Peugeot 308 (2024 year). Manual in english

226

Technical data

Engines and towed loads - Electric

EV 156 Standard Range

Codes

MEL ZLE 54 FWD

Model codes:

Hatchback: FM...

SW: FN...

ZKW/Z

Body styles

Hatchback

Braked trailer (within the GTW limit) (kg)

on a 10% or 12% gradient

Unbraked trailer (kg)

Maximum authorised nose weight (kg)

Electric motor

Technology

Synchronous with permanent magnets

Max. power : EC standard (kW)/(hp)

115/156

Traction battery

Technology

Lithium-Ion

Installed capacity (kWh)

(Battery M)

Domestic charging

Mode 2

Alternating current (AC) voltage

Rating (A)

230 (single-phase)

8 or 16

Accelerated charging

Mode 3

Alternating current (AC) voltage

Rating (A)

230 (single-phase or three-phase)

16 or 32

228

Technical data

Identification markings

Various visible markings for vehicle

identification

and vehicle search.

A. Vehicle Identification Number (VIN), under

the bonnet.

Stamped on the chassis.

B. Vehicle Identification Number (VIN), on the

dashboard.

Printed on an adhesive label visible through the

windscreen.

C. Manufacturer's label.

Affixed to the right-hand door.

Bears the following information:

– Manufacturer’s name.

– European whole vehicle type approval

number.

– Vehicle Identification number (VIN).

– Gross vehicle weight (GVW).

– Gross train weight (GTW).

– Maximum weight on the front axle.

– Maximum weight on the rear axle.

D. Tyres/paint code label.

Affixed to the driver's door.

Bears the following information about the tyres:

– Tyre pressures, unladen and laden.

– Tyre specification, made up of the dimensions

and type as well as the load and speed indices.

– Spare tyre inflation pressure.

Also indicates the paint colour code.

The vehicle may be originally equipped

with tyres with higher load and speed

indices than those indicated on the label,

without affecting tyre pressure (on cold tyres).

In the event of a change in the type of tyres,

contact a PEUGEOT dealer for the tyre fits

approved for the vehicle.

229

PEUGEOT i-Connect Advanced - PEUGEOT i-Connect

PEUGEOT i-Connect

Advanced - PEUGEOT

i-Connect

GPS navigation -

Applications - Multimedia

audio system - Bluetooth

telephone

The functions and settings described

vary according to the version and

configuration of the vehicle, and according to

the country of sale.

For safety reasons and because they

require continued attention on the part of

the driver, the following operations must be

carried out with the

vehicle stationary

and

the ignition on:

– Pairing the smartphone with the system via

Bluetooth

– Using the smartphone.

– Connecting to Mirror Screen

(Apple

CarPlay

or Android Auto).

– Changing the system settings and

configuration.

The message

Energy economy mode

displayed when the system is about to go

into standby.

For more information on

Energy economy

mode

, refer to the "Practical information"

section.

The AM radio selection mode is not

available on electric vehicles.

Warning

Navigation is a driving aid. It cannot

replace the driver. All guidance instructions

should be carefully checked by the user.

By using the navigation, you accept the

following terms and conditions:

https://www.tomtom.com/en_gb/legal/

eula-automotive/?388448

First steps

The system starts when the ignition is

switched on.

Short press, ignition off: system on/off.

Short press, ignition on: mute/restore sound.

Long press, ignition on: start standby mode

(mute sound, screens and clock display off).

Rotation: volume adjustment.

Information

This system gives access to the following

elements:

– Audio equipment and telephone controls with

display of associated information.

– Connected services and display of associated

information.

– Navigation system controls and display

of associated information (depending on

equipment).

– Voice recognition (depending on equipment).

– Time and outside temperature.

– Heating/air conditioning system controls and

reminders of settings.

– Settings for driving aid functions, comfort

and safety functions, extended head-up display

(depending on equipment and version), audio

equipment and digital instrument panel.

– Settings for functions specific to rechargeable

hybrid vehicles.

– Settings for functions specific to electric

vehicles.

– Display of visual manoeuvring aid functions.

– Interactive handbook.

– Video tutorials (e.g. screen management,

driving aids, voice recognition).

Upper banner

Certain information is displayed permanently in

the upper banner of the touch screen:

– Outside temperature from the vehicle's

sensors (associated with a blue symbol if there is

a risk of ice).

– Temperature setting reminder for the air

conditioning on the driver's and passenger sides.

– Charge level of the connected smartphone.

230

PEUGEOT i-Connect Advanced - PEUGEOT i-Connect

– System connection status (Bluetooth

, Wi-Fi,

mobile telephone network).

– Time.

– Quick access to the Mirror Screen

functions

(associated with a connected smartphone).

Swipe down from the upper edge of the touch

screen to access the notifications centre and

display a list of quick settings :Guest, Privacy

Settings, Brightness, My Devices, night mode,

etc.

Principles

► Use this button (HOME) to display the

most recent home page used; a second

press displays the first home page, then press

the virtual buttons displayed on the touch screen.

Scroll through the home pages by sliding

your finger along the screen to the right or

to the left.

Principle of movement in the system

Depending on the pages displayed on the

screen, scroll through the text or the menu (on

the left side of the screen) by sliding your finger,

as with a smartphone.

Touch buttons

Display/hide the context menu.

Return to the previous page.

► To change the status of a function, press the

description for the corresponding line (change

confirmed by the slider moving to the right/left:

function activated/deactivated).

Access to additional information about the

function.

Access to a function’s settings.

Add/delete shortcuts.

Configuring profiles

Press the "

Settings

" application.

In the list, select the "

Profile

" tab.

The screen displays a "Guest" profile built

into the system and allows you to create and

personalise several new profiles with or without

an associated mobile device.

