (depending on

equipment).

Select the "

Type

” option to select the type

of "Danger area".

Select the

"Speed

" option and enter it

using the virtual keypad.

Press "

" to save and send the

information.

Displaying fuel information

Press

Navigation

to display the main

page.

Press this button to display the list of

services.

Press "

POI on map" to display the list

of points of interest.

Press one of the buttons to search for

Stations

Activate/deactivate "

Stations

Press this button to display a secondary

page.

Select the "

Settings

” tab.

Select the desired fuel.

Press "

" to save.

265

PEUGEOT Connect Nav

Displaying charging station

details

Press

Navigation

to display the main

page.

Press this button to display the list of

services.

Press "

POI on map" to display the list

of points of interest.

Press one of the buttons to search for

Stations

Activate/deactivate "

Stations

Press this button to display a secondary

page.

Select the "

Settings

" tab.

Select the desired connector type.

Press "

" to save.

Displaying weather

information

Press

Navigation

to display the main

page.

Press this button to display the list of

services.

Select "

View map

Select "

Weather

Press this button to display basic

information.

Press this button to display detailed

weather information.

The temperature displayed at 6 a.m. will

be the maximum temperature for the day.

The temperature displayed at 6 p.m. will be

the minimum temperature for the night.

Applications

USB sockets

Depending on equipment, for more information

on the USB sockets compatible with

CarPlay

Android Auto

applications, refer to the "Ease of

use and comfort" section.

For the list of compatible smartphones,

visit the Manufacturer's website in your

country.

Synchronising a smartphone enables

users to display applications that support

the smartphone’s CarPlay

or Android Auto

technology on the vehicle’s screen. For

CarPlay

technology, the CarPlay

function

must first be activated on the smartphone.

Unlock the smartphone for the communication

process between the smartphone and the

system to work.

As principles and standards are constantly

changing,

we recommend keeping the

smartphone's operating system up-to-

date, together with the date and time on

the smartphone and the system

Connectivity

Press

Applications

to display the main

page.

Press "

Connectivity

" to access the

CarPlay

Android Auto

functions.

CarPlay

smartphone

connection

Depending on country.

On connecting the USB cable, the

CarPlay

function deactivates the

system's Bluetooth

mode.

The "

CarPlay

" function requires the use of

a compatible smartphone and compatible

applications.

Connect the USB cable. The smartphone

charges when connected by the USB

cable.

Press "

Telephone

" to display the

CarPlay

interface.

Connect the USB cable. The smartphone

charges when connected by the USB

cable.

266

PEUGEOT Connect Nav

From the system, press "

Applications

" to

display the main page.

Press "

Connectivity

" to access the "CarPlay

”

function.

Press "

CarPlay

" to display the CarPlay

interface.

When the USB cable is disconnected

and the ignition is switched off then back

on, the system will not automatically switch to

Radio Media mode; the source must be

changed manually.

Android Auto smartphone

connection

Depending on country.

Install the "

Android Auto

" application on

the smartphone via "Google Play".

The "

Android Auto

" function requires the use

of a compatible smartphone and compatible

applications.

Connect the USB cable. The smartphone

charges when connected by the USB

cable.

From the system, press "

Applications

" to

display the main page.

Press "

Connectivity

" to access the "Android

Auto” function.

Press "

Android Auto

" to start the

application in the system.

During the procedure, several screen

pages relating to certain features are

displayed.

Accept to start and complete the connection.

Access to the different audio sources remains

available in the margin of the Android Auto

display, using the touch buttons located in the

upper bar.

Access to the menus for the system is possible

at any time using the dedicated buttons.

In Android Auto mode, the function that

displays rolling menus by briefly pressing

the screen with three fingers is disabled.

There may be a pause before

applications become available,

depending on the quality of the network.

Car Apps

Press

Applications

to display the main

page.

Press "

Car Apps

" to display the applications

home page.

Internet Browser

Press

Applications

to display the main

page.

Press "

Connectivity

" to access the "

Connected

Apps

” function.

Press "

Connected Apps

" to display the browser

home page.

Select the country of residence.

Press "

" to save and start the browser.

Connection to the internet is via one of

the network connections provided by the

vehicle or the user.

Bluetooth connection

The services available depend on the

network, the SIM card and the

compatibility of the Bluetooth devices used.

Consult the smartphone user guide and the

service provider to check which services are

available.

The Bluetooth function must be activated

and the smartphone configured as

"Visible to all".

