Practical information

- The towball must not be able to move in

Maintenance

its carrier; test by attempting to shake it with

Correct operation is only possible if the towball

your hand.

and its carrier are kept clean.

If the towball is not locked, the trailer can

Before cleaning the vehicle with a high-pressure

become detached - risk of an accident!

jet wash, the towball must be removed and the

protective plug fitted to the carrier.

During use

Work on the towing device

Never release the locking system with a

Contact a PEUGEOT dealer or a

trailer or load carrier on the towball.

qualified workshop.

Never exceed the maximum authorised

weight for the vehicle - the Gross Train

► The wheel 6 rotates a quarter turn anti-

Weight or GTW.

Fitting the towball

clockwise; take care to keep your hands clear!

Always comply with the maximum authorised

load on the towing device: if it is exceeded,

this device may become detached from the

vehicle - risk of an accident!

Before driving, check the headlamp height

adjustment and check that the lamps on the

trailer operate correctly.

For more information on Headlamp height

adjustment, refer to the corresponding

section.

After use

► Below the rear bumper, remove the protective

► Check that the mechanism has correctly

When travelling without a trailer or

plug 2 from the carrier 1.

locked into place (position A).

load carrier, remove the towball and fit the

► Insert the end of the towball 5 into the carrier

► Close the lock 7 using the key.

protective plug into the carrier, to provide

1 and push it upwards; it will lock into position

► Remove the key. The key cannot be removed

clear visibility of the number plate and/or its

automatically.

while the lock is open.

lighting. Also, the connection socket must be

► Clip the cap onto the lock.

tilted to the top position to avoid damaging the

equipment while driving.

161

Practical information

► Remove the protective cover from the

► Insert the key into the lock 7.

► Replace the protective plug 2 into the

towball.

► Open the lock using the key.

carrier 1.

► Attach the trailer to the towball.

► Stow the towball in its bag to protect it from

► Attach the cable on the trailer to the safety

knocks and dirt.

eye 4 on the carrier.

► Insert the trailer plug and rotate it by a

Roof bars

quarter turn to connect it to the connection

socket 3 on the carrier.

As a safety measure and to avoid

damaging the roof, it is essential to use

Removing the towball

transverse roof bars approved for your

► Grasp the trailer's plug, perform a quarter

vehicle.

turn and pull to disconnect it from the connection

Observe the instructions on fitting and use

socket 3 on the carrier.

contained in the guide supplied with the roof

► Detach the trailer's safety cable from the

► Hold the towball 5 firmly in one hand; using

bars.

safety eye 4 on the carrier.

the other hand, pull and turn the wheel 6 fully in

► Unhitch the trailer from the towball.

a clockwise direction until it stops; do not release

Maximum load distributed over the roof

► Replace the protective cover over the towball.

the wheel.

bars, for a loading height not exceeding

► Remove the cap from the lock and press it

► Extract the towball from the base of its

40 cm: 70 kg.

onto the head of the key.

carrier 1.

As this value may change, please verify the

► Release the wheel; it automatically locks in

maximum load quoted in the guide supplied

the unlocked position (position B).

with the roof bars.

162

Practical information

If the height exceeds 40 cm, adapt the speed

Direct fitting on roof

Observe the legislation in force in your

of the vehicle to the profile of the road to

country relating to the use of snow

avoid damaging the roof bars and the fixings

chains and maximum authorised speeds.

on the vehicle.

Only use chains that have been designed to be

Be sure to refer to national legislation in order

fitted on the type of wheel on the vehicle:

to comply with the regulations for transporting

objects that are longer than the vehicle.

Original tyre size

Maximum link size

195/55 R16

9 mm (Polaire XP9)

Recommendations

Distribute the load uniformly, taking care

205/45 R17

Cannot be fitted with

to avoid overloading one of the sides.

chains

Arrange the heaviest part of the load as close

For more information on snow chains, contact a

as possible to the roof.

PEUGEOT dealer or a qualified workshop.

The transverse bars must only be fixed at the

Secure the load firmly.

four anchorage points located on the roof frame.

Drive gently: the vehicle will be more

Installation tips

These points are concealed by the vehicle doors

susceptible to the effects of side winds and its

► To fit the snow chains during a journey, stop

when the doors are closed.

stability may be affected.

the vehicle on a flat surface at the side of the

The roof bar fixings have a stud which must be

Regularly check the security and tight

road.

inserted into the opening of each anchorage

fastening of the roof bars, at least before each

► Apply the parking brake and position any

point.

trip.

wheel chocks under the wheels to prevent

Remove the roof bars once they are no longer

movement of the vehicle.

needed.

Snow chains

► Fit the snow chains following the instructions

In wintry conditions, snow chains improve

provided by the manufacturer.

traction as well as the behaviour of the vehicle

► Move off gently and drive for a few moments,

when braking.

without exceeding 31 mph (50 km/h).

► Stop the vehicle and check that the snow

Snow chains must be fitted only to the

chains are correctly tightened.

front wheels.

They must never be fitted to "space-saver"

It is strongly recommended that you

type spare wheels.

practise fitting the snow chains on a level

and dry surface before setting off.

163

Practical information

Avoid driving with snow chains on roads

Fitting

► Check that the unit is held firmly in place by

that have been cleared of snow to avoid

pressing around the edges.

Upper/side very cold climate screens

damaging the vehicle's tyres and the road

Repeat the same steps for the other upper

surface. If the vehicle is fitted with alloy

screen, then for the side screen in the grille

wheels, check that no part of the chain or its

below the number plate.

fixings is in contact with the wheel rim.

Lower very cold climate screen

► Place the lower screen against the lower

bumper grille.

Very cold climate screens

► Insert the mounting tabs into the bumper until

(Depending on engine and on country of sale)

they are all properly seated.

This removable device prevents the

► Check that the unit is held firmly in place by

accumulation of snow around the radiator

When fitting for the first time, adapt the 2

pressing around the edges.

cooling fan.

upper very cold climate screens to the

It consists of two elements for the upper part of

vehicle's grille type:

Removing

the front grille and two other elements for the

- Grille A, "MAINSTREAM" (MS) type.

For the lower and side very cold climate

lower part.

- Grille B, "UPPER" (UP) type.

screen

In case of difficulty with installation/

removal

Contact a PEUGEOT dealer or a qualified

workshop.

Before any operation, ensure that the

engine is off and the cooling fan has

stopped.

► Place one of the upper screens against the

It is essential to remove them when:

corresponding side of the upper bumper grille.

- the outside temperature exceeds

► First insert the upper mounting tabs into the

10°C.

bumper.

- recovery is in progress.

► Tilt the screen downwards until the lower

► Insert a screwdriver into the slots located on

– the speed is above 75 mph (120 km/h).

mounting tabs are properly seated in the bumper

the top of the lower screen and side screen to

(press on each tab to ensure it clicks into place).

detach them from the grille.

164

Practical information

► Gently tilt the upper screen and side screen

telematics system, dipped beam headlamps or

Load reduction mode

downwards.

courtesy lamps.

This system manages the use of certain

► Pull the unit towards you and support it as it

becomes unclipped.

Selecting the mode

functions according to the level of charge

remaining in the battery.

For the upper very cold climate screens

A confirmation message is displayed when

When the vehicle is being driven, the load

energy economy mode is entered, and the active

reduction function temporarily deactivates certain

functions are placed on standby.

functions, such as the air conditioning and the

If a telephone call is in progress at the

heated rear screen.

time, it will be maintained for around 10

The deactivated functions are reactivated

minutes via the audio system’s hands-free

automatically as soon as conditions permit.

system.

Bonnet

Exiting the mode

Stop & Start / e-Auto mode

These functions are automatically reactivated the

Before doing anything under the bonnet,

next time the vehicle is used.

you must switch off the ignition to avoid any

To restore the use of these functions

risk of the engine restarting automatically.

immediately, start the engine and let it run:

Take care with objects or clothing that could

► Press the lower mounting lugs to release

- For less than 10 minutes, to use the

be caught in the blades of the cooling fan

them from the grille.

equipment for approximately 5 minutes.

or in certain moving components - risk of

► Gently tilt the upper screen upwards.

- For more than 10 minutes, to use the

strangulation and serious injury!

► Pull the unit towards you and support it as it

equipment for approximately 30 minutes.

becomes unclipped.

Let the engine run for the specified duration to

ensure that the battery charge is sufficient.

To recharge the battery, avoid repeatedly or

Energy economy mode

continuously restarting the engine.

This system manages the duration of use of

A flat battery prevents the engine from

Electric motor

certain functions, in order to conserve a sufficient

starting.

Take care with objects or clothing that

level of charge in the battery with the ignition off.

For more information on the 12 V battery,

could be caught in the blades of the cooling

After switching off the engine and for a maximum

refer to the corresponding section.

fan or in certain moving components - risk of

cumulative period of around 30 minutes, you can

strangulation and serious injury!

continue to use functions such as the audio and

165

Practical information

Before carrying out any work under the

Opening

Closing

bonnet, you must switch off the ignition, check

► Open the left-hand front door.

► Hold the bonnet and pull out the stay from the

that the READY indicator lamp is off on the

support slot.

instrument panel and disconnect the nozzle

► Clip the stay in its housing.

from the charging connector if it is connected.

► Lower the bonnet and release it near the end

of its travel.

► Pull on the bonnet to check that it is locked

correctly.

Because of the presence of electrical

equipment under the bonnet, it is strongly

The location of the interior bonnet

recommended that exposure to water (rain,

release lever prevents the bonnet being

► Pull the interior release lever, located at the

washing, etc.) be limited.

opened when the left-hand front door is

bottom of the door frame, towards you.

closed.

Engine compartment

The engine shown here is an example for

When the engine is hot, handle the

illustrative purposes only.

exterior safety catch and the bonnet stay

The locations of the following components may

with care (risk of burns), using the protected

vary:

area.

- Air filter.

When the bonnet is open, take care not to

- Engine oil dipstick.

damage the safety catch.

- Engine oil filler cap.

Do not open the bonnet under very windy

conditions.

Petrol engine

Cooling of the engine when stopped

► Lift the exterior safety catch and raise the

The engine cooling fan may start after

bonnet.

the engine has been switched off.