The "

Guest

" profile has a default display

with the possibility of adding to it and/or

returning it to its initial configuration. This profile

is built into the system and cannot be deleted.

Each profile created can be associated

with a mobile device of your choice

connected via Bluetooth

; the Bluetooth

function

of the mobile device must first be activated. This

association allows the system to detect your

presence in the vehicle when it starts and to

propose the activation of your personalised

profile.

If a profile is not connected to the mobile device,

the last profile used will be highlighted.

Select "

Create Profile

", then follow the

procedure.

Creating a new profile allows you to personalise:

– Language, units, Privacy Settings.

– Screen configuration, appearance, i-Toggles

(depending on equipment).

– Audio settings, favourite radio stations.

– Lighting, interior ambience (refer to the "Ease

of use and comfort" section).

– Navigation history, favourite points of interest

(POIs), navigation settings.

– Some driving aids and the list of favourites.

To delete a profile, select it from the list of

profiles then press the bin.

Privacy Settings

The "Privacy Settings" management is

associated with each profile. This function is

used with:

a "Guest" profile configured by default in "Private

Mode",

a profile to be created in the system, with or

without connection to a mobile device.

For each profile (even "Guest"), the last privacy

mode saved value will be restored.

Sharing Data and Location

This mode allows the vehicle to externally

transmit all the personal data needed for each

valid available connected service.

The personal data required to use the

connected services is sent to the

providers of these services.

231

PEUGEOT i-Connect Advanced - PEUGEOT i-Connect

Sharing Data

This mode allows the vehicle to externally

transmit all the data needed for each valid

available connected service, with the exception

of vehicle location data (e.g. GPS coordinates).

Some connected services may not

function without the vehicle location data.

This mode will not be applied to the

emergency call function or to specific

services to which the user has consented

under the terms of commercial contracts

(e.g. Connected alarm).

Private Mode

This mode does not allow the vehicle to

transmit personal data outside the vehicle.

Connected services will only perform

local processing inside the vehicle with

limited functions.

This mode will not be applied to the

emergency call function or to specific

services to which the user has consented

under the terms of commercial contracts

(e.g. Connected alarm).

Professional purposes

If the vehicle is used for professional

purposes or under the terms of specific

contracts (e.g. corporate fleet, government

assignment), some privacy modes will not

be available for the user on the screen,

depending on the data sharing needs of the

services.

To change mode, swipe down from the upper

edge of the touch screen to display all of the

quick settings.

Press this button and select the chosen

mode. The mode is highlighted.

Press the "

Settings

" application.

In the list, select the "

Connectivity

" tab.

Select "

Privacy Settings

Choose the mode.

Internet portal

During the first use, upon acquisition of the

vehicle, the user is invited to select the country

of residence for the use of the Internet portal.

If the country is not selected, the notification is

stored in the notification centre and disappears

once the country is selected. Slide a finger on

the touch screen from top to bottom to display all

the notifications.

The selection of a country is necessary to use

the available internet applications.

Press the "

Settings

" application.

In the list, select the "

Connected Services

Choose the country.

The first time you use it, via a connected

mobile device, the system links to your

profile. The connected mobile device serves as

an access key to saved personal information.

First activate the mobile device’s Bluetooth

function.

Select the desired application, authentication will

be requested if necessary. This authentication

will be saved for future uses via the mobile

device connected to the current profile.

An authentication will be requested at each use if

the mobile device is not connected to the current

profile or if the Guest profile is used.

With the use of the “Guest” profile, an

identification will be requested for each

use.

Updating the system

Managing devices remotely and

remote updating of software and

firmware.

Being an integral part of the service used to

provide connected services contract(s), the

required management of devices as well as

the required updating of the software and

firmware associated with the aforementioned

connected service will be carried out remotely,

in particular using "Over the Air" technology.

To do this, a secure connection via radio

network is established between the vehicle

232

PEUGEOT i-Connect Advanced - PEUGEOT i-Connect

and the Manufacturer's device management

server each time the ignition is switched on,

when a mobile telephone network is available.

Depending on the vehicle's equipment,

the connection configuration must be set

to "Connected vehicle" to enable to the

connection to the radio network.

Irrespective of a valid subscription to a

connected service, the remote management

of devices relating to or connected with

the security of devices, and the updating

of software and firmware, will be carried

out when necessary in order to comply

with a legal requirement applicable to the

Manufacturer (e.g. the applicable law in terms

of product liability, the regulations governing

e-call) or when necessary to protect the

respective vital interests of the vehicle's users

and passengers.

The establishment of a secure connection via

radio network and the corresponding remote

updates are not affected by the privacy

settings and are intended to be carried out

after being initialised by the user in response

to a related notification.

The system can notify the receipt of an update

when it is connected to an exterior Wi-Fi network

or a mobile telephone network.

Large updates are downloaded only via the Wi-Fi

network.

The availability of an update is notified on the

screen at the end of the journey with an option

of immediate installation or postponement of

installation.

The installation time is variable and can take

several minutes with a maximum of about 30

minutes. A notification will give an estimate of the

duration and a description of the update.

Update information is available through the

"Settings" application.

Press the "

Settings

" application.

In the list, select the "

Updates

" tab.

This button allows you to change the

authorisation for automatic downloading

of updates via an exterior Wi-Fi network.

For safety reasons and because it

requires sustained attention on the part

of the driver, the installation must be carried

out with the ignition on but without starting the

engine.

The installation cannot be carried out in the

following cases:

– engine running.

– emergency call in progress.

– insufficient battery level.

– when charging for electric vehicles.

If an update has failed or has expired, contact a

dealer or a qualified workshop.

The Manufacturer does not charge for

the use of this service.