To complete the pairing, whichever procedure is

used (from the smartphone or from the system),

ensure that the code is the same in the system

and in the smartphone.

If the pairing procedure fails, we

recommend deactivating and then

reactivating the Bluetooth function on the

smartphone.

267

PEUGEOT Connect Nav

Procedure from the smartphone

Select the name of the system in the list

of detected devices.

In the system, accept the connection request

from the smartphone.

Procedure from the system

Press

Connect-App

to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Press "

Bluetooth connection

Select "

Search

The list of detected smartphones is

displayed.

Select the name of the chosen

smartphone in the list.

Depending on the type of smartphone,

you may by prompted to accept the

transfer of contacts and messages.

Connection sharing

The system offers to connect the smartphone

with 3 profiles:

– "

Telephone

" (hands-free kit, telephone only),

– “

Streaming

" (streaming: wireless playing of

audio files on the smartphone),

– "

Mobile internet data

The "

Mobile internet data

" profile must

be activated for connected navigation (if

the vehicle does not have "Emergency and

assistance call" services), after first activating

smartphone connection sharing.

Select one or more profiles.

Press "

" to confirm.

Wi-Fi connection

Network connection via the smartphone's Wi-Fi.

Press

Connect-App

to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Wi-Fi network connection

Select the "

Secured

", "

Not secured

" or

Stored

” tab.

Select a network.

Using the virtual keypad , enter the Wi-Fi

network "

Key

" and "

Password

Press "

" to establish the connection.

The Wi-Fi connection and Wi-Fi

connection sharing are exclusive.

Wi-Fi connection sharing

Depending on equipment.

Creation of a local Wi-Fi network by the system.

Press

Connect-App

to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Share Wi-Fi connection

Select the "

Activation

" tab to activate or

deactivate Wi-Fi connection sharing.

And/or

Select the "

Settings

" tab to change the system’s

network name and password.

Press "

" to confirm.

To protect against unauthorised access

and to make all systems as secure as

possible, the use of a security code or a

complex password is recommended.

Managing connections

Press

Connect-App

to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Manage connection

With this function, you can view the access to

connected services, the availability of connected

services and modify the connection mode.

268

PEUGEOT Connect Nav

Radio

Selecting a station

Press

Radio Media

to display the main

page.

Press "

Frequency

Press one of the buttons to perform an

automatic search for radio stations.

Move the slider to manually search for

frequencies up or down.

Press

Radio Media

to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Radio stations

" on the secondary

page.

Press "

Frequency

Enter the values using the virtual keypad.

First enter the units then click on the

decimals field to enter the figures after the

decimal point.

Press "

" to confirm.

Radio reception may be affected by the

use of electrical equipment not approved

by the Brand, such as a USB charger

connected to the 12 V socket.

The exterior environment (hills, buildings,

tunnels, basement car parks, etc.) may

block reception, including in RDS mode.

This phenomenon is perfectly normal in the

context of radio wave transmission, and

in no way indicative of an audio system

malfunction.

Presetting a station

Select a radio station or frequency.

(refer to the corresponding section)

Press "

Presets

Make a long press on one of the buttons

to preset the station.

Changing the waveband

Press

Radio Media

to display the main

page.

To change the waveband, press "Band…",

displayed at the top right of the screen.

Activating/Deactivating RDS

RDS, if activated, allows you to continue

listening to the same station by automatic

retuning to alternative frequencies.

Press

Radio Media

to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Radio settings

Select "

General

Activate/deactivate "

Station follow

Press "

" to confirm.

RDS station tracking may not be

available nationwide, as many radio

stations do not cover 100 % of the country.

This explains the loss of reception of the

station during a journey.

Displaying text information

The "Radio Text" function displays information

transmitted by the radio station relating to the

station or the currently playing song.

Press

Radio Media

to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Radio settings

Select "

General

Activate/deactivate "

Display radio text

Press "

" to confirm.

Playing TA messages

The TA (Traffic Announcement) function gives

priority to TA alert messages. To operate, this

function needs good reception of a radio station

that carries this type of message. While traffic

information is being broadcast, the current

media is automatically interrupted so that the

269

PEUGEOT Connect Nav

TA message can be heard. Normal play of the

previously playing media resumes at the end of

the message.

Select "

Announcements

Activate/deactivate "

Traffic

announcement

Press "

" to confirm.

DAB (Digital Audio

Broadcasting) radio

Terrestrial Digital Radio

Digital radio provides higher quality sound.

The various "multiplexes/ensembles" offer a

choice of radio stations organised in alphabetical

order.