► Unclip the stay from its housing and place it

Take care with objects or clothing that

in the support slot to hold the bonnet open.

could be caught in the blades of the fan!

166

Practical information

1. Screenwash fluid reservoir

Checking levels

Engine oil

2. Engine coolant reservoir

The level is checked, with the engine

Check all of the following levels regularly in

3. Brake fluid reservoir

having been switched off for at least 30

accordance with the Manufacturer's service

4. Battery/Fuses

minutes and on level ground, either using the oil

schedule. Top them up if required, unless

5. Fusebox

level indicator in the instrument panel when the

otherwise indicated.

6. Air filter

ignition is switched on (for vehicles equipped

If a level drops significantly, have the

7. Engine oil filler cap

with an electric gauge), or using the dipstick.

corresponding system checked by a PEUGEOT

8. Engine oil dipstick

It is normal to top up the oil level between two

dealer or a qualified workshop.

services (or oil changes). It is recommended

Electric motor

The fluids must comply with the

that you check the level, and top up if necessary,

Manufacturer's requirements and with

every 3,000 miles (5,000 km).

the vehicle's engine.

In order to maintain the reliability of the

engine and emissions control system,

Take care when working under the

never use additives in the engine oil.

bonnet, as certain areas of the engine

may be extremely hot (risk of burns) and the

cooling fan could start at any time (even with

Checking using the dipstick

the ignition off).

For the location of the dipstick, please refer

1. Screenwash fluid reservoir

to the illustration of the corresponding engine

2. Engine coolant reservoir (level only)

compartment.

Used products

3. Brake fluid reservoir

► Grasp the dipstick by its coloured grip and

4. Battery/Fuses

Avoid prolonged contact of used oil or

pull it out completely.

5. Fusebox

fluids with the skin.

► Wipe the end of the dipstick using a clean,

400 V electrical circuit

Most of these fluids are harmful to health and

lint-free cloth.

7. Emergency circuit-breaker for emergency

very corrosive.

services and maintenance technicians

For more information on the Charging system

Do not discard used oil or fluids into

(Electric), refer to the corresponding section.

sewers or onto the ground.

Empty used oil into the containers reserved

for this purpose at a PEUGEOT dealer or a

qualified workshop.

► Reinsert the dipstick and push fully down,

then pull it out again to visually check the oil

167

Practical information

level: the correct level is between marks A (max)

► After checking the level, carefully screw the

The check and top-up must only be done with

and B (min).

oil filler cap back on and push the dipstick back

the engine cold.

Do not start the engine if the level is:

into its tube up to the stop.

A level of coolant that is too low risks causing

- above mark A: contact a PEUGEOT dealer or

major damage to the engine; the coolant level

The dipstick must be pushed completely

a qualified workshop.

must be close to the "MAX" mark without ever

in to prevent oil from spilling onto the

- below mark B: top up the engine oil

going above it.

engine. Risk of fire inside the engine

immediately.

If the level is close to or below the "MIN" mark, it

compartment.

is essential to top it up.

Oil grade

When the engine is hot, the temperature of the

Before topping up or changing the

The oil level indication displayed on the

coolant is regulated by the fan.

engine oil, check that the oil is suitable

instrument panel when the ignition is

As the cooling system is pressurised, wait at

for your engine and complies with the

switched on is not valid for 30 minutes

least one hour after switching off the engine

recommendations in the service schedule

following an addition of oil.

before carrying out any work.

supplied with the vehicle (or available

In order to avoid the risk of scalding if you need

from your PEUGEOT dealer or qualified

to top up in an emergency, wrap a cloth around

workshop).

Brake fluid

the cap and unscrew the cap by two turns to

Use of non-recommended oil may invalidate

The level of this fluid should be close to

allow the pressure to drop.

your warranty in the event of engine failure.

the "MAX" mark. If not, check the brake

Once the pressure has dropped, remove the cap

pads for wear.

and top up to the required level.

To know how often the brake fluid should be

Topping up the engine oil level

replaced, refer to the manufacturer's servicing

For electric versions

For the location of the engine oil filler cap, please

schedule.

Do not top up the coolant.

refer to the corresponding engine compartment

illustration.

Clean the cap before removing it to refill.

Use only DOT4 brake fluid from a sealed

Never remove the oil filler cap with the

container.

engine running. Risk of burns and

splashes inside the engine compartment.

Engine coolant

► Add oil in small quantities, avoiding any spills

If the level is close to or below

on engine components (risk of fire).

For petrol or hybrid versions

the "MIN" mark, it is essential to contact a

► Wait a few minutes before checking the level

It is normal to top up this fluid between

PEUGEOT dealer or a qualified workshop.

again using the dipstick.

two services.

► Top up the level if necessary.

168

Practical information

Screenwash fluid

12 V battery

Air filter

Top up to the required level when

The battery does not require any

Depending on the environment and the

necessary.

maintenance.

use of the vehicle (e.g. dusty atmosphere,

Check regularly that the terminals are correctly

city driving), change it twice as often, if

Fluid specification

tightened (versions without quick-release

necessary.

The fluid must be topped up with a pre-mixed

terminals) and that the connections are clean.

product.

Oil filter

For more information on the precautions

In winter (temperatures below zero), a fluid

Change the oil filter each time the engine

to take before any work on the 12 V

containing an anti-freeze agent which is

oil is changed.

battery, refer to the corresponding section.

appropriate for the temperature conditions

must be used in order to protect the system's

Manual gearbox

Versions equipped with Stop & Start are

components (pump, tank, ducts, jets).

The gearbox does not require any

fitted with a 12 V lead-acid battery with

maintenance (no oil change).

Filling with pure water is prohibited in all

special technology and specifications.

circumstances (risk of freezing,

Its replacement should be carried out only by

Automatic gearbox

limescale, etc.).

a PEUGEOT dealer or a qualified workshop.

The gearbox does not require any

maintenance (no oil change).

Passenger compartment

Checks

Manual parking brake

filter

Unless otherwise indicated, check these

If you notice excessive brake lever travel

components in accordance with the

Depending on the environment and the

or decreased effectiveness, the parking

Manufacturer's service schedule and according

use of the vehicle (e.g. dusty atmosphere,

brake must be adjusted, even between two

to your engine.

city driving), change it twice as often, if

services.

Otherwise, have them checked by a PEUGEOT

necessary.

This system must be checked by a PEUGEOT

dealer or a qualified workshop.

A clogged passenger compartment filter

dealer or a qualified workshop.

Only use products recommended by

can adversely affect air conditioning

system performance and generate

Electric parking brake

PEUGEOT or products of equivalent

quality and specification.

undesirable odours.

This system does not require any routine

In order to optimise the operation of

servicing. However, in the event of a

components as important as those in the

problem, do not hesitate to have the system

braking system, PEUGEOT selects and offers

checked by a PEUGEOT dealer or a qualified

very specific products.

workshop.

169

Practical information

For more information on the Electric

(10 kilometres) at over 31 mph (50 km/h), add

Shock absorbers

parking brake, refer to the

0.3 bar (30 kPa) to the values indicated on the

It is not easy for drivers to detect when

corresponding section.

label.

shock absorbers are worn. Nevertheless,

Under-inflation increases energy

the shock absorbers have a major impact on

Brake pads

consumption. Non-compliant tyre

road holding and braking performance.

pressures cause tyres to wear prematurely

For your safety and driving comfort, it is

Brake wear depends on the style of

and have an adverse effect on the vehicle's

important to have them regularly checked by a

driving, particularly in the case of vehicles

road holding - risk of accident!

PEUGEOT dealer or a qualified workshop.

used in town, over short distances. It may be

necessary to have the condition of the brakes

Driving with worn or damaged tyres reduces the

Timing and accessory kits

checked, even between vehicle services.

braking and road holding performance of the

The timing and accessory kits are used

Unless there is a leak in the circuit, a drop in the

vehicle. Regularly check the condition of the

from the time the engine is started until it

brake fluid level indicates that the brake pads

tyres (tread and sidewalls) and rims as well as

is switched off. It is normal for them to wear over

are worn.

the presence of the valve caps.

time.

After washing the vehicle, moisture, or in

When the wear indicators no longer appear set

A faulty timing or accessory kit can damage

wintry conditions, ice can form on the

back from the tread, the depth of the grooves is

the engine, rendering it unusable. Observe the

brake discs and pads: braking efficiency may

less than 1.6 mm; replace the tyres as soon as

recommended replacement frequency, stated in

be reduced. Gently dab the brakes to dry and

possible.

distance travelled or time elapsed, whichever is

defrost them.

Using different size wheels and tyres from those

reached first.

specified can affect the lifetime of tyres, wheel

rotation, ground clearance, the speedometer

Brake disc/drum wear

Free-wheeling

reading and have an adverse effect on road

For any information on checking brake

holding.

In certain situations, it is necessary to put the

disc/drum wear, contact a PEUGEOT

Fitting different tyres on the front and rear axles

vehicle into free-wheeling mode (e.g. towing, on

dealer or a qualified workshop.

can cause the ESC to mistime.

a rolling road, automatic car wash (Wash mode),

Always mark the direction of rotation on the tyres

rail or sea transport).

Wheels and tyres

that will be stored when fitting winter or summer

The procedure varies according to the type of

The inflation pressure of all tyres,

tyres. Store them in a cool, dry place and away

gearbox and parking brake.

including the spare wheel, must be

from direct exposure to the sun's rays.

Never leave the vehicle unattended with

checked on "cold" tyres.

Winter or 4-seasons tyres can be

the vehicle into free-wheeling mode.

The pressures indicated on the tyre pressure

identified by this symbol on their

label are valid for "cold" tyres. If you have driven

sidewalls.

for more than 10 minutes or more than 6 miles

170

Practical information

Keyless Entry and Start

With automatic gearbox

You must not depress the brake pedal

(EAT8 or Hybrid) and

(EAT8 or Hybrid) or drive

while switching the ignition on again, then

switching it off. If you do, the engine will start,

manual parking brake

selector and electric parking

requiring you to restart the procedure.

brake

With manual or EAT6

Release procedure

automatic gearbox and

► With the vehicle stationary and the engine

Release procedure

running, select mode N and switch off the

electric parking brake

► With the vehicle stationary and the engine

engine.

running, depress the brake pedal and select

Within 5 seconds:

mode N.