However, the use of Wi-Fi and/or mobile

telephone networks by your smartphone may

incur extra charges if you exceed the data

allowance included in your contract.

Any associated costs will be billed to you by

your mobile telephone operator.

Personalisation

Press and hold the screen from one of the

system's home pages.

Press the "

Settings

" application.

In the list, select the "

Customization

" tab.

Press the "

Displays

" field.

A page divided into 2 parts is displayed.

Press the HOME button at any time to leave this

page.

Personalising the screen

Press the pencil in the "

Customize

Touchscreen

" part.

A representation of the organisation of the

different home page (

HOME

) Widgets is

displayed.

A Widget is a reduced window of an

application or service.

Adding a Widget

To add a Widget, press "

Widget

" on the

left of the screen.

233

PEUGEOT i-Connect Advanced - PEUGEOT i-Connect

Press one of these buttons on the screen.

Select the desired Widget.

Press the back arrow to return to the

previous page.

Organising the Widgets on a home

page (HOME)

To move a Widget, press and hold it, then drag it

to the desired location.

Adding a page

To add a page, press "

Page

" on the left of

the screen.

Press the back arrow to return to the

previous page.

Deleting a Widget

To move a Widget to the bin, press and

hold it, then drag it to the bin.

Personalising the

instrument panel

Press the pencil in the "

Customize

Driver Information

" part.

The modification of the organisation of the

different Widget is displayed on the instrument

panel in real time.

A Widget is a reduced window of an

application or service.

Adding a Widget

To add a Widget, press "

Widget

" on the

left of the screen.

Press one of these buttons on the screen.

Select the desired Widget.

Press the back arrow to return to the

previous page.

Deleting a Widget

To move a Widget to the bin, press and

hold it, then drag it to the bin.

Personalising i-Toggles

(depending on equipment)

In the central screen, display the page containing

the button that you want to include.

The shortcuts are used to access an

application (air conditioning page, radio

page, etc.) or to perform an action (set the

temperature to 21°, call a selected directory

contact, etc.).

Press and hold the shortcut you want to

replace.

A panel is displayed on the central screen with

all of the eligible shortcuts in boxes.

A notification also informs you of the next step to

perform.

Select the new shortcut required. It will be

duplicated in i-Toggles and will replace the one

originally selected. A notification also informs you

of this.

To exit this function at any time, press this

button or press the main "Home" button.

Steering-mounted

controls

Voice control

Short press, system voice commands

(depending on equipment).

Long press, voice commands of the smartphone

connected using Bluetooth

or Mirror Screen

(Apple

CarPlay

/Android Auto) via the system.

Increase volume.

Decrease volume.

Mute the sound: long press on the

decrease volume button.

Restore the sound by pressing one of the two

volume buttons.

Incoming call

(short press): accept the

call.

Call in progress

(short press): hang up.

Incoming call

(long press): refuse the incoming

call.

Out of call

(short press): access the call log of

the telephone connected via Bluetooth

Mirror Screen

connected

(short press): access

the projected view of the telephone application of

your Mirror Screen

equipment.

234

PEUGEOT i-Connect Advanced - PEUGEOT i-Connect

Radio

: automatic search for the

previous/next station (in the list of

radio stations sorted by name or by frequencies).

Media

: previous/next track, movement in the

lists.

Phone

: browse the telephone's call log.

Short press

: validate a selection. Out of

selection, display the lists.

Applications

From the home page, press this button to

access the applications wall.

From any page, press the touch screen

with three or more fingers to display the

applications wall.

Help

Access the handbook and watch tutorials.

Media

Select an audio source or radio station.

Mirror Screen

Smartphone connected with Mirror

Screen

: access to the projected view of

Apple

CarPlay

or Android Auto.

Smartphone not connected: access the menu

allowing you to connect a smartphone.

Navigation

(depending on equipment)

Enter navigation settings and choose a

destination.

Use services available in real time, depending on

equipment.

Voice commands

(depending on equipment)

Use the system or smartphone voice recognition

via the system.

Phone

Telephone not connected: access the

menu allowing you to connect a telephone.

Telephone connected: access the call log,

contacts and telephone settings.

Two connected telephones: access the contents

of the priority telephone with the possibility of

changing the priority of the telephone.

Settings

Main settings for the audio system, touch

screen and digital instrument panel.

Voice commands

First steps

(depending on equipment)

The voice recognition service offers a

choice of 20 languages minimum (French,

German, English (UK), English (US), Arabic,

Brazilian, Chinese, Danish, Spanish, Hebrew,

Italian, Japanese, Dutch, Norwegian, Polish,

Portuguese, Russian, Swedish, Czech, Turkish)

available with the cellular network and in line

with the language chosen and previously

configured in the system.

The system supports two languages for cases

where the area in which the vehicle is travelling

is not covered by the cellular network.

These languages, referred to as on-board

languages, are downloaded into the system.

If the chosen language has not been

downloaded, a message on the screen appears

as soon as the cellular network is not connected

for the first time and offers to download it.

To use this new language in all areas, download

it beforehand (ignition on without starting the

engine) via the Wi-Fi network.

Apply the download procedure displayed on the

screen.

Downloading this new language removes the

least used on-board language.

Information - Using the

system

When voice commands are activated, say

your command after the audible signal.

For commands in several stages, interaction

takes place with the system to complete the

initial request.

Some commands self-validate after 7 seconds.

If the system has not taken your command into

account, it will indicate this by a voice message

and an on-screen display.

Press the "

Settings

" application.

In the list, select the "

Voice Assistant

" tab.

235

PEUGEOT i-Connect Advanced - PEUGEOT i-Connect

Activate/Deactivate:

– "

Detect (Wake up Word)

": to invoke the voice

recognition using the keyword "

OK Peugeot

– "

Data Usage

": to authorise our supplier to

re-use your data in order to let him globally

improve its capabilities in term of voice

recognition and voice assistance.