Press

Radio Media

to display the main

page.

Press “Band …" at the top right of the screen to

display the "

DAB

" waveband.

FM-DAB tracking

"DAB" does not cover 100% of the territory.

When the digital radio signal is poor,

“FM-DAB auto tracking" enables you to continue

listening to the same station by automatically

switching to the corresponding FM analogue

station (if there is one).

Press

Radio Media

to display the main

page.

Press the "

OPTIONS

" button to go to the

secondary page.

Select "

Radio settings

Select "

General

Activate/deactivate "

FM-DAB Follow-up

Activate/deactivate "

Station follow

Press "

If "FM-DAB auto tracking" is activated,

there may be a time lag of a few seconds

when the system switches to "FM" analogue

radio, and in some cases a change in volume.

When the digital signal quality is restored, the

system automatically changes back to "DAB".

To minimise this time lag, storing radio

stations in the "DAB" band is recommended.

If the "DAB" station being listened to is

not available on "FM" ("

FM-DAB

" greyed

out), or "FM-DAB auto tracking" is not

activated, the sound will cut out when the

digital signal becomes too weak.

Media

USB port

Insert the USB memory stick into the USB

port or connect the USB device to the

USB port using a suitable cable (not supplied).

To protect the system, do not use a USB

hub.

The system builds playlists (in temporary

memory); this operation can take from a

few seconds to several minutes at the first

connection.

Reduce the number of non-music files and the

number of folders to reduce the waiting time.

Playlists are updated whenever the ignition

is switched off or a USB memory stick is

connected. The audio system memorises these

lists, which will subsequently load faster if they

have not been changed.

Auxiliary socket (AUX)

Depending on equipment

Connect a portable device (MP3 player,

etc.) to the auxiliary jack socket using an

audio cable (not supplied).

This source is only available if "Auxiliary input"

has been selected in the audio settings.

First adjust the volume on the portable device

(to a high level). Then adjust the volume of the

audio system.

Controls are managed via the portable device.

270

PEUGEOT Connect Nav

Selecting the source

Press

Radio Media

to display the main

page.

Select "

SOURCES

Select the source.

Watching a video

Depending on equipment/Depending on version/

Depending on country.

Insert a USB memory stick in the USB port.

Video control commands are accessible

only through the touch screen.

Press

Radio Media

to display the main

page.

Select "

SOURCES

Select

Video

to start the video.

To remove the USB memory stick, press

the pause button to stop the video, then

remove the memory stick.

The system can play video files in the MPEG-4

Part 2, MPEG-2, MPEG-1, H.264, H.263, VP8,

WMV and RealVideo formats.

Streaming Bluetooth

Streaming allows you to listen to the audio feed

from your smartphone.

The Bluetooth profile must be activated.

First adjust the volume on the portable device (to

a high level).

Then adjust the volume of the audio system.

If play does not start automatically, it may be

necessary to start the audio playback from the

smartphone.

Control is from the portable device or by using

the system's touch buttons.

Once connected in streaming mode, the

smartphone is considered to be a media

source.

Connecting Apple

players

Connect the Apple

player to the USB port using

a suitable cable (not supplied).

Play starts automatically.

Control is via the audio system.

The classifications available are those of

the portable device connected (artists/

albums/genres/playlists/audio books/

podcasts).

The default classification used is by artist. To

modify the classification used, return to the

first level of the menu then select the desired

classification (playlists for example) and

confirm to go down through the menu to the

desired track.

The version of software in the audio system may

not be compatible with the generation of the

Apple

player.

Information and advice

The system supports USB mass storage

devices, BlackBerry

devices and Apple

players

via the USB ports. The adapter cable is not

supplied.

Devices are managed using the audio system

controls.

Other devices, not recognised on connection,

must be connected to the auxiliary socket using

a jack cable (not supplied) or via Bluetooth

streaming, if compatible.

The audio system will only play audio files with

".wma", ".aac", ".flac", ".ogg" and ".mp3" file

extensions, at bit rates between 32 Kbps and

320 Kbps.

It also supports VBR (Variable Bit Rate) mode.

No other file types (".mp4", etc.) can be read.

All ".wma" files must be standard WMA 9 files.

The supported sampling rates are 32, 44 and

48 KHz.

To avoid reading and display problems, we

recommend choosing file names less than 20

characters long that do not contain any special

characters (e.g. “ ? . ; ù).

Use only USB memory sticks in FAT32 format

(File Allocation Table).

We recommend using the original USB

cable for the portable device.