► Switch on the ignition.

Within 5 seconds:

To release them

► While depressing the brake pedal, move the

► Depress and hold the brake pedal, then

push selector forwards or backwards to confirm

► With the engine running and while depressing

observe this order: switch off the engine and

mode N.

the brake pedal, move the gear selector to the

move the push selector forwards or backwards.

► Switch off the ignition.

neutral position.

► Release the brake pedal, then switch on the

► While depressing the brake pedal, switch off

If the 5-second time limit is exceeded,

ignition.

the engine.

the gearbox engages mode P; it is then

► Place your foot on the brake and press the

► Release the brake pedal, then switch on the

necessary to restart the procedure.

electric parking brake control to release it.

ignition.

► Release the brake pedal, then switch off the

► While depressing the brake pedal, press the

Reverting to normal operation

ignition.

control to release the parking brake.

► Press button P on the selector.

A message is displayed on the

► Release the brake pedal, then switch off the

instrument panel to confirm the unlocking

ignition.

of the wheels for 15 minutes.

Reverting to normal operation

When the vehicle is free-wheeling, the

► While depressing the brake pedal, restart the

audio system cannot be updated (message

engine and apply the parking brake.

displayed on the instrument panel).

171

Practical information

After 15 minutes or reverting to normal

Depending on the environment, clean the

Bodywork

operation

vehicle frequently to remove salty deposits

High-gloss paint

(in coastal areas), soot (in industrial areas)

► While depressing the brake pedal, restart the

and mud/salts (in wet or cold areas). These

engine and select mode P.

Do not use abrasive products, solvents,

substances can be highly corrosive.

petrol or oil to clean the bodywork.

Contact a PEUGEOT dealer or a qualified

Never use an abrasive sponge to clean

Advice on care and

workshop for advice on removing stubborn

stubborn stains - risk of scratching the

stains requiring special products (such as tar

maintenance

paintwork!

or insect removers).

Do not apply polish in strong sunshine, or to

Preferably, have paint touch-ups performed

General recommendations

plastic or rubber parts.

by a PEUGEOT dealer or a qualified

Observe the following recommendations to avoid

workshop.

damaging the vehicle.

Use a soft cloth and soapy water or a pH

neutral product.

Exterior

Interior

Gently wipe the bodywork with a clean

Never use a high-pressure jet wash in

When washing the vehicle, never use a

microfibre cloth.

the engine compartment - risk of

water hose or high-pressure jet to clean

Apply polish with the vehicle clean and dry.

damaging the electrical components!

the interior.

Comply with the instructions for use stated on

Do not wash the vehicle in bright sunshine or

Liquids carried in cups or other open

the product.

extremely cold conditions.

containers can spill, presenting a risk of

damage to the instruments and controls and

Decals

the controls located on the centre console. Be

(Depending on version)

When washing the vehicle in an

vigilant!

automatic roller-brush car wash, be sure

Do not use a high-pressure washer to

To clean instrument panels, touch screens

to lock the doors and, depending on version,

clean the vehicle - risk of damaging or

or other displays, wipe gently with a soft,

move the electronic key away.

detaching the decals!

dry cloth. Do not use products (e.g. alcohol,

When using a pressure washer, keep the jet

disinfectant) or soapy water directly on these

nozzle at a minimum distance of 30 cm from

surfaces - risk of damage!

Use a high-flow hose (temperature

the vehicle (particularly when cleaning areas

between 25°C and 40°C).

containing chipped paint, sensors or seals).

Place the jet of water perpendicular to the

Promptly clean up any stains containing

surface to be cleaned.

chemicals liable to damage the vehicle's

Rinse the vehicle with demineralised water.

paintwork (including tree resin, bird

droppings, insect secretions, pollen and tar).

172

Practical information

Textile

Product/Procedure to use depending

Alcantara^®

on the type of stain:

The dashboard, door panels and seats may

Alcantara^® is an elegant and practical material

- Grease, oil and ink: clean with a pH-neutral

contain parts made of textile material.

which is very resistant and easy to maintain.

detergent.

Maintenance

- Vomit: clean with sparkling mineral water.

Do not use printed cloths or

- Blood: spread flour over the stain and allow

printed absorbent paper.

Do not use aggressive cleaning products

to dry; remove with a slightly damp cloth.

Do not use steam-cleaning systems.

(e.g. alcohol, solvent or ammonia).

- Mud: allow to dry and then remove with a

Do not use steam-cleaning systems - risk of

slightly damp cloth.

Remove dust from the Alcantara^® parts

affecting the adhesion of the fabrics!

- Cake, chocolate, ice cream: clean with

regularly with a dry cloth, soft brush or

lukewarm water.

vacuum cleaner.

Remove dust from the textile parts

- Sugary and/or alcoholic drinks: clean with

Clean the Alcantara^®, without rubbing too

regularly with a dry cloth, soft brush or

lukewarm water, or lemon juice if the stain is

vigorously, with a white cotton cloth which is

vacuum cleaner.

persistent.

slightly damp.

Rub down the textile parts once per year with

- Hair gel, coffee, tomato sauce, vinegar:

a clean, damp cloth. After leaving overnight to

To find out which products and procedures to

clean with lukewarm water and lemon juice.

dry, brush with a soft-bristled brush.

use on different types of stains, refer to the

For solid substances, then use a soft brush or

vacuum cleaner.

"Textile - Stain removal" section.

Stain removal

For more information, go to the Alcantara^®

For liquid substances, then use a damp

microfibre cloth and then dry with another

trademark website: www.alcantara.com.

Do not rub the stain or it may spread or

cloth.

you may cause the substance to

Leather

penetrate the surface.

Leather is a natural product. Appropriate regular

care is essential for its durability.

Act quickly by reducing the stain from its

It must be protected and nourished using a

edges inwards.

specific leather product, to keep it supple and

Remove as much substance or solids as

preserve its original appearance.

possible using a spoon or spatula, and

remove as much liquid as possible using

Do not use maintenance products which

absorbent paper.

are not suitable for cleaning leather

(e.g. solvent, detergent, petrol, pure alcohol).

Do not use bleaching or colour-removal

products (e.g. perchloroethylene).

173

In the event of a breakdown

Warning triangle

Tool kit

This reflective and dismantable device is to be

Set of tools supplied with the vehicle.

installed on the side of the road when a vehicle

Its content depends on your vehicle's equipment:

is broken down or damaged.

- Temporary puncture repair kit.

- Spare wheel.

Before getting out of the vehicle

Turn on the hazard warning lamps, then

These tools are specific to the vehicle

put on the safety vest to assemble and install

and may vary according to the level of

the triangle.

equipment.

Under the boot carpet

Do not use them for any other purpose.

► Raise the boot carpet by pulling the strap to

access the tools.

Assembling and placing the

Access to the tools

triangle

List of tools

Depending on version, the tool kit is stored in a

bag or in a storage box in the boot.

1. Chock to immobilise the vehicle (depending

on equipment)

2. Socket for the security bolts (located in the

On the boot carpet

glove box) (depending on equipment)

For versions supplied with a triangle as original

To adapt the wheelbrace to the special

equipment, refer to the illustration above.

‘security’ bolts.

For other versions, refer to the assembly

3. Removable towing eye

instructions provided with the triangle.

► Put the triangle in place behind the vehicle,

For more information on Towing the vehicle

as required by local legislation.

and using the removable towing eye, refer to the

corresponding section.

175

In the event of a breakdown

With temporary puncture repair kit

6. Jack with integrated handle

Temporary puncture

To raise the vehicle.

repair kit

7. Wheel bolt cap removal tool (depending on

equipment)

Visit this link to view explanatory videos:

For removing the wheel bolt head finishers on

http://q-r.to/bagGl9

alloy wheels.

For more information on the Spare wheel, refer

to the corresponding section.

The jack must only be used to change a

12 V compressor with cartridge of sealant

wheel with a damaged or punctured tyre.

and speed limit sticker

Do not use any jack other than the one

Made up of a compressor and a sealant

For temporary repair of a tyre and to adjust

supplied with the vehicle.

cartridge, it allows you to carry out a temporary

the tyre pressure.

If the vehicle does not have its original jack,

repair of the tyre so that you can drive to the

contact a PEUGEOT dealer or a qualified

nearest garage.

For more information on the Temporary

workshop to obtain the one that was intended

It is designed to repair most punctures located

puncture repair kit, refer to the corresponding

by the manufacturer.

on the tyre tread.

section.

The jack meets European standards,

The vehicle's electric system allows the

as defined in the Machinery Directive

With spare wheel

connection of the compressor to the 12 V

2006/42/CE, and also complies with UKCA

power supply for long enough to repair a tyre

requirement, as defined by the Supply

after a puncture.

of Machinery (Safety) Regulations 2008

No.1597.

For more information on the Tool kit,

The jack does not require any maintenance.

refer to the corresponding section.

5. Wheelbrace

For removing the wheel bolts.

176

In the event of a breakdown

Tyre inflation pressures are indicated on

► Fully uncoil the electric cable stowed under

this label.

the compressor.

For more information on Identification

► Connect the compressor's electric plug to the

markings, particularly this label, refer to the

vehicle's 12 V socket.

corresponding section.

► Affix the speed limit sticker.

Should the pressure of one or more tyres

The speed limit sticker must be affixed

► Remove the transparent cap from the bottle

be adjusted, it is necessary to reinitialise

inside the vehicle in the area close to the

of sealant.

the under-inflation detection system.

driver, to remind them that a wheel is in

► Lift the protective cover before installing the

For more information on Tyre under-inflation

temporary use.

bottle of sealant on the compressor.

detection, refer to the corresponding section.

► Switch the ignition on.

► Turn the bottle of sealant over and screw it a

quarter turn into the compressor.

Repair procedure

► Remove the valve cap from the tyre to be

repaired, and place it in a clean place.

Do not remove any foreign body

(e.g. nail, screw) which has penetrated

the tyre.