Voice Assistant/Data usage

Vehicle's location and voice recordings

are not concerned; only textual transcriptions

of your conversations with the voice assistant

are kept after to be pseudonymised.

Opening voice recognition

Voice commands can be used on any

screen page, provided there are no other

sources which take priority in use (reverse,

emergency or assistance call, telephone call,

other smartphone voice recognition already

launched).

Choice of opening voice recognition:

► Say "

OK Peugeot

► Press the button located on the steering

wheel.

► Press the touch screen button.

To ensure that voice commands are

always recognised by the system, please

follow these recommendations:

–

Use natural language in a normal tone

without breaking up words or raising your

voice.

– After opening voice recognition with the

steering wheel-mounted button or the button

on the touch screen, always wait for the

"beep" (audible signal) before talking. No

"beep" sounds when voice recognition is

opened using "

OK Peugeot

– For optimal operation, it is recommended

that you close the windows and the sunroof

(depending on equipment) to avoid any

external interference, and switch the

ventilation off.

– Before speaking the voice commands, ask

the other passengers not to speak.

Voice command example for air

conditioning:

"raise the fan speed"

"Turn on air conditioning"

"i'm too hot"

Voice command example for radio and

media:

"I want to listen to michael jackson"

"switch to radio"

"tune to 88.5"

Media voice commands are only

available with an USB connection.

Voice command example for navigation:

"navigate home"

"Navigate me to gabrielle's house"

"search for public parking nearby"

Depending on the country, give

destination (address) instructions in the

language configured for the system.

Voice command example for telephone:

"Call Matthew's mobile"

"call 0113 345 9869"

"Call jonathan"

If there is no telephone connected by

Bluetooth

, a pop-up window appears:

Connect a telephone by Bluetooth

", and

the voice session will be closed.

Voice command example for the weather:

"do i need a raincoat"

"how is the weather tonight"

"what is today's humidity level"

236

PEUGEOT i-Connect Advanced - PEUGEOT i-Connect

Navigation

Navigation home screen

(depending on equipment)
Access to additional videos

https://www.tomtom.com/

PSAGroup-Connected-Nav

Press the "

Navigation

" application to

display the navigation home screen.

Press "

Search

" to enter an address or a

name.

Press this button to display the main

menu for the various options.

Press this button to display the 3D/2D

mode.

Select "

Sound activated

", "

Alerts only

and "

Silent

" with successive presses on

this button.

Press the "plus"/"minus" buttons to zoom

in/out, or use two fingers on the screen.

Main menu

Press the "

Navigation

" application to

display the navigation home screen.

Press this button to display the main

menu for the various options.

Select "

Search

" to enter an address,

name or some points of interest.

Select "

Go home

" using an address

previously saved in "

Add home

Select "

Go to work

" using an address

previously saved in "

My places

Select "

Recent destinations

" to display

the latest destinations searched.

Select "

Current trip

" to open another

menu and perform various actions for the

current planned route.

Select "

My places

" for quick access to

saved places as well as favourite

destinations.

Select "

My trips

" to display your favourite

routes.

Select "

Parking

" to display the various

parking options in the area.

Select "

Service station

" to display the

different service stations on the current

route or near the current location.

Select "

TomTom service

" to check the

network status.

Select "

Settings

" to enter the vehicle type

and to personalise the display, voice

instructions, map options, trip planning, sounds

and alerts, and system information.

Select this button to display details on

software versions as well as legal

information. Details of the Open Source software

libraries used and their licence URLs.

Regular connection to a secure Wi-Fi

access point automatically updates the

installed mapping globally.

The mapping is also updated using a cellular

network, depending on version, country of

sale, the vehicle's level of equipment, as well

as the subscription to connected services and

options.

However, using your smartphone's Wi-Fi

and/or cellular networks may incur additional

charges if you exceed your data plan.

These charges, if any, will be passed on to

your telephone operator's bill.

Connectivity

Connecting a wired device

by USB

The USB connection of a mobile device allows it

to be recharged. It makes its authorised media

content available to the system (Media content

of iPod

type).

Only one USB socket will allow a Mirror

Screen connection (Apple

CarPlay

Android Auto) for the compatible connected

mobile devices and to use some of the device's

applications on the touch screen.

For more information on the USB socket

compatible with the Mirror Screen

function,

refer to the "Ease of use and comfort - Fittings"

section.

237

PEUGEOT i-Connect Advanced - PEUGEOT i-Connect

The mobile device is in charging mode when

connected with the USB cable.

It is recommended that you use your

device's original USB cables, preferably

with a short cable to ensure optimum

performance.

To protect the system, do not use a USB

hub.

Bluetooth

connection

Connecting a mobile device to the vehicle's

system via Bluetooth

provides access to its

contents and its "Media" streaming. It also

enables the Phone function to be activated.

The connection can be initiated either from the

mobile device's Bluetooth

menu or from the

vehicle's system, which requires opening the "My

Devices" menu for the first connection.

In some cases, you will need to unlock

your device and check the authorisation

to synchronise contacts and recent calls.

Some features may not be supported by your

device.

For information on the partial or full

compatibility of device models or

smartphones, please connect to the Brand’s

national website.

Pairing procedure from a device

From the Bluetooth

menu on your mobile

device, select the system’s name from the

list of detected devices.

In order to make your system’s

Bluetooth

visible, first open the "

Devices

" menu on the system.

Continue the first connection procedure

proposed by the system and on the device.

For example: validating pairing codes.

Pairing procedure from the system

Press the "

Settings

" application.

In the list, select the "

Connectivity

" tab.