271

PEUGEOT Connect Nav

Telephone

Pairing a Bluetooth

telephone

The services available depend on the

network, the SIM card and the

compatibility of the Bluetooth devices used.

Consult the telephone user guide and the

service provider to check which services are

available.

The Bluetooth function must be activated

and the telephone configured as "Visible

to all” (in the telphone settings).

To complete the pairing, whichever procedure is

used (from the telephone or from the system),

ensure that the code is the same in the system

and in the telephone.

If the pairing procedure fails, we

recommend deactivating and then

reactivating the Bluetooth function on the

telephone.

Procedure from the telephone

Select the system name in the list of

detected devices.

In the system, accept the connection request

from the telephone.

Procedure from the system

Press

Telephone

to display the main

page.

Press "

Bluetooth search

Select "

Search

The list of detected telephones is

displayed.

Select the name of the chosen telephone

in the list.

Connection sharing

The system offers to connect the telephone with

3 profiles:

– "

Telephone

" (hands-free kit, telephone only),

– “

Streaming

" (streaming: wireless playing of

audio files on the telephone),

– "

Mobile internet data

The "

Mobile internet data

" profile must

be activated for connected navigation,

after first activating smartphone connection

sharing.

Select one or more profiles.

Press "

" to confirm.

Depending on the type of telephone, you may by

prompted to accept the transfer of contacts and

messages.

The ability of the system to connect just

one profile depends on the telephone.

All three profiles may connect by default.

The profiles compatible with the system

are: HFP, OPP, PBAP, A2DP, AVRCP,

MAP and PAN.

Visit the Brand's website for more information

(compatibility, additional help, etc.).

Automatic reconnection

On returning to the vehicle, if the last telephone

connected is present again, it is automatically

recognised and within about 30 seconds

after switching on the ignition, the pairing is

established automatically (Bluetooth activated).

To modify the connection profile:

Press

Telephone

to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Bluetooth connection

" to display

the list of paired devices.

Press the "Details" button.

Select one or more profiles.

Press "

" to confirm.

272

PEUGEOT Connect Nav

Managing paired telephones

This function lets you connect or disconnect a

device or delete a pairing.

Press

Telephone

to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Bluetooth connection

" to display

the list of paired devices.

Press on the name of the telephone

selected in the list to disconnect it.

Press again to connect it.

Deleting a telephone

Select the basket at top right of the

screen to display a basket alongside the

telephone chosen.

Press the basket alongside the telephone

chosen to delete it.

Receiving a call

An incoming call is announced by a ring and a

superimposed display in the screen.

Make a short press on the steering

mounted telephone button to accept an

incoming call.

And

Make a long press

on the steering mounted telephone button

to reject the call.

Select "

End call

" on the touch screen.

Making a call

Using the telephone is not recommended

while driving.

Park the vehicle.

Make the call using the steering mounted

controls.

Calling a new number

Press

Telephone

to display the main

page.

Enter the phone number using the digital

keypad.

Press "

Call" to start the call.

Calling a contact

Press

Telephone

to display the main

page.

Or press and hold

the steering mounted telephone button.

Select "

Contact

Select the desired contact from the displayed list.

Select "

Call

Calling a recently used

number

Press

Telephone

to display the main

page.

Press and hold

the steering mounted telephone button.

Select "

Calls

Select the desired contact from the displayed list.

It is always possible to make a call

directly from the telephone; as a safety

measure, first park the vehicle.

Managing contacts/entries

Press

Telephone

to display the main

page.

Select "

Contact

Select "

Create

" to add a new contact.

Press the "

Telephone

" tab to enter the

contact’s telephone number(s).

Press the "

Address

" tab to enter the

contact’s address(es).

Press the "

Email

" tab to enter the

contact’s email address(es).

Press "

" to save.

273

PEUGEOT Connect Nav

Press this button to sort contacts by

Surname+first name or by First

name+surname.

The "

Email

" function allows email

addresses to be entered for a contact,

but the system is not able to send emails.

Managing messages

Press

Telephone

to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Messages

" to display the list of

messages.

Select the "

All

", "

Incoming

" or "

Sent

”

tab.

Select the details of the message chosen

in one of the lists.

Press "

Answer

" to send a quick message

stored in the system.

Press "

Call" to start the call.

Press "

Play

" to listen to the message.

Access to "

Messages

" depends on the

compatibility between the smartphone

and the onboard system.

Some smartphones retrieve messages or

email messages more slowly than others.