► Park the vehicle without obstructing traffic

► Switch on the compressor by moving the

and apply the parking brake.

switch to position "I" until the tyre pressure

► Follow the safety instructions (hazard

reaches 2 bar. The sealant product is injected

warning lamps, warning triangle, high visibility

under pressure into the tyre; do not disconnect

jacket, etc.) according to the legislation in force

the pipe from the valve during this operation (risk

in the country in which you are driving.

of blowback).

► Switch the ignition off.

► Uncoil the pipe stowed under the compressor.

If after approximately 7 minutes, the

► Connect the pipe from the compressor to the

pressure of 2 bar is not reached, this

valve of the tyre to be repaired and tighten firmly.

indicates that the tyre is not repairable;

► Check that the compressor switch is in

contact a PEUGEOT dealer or a qualified

position "O".

workshop for assistance.

177

In the event of a breakdown

► Move the switch to position "O".

► Stop to check the repair and the tyre

► Fully uncoil the electric cable stowed under

► Disconnect the compressor's electric plug

pressure using the kit:

the compressor.

from the vehicle's 12 V socket.

• If the tyre pressure is incorrect, contact a

► Connect the compressor's electric plug to the

► Remove the kit.

PEUGEOT dealer to have the tyre changed.

vehicle's 12 V socket.

► Refit the cap on the valve.

• If the tyre pressure is correct, drive a second

► Switch the ignition on.

► Remove and store the bottle of sealant.

time for approximately 3 miles (5 kilometres)

► Start the compressor by placing the switch at

at reduced speed (between 12 and 37 mph

position "I" and adjust the pressure to the value

The sealant product is harmful if

(20 and 60 km/h)), stop then check again

shown on the vehicle's tyre pressure label. To

swallowed and causes irritation to the

the tyre pressure using the kit to confirm the

deflate: press the black button located on the

eyes.

effective repair of the tyre.

compressor pipe, near the valve connection.

Keep this product out of the reach of children.

The use-by date of the fluid is marked on the

With a tyre repaired using this type of kit,

If after 7 minutes the pressure of 2 bar is

bottle.

do not exceed a speed of 50 mph

not reached, the tyre is damaged;

After use, do not discard the bottle into the

(80 km/h) and do not drive more than

contact a PEUGEOT dealer or a qualified

environment; take it to a PEUGEOT dealer or

125 miles (200 km).

workshop for assistance.

an authorised waste disposal site.

You must contact a PEUGEOT dealer or a

► Once the correct pressure is reached, put the

Do not forget to obtain a new bottle of

qualified workshop to have the repair checked

switch in position "O".

sealant, available from a PEUGEOT dealer or

and the tyre changed.

► Remove the kit and stow it.

a qualified workshop.

► Refit the cap on the valve.

Checking/adjusting tyre

pressures

Spare wheel

The compressor can be used, without injecting

sealant, to check and, if necessary, adjust the

Visit this link to view explanatory videos:

tyre pressures.

http://q-r.to/bagGl9

► Remove the valve cap from the tyre and keep

it in a clean place.

► Uncoil the pipe stowed under the compressor.

► Screw the pipe onto the valve and tighten

► Drive immediately for approximately 3 miles

firmly.

(5 kilometres) at reduced speed (between

► Check that the compressor switch is in

12 and 37 mph (20 and 60 km/h)) to plug the

position "O".

For more information on the Tool kit,

puncture.

refer to the corresponding section.

178

In the event of a breakdown

Spare wheel tyre pressure

Removing the spare wheel

► Position the fastening device (nut and bolt) in

The inflation pressure for the spare

the middle of the wheel.

wheel is indicated on the tyre pressure label

► Tighten the central nut sufficiently to retain

- ensure that its inflation pressure is checked

the wheel correctly.

regularly.

► Depending on version, put the tool box back

For more information on Identification

in place in the middle of the wheel and clip it in

markings, particularly the tyre pressure label,

place.

refer to the corresponding section.

Removing a wheel

Accessing the spare wheel

Parking the vehicle

► Slacken the central nut.

Immobilise the vehicle where it does

► Remove the fastening device (nut and bolt).

not obstruct traffic: the ground must be level,

► Lift the spare wheel towards you from the

stable and non-slippery.

rear.

With a manual gearbox, engage first gear

► Take the wheel out of the boot.

to lock the wheels, apply the parking brake,

unless it is set to automatic mode, and switch

Putting the spare wheel back in place

off the ignition.

The punctured wheel cannot be put

With an automatic gearbox, select mode P

under the boot floor.

to lock the wheels, apply the parking brake,

unless it is set to automatic mode, and switch

The spare wheel is stored under the boot carpet.

off the ignition.

To access the spare wheel, first refer to the Tool

Check that the parking brake indicator lamps

kit section.

on the instrument panel are on fixed.

Depending on version, the spare wheel

The occupants must get out of the vehicle

may be a standard steel, non-standard or

and wait where they are safe.

'space-saver' wheel.

If necessary, place a chock under the wheel

diagonally opposite the wheel to be changed.

Never go underneath a vehicle raised using a

jack; use an axle stand.

► Put the spare wheel back in place in its

housing.

► Slacken the nut on the bolt by a few turns.

179

In the event of a breakdown

Wheel with wheel trim

- If the vehicle has steel wheels, remove the

When removing the wheel, first remove

wheel trim.

the wheel trim by pulling with both hands on

- If the vehicle has alloy wheels, remove the

one of the upper arms.

central bolt cover using tool 7.

When refitting the wheel, refit the wheel

- If the vehicle is so equipped, fit security bolt

trim, starting by placing its aperture in line

socket 2 to wheelbrace 5 to slacken the security

with the valve and then pushing it into place

bolt.

all round its edge with the palm of your hand.

- Slacken the other bolts using the

wheelbrace 5 only.

Never use an impact wrench on the

security bolt socket.

► Extend jack 6 until its head comes into

contact with jacking point A or B; contact area A

or B on the vehicle must be properly inserted

into the central part of the head of the jack.

► Raise the vehicle until there is sufficient

space between the wheel and the ground to

easily admit the spare (not punctured) wheel.

Ensure that the jack is stable. If the

ground is slippery or loose, the jack may

slip or collapse - risk of injury!

► Place the foot of jack 6 on the ground and

Take care to position the jack strictly at

ensure that it is directly below the front A or

one of the jacking points A or B under the

rear B jacking point on the underbody, whichever

vehicle, ensuring that the head of the jack is

is closest to the wheel to be changed.

centred under the contact area on the vehicle.

Otherwise, there is a risk of damage to the

vehicle and/or of the jack collapsing - risk of

injury!

180

In the event of a breakdown

► Remove the bolts and store them in a clean

► Tighten the security bolt using the

place.

► Fit the wheel on the hub.

wheelbrace 5 equipped with a security socket 2.

► Remove the wheel.

► Screw in the bolts by hand as far as possible.

► Tighten the other bolts using the

► Pre-tighten the security bolt using the

wheelbrace 5 only.

Fitting a wheel

wheelbrace 5 equipped with a security socket 2.

► Refit the bolt covers to each of the bolts

► Pre-tighten the other bolts using the

(depending on equipment).

Fitting a steel or "space-saver" type

wheelbrace 5 only.

► Store the tools.

spare wheel

After changing a wheel

With a non-standard or 'space-saver'

spare wheel

If the vehicle is fitted with alloy wheels, the

washers A do not make contact with the steel

or "space-saver" type spare wheel. The wheel

is held in place by the conical contact surface

Deactivate certain driving aid functions

► Lower the vehicle again fully.

B of each bolt.

(Active Safety Brake, Adaptive cruise control,

► Fold jack 6 and remove it.

etc.).

Do not exceed the maximum authorised

speed of 50 mph (80 km/h) or the maximum

distance of 50 miles (80 km).

181

In the event of a breakdown

Driving with more than one spare wheel of

Always replace a failed bulb with a new bulb

this type is prohibited.

of the same type and specification. To avoid

The wheel trim from the replaced wheel must

lighting imbalance, replace the bulbs in pairs.

not be refitted.

Refitting the lamp units

Go to a PEUGEOT dealer or a qualified

Perform the operations in the reverse

workshop.

order to dismantling.

Have the tightening of the spare wheel's bolts

and its tyre pressure checked.

The headlamps have polycarbonate

Light-emitting diode (LED)

Have the punctured tyre examined. After

lenses with a protective coating:

inspection, the technician will advise you on

headlamps and lamps

- Do not clean them with a dry or abrasive

whether the tyre can be repaired or if it must

cloth, nor with detergent or solvent

Depending on version, the affected types of

be replaced.

products.

headlamps/lamps are:

- Use a sponge and soapy water or a pH

- LED technology headlamps.

neutral product.

- Full LED technology headlamps.

Changing a bulb

- When using a high-pressure washer on

- Offset daytime running lamps.

persistent marks, do not keep the lance

- Direction indicator side repeaters.

In some weather conditions (e.g. low

directed towards the headlamps, lamps or

- Side spotlamps.

temperature or humidity), misting on the

their edges for too long, so as not to damage

- 3D rear lamps.

internal surface of the glass of the headlamps

their protective coating and seals.

- Brake lamps.

and rear lamps is normal, and will disappear

- Third brake lamp.

after the lamps have been on for a few

- Number plate lamps.

Changing a bulb must only be done with

minutes.

the ignition off and after the headlamp /

Replacement of this type of bulb

lamp has been switched off for several

Contact a PEUGEOT dealer or a

Never look too closely at the light beam

minutes - risk of serious burns!

qualified workshop.

of LED technology lamps - risk of serious

Do not touch the bulb directly with your

Do not touch LED or Full LED technology

eye injury!

fingers; use a lint-free cloth.

headlamps - risk of electrocution!

It is essential only to use anti-ultraviolet

(UV) type bulbs, so as not to damage the

headlamp.

182

In the event of a breakdown

Front lamps

2. Main beam headlamps (LED)

Amber coloured bulbs must be replaced

by bulbs with identical specifications and

3. Direction indicators (PY21W amber).

Model with Full

4. Daytime running lamps / Sidelamps (LED)

colour.

LED technology headlamps

Opening the bonnet/Accessing the

Rear lamps

bulbs

Proceed with caution when the engine is hot -

Model with Full LED lamps

risk of burns!

Take care with objects or clothing that could

be caught in the blades of the cooling fan -

risk of strangulation!