Select "

My Devices

Select the name of the mobile device that

you want to connect, from:

– The list of known devices (if the device has

already been connected to the system).

– The list of detected devices (if the device

has never been connected to the system or

previously deleted from the system).

A mobile device already connected to the

system will be able to reconnect

automatically when the vehicle is started,

once the user profile has been selected.

Automatic reconnection is put on hold as

soon as the "My Devices" menu is opened.

This is to allow the system to make its

Bluetooth

visible for the connection of a new

device.

The system is disconnected when the driver’s

door is opened and the ignition is switched

off.

Automatic reconnection

The system allows automatic reconnection of

devices already connected and detected when a

user profile is selected.

The priority reconnected devices are those which

have been linked to the selected user profile or,

failing this, the last connected devices.

Wi-Fi connection

The system has an external Wi-Fi connection

mode for performing system updates.

Press the "

Settings

" application.

In the list, select the "

Connectivity

" tab.

Select "

Wi-Fi

Activate/Deactivate "

Wi-Fi

The system starts a search for

nearby Wi-Fi networks. This may take a few

seconds.

Select the Wi-Fi network to connect to and enter

its password.

To protect your system, only networks

with a sufficient level of security are

238

PEUGEOT i-Connect Advanced - PEUGEOT i-Connect

allowed to connect. WPA2 encryption level,

equivalent to a domestic level, is required.

Any network already connected to the

system will reconnect automatically as

soon as it is detected by the system and after

having previously activated the Wi-Fi function.

The Wi-Fi connection of the system to a

device already connected using a Mirror

Screen

wireless connection is not possible.

In this case, favour a Mirror

Screen

connection using the USB socket.

Device management

For each device already connected to the

system using a wireless connection (Bluetooth

or wireless Mirror Screen

connection), it is

possible to determine a preferred connection

mode (depending on the functions the device

can support). It is therefore possible to determine

whether the device should be connected using

a wireless Bluetooth

connection or a wireless

Mirror Screen

connection each time the system

is started once the profile is chosen.

Press the "

Settings

" application.

In the list, select the "

Connectivity

Select "

My Devices

" to display the list of

paired devices.

Press this button to manage the

connection of a device.

Choose a connection type then confirm this

choice by pressing “

APPLY

Deleting a device

Press the "

Settings

" application.

In the list, select the "

Connectivity

Select "

My Devices

" to display the list of

paired devices.

Press this button.

Press "

DELETE

Confirm by pressing “

YES

”.

Some devices that have just been

deleted from the system request a

connection, refuse this request.

Mirror Screen

When a smartphone is connected using

Mirror Screen

, the vehicle's location and

some vehicle data is sent to the smartphone

(e.g. brand, left-hand or right-hand drive, day/

night mode, physical speed).

Apple

CarPlay

smartphone

connection

Connecting just one Apple

CarPlay

smartphone

can be carried out either by USB cable or using

a wireless connection.

First activate the Siri

function on your

Apple

smartphone.

If the device fails to connect, refer to the

Apple website to check that the device is

compatible with this function.

If the problem persists, delete all saved

connections on the smartphone and on the

system before attempting a new connection.

The cable connection requires that you

deactivate the CarPlay function in the

Settings

Bluetooth

menu of your smartphone.

In the

Bluetooth

menu, click on the "

" next to

the relevant vehicle and deactivate CarPlay.

Connect the smartphone to the system

using the USB socket compatible with

Mirror Screen.

Apple

CarPlay

is automatically launched a few

seconds after the USB connection has been

established. In some cases, it may be necessary

to unlock your device.

The smartphone charges when connected by the

USB cable.

The cable connection allows you to avoid

disconnections, especially when passing through

toll booths.

Only one USB socket enables the Mirror

Screen

connection (Apple

CarPlay

);

refer to the "Ease of use and comfort

- Fittings" section.

It is recommended that you use the device's

original USB cables, preferably with a short

cable to ensure optimum performance.

239

PEUGEOT i-Connect Advanced - PEUGEOT i-Connect

The wireless connection of an Apple

CarPlay

smartphone can be initiated from the "

Devices

" menu.

First activate the smartphone’s CarPlay

function.

In the

Bluetooth

menu, click on the "

" next to

the relevant vehicle and activate CarPlay.

Press the "

Settings

" application.

In the list, select the "

Connectivity

Select "

My Devices

" to display the device

to be connected to Apple

CarPlay

If the device has already been connected to the

system via Bluetooth

, select the device settings

from the list of known devices and choose

Apple

CarPlay

as the wireless connection

mode.

If the device has never been connected to the

system before, it will have to be paired (refer to

the "Bluetooth

connection" section).

The system detects if the smartphone is

compatible with Apple

CarPlay

and offers to

connect to it following the pairing process.

Subsequent automatic connection of the

smartphone requires activation of the Bluetooth

on your device.

As soon as the connection is established,

press this button to display the

Apple

CarPlay

" interface.

To initiate the smartphone voice

commands, press and hold the steering-

mounted control button.

Android Auto smartphone

connection

Connecting just one Android Auto smartphone

can be carried out either by USB cable or using

a wireless connection.

First install the "

Android Auto

application via "Play Store" on your

smartphone.

The "

Android Auto

" function requires a

compatible smartphone.

If the device fails to connect, refer to the

Android Auto website to check that the device

is compatible with this function.

If the problem persists, delete all saved

connections on the smartphone and on the

system before attempting a new connection.

To ensure an optimum wireless connection,

we recommend avoiding placing your

smartphone too close to other Wi-Fi networks

to which it can connect automatically.

The cable connection requires that you

deactivate the Android Auto wireless function,

in the

Settings

menu of the "

Android Auto

application of your smartphone.