Managing quick messages

Press

Telephone

to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Quick messages

" to display the

list of messages.

Select the "

Delayed

", "

My arrival

", "

Not

available

" or "

Other

" tab, enabling you to

create new messages.

Press "

Create

" to write a new message.

Select the message chosen in one of the

lists.

Press "

Transfer

" to select one or more

recipients.

Press "

Play

" to start playing the message.

Managing email

Press

Telephone

to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Email

" to display the list of

messages.

Select the "

Incoming

", "

Sent

" or "

Not

read

” tab.

Select the message chosen in one of the lists.

Press "

Play

" to start playing the message.

Access to email messages depends on

the compatibility between the

smartphone and the onboard system.

Settings

Audio settings

Press

Settings

to display the main page.

Select "

Audio settings

Then select "

Ambience

", "

Position

", "

Sound

Voice

" or "

Ringtone

Press "

" to save the settings.

The balance/distribution (or spatialisation

with the Arkamys

system) uses audio

processing to adjust the sound quality

according to the number of passengers in the

vehicle.

Available only with the front and rear speaker

configuration.

The

Ambience

setting (choice of 6

ambiances) as well as for

Bass

Medium

and

Treble

are different and independent for

each audio source.

Activate or deactivate "

Loudness

274

PEUGEOT Connect Nav

The "

Position

" settings (All passengers,

Driver and Front only) are common to all

sources.

Activate or deactivate "

Touch tones

Volume linked to speed

" and "

Auxiliary

input

Onboard audio: Arkamys Sound Staging

optimises the sound distribution inside

the passenger compartment.

Configuring profiles

Press

Settings

to display the main page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Setting of the profiles

Select "

Profile 1

", "

Profile 2

", "

Profile 3

” or

Common profile

Press this button to enter a name for the

profile using the virtual keypad.

Press "

" to confirm.

Press this button to add a photograph to

the profile.

Insert a USB memory stick containing the

photograph in the USB port.

Select the photograph.

Press "

" to accept the transfer of the

photograph.

Press "

" again to save the settings.

The location for the photograph is

square; the system reshapes the original

photograph if in another format.

Press this button to reset the selected

profile.

Resetting the selected profile activates

the English language by default.

Select a "

Profile

" (1 or 2 or 3) to link "

Audio

settings

" with it.

Select "

Audio settings

Then select "

Ambience

", "

Position

"; "

Sound

Voice

" or "

Ringtone

Press "

" to save the selected profile’s

settings.

Modifying system settings

Press

Settings

to display the main page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Screen configuration

Select "

Animation

Activate or deactivate:

Automatic

scrolling

Select "

Brightness

Move the slider to adjust the brightness of

the screen and/or the instrument panel.

Press

Settings

to display the main page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

System settings

Select "

Units

" to change the units of distance,

fuel consumption and temperature.

Select "

Factory settings

" to restore the initial

settings.

Resetting the system to "Factory

settings" activates English and degrees

Fahrenheit and deactivates summer time.

Select "

System info

" to display the versions of

the various modules installed in the system.

Selecting the language

Press

Settings

to display the main page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Languages

" to change the

language.

Setting the date

Press

Settings

to display the main page.

Press the "

OPTIONS

" button to access the

secondary page.

275

PEUGEOT Connect Nav

Select "

Setting the time-date

Select "

Date

Press this button to set the date.

Press "

" to confirm.

Select the display format for the date.

Time and date setting is only available if

"GPS synchronisation" is deactivated.

Setting the time

Press

Settings

to display the main page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Setting the time-date

Select "

Time

Press this button to set the time using the

virtual keypad.

Press "

" to confirm.

Press this button to set the time zone.

Select the display format for the time

(12h/24h).

Activate or deactivate summer time (+1

hour).

Activate or deactivate GPS

synchronisation (UTC).

Press "

" to confirm.

The system may not automatically

manage the change between winter and

summer time (depending on the country of

sale).

Colour schemes

Depending on equipment/Depending on version.

As a safety measure, the procedure for

changing the colour scheme is only

possible when the

vehicle is stationary

Press

Settings

to display the main page.

Select "

Color schemes

Select a colour scheme in the list then

press "

" to confirm.

Whenever the colour scheme is

changed, the system restarts, temporarily

displaying a black screen.

Frequently asked

questions

The following information groups together the

answers to the most frequently asked questions

concerning the system.

Navigation

I cannot enter the navigation address.

The address is not recognised.

► Use the "intuitive method" by pressing

the "Search…" button at the bottom of the

"Navigation” page.