Direction indicators

1. Dipped beam headlamps

Rapid flashing of a direction indicator

2. Main beam headlamps

lamp (left or right) indicates that one of

3. Direction indicators

the bulbs on the corresponding side has

4. Daytime running lamps / Sidelamps

failed.

1. Sidelamps / Daytime running lamps

Model with LED technology

2. Brake lamps

headlamps

3. Reversing lamps

4. Direction indicators

► Remove the protective cover by pulling the

tab.

► Turn the bulb holder anti-clockwise.

► Pull the bulb and bulb holder assembly

backwards.

1. Dipped beam headlamps (LED)

► Replace the bulb.

183

In the event of a breakdown

Model with LED lamps

► Turn the bulb 1 a quarter turn to the left and

remove it.

► Pull the bulb 2 to remove it.

► Replace the bulb.

Engage the lamp unit in its guides while

keeping it in line with the centreline of the

vehicle.

Tighten without forcing to guarantee correct

► Remove the access flap on the

sealing and to avoid damaging the lamp unit.

corresponding side trim, so that the lamp unit

fixing can be accessed.

Foglamp (P21W)

► Slacken the fixing nut with a socket wrench.

1. Sidelamps (LED)

► Finish slackening it by hand to recover the

2. Direction indicators (PY21W amber).

nut, making sure that it does not fall.

3. Reversing lamps (W16W)

► Push the retaining clip outwards and remove

4. Brake lamps (LED)

the lamp unit from the back.

Reversing lamps and direction indicators

Rapid flashing of a direction indicator

lamp (left or right) indicates that one of

the bulbs on the corresponding side has

failed.

For access, pass your hand under the bumper

Amber coloured bulbs, such as the

on the left-hand side.

► Unclip the four fixings around the bulb holder.

► Turn the bulb holder a quarter turn to the left

direction indicators, must be replaced by

► Remove the bulb holder.

and pull it out.

bulbs with identical colour and specifications.

Once the lamp unit and the bulb holder are

► Turn the bulb a quarter turn to the left and

These bulbs are changed from inside the boot.

removed:

pull it out.

► Open the boot.

1. Direction indicators

► Replace the bulb.

2. Reversing lamps

184

In the event of a breakdown

Frozen battery

Fuses

12 V battery / Accessory

Never try to charge a frozen battery - risk

battery

of explosion!

Changing a fuse

All work must be carried out only by a

If the battery has frozen, have it checked by a

PEUGEOT dealer or a qualified workshop.

Lead-acid starter batteries

PEUGEOT dealer or by a qualified workshop,

The replacement of a fuse by a third party

who will verify that the internal components

These batteries contain harmful

have not been damaged and that the case

could cause a serious malfunction of the

substances (sulphuric acid and lead).

has not cracked, which could lead to a risk of

vehicle.

They must be disposed of in accordance

leakage of toxic and corrosive acid.

with regulations and must never under any

Installing electrical accessories

circumstances be discarded with household

The vehicle's electrical system is

Electronic control units/LED

waste.

designed to operate with standard or optional

technology headlamps

Dispose of used batteries at a designated

equipment.

Never connect the negative jump lead to the

collection point.

Before fitting other electrical equipment

metal part of the electronic control units or at

or accessories to your vehicle, contact a

the back of the headlamps.

Protect your eyes and face before

Risk of destroying the electronic control units

PEUGEOT dealer or a qualified workshop.

handling the battery.

and/or headlamps!

All operations on the battery must be carried

Connect to the remote earth point provided

PEUGEOT accepts no responsibility for

out in a well ventilated area and away from

for this purpose.

the cost incurred in repairing the vehicle

naked flames and sources of sparks, to avoid

or for rectifying malfunctions resulting from

any risk of explosion or fire.

the installation of accessories not supplied or

Automatic gearbox

Wash your hands afterwards.

not recommended by PEUGEOT and not

Never try to start the engine by pushing

installed in accordance with its

the vehicle.

Electronic control units/LED

recommendations, in particular when the

technology headlamps

Electric vehicles

combined power consumption of all of the

Never connect the negative jump lead to the

additional equipment connected exceeds 10

metal part of the electronic control units or at

Flat accessory battery

milliamperes.

the back of the headlamps.

It is no longer possible to start the motor

Risk of destroying the electronic control units

or recharge the traction battery.

and/or headlamps!

Connect to the remote earth point provided

for this purpose.

185

In the event of a breakdown

Precautions before working on the

The two vehicles must not be in contact with

accessory battery

each other.

Select mode P, switch off the ignition, check

Switch off all electricity-consuming equipment

that the instrument panel is off and that the

on both vehicles (audio system, wipers,

vehicle is not being charged.

lighting, etc.).

Make sure that the jump leads are well away

Jump-starting another vehicle

from the engine’s moving parts (fan, belt,

Do not use the accessory battery to

etc.).

jump-start another vehicle or to charge

Do not disconnect the (+) terminal while the

another vehicle's battery.

For access to the (+) terminal:

engine is running.

► Release the bonnet by pulling the internal

release lever, then the external safety catch.

Symbols

► Raise the bonnet.

No sparks or naked flames, no smoking.

(+) Positive terminal with a quick-release

terminal.

Always protect your eyes. Explosive

(-) Negative terminal.

gases can cause blindness and injury.

The negative terminal is a fastening bracket on

Keep the vehicle's battery out of the reach

the battery's negative terminal.

of children.

The vehicle's battery contains sulphuric

Starting using another battery

► Lift the plastic cover on the (+) terminal, if the

acid which can make you go blind or

If the vehicle's battery is flat, the engine can be

vehicle has one.

cause severe burns.

started using a backup battery (either external or

► Connect the red cable to the (+) terminal of

For more information, refer to the

from another vehicle) and jump leads or using a

flat battery A (at the metal elbow), then to the

handbook.

battery booster.

(+) terminal of the backup battery B or of the

Explosive gases can be present close to

booster.

the battery.

Never start the engine by connecting a

► Connect one end of the green or black cable

battery charger.

to the (-) terminal of the backup battery B or of

For petrol versions

Never use a 24 V or higher battery booster.

the booster (or to an earth point on the assisting

Check beforehand that the backup battery

Procedure for starting the engine using another

vehicle).

has a nominal voltage of 12 V and a capacity

battery or for charging a discharged battery.

► Connect the other end of the green or black

at least equal to that of the discharged

cable to the earth point C.

Accessing the battery

battery.

The battery is located under the bonnet.

186

In the event of a breakdown

► Start the engine on the assisting vehicle and

To charge the vehicle's battery yourself,

• the positive (+) red cable to the (+) terminal

leave it running for a few minutes.

use only a charger compatible with

of battery A.

► Operate the starter on the broken down

lead-acid batteries with a nominal voltage of

• the negative (-) black cable to earth point C

vehicle and let the engine run.

12 V.

on the vehicle.

If the engine does not start immediately, switch

► At the end of the charging operation, switch

off the ignition and wait a few moments before

Follow the instructions provided by the

off charger B before disconnecting the cables

trying again.

manufacturer of the charger.

from battery A.

► Wait for it to return to idle.

Never reverse polarities.

If this label is present, use only a 12 V

► Disconnect the jump leads in reverse order.

charger to avoid causing irreversible

► Refit the plastic cover to the (+) terminal, if

It is not necessary to disconnect the

damage to the electrical components.

the vehicle has one.

battery.

► Allow the engine to run for at least

30 minutes, with the vehicle stationary, so that

► Switch the ignition off.

24V

the battery reaches an adequate state of charge.

► Switch off all electrical consumers (audio

system, lighting, wipers, etc.).

Driving immediately without having

12V

reached a sufficient level of charge may

affect some of the vehicle's functions (e.g.

Stop & Start).

Disconnecting/reconnecting the

battery

Charging the battery using a battery

In order to maintain an adequate state of

charger

charge for starting the engine, we recommend

For optimum service life of the battery, it is

disconnecting the battery if the vehicle is to be

essential to maintain an adequate state of

unused for an extended period.

► Switch off charger B before connecting

charge.

Before disconnecting the battery:

the cables to the battery, so as to avoid any

In some circumstances, it may be necessary to

► Close all openings (doors, boot, windows,

dangerous sparks.

charge the battery:

roof).

► Ensure that the charger cables are in good

- When using the vehicle mainly for short

► Switch off all electricity-consuming devices

condition.

journeys.

(audio system, wipers, lamps, etc.).

► Lift the plastic cover on the (+) terminal, if the

- If the vehicle is to be taken off the road for

► Switch off the ignition and wait for 4 minutes.

vehicle has one.

several weeks.

After accessing the battery, it is only necessary

► Connect the cables of charger B as follows:

Consult a PEUGEOT dealer or a qualified

to disconnect the (+) terminal.

workshop.

187

In the event of a breakdown

Quick-release terminal clamp

► Push clamp B fully down.

► After reconnecting the 12 V battery, perform

► Lower lever A to lock clamp B.

the automatic reset procedures of the electronic

Disconnecting the (+) terminal

► Depending on equipment, lower the plastic

systems and manual reset of some equipment.

cover on the (+) terminal.

For more information on Following

reconnection, refer to the corresponding

Do not force the lever when pressing on

section.

it, as if the clamp is not positioned

correctly, locking will then not be possible.

Accessing the battery

Start the procedure again.

The battery is located under the bonnet.

The Stop & Start system may not be

operational during the trip following the

first engine start.

In this case, the system will only be available

► Depending on equipment, lift the plastic cover

again after a continuous period with the

on the (+) terminal.

vehicle immobilised, the duration of which

► Raise lever A fully to release clamp B.

depends on the exterior temperature and the

► Remove clamp B by lifting it off.

state of charge of the battery (up to about 8

Reconnecting the (+) terminal

hours).

For access to the (+) terminal:

► Release the bonnet by pulling the internal

release lever, then the external safety catch.

For hybrid versions

► Raise the bonnet.

Procedure for starting the engine using another

(+) Positive terminal with a quick-release

battery or for charging a discharged battery

terminal.

(12 V or 48 V).

(-) Negative terminal.

► Access to the 12 V battery.