Connect the smartphone to the system

using the USB socket compatible with

Mirror Screen

Android Auto is automatically launched a few

seconds after the USB connection has been

established. A validation procedure on the

smartphone has to be followed for the first

connection, with the vehicle stationary.

The smartphone charges when connected by the

USB cable.

The cable connection allows you to avoid

disconnections, especially when passing through

toll booths.

Only one USB socket enables the Mirror

Screen

connection (Android Auto); refer

to the "Ease of use and comfort - Fittings"

section.

It is recommended that you use the device's

original USB cables, preferably with a short

cable to ensure optimum performance.

The wireless connection of an Android Auto

smartphone can be initiated from the "

Devices

" menu.

First activate the smartphone’s Android Auto

wireless function, in the

Settings

menu of the

Android Auto

" application of your smartphone.

Press the "

Settings

" application.

In the list, select the "

Connectivity

" tab.

Select "

My Devices

" to display the device

to be connected to Android Auto.

If the device has never been connected to the

system before, it will have to be paired (refer to

the "Bluetooth

connection" section).

The system detects if the smartphone is

compatible with Android Auto and offers to

connect to it following the pairing process.

240

PEUGEOT i-Connect Advanced - PEUGEOT i-Connect

If the device has already been connected to the

system via Bluetooth

, select the device settings

from the list of known devices and choose

Android Auto as the wireless connection mode.

The subsequent automatic connection of the

smartphone requires activation of Bluetooth

your device.

As soon as the connection is established,

press this button to display the "

Android

Auto

" interface.

To initiate the smartphone voice

commands, press and hold the steering-

mounted control button.

Media

Changing source

Press the "

Media

" application.

Press this button to change source (radio,

audio streaming via a USB socket,

Bluetooth

or Mirror Screen

Selecting a radio station

Press the "

Media

" application.

In the list, select the "

Player

" tab.

Press one of the buttons to

perform an automatic search for

radio stations.

Move the slider to manually search for

frequencies up or down.

Press this button.

Enter the frequency values using the

virtual keypad.

Press this button to confirm.

A list of stations is available by pressing the

“

Stations

” tab.

Press “

Mute

” to activate/deactivate the

sound.

Radio reception may be affected by the

use of electrical equipment not approved

by the Brand, such as a charger with USB

socket connected to the 12 V socket.

The exterior environment (hills, buildings,

tunnels, basement car parks, etc.) may block

reception, including in RDS mode. This

phenomenon is normal in the propagation

of radio waves and does not indicate any

malfunction of the system.

Storing a radio station

Select a station.

Press the "

Media

" application.

In the list, select the "

Player

” tab.

Press the "

Radio Favorites

" button.

Storing takes place via a short or long

press on one of these buttons, or a long

press on an existing favourite radio station,

which will be replaced.

Press this button to return to the previous

page.

Automatic search for radio

stations

Via the

"Media"

application.

Press the "

Media

" application.

In the list, select the "

Stations

" tab.

The search is carried out automatically.

Using the steering-mounted

controls, press and hold this

button.

The search is carried out automatically.

Activating radio station

tracking

The system changes frequency automatically to

obtain better reception.

Press the "

Media

" application.

In the list, select the "

Settings

” tab.

Activate “

Radio Station Tracking

”.

The lighting of the slider confirms that the

function is activated.

241

PEUGEOT i-Connect Advanced - PEUGEOT i-Connect

Changing the waveband

Press the "

Media

" application.

In the list, select the "

Player

" tab.

Press this button to change the waveband

(FM - AM - DAB) according to the country

of sale.

Activating traffic

announcements

This function gives priority to listening to

Traffic

announcements

alert messages. To be active,

this function needs good reception of a radio

station that transmits this type of message.

While traffic information is being broadcast, the

current radio station is automatically interrupted

so that the message can be heard. Normal radio

listening resumes as soon as the message is

finished.

Press the "

Media

" application.

In the list, select the "

Settings

” tab.

Activate “

Traffic Announcement (TA)

”.

The lighting of the slider confirms that the

function is activated.

Audio streaming

The streaming function allows you to listen to

the audio stream coming from the smartphone(s)

connected via Bluetooth

, USB (iPod

type) or

Mirror Screen

First adjust the volume on the portable device (to

a high level).

Then adjust the volume of the system.

If playback does not start, it may be necessary to

start the audio playback from the smartphone.

Control is from the portable device or by using

the system's touch buttons.

Once connected in streaming mode, the

smartphone is considered to be a media

source.

Playing a track

Press the "

Media

" application.

If several devices are connected, press

this button to select one.

Once the device is connected, browsing through

the files is possible by pressing the "

Playlist

" or

Library

" button.

Short press: go to the previous/

next track.

Long press: fast-forward/rewind in a track.

Repeat the current title or the list of

selected titles.

Random track playback.

Sound deactivation/reactivation.

Configuring audio and radio

settings

Audio settings can be accessed in 2 different

ways.

Via the

Media

application

Press the "

Media

" application.

In the list, select the "

Settings

" tab.

Via the

Settings

application

Press the "

Settings

" application.

In the list, select the "

Audio and Radio

" tab.

It is possible to configure:

– Sound Settings.

– Radio Settings.

– Volume Settings.

Information and advice

The system supports USB Mass Storage devices

or Apple

devices via the USB sockets. The

adapter cable is not supplied.

Devices are managed using the audio system

controls.

The system will only play audio files with ".wma,

.aac, .flac, .ogg, .mp3" file extensions, at bit rates

between 32 Kbps and 320 Kbps.

It also supports VBR (Variable Bit Rate) mode.

No other file types (".mp4", etc.) can be read.

".wma" files must be of the WMA 9 standard.