The route calculation is not successful.

The route settings may conflict with the current

location (for example, if toll roads are excluded

but the vehicle is on a toll road).

► Check the route settings in the "Navigation"

menu.

I am not receiving "Danger zone" alerts.

You have not subscribed to the online services

option.

► If you have subscribed to the option:

- a few days may elapse before the service is

activated,

- services may not be selected in the system

menu,

- online services are not active ("TOMTOM

TRAFFIC" not shown on the map).

The POIs do not appear.

The POIs have not been selected.

► Set the zoom level to 200 metres (656 ft), or

select POIs from the POI list.

The "Danger zone" audible warning feature is

not working.

The audible warning is not active or the volume

is too low.

276

PEUGEOT Connect Nav

► Activate the audible warning in the

"Navigation" menu and check the voice volume

in the sound settings.

The system does not suggest a detour

around an incident on the route.

The route settings do not take account of TMC

messages.

► Configure the "Traffic info" function in the

route settings list (None, Manual or Automatic).

I am receiving a "Danger zone" alert which is

not on my route.

As well as providing guided navigation, the

system announces all "Danger areas" positioned

in a cone located in front of the vehicle. It may

provide an alert for "Danger areas" located on

nearby or parallel roads.

► Zoom the map to show the exact location

of the "Danger area". You can select "On the

route" to stop receiving warnings or decrease the

warning duration.

Certain traffic jams along the route are not

indicated in real time.

On starting, a few minutes may elapse before

the system begins to receive traffic information.

► Wait until traffic information is being received

correctly (traffic information icons shown on the

map).

In certain countries, only major routes

(motorways, etc.) are listed for the traffic

information.

This is perfectly normal. The system is

dependent on the traffic information available.

The altitude is not displayed.

On starting, GPS initialisation may take up to

3 minutes to receive more than 4 satellites

correctly.

► Wait until the system has started up

completely so that there is GPS coverage by at

least 4 satellites.

Depending on the geographical environment

(tunnel, etc.) or the weather, the conditions of

reception of the GPS signal may vary.

This behaviour is normal. The system is

dependent on the GPS signal reception

conditions.

My navigation is no longer connected.

During start-up and in certain geographical

areas, the connection may be unavailable.

► Check that the online services are activated

(settings, contract).

Radio

The reception quality of the radio station

being listened to gradually deteriorates or

the station presets are not working (e.g. no

sound, "87.5" MHz is displayed).

The vehicle is too far from the selected station’s

transmitter, or no transmitter is present in the

geographical area.

► Activate the "RDS" function by means of the

short-cut menu to enable the system to check

whether there is a more powerful transmitter in

the geographical area.

The aerial is missing or damaged (e.g. when

going through a car wash or in an underground

car park).

► Have the aerial checked by a dealer.

The surrounding area (e.g. hill, building, tunnel,

underground car park, etc.) is blocking reception,

including in RDS tracking mode.

This is a perfectly normal phenomenon, and is

not indicative of an audio system malfunction.

I cannot find some radio stations in the list of

stations received.

The name of the radio station changes.

The station is no longer received or its name has

changed in the list.

Some radio stations send other information

in place of their name (the title of the song for

example).

The system interprets these details as the station

name.

► Press "Update list" in the "Radio stations"

secondary menu.

Media

Playback of my USB memory stick starts only

after a very long wait (around 2 to 3 minutes).

Some files supplied with the memory stick may

greatly slow down access to reading the memory

stick (multiplication by 10 of the cataloguing

time).

► Delete the files supplied with the memory

stick and limit the number of sub-folders in the

file structure on the memory stick.

There may be an extended pause after

inserting a USB stick.

277

PEUGEOT Connect Nav

The system reads a variety of data (folder, title,

artist, etc.). This can take from a few seconds to

a few minutes.

This is perfectly normal.

Some characters in information about the

currently playing media may not be displayed

correctly.

The audio system is unable to process certain

types of character.

► Use standard characters to name tracks and

folders.

Playback of streaming files does not start.

The connected device does not automatically

launch playback.

► Start playback from the device.

Track names and playing times are not

displayed on the audio streaming screen.

The Bluetooth profile does not allow the transfer

of this information.

Telephone

I am unable to connect my Bluetooth

telephone.

The telephone's Bluetooth function may be

switched off or the device may not be visible.

► Check that the telephone has Bluetooth

switched on.

► Check in the telephone settings that it is

"visible to all".

► Deactivate then reactivate the telephone’s

Bluetooth function.