The negative terminal is a fastening bracket on

For more information on Accessing the battery,

the battery's negative terminal.

refer to the corresponding section.

► If necessary, perform the 12 V battery

Starting using another battery

disconnection/reconnection procedure.

The hybrid system starts the vehicle, but

For more information on Disconnecting/

► Raise lever A fully.

Reconnecting the battery, refer to the

a 12 V supply is required. There are

► Refit open clamp B on the (+) terminal.

corresponding section.

several reasons why the vehicle cannot be

started.

188

In the event of a breakdown

If the 12 V battery is flat, the 12 V power supply

► Connect the red cable to the (+) terminal of

Charging the 12 V battery using a

can be ensured using a backup battery (either

flat battery A (at the metal elbow), then to the

battery charger

external or from another vehicle) and jump leads

(+) terminal of the backup battery B or of the

For optimum service life of the battery, it is

or using a battery booster or using a battery

booster.

essential to maintain an adequate state of

charger.

► Connect one end of the green or black cable

charge.

to the (-) terminal of the backup battery B or of

Never use a 24 V or higher battery

In some circumstances, it may be necessary to

the booster (or to an earth point on the assisting

booster.

charge the battery (e.g. if the vehicle is to be

vehicle).

Check beforehand that the backup battery

taken off the road for several weeks)

► Connect the other end of the green or black

has a nominal voltage of 12 V and a capacity

Consult a PEUGEOT dealer or a qualified

cable to the earth point C.

at least equal to that of the discharged

workshop.

► Start the engine on the assisting vehicle and

battery.

leave it running for a few minutes.

The hybrid system is connected to the

The two vehicles must not be in contact with

► Operate the starter on the broken down

12 V network through the DC/DC

each other.

vehicle and let the engine run.

converter. Any operation may affect the

Switch off all electricity-consuming equipment

If the engine does not start immediately, switch

overall behaviour of the system.

on both vehicles (audio system, wipers,

off the ignition and wait a few moments before

To charge the vehicle's battery yourself, use

lighting, etc.).

trying again.

only a charger compatible with lead-acid

Make sure that the jump leads are well away

► Wait for it to return to idle.

batteries with a nominal voltage of 12 V.

from the engine’s moving parts (fan, belt,

► Disconnect the jump leads in reverse order.

etc.).

► Refit the plastic cover to the (+) terminal, if

Follow the instructions provided by the

Do not disconnect the (+) terminal while the

the vehicle has one.

manufacturer of the charger.

engine is running.

► Allow the engine to run for at least

Never reverse polarities.

30 minutes, with the vehicle stationary, so that

the battery reaches an adequate state of charge.

It is not necessary to disconnect the

battery.

Driving immediately without having

reached a sufficient level of charge may

► Switch the ignition off.

affect some of the vehicle's functions (e.g.

► Switch off all electrical consumers (audio

e-Auto mode).

system, lighting, wipers, etc.).

► Lift the plastic cover on the (+) terminal, if the

vehicle has one.

189

In the event of a breakdown

Do not try to charge the hybrid system

directly.

The hybrid system is connected to the 12 V

network through the DC/DC converter. Any

operation may affect the overall behaviour of

the system.

Only use a specific 12 V battery charger

► Switch off charger B before connecting

capable of maintaining 13.5 V with a high

► Switch off charger B before connecting the

the cables to the battery, so as to avoid any

level of current 40-50 A (approx. 600 W).

cables to the 12 V battery, so as to avoid any

dangerous sparks.

To charge the vehicle's battery yourself, use

dangerous sparks.

► Ensure that the charger cables are in good

only a charger compatible with lead-acid

► Ensure that the charger cables are in good

condition.

batteries with a nominal voltage of 12 V.

condition.

► Lift the plastic cover on the (+) terminal, if the

Never use a 24 V or higher battery booster.

► Lift the plastic cover on the (+) terminal, if the

vehicle has one.

► Connect the cables of charger B as follows:

Follow the instructions provided by the

• the positive (+) red cable to the (+) terminal

manufacturer of the charger.

of battery A.

of battery A,

Never reverse polarities.

• the negative (-) black cable to earth point C

on the vehicle.

It is not necessary to disconnect the

► At the end of the charging operation, switch

► Open the driver's door to wake up the vehicle

battery.

off charger B before disconnecting the cables

(or turn the ignition on without pressing the

from battery A.

brake pedal).

► Switch the ignition off.

The hybrid system will automatically start

► Switch off all electrical consumers (audio

Charging the 48 V battery using a

charging the 48 V battery after 1 minute with

system, lighting, wipers, etc.).

12 V battery charger

a 12 V power supply higher than 13.5 V. The

If the start fails, refer to the paragraph "Starting

current supplied by the battery charger should be

using another battery" and follow the

about 30-50A.

recommended procedure.

When the appropriate energy level is reached in

In case of failure, especially after long storage,

the 48 V battery, the hybrid system automatically

the 48 V battery may be discharged and require

stops the charging process of the 48 V battery.

a charging process.

The current supplied by the 48 V battery should

be about 10-15 A.

190

In the event of a breakdown

► At the end of the charging operation, switch

Quick-release terminal clamp

► Push clamp B fully down.

off charger B before disconnecting the cables

► Lower lever A to lock clamp B.

from 12 V battery A.

Disconnecting the (+) terminal

► Depending on equipment, lower the plastic

► Refit the plastic cover to the (+) terminal, if

cover on the (+) terminal.

the vehicle has one.

Do not force the lever when pressing on

► Operate the starter on the vehicle and let the

it, as if the clamp is not positioned

engine run.

correctly, locking will then not be possible.

► Wait for it to return to idle.

Start the procedure again.

► Allow the engine to run for at least

30 minutes, with the vehicle stationary, so that

The Stop & Start system may not be

the 48 V battery reaches an adequate state of

operational during the trip following the

charge.

first engine start.

Disconnecting/reconnecting the

In this case, the system will only be available

► Depending on equipment, lift the plastic cover

battery

on the (+) terminal.

again after a continuous period with the

vehicle immobilised, the duration of which

In order to maintain an adequate state of

► Raise lever A fully to release clamp B.

depends on the exterior temperature and the

charge for starting the engine, we recommend

► Remove clamp B by lifting it off.

state of charge of the battery (up to about 8

disconnecting the battery if the vehicle is to be

Reconnecting the (+) terminal

hours).

unused for an extended period.

Before disconnecting the battery:

► Close all openings (doors, boot, windows,

Following reconnection

roof).

After reconnecting the battery, turn on the

► Switch off all electricity-consuming devices

ignition and wait 1 minute before starting the

(audio system, wipers, lamps, etc.).

engine, to enable the electronic systems to

► Switch off the ignition and wait for 4 minutes.

initialise.

After accessing the battery, it is only necessary

If minor problems nevertheless persist following

to disconnect the (+) terminal.

this operation, contact a PEUGEOT dealer or a

qualified workshop.

Referring to the relevant section, reinitialise

certain equipment:

► Raise lever A fully.

- Remote control key or electronic key

► Refit open clamp B on the (+) terminal.

(depending on version).

191

In the event of a breakdown

- Electric windows.

When towing a vehicle with all four wheels on

- towing with only two wheels on the ground;

- Date and time.

the ground, always use an approved towbar;

- four-wheel drive vehicle;

- Preset radio stations.

ropes and straps are prohibited.

- no approved towbar available.

The towing vehicle must move off gently.

When the vehicle is towed with its engine

Before towing the vehicle, it is essential

Towing the vehicle

off, there is no longer braking and steering

to put the vehicle in free-wheeling mode.

assistance.

For more information on Free-wheeling, refer

General recommendations

Observe the legislation in force in the

to the corresponding section.

country where you are driving.

A professional recovery service must

Check that the towing vehicle is heavier than

be called in the following cases:

Electric motor

the towed vehicle.

- broken down on a motorway or main road;

An electric vehicle cannot under any

The driver must remain at the wheel of the

- not possible to put the gearbox into neutral,

circumstances be used to tow another

towed vehicle and must have a valid driving

unlock the steering, or release the parking

vehicle.

licence.

brake;

However, it may be used, for example, to exit

- not possible to tow a vehicle with an

a rut.

automatic gearbox, with the engine running;

Towing constraints

Type of vehicle

Front wheels on the

Rear wheels on the

Flatbed

4 wheels on the ground

(engine/gearbox)

ground

with towbar

Internal combustion/Manual

Internal combustion/Automatic

192

In the event of a breakdown

Towing constraints

Type of vehicle

Front wheels on the

Rear wheels on the

Flatbed

4 wheels on the ground

(engine/gearbox)

ground

with towbar

Hybrid/Automatic

Electric 2WD

In case of battery or electric parking brake failure, it is essential to call a professional using flatbed recovery vehicles (excluding manual gearbox).

► Unclip the cover by pressing at its top left-

► Switch on the hazard warning lamps on both

Accessing the tools

hand corner.

vehicles in accordance with the legislation in

For more information on accessing the Tool kit,

To be towed:

force in the country in which you are driving.

refer to the corresponding section.

► Screw the towing eye in fully.

► Move off gently, drive slowly and only for a

► Install the towbar.

short distance.

Towing your vehicle

► Put the gearbox into neutral.

To access the front screw thread:

Failure to observe this instruction could

result in damage to certain components

(e.g. braking, transmission) and to the

absence of braking assistance the next time

the engine is started.

Automatic gearbox

Never tow the vehicle with the driving

wheels on the ground and the engine off.

► Unlock the steering and release the parking

brake.

193

Technical data

must be reduced by 10% for each additional

Engine technical data and

1,000 metres of altitude.

towed loads

The maximum authorised nose weight

corresponds to the weight permitted on the

Engines

towball.

The engine characteristics are given in the

When exterior temperatures are high, the

vehicle's registration document, as well as in

vehicle performance may be limited in

sales brochures.

order to protect the engine. When the exterior

Only the values available at the time of

temperature is higher than 37°C, reduce the

publication are presented in the tables.

towed weight.

Contact a PEUGEOT dealer or a qualified

workshop to obtain missing values.

Towing even with a lightly loaded vehicle

The maximum power corresponds to the

can adversely affect its road holding.

value type-approved on a test bed, under

Braking distances are increased when towing

conditions defined by European legislation

a trailer.