The supported sampling rates are 32, 44 and

48 KHz.

242

PEUGEOT i-Connect Advanced - PEUGEOT i-Connect

To avoid reading and display problems, we

recommend choosing file names less than 20

characters long that do not contain any special

characters (e.g. “ ? . ; ù).

Use only USB memory sticks in FAT32 format

(File Allocation Table).

We recommend using the original USB

cable for the portable device.

Phone

Receiving a call

An incoming call is announced by a ring and a

display overlaid on the screen.

Accepting the call:

briefly press the telephone button on the

steering-mounted controls to accept an

incoming call.

Press this touch screen button.

Ending the call:

press and hold...

...the telephone button on the steering-

mounted controls to refuse the call.

Press this touch screen button.

Press this button on the touch screen to

send an automatic message indicating

that you are driving.

Making a call

Using the telephone is strongly

discouraged while driving.

Park the vehicle.

Making a call using the numeric

keypad

Press the "

Phone

" application.

In the list, select the “

Keypad

” tab then dial the

number.

Press this button to make the call.

Making a call using the list of recent

calls

Press the "

Phone

" application.

In the list, select the "

Calls

" tab.

Briefly press...

...the telephone button on the steering-

mounted controls.

Select and call one of the most recent numbers

called in the list.

It is always possible to make a call

directly from the telephone; as a safety

measure, first park the vehicle.

Calling a contact

Press the "

Phone

" application.

In the list, select the "

Contacts

” tab.

Select the desired contact in the displayed list.

Call the contact by selecting one of the

contact's phone numbers.

Organising the contact list

Press the "

Phone

" application.

In the list, select the “

Settings

” tab to display the

telephone-related settings.

Choose to list the contacts starting with

their first or last name.

Connecting two phones

The system allows two phones to be

connected simultaneously:

– 2 via Bluetooth

connection.

– 1 via Bluetooth

connection and 1 via Mirror

Screen

connection.

Display and content priority is given to the last

phone used.

To change the priority of the phone:

243

PEUGEOT i-Connect Advanced - PEUGEOT i-Connect

Press the "

Phone

" application.

Press this button to change the priority of

the phone.

Settings

Configuring the screen

display

Press the "

Settings

" application.

In the list, select the "

Customization

" tab.

It is possible to configure:

– the screen colours associated with the interior

ambient lighting. Refer to the "Ease of use and

comfort" section.

– the sound ambience.

– the visual welcome and goodbye animations.

– the screen transition animations.

Managing the system

connectivity

Press the "

Settings

" application.

In the list, select the "

Connectivity

" tab.

It is possible to manage:

– The Bluetooth

connection.

– The Mirror Screen

smartphone connections

(Apple

CarPlay

/Android Auto).

– The Wi-Fi connection.

– The privacy mode.

Configuring the system

Press the "

Settings

" application.

In the list, select the "

System

” tab.

It is possible to configure:

– the language.

– the date & time.

– the unit of distance and consumption

(kWh/100 miles - miles, mi/kWh - miles, km/kWh

- km).

– the temperature unit (Fahrenheit, Celsius).

It is also possible to reset the system

configuration.

Selecting the language

Select "

Language

" to change the

language.

Press the desired language.

Press the back arrow to return to the

previous page.

Setting the date and time

Select “

Date and Time

” to modify the date and

time.

“

Automatic Date and Time

” is activated

by default, so that the setting is made

automatically according to your geolocation.

To adjust manually, deactivate “

Automatic Date

and Time

”.

Press the “

Select Time Zone

” field then define

a time zone.

Press the back arrow to return to the

previous page.

Press the “

Time Settings

” line then set the time.

Press "

" to confirm.

Press the “

Date

” line then set the date.

Press "

" to confirm.

Select the Time Format (12h/24h).

Select the Date Format.

The system does not automatically

change between winter and summer time

(depending on the country of sale).

Help

Press the "

Help

" application.

In the list, select the “

User Manual

” tab to

consult the vehicle’s handbook.

In the list, select the “

Tutorials

” tab to watch

explanatory videos for a quick start on screen

management, certain driving aids and voice

recognition.

User Manual

Select the display language.

The handbook home page is displayed.

244

PEUGEOT i-Connect Advanced - PEUGEOT i-Connect

It presents the different possibilities for accessing

the information sought:

Visual search

Access to subjects via pictures

representing the exterior and interior of the

vehicle.

Indicator lamps

Access to the descriptions/operation of

the instrument panel warning/indicator lamps.

System

Access to sections dedicated to the

various audio equipment and telematics

systems.

Contents

Access to subjects via the main sections

of the handbook.

Visual search

Press

Visual search

Press one of the pictures located at the bottom

of the screen.

Press one of the bullet points in the

enlarged view.

There are two cases:

– Direct display of the subject, if only one

subject is associated with the bullet point.

– Display of a list of subjects, if several subjects

are associated with the bullet point.

Indicator lamps

Press

Indicator lamps

The mosaic of warning/indicator lamps is

displayed.

The warning/indicator lamps are sorted by

colour.

Press the warning/indicator lamp concerned; the

corresponding content is displayed.

Back to the mosaic of warning/indicator

lamps.

System

Press

System

The list of audio and telematics systems is

displayed.

Press on the section concerned; the list of

subjects is displayed.

Press on the subject concerned;

the corresponding content is displayed.

If the subject has more than one page,

drag horizontally.

Back to the list of subjects.

Contents

Press

Contents

The list of sections is displayed.

Press on the section concerned; the list of

subjects is displayed.

Press on the subject concerned;

the corresponding content is displayed.

If the subject has more than one page,

drag horizontally.

Back to the list of subjects.

245

Vehicle data recording and privacy

Vehicle data recording

and privacy

Electronic control units are installed in your

vehicle. These control units process data

received from the vehicle's sensors, for example,

or data they generate themselves or exchange

with each other. Some of these control units are

required for the correct operation of your vehicle,

some others assist you while driving (driving or

manoeuvring aids), while others provide comfort

or infotainment functions.