The Bluetooth telephone is not compatible with

the system.

► You can check the compatibility of the

telephone on the Brand's website (services).

Android Auto and/or CarPlay do not work.

Android Auto and CarPlay may not activate if the

USB cables are of poor quality.

► Use genuine USB cables to ensure

compatibility.

Android Auto and/or CarPlay do not work.

Android Auto and CarPlay are not available in all

countries.

► Check the list of supported countries via

these websites: Google Android Auto or Apple.

The volume of the telephone connected via

Bluetooth is too low.

The volume depends on both the system and the

telephone.

► Increase the volume of the audio system, to

maximum if required, and increase the volume of

the telephone if necessary.

Ambient noise affects the quality of the

telephone call.

► Reduce ambient noise (e.g. close the

windows, reduce ventilation, slow down).

Some contacts are duplicated in the list.

The options for synchronising contacts are:

synchronise the contacts on the SIM card, the

contacts on the telephone, or both. When both

synchronisations are selected, some contacts

may be duplicated.

► Select "Display SIM card contacts" or

"Display telephone contacts".

The contacts are not listed in alphabetical

order.

Some telephones offer display options.

Depending on the settings chosen, contacts can

be transferred in a specific order.

► Modify the telephone directory display

settings.

The system is not receiving SMS text

messages.

Bluetooth mode does not allow SMS text

messages to be sent to the system.

Settings

When the treble and bass settings are

changed, the ambience is deselected.

When the ambience is changed, the treble

and bass settings are reset.

Selecting an ambience imposes the treble and

bass settings, and vice versa.

► Modify the treble and bass or ambience

settings to obtain the desired musical ambience.

When the balance settings are changed, the

distribution is deselected.

When the distribution setting is changed, the

balance settings are deselected.

Selecting a distribution setting imposes the

balance settings, and vice versa.

► Modify the balance setting or the distribution

setting to obtain the desired sound quality.

There is a difference in sound quality

between audio sources.

To allow for optimal listening quality, the sound

settings can be tailored to different audio

sources, which can generate audible differences

when changing source.

278

PEUGEOT Connect Nav

► Check that the sound settings are appropriate

to the sources listened to. We recommend

setting the sound functions (Bass, Treble,

Balance) to the middle position, setting the

musical ambience to "None", setting loudness

correction to "Active" in USB mode and "Inactive"

in Radio mode.

► In all cases, after applying sound settings,

adjust the volume level on the portable device (to

a high level) first. Then adjust the volume level

on the audio system.

When the engine is off, the system switches

off after several minutes of use.

When the engine is switched off, the system's

operating time depends on the state of charge of

the battery.

The switch-off is normal: the system

automatically goes into energy economy mode

and switches off to maintain an adequate charge

in the battery.

► Start the vehicle’s engine to increase the

charge of the battery.

The date and time cannot be set.

Date and time settings are only available if

satellite synchronisation is deactivated.

► Settings menu/Options/Date-Time Setting.

Select the "Time" tab and deactivate "GPS

synchronisation" (UTC).

279

Vehicle data recording and privacy

Vehicle data recording

and privacy

Electronic control units are installed in your

vehicle. These control units process data

received from the vehicle's sensors, for example,

or data they generate themselves or exchange

with each other. Some of these control units are

required for the correct operation of your vehicle,

some others assist you while driving (driving or

manoeuvring aids), while others provide comfort

or infotainment functions.

The following contains general information about

how data is processed within the vehicle.

You will find additional information about the

specific data which is downloaded, stored

and transmitted to third parties and what it is

used for in your vehicle under the keyword

"Data protection". This information is directly

associated with the references for the functions

in question contained in the corresponding

vehicle handbook, or in the general terms and

conditions of sale.

This information is also available online.

Vehicle operating data

The control units process the data used for the

operation of the vehicle.

This data includes, for example:

– Information about the state of the vehicle

(e.g. speed, travel time, lateral acceleration,

wheel rotation rate, fastened seat belts display).

– Environmental conditions (e.g. temperature,

rain sensor, distance sensor).

As a general rule, this data is temporary, is

not stored for longer than one operating cycle

and is only used within the vehicle itself. The

control units often record this data (including the

vehicle's key). This function allows either the

temporary or permanent storage of information

about the state of the vehicle, stresses on

components, servicing requirements, as well as

events and technical errors.

Depending on the vehicle's equipment level, the

data stored is as follows:

– Operating state of system components

(e.g. filling level, tyre pressures, battery charge

status).