(Directive 1999/99/EC).

When using a vehicle to tow, never exceed

a speed of 62 mph (100 km/h) (observe the

For more information, contact a PEUGEOT

local legislation in force).

dealer or a qualified workshop.

Weights and towed loads

The weights and towed loads relating to

the vehicle are indicated on the registration

document, as well as in sales brochures.

These values are also indicated on the

manufacturer's plate or label.

For more information, contact a PEUGEOT

dealer or a qualified workshop.

The GTW (Gross Train Weight) and towed load

values indicated are valid up to a maximum

altitude of 1,000 metres. The towed load value

195

Technical data

Engines and towed loads - Petrol

Engines

1.2 PureTech 75

1.2 PureTech 100 S&S

S&S

Gearboxes

BVM5

BVM6

EAT8

(Manual 5-speed)

(Manual 6-speed)

(Auto. 8-speed)

Codes

EB2FAMD MA

EB2FAD MA STT

EB2ADTD_B MB6

EB2ADTD ATN8

(euro 6.1)

(euro 6.4)

STT

(euro 6.4)

(euro 6.3 / 6.4)

Model codes:

HMG

HMH

HNE

HNK

Cubic capacity (cc)

1,199

Max. power: EC standard (kW)

Fuel

Unleaded

(RON 91 minimum)

(RON 95 minimum)

Braked trailer (within the GTW limit) (kg)

500

1,200

on a 10% or 12% gradient

Unbraked trailer (kg)

500

580

600

Maximum authorised nose weight (kg)

Engines

1.2 PureTech 130

1.2 PureTech 130 S&S

Gearboxes

EAT6

EAT8

(Auto. 6-speed)

(Auto. 8-speed)

Codes

EB2ADTSM AT6III

EB2ADTS ATN8 STT

(euro 6.1)

(euro 6.3 / 6.4)

Model codes:

HNL

HNS

UP...

Cubic capacity (cc)

1,199

196

Technical data

Engines and towed loads - Hybrid

HYBRID 100 e-DCS6

HYBRID 136 e-DCS6

Codes

EB2LTEDH2 EDCT6 Euro 6.4

EB2L TDH2 EDCT6 Euro 6.4

Model codes

HPX

HPY

J...

Braked trailer (within the GTW limit) (kg)

1,200

on a 10% or 12% gradient

Unbraked trailer (kg)

645

650

Maximum authorised nose weight (kg)

Petrol engines

PureTech 100

PureTech 136

Gearboxes

Electric dual-clutch automatic 6-speed

Cubic capacity (cc)

1,199

Max. power: EC standard (kW)

100

Fuel

Unleaded

Electric motor

Technology

Synchronous with permanent magnets

Max. power: EC standard (kW)

Traction battery

Technology

Lithium-Ion

Voltage (Volts DC)

Installed capacity (kWh)

0.9

198

Technical data

Bears the following information:

Dimensions (mm)

- Manufacturer’s name.

These dimensions have been measured on an

- European whole vehicle type approval

unladen vehicle.

number.

- Vehicle Identification number (VIN).

- Gross vehicle weight (GVW).

- Gross train weight (GTW).

- Maximum weight on the front axle.

- Maximum weight on the rear axle.

D. Tyres/paint code label.

Affixed to the driver's door.

Identification markings

Bears the following information about the tyres:

Various visible markings for vehicle identification

- Tyre pressures, unladen and laden.

and vehicle search.

- Tyre specification, made up of the dimensions

and type as well as the load and speed indices.

- Spare tyre inflation pressure.

Also indicates the paint colour code.

The vehicle may be originally equipped

with tyres with higher load and speed

indices than those indicated on the label,

without affecting tyre pressure (on cold tyres).

In the event of a change in the type of tyres,

contact a PEUGEOT dealer for the tyre fits

A. Vehicle Identification Number (VIN), under

approved for the vehicle.

the bonnet.

Stamped on the chassis.

B. Vehicle Identification Number (VIN), on the

dashboard.

Printed on an adhesive label visible through the

windscreen.

C. Manufacturer's label.

Affixed to the right-hand door.

200

Touch screen 10" & Bluetooth Radio & Telephone

(short-circuit) that could lead to death

With the ignition off, a press turns the system on.

Touch screen 10" &

(electrocution)!

Increase or decrease the volume using

Bluetooth Radio &

In the event of a problem, always contact a

the wheel or the "plus" or "minus" buttons

PEUGEOT dealer or a qualified workshop.

(depending on the equipment).

Telephone

Use the buttons on either side of or below the

The system is protected so that it only

touch screen to access the menus, then press

Multimedia audio system -

operates in the vehicle.

the virtual buttons on the touch screen.

Applications - Bluetooth^®

The message Energy economy mode is

Depending on the model, use the "HOME" and

displayed when the system is about to go into

"Vehicle" buttons below the touch screen to

telephone

standby.

access the menus, then press the virtual buttons

The functions and settings described

on the touch screen.

vary according to the vehicle version and

At all times it is possible to display the rolling

The system’s Open Source Software

configuration, as well as the country of sale.

menus by pressing the screen briefly with three

(OSS) source codes are available at the

fingers.

following addresses:

On pages with multiple tabs at the bottom of the

For safety reasons and because they

https://www.groupe-psa.com/fr/oss/

screen, you can switch between pages either

require sustained attention by the driver,

https://www.groupe-psa.com/en/oss/

by tapping the tab for the desired page or by

the following operations must be carried out

swiping the pages to the left or right with your

with the vehicle stationary and the ignition

The system transmits and/or receives

finger.

on:

radio waves subject to the Directive

Press the back arrow to go back a level or

- Connecting the smartphone via Bluetooth,

2014/53/EU.

confirm.

USB or Wi-Fi.

The manufacturers of the mentioned system

- Using the smartphone.

declare the conformity with the Directive

The touch screen is of the "capacitive"

- Connecting to the CarPlay^® or Android

2014/53/EU.

type.

Auto applications (certain applications stop

The full text of the EU declaration of

To clean the screen, use a soft, non-abrasive

displaying when the vehicle is moving).

conformity for each system is available at the

cloth (e.g. spectacles cloth) with no additional

- Changing the system settings and

following address:

product.

configuration.

http://public.servicebox.peugeot.com/APddb/

Do not use sharp objects on the screen.

Do not touch the screen with wet hands.

Any intervention or modification on the

Certain information is displayed permanently on

vehicle's system is strictly forbidden

First steps

the main screen:

- Risk of serious burns or electric shock

With the engine running, a press mutes

the sound.

201

Touch screen 10" & Bluetooth Radio & Telephone

- Air conditioning status information (depending

Mute by pressing the volume increase and

Menus

on version), and direct access to the

decrease buttons simultaneously (depending on

corresponding menu.

equipment).

Radio Media

- Radio Media and Telephone menu status

Restore the sound by pressing one of the two

information.

volume buttons.

- Privacy status information.

Telephone (short press): start telephone

- Access to the touch screen and digital

call.

instrument panel settings.

Call in progress (short press): access

Audio source selection (depending on

telephone menu.

equipment):

Telephone (long press): reject an incoming call,

- FM/DAB/AM radio stations (depending on

end call; when no call is in progress, access

equipment).

telephone menu.

- Telephone connected via Bluetooth and

Radio (rotate): automatic search for the

Bluetooth multimedia broadcast (streaming).

previous/next station.

- USB Memory stick.

Media (rotate): previous/next track, move

Select an audio source or radio station.

through a list.

In very hot conditions, the volume may

Short press: confirm a selection; if nothing

be limited to protect the system. It may

selected, access presets.

enter standby mode (with the screen and

Telephone

Accelerated navigation.

sound off) for 5 minutes or more.

The system will resume normal operation

when the temperature in the passenger

compartment has dropped.

The system is operational in temperatures

between -40°C and +70°C.

Steering mounted controls

Voice control: smartphone voice

commands.

Connect a mobile phone via Bluetooth^®.

Run certain applications from a

Vol+^{Increase volume.}

smartphone connected via CarPlay^® or Android

Auto.

Vol-^{Decrease volume.}

202

Touch screen 10" & Bluetooth Radio & Telephone

Applications

Driving

Air conditioning

Access configurable equipment.

Activate, deactivate or configure certain

Manage various temperature and air flow

vehicle functions.

settings.

Settings

Navigation

Radio

Selecting a station

Press Radio Media to display the main

page.

Press one of the buttons to perform an

automatic search for radio stations.

Move the slider to manually search for

frequencies up or down.

Configure the navigation and select your

Configure the sound (balance, ambience,

Press the frequency to enter the FM and

destination via CarPlay^® or Android Auto.

etc.), the display (language, units, date,

AM waveband values using the virtual

time, etc.), and some system functions.

keypad.

Press "OK" to confirm.

203

Touch screen 10" & Bluetooth Radio & Telephone

Radio reception may be affected by the

Activating/Deactivating RDS

Playing TA messages

use of electrical equipment not approved

RDS, if activated, allows you to continue

The TA (Traffic Announcement) function gives

by the Brand, such as a USB charger

listening to the same station by automatically

priority to TA alert messages. To operate, this

connected to the 12 V socket.

retuning to alternative frequencies.

function needs good reception of a radio station

The exterior environment (hills, buildings,

Press Radio Media to display the main

that transmits this type of message. While traffic

tunnels, basement car parks, etc.) may

page.

information is being broadcast, the current

block reception, including in RDS mode.

Press the "OPTIONS" button to access the

media is automatically interrupted so that the

This phenomenon is perfectly normal in the

secondary page.

TA message can be heard. Normal play of the

context of radio wave transmission, and

Activate/deactivate "RDS".

previously playing media resumes at the end of

in no way indicative of an audio system

the message.

malfunction.

Press in the shaded area to confirm.

Press Radio Media to display the main

page.

Changing the waveband

Press the "OPTIONS" button to access the

RDS station tracking may not be

secondary page.

Press Radio Media to display the main

available nationwide, as many radio

Activate/deactivate "TA".

page.

stations do not cover 100 % of the country.

Press the "OPTIONS" button to access the

This explains the loss of reception of the

Press in the shaded area to confirm.

secondary page.

station during a journey.