The following contains general information about

how data is processed within the vehicle.

You will find additional information about the

specific data which is downloaded, stored

and transmitted to third parties and what it is

used for in your vehicle under the keyword

"Data protection". This information is directly

associated with the references for the functions

in question contained in the corresponding

vehicle handbook, or in the general terms and

conditions of sale.

This information is also available online.

Vehicle operating data

The control units process the data used for the

operation of the vehicle.

This data includes, for example:

– Information about the state of the vehicle

(e.g. speed, travel time, lateral acceleration,

wheel rotation rate, fastened seat belts display).

– Environmental conditions (e.g. temperature,

rain sensor, distance sensor).

As a general rule, this data is temporary, is

not stored for longer than one operating cycle

and is only used within the vehicle itself. The

control units often record this data (including the

vehicle's key). This function allows either the

temporary or permanent storage of information

about the state of the vehicle, stresses on

components, servicing requirements, as well as

events and technical errors.

Depending on the vehicle's equipment level, the

data stored is as follows:

– Operating state of system components

(e.g. filling level, tyre pressures, battery charge

status).

– Faults and malfunctions in important system

components (e.g. lamps, brakes).

– System reactions in specific driving situations

(e.g. deployment of an airbag, triggering of

stability control and braking systems).

– Information about events which have

damaged the vehicle.

– For electric and rechargeable hybrid vehicles,

the traction battery charge level and the

estimated driving range.

In particular circumstances (e.g. if the vehicle

has detected a malfunction), it may be necessary

to record data which would otherwise simply not

be stored.

When taking your vehicle in for servicing

(e.g. repairs, maintenance), the stored operating

data may be read along with the vehicle's

identification number and used if necessary.

The personnel working for the servicing network

(e.g. garages, manufacturers) or third parties

(e.g. roadside assistance agents) may read

the vehicle's data. This also applies to work

carried out under warranty and quality assurance

measures.

This data is generally read via the OBD

(On-Board Diagnostics) port fitted by law to

the vehicle. It is used to report on the technical

state of the vehicle or its components and

facilitates the diagnosis of malfunctions, in

compliance with warranty obligations and for

quality improvement. This data, in particular the

information relating to stress on components,

technical events, operator errors and other

malfunctions, is sent to the Manufacturer, if

necessary, along with the vehicle's identification

number. The Manufacturer's liability may also be

engaged. The Manufacturer may also use the

operating data taken from the vehicle for product

recalls. This data may also be used to check the

customer's warranty and any claims made under

warranty.

Any malfunctions stored in the vehicle may be

reset by an after-sales service company during

servicing or repair work, or at your request.

246

Vehicle data recording and privacy

Comfort and infotainment

functions

Comfort settings and personalised settings

may be saved in the vehicle and modified or

reinitialised at any time.

Depending on the vehicle's equipment level, this

may include:

– Seat and steering wheel position settings.

– Chassis and air conditioning settings.

– Personalised settings such as the interior

lighting.

You can enter your own data into the functions

of your vehicle's audio and telematic system, as

part of the selected functionalities.

Depending on the vehicle's equipment level, this

may include:

– Multimedia data such as music, videos or

photos to be read by an integrated multimedia

system.

– Address book data to be used with an

integrated hands-free system or with an

integrated navigation system.

– Entered destinations.

– Data regarding the use of online services.

This data for the comfort and infotainment

functions may be stored locally in the vehicle

or saved to a device that you have connected

to the vehicle (e.g. smartphone, USB memory

stick or MP3 player). Data that you have entered

yourself may be deleted at any time.

This data may also be transmitted outside the

vehicle at your request, particularly when using

online services in line with the settings that you

have selected.

Smartphone integration

(e.g. Android Auto

Apple

CarPlay

)

If your vehicle is equipped accordingly, you can

connect your smartphone or another mobile

device to the vehicle in order to operate it using

the vehicle's integrated controls. Images and

sounds from the smartphone can be transmitted

through the audio and telematics system.

Specific information is simultaneously sent

to your smartphone. Depending on the type

of integration, this includes data such as location,

day/night mode and other general information

about the vehicle. For more information, please

refer to the user instructions for the vehicle or the

audio and telematics system.

Integrating a smartphone allows you to use

its applications, such as a navigation app or

music player. No other integration between

the smartphone and the vehicle is possible, in

particular active access to vehicle data. How the

data is processed subsequently is determined

by the supplier of the application being used.

The ability the change settings depends on the

application in question and on the operating

system installed on your smartphone.

Online services

If your vehicle is connected to a wireless

network, data can be exchanged between

your vehicle and other systems. Connection

to a wireless network is made possible via a

transmitter located in your vehicle or a mobile

device that you have provided (e.g. smartphone).

The online services can be used via this wireless

connection. These include online services and

applications (apps) provided to you by the

Manufacturer or other suppliers.

Exclusive services

As regards the Manufacturer's online services,

the corresponding functions are described by

the Manufacturer in an appropriate medium

(e.g. handbook, Manufacturer's website) and the

information about data protection is provided.

Personal data may be used for online services.

The exchange of data for this purpose takes

place over a secure connection, using for

example the Manufacturer's dedicated computer

systems. The collection, processing and use of

personal data for the development of services

are carried out solely on the basis of a legal

authorisation, for example in the case of a

legal emergency call system or a contractual

agreement or else under a consent agreement.

You can activate or deactivate the services and

functions (some may be chargeable) and, in

some cases, the vehicle's entire connection to

the wireless network. This does not include the

Peugeot 308 (2024 year). Manual in english - page 8