– Faults and malfunctions in important system

components (e.g. lamps, brakes).

– System reactions in specific driving situations

(e.g. deployment of an airbag, triggering of

stability control and braking systems).

– Information about events which have

damaged the vehicle.

– For electric and rechargeable hybrid vehicles,

the traction battery charge level and the

estimated driving range.

In particular circumstances (e.g. if the vehicle

has detected a malfunction), it may be necessary

to record data which would otherwise simply not

be stored.

When taking your vehicle in for servicing

(e.g. repairs, maintenance), the stored operating

data may be read along with the vehicle's

identification number and used if necessary.

The personnel working for the servicing network

(e.g. garages, manufacturers) or third parties

(e.g. roadside assistance agents) may read

the vehicle's data. This also applies to work

carried out under warranty and quality assurance

measures.

This data is generally read via the OBD

(On-Board Diagnostics) port fitted by law to

the vehicle. It is used to report on the technical

state of the vehicle or its components and

facilitates the diagnosis of malfunctions, in

compliance with warranty obligations and for

quality improvement. This data, in particular the

information relating to stress on components,

technical events, operator errors and other

malfunctions, is sent to the Manufacturer, if

necessary, along with the vehicle's identification

number. The Manufacturer's liability may also be

engaged. The Manufacturer may also use the

operating data taken from the vehicle for product

recalls. This data may also be used to check the

customer's warranty and any claims made under

warranty.

Any malfunctions stored in the vehicle may be

reset by an after-sales service company during

servicing or repair work, or at your request.

280

Vehicle data recording and privacy

Comfort and infotainment

functions

Comfort settings and personalised settings

may be saved in the vehicle and modified or

reinitialised at any time.

Depending on the vehicle's equipment level, this

may include:

– Seat and steering wheel position settings.

– Chassis and air conditioning settings.

– Personalised settings such as the interior

lighting.

You can enter your own data into the functions

of your vehicle's audio and telematic system, as

part of the selected functionalities.

Depending on the vehicle's equipment level, this

may include:

– Multimedia data such as music, videos or

photos to be read by an integrated multimedia

system.

– Address book data to be used with an

integrated hands-free system or with an

integrated navigation system.

– Entered destinations.

– Data regarding the use of online services.

This data for the comfort and infotainment

functions may be stored locally in the vehicle

or saved to a device that you have connected

to the vehicle (e.g. smartphone, USB memory

stick or MP3 player). Data that you have entered

yourself may be deleted at any time.

This data may also be transmitted outside the

vehicle at your request, particularly when using

online services in line with the settings that you

have selected.

Smartphone integration

(e.g. Android Auto

Apple

CarPlay

)

If your vehicle is equipped accordingly, you can

connect your smartphone or another mobile

device to the vehicle in order to operate it using

the vehicle's integrated controls. Images and

sounds from the smartphone can be transmitted

through the audio and telematics system.

Specific information is simultaneously sent

to your smartphone. Depending on the type

of integration, this includes data such as location,

day/night mode and other general information

about the vehicle. For more information, please

refer to the user instructions for the vehicle or the

audio and telematics system.

Integrating a smartphone allows you to use

its applications, such as a navigation app or

music player. No other integration between

the smartphone and the vehicle is possible, in

particular active access to vehicle data. How the

data is processed subsequently is determined

by the supplier of the application being used.

The ability the change settings depends on the

application in question and on the operating

system installed on your smartphone.

Online services

If your vehicle is connected to a wireless

network, data can be exchanged between

your vehicle and other systems. Connection

to a wireless network is made possible via a

transmitter located in your vehicle or a mobile

device that you have provided (e.g. smartphone).

The online services can be used via this wireless

connection. These include online services and

applications (apps) provided to you by the

Manufacturer or other suppliers.

Exclusive services

As regards the Manufacturer's online services,

the corresponding functions are described by

the Manufacturer in an appropriate medium

(e.g. handbook, Manufacturer's website) and the

information about data protection is provided.

Personal data may be used for online services.

The exchange of data for this purpose takes

place over a secure connection, using for

example the Manufacturer's dedicated computer

systems. The collection, processing and use of

personal data for the development of services

are carried out solely on the basis of a legal

authorisation, for example in the case of a

legal emergency call system or a contractual

agreement or else under a consent agreement.

You can activate or deactivate the services and

functions (some may be chargeable) and, in

some cases, the vehicle's entire connection to

the wireless network. This does not include the

Peugeot 5008 (2024 year). Manual in english - page 9