Press "Band" to change waveband.

Displaying text information

Audio settings

Press in the shaded area to confirm.

The "Radio Text" function displays information

Press Radio Media to display the main

transmitted by the radio station relating to the

page.

Presetting a station

station or the currently playing song.

Press the "OPTIONS" button to access the

Press Radio Media to display the main

secondary page.

Select a radio station or frequency.

page.

Press "Audio settings".

Make a short press on the star outline. If

the star is solid, the radio station is

Press the "OPTIONS" button to access the

secondary page.

Select the "Tone", "Balance" or "Sound"

already preset.

Activate/deactivate "News".

tab to configure the sound settings.

Press the back arrow to confirm.

Select a radio station or frequency.

Press "Preset".

Press in the shaded area to confirm.

Make a long press on one of the buttons

In the "Tone" tab, the Ambience, Bass,

to preset the station.

Medium and Treble sound settings are

204

Touch screen 10" & Bluetooth Radio & Telephone

different and independent for each audio

Press the "OPTIONS" button to access the

If the "DAB" station being listened to is

source.

secondary page.

not available on "FM", or if "FM-DAB

In the "Balance” tab, the All passengers,

Press "Band" to select "DAB band".

Follow-up" is not activated, the sound will cut

Driver and Front only settings are common

out when the digital signal becomes too weak.

to all sources.

Press in the shaded area to confirm.

In the "Sound” tab, activate or deactivate

"Volume linked to speed", "Auxiliary input"

Media

and "Touch tones".

FM-DAB Follow-up

"DAB" does not cover 100% of the territory.

USB port

The balance/distribution (or spatialisation

When the digital radio signal is poor, the

Insert the USB memory stick into the USB

with the Arkamys^© system) uses audio

"FM-DAB Follow-up" enables you to continue

port or connect the USB device to the

processing to adjust the sound quality

listening to the same station by automatically

USB port using a suitable cable (not supplied).

according to the number of passengers in the

switching to the corresponding "FM" analogue

vehicle.

station (if there is one).

To protect the system, do not use a USB

Press Radio Media to display the main

hub.

page.

Onboard audio: Arkamys Sound Staging^©

Press the "OPTIONS" button to go to the

The system builds playlists (in temporary

optimises the sound distribution inside

secondary page.

memory); this operation can take from a

the passenger compartment.

Activate/deactivate "FM-DAB Follow-up".

few seconds to several minutes at the first

connection.

Press in the shaded area to confirm.

Reduce the number of non-music files and the

DAB (Digital Audio

number of folders to reduce the waiting time.

Broadcasting) radio

Playlists are updated whenever the ignition

If "FM-DAB Follow-up" is activated, there

is switched off or a USB memory stick is

may be a time offset of a few seconds

connected. The audio system memorises these

Terrestrial Digital Radio

when the system switches to "FM" analogue

lists, which will subsequently load faster if they

Digital radio provides higher quality sound.

radio, and in some cases a change in volume.

have not been changed.

The various "multiplexes/ensembles" offer a

When the digital signal quality is restored, the

choice of radio stations organised in alphabetical

system automatically changes back to "DAB".

Selecting the source

order.

To minimise this time lag, storing radio

Press Radio Media to display the main

stations in the "DAB" band is recommended.

page.

Press the "SOURCES" button.

Select the source.

205

Touch screen 10" & Bluetooth Radio & Telephone

Bluetooth Streaming^®

confirm to go down through the menu to the

Use only USB memory sticks in FAT32 format

desired track.

(File Allocation Table).

Streaming allows you to listen to the audio feed

from your smartphone.

We recommend using the original USB

The version of software in the audio system may

The Bluetooth profile must be activated.

cable for the portable device.

not be compatible with the generation of the

First adjust the volume on the portable device

Apple^® player.

(to a high level). Then adjust the volume of the

system.

Information and advice

Telephone

If play does not start automatically, it may be

The system supports USB mass storage

necessary to start the audio playback from the

devices, BlackBerry^® devices or Apple^® players

Pairing a Bluetooth^®

smartphone.

via the USB ports. The adapter cable is not

Control is from the portable device or by using

telephone

supplied.

the system's touch buttons.

Devices are managed using the audio system

The services available depend on the

Once connected in Streaming mode, the

controls.

network, the SIM card and the

smartphone is considered to be a media

Other devices, not recognised on connection,

compatibility of the Bluetooth devices used.

source.

must be connected via Bluetooth streaming, if

Consult the telephone user guide and the

compatible.

service provider to check which services are

To protect the system, do not use a USB

available.

Connecting Apple^® players

hub.

Connect the Apple^® player to the USB socket

The Bluetooth function must be activated and

using a suitable cable (not supplied).

the telephone configured as "Visible to all” (in the

The audio system will only play audio files with

Play starts automatically.

telephone settings).

".wav", ".wma", ".aac", ".ogg" and ".mp3" file

Control is via the audio system.

To complete the pairing, whichever procedure is

extensions, at bit rates between 32 Kbps and

320 Kbps.

used (from the telephone or from the system),

The classifications available are those of

It also supports VBR (Variable Bit Rate) mode.

ensure that the code is the same in the system

the portable device connected (artists/

No other file types (".mp4", etc.) can be read.

and in the telephone.

albums/genres/playlists/audio books/

podcasts). It is also possible to use a

All ".wma" files must be standard WMA 9 files.

If the pairing procedure fails, we

classification structured in the form of a

The supported sampling rates are 11, 22, 44 and

recommend deactivating and then

library.

48 KHz.

reactivating the Bluetooth function on the

The default classification used is by artist. To

To avoid reading and display problems, we

telephone.

modify the classification used, return to the

recommend choosing file names less than 20

first level of the menu then select the desired

characters long that do not contain any special

classification (playlists for example) and

characters (e.g. “ ? . ; ù).

206

Touch screen 10" & Bluetooth Radio & Telephone

Procedure from the telephone

The ability of the system to connect just

Managing paired telephones

Select the name of the system in the list

one profile depends on the telephone.

This function lets you connect or disconnect a

of detected devices.

All three profiles may connect by default.

device or delete a pairing.

In the system, accept the connection request

Press Telephone to display the main

from the telephone.

The profiles compatible with the system

page.

are: HFP, OPP, PBAP, A2DP, AVRCP,

Press the "PHONE" button to access the

Procedure from the system

MAP and PAN.

secondary page.

Press Telephone to display the main

Press "Bluetooth connection" to

Visit the Brand's website for more information

page.

display the list of paired devices.

(compatibility, additional help, etc.).

Press "Connected Devices".

Press on the name of the telephone

The list of detected telephones is

selected in the list to disconnect it.

Automatic reconnection

displayed.

Press again to connect it.

On returning to the vehicle, if the last telephone

Press this button to start searching for

connected is present again, it is automatically

Deleting a telephone

new devices.

recognised and within about 30 seconds

Select the name of the chosen telephone

Press the basket at the top right of the

after switching on the ignition, the pairing is

in the list.

screen to display a basket alongside the

established automatically (Bluetooth activated).

Complete the pairing with the displayed code.

telephone chosen.

To modify the connection profile:

Press the basket alongside the telephone

Connection sharing

Press Telephone to display the main

chosen to delete it.

page.

The system offers to connect the telephone with

3 profiles:

Press the "PHONE" button to access the

Receiving a call

secondary page.

- "Telephone" (hands-free kit, telephone only),

An incoming call is announced by a ring and a

Press "Bluetooth connection" to

- “Streaming" (streaming: wireless playing of

superimposed display in the screen.

display the list of paired devices.

audio files on the telephone),

Make a short press on the steering

Press the "Details" button for a paired

- "Mobile internet data".

mounted PHONE button to accept an

device.

Select one or more profiles.

incoming call.

Select one or more profiles.

And

Press "OK" to confirm.

Make a long press

Press "OK" to confirm.

Depending on the type of telephone, you may by

on the steering mounted PHONE button

prompted to accept the transfer of contacts and

to reject the call.

messages.

207

Touch screen 10" & Bluetooth Radio & Telephone

Press "End call".

Calling a recently used

technology on the vehicle’s screen. For CarPlay^®

technology, the CarPlay^® function must first be

number

activated on the smartphone.

Making a call

Press Telephone to display the main

The smartphone can be connected via USB

page.

cable or via a wireless connection.

Using the telephone is not recommended

while driving.

Unlock the smartphone for the

Press and hold

Parking the vehicle.

communication process between the

Make the call using the steering mounted

smartphone and the system to work.

the steering mounted button.

controls.

As principles and standards are constantly

changing, we recommend keeping the

Press "Recent calls".

smartphone's operating system up-to-

Select the desired contact from the displayed list.

Calling a new number

date, together with the date and time on

Press Telephone to display the main

It is always possible to make a call

the smartphone and the system.

page.

directly from the telephone; as a safety

Enter the phone number using the digital

measure, first park the vehicle.

For the list of compatible smartphones,

keypad.

visit the Manufacturer's website in your

Press "Call" to start the call.

Setting the ringtone

country.

Press Telephone to display the main

USB sockets

Calling a contact

page.

Press the "OPTIONS" button to access the

Depending on equipment, for more information

Press Telephone to display the main

secondary page.

on the USB sockets compatible with CarPlay^® or

page.

Press "Ring volume" to display the

Android Auto applications, refer to the "Ease of

Or press and hold

volume bar.

use and comfort" section.

Press the arrows or move the slider to set

Wireless connection

the steering mounted PHONE button.

the ring volume.

Before using CarPlay^® or Android Auto

Press "Contacts".

Using CarPlay^® or Android

wirelessly, ensure the Wi-Fi regulatory

Select the desired contact from the displayed list.

restrictions of your geographic location are

Press "Call".

Auto

Synchronising a smartphone enables users

to display applications that support the

smartphone’s CarPlay^® or Android Auto

208

Touch screen 10" & Bluetooth Radio & Telephone

met, as indicated by a message on the touch

CarPlay^® smartphone

The CarPlay^® navigation can be accessed

screen.

at any time by pressing the system's

connection

If the 5 GHz Wi-Fi network frequency is not

Navigation button.

allowed in your location, select 2.4 GHz at the

The availability of the application depends on the

Wireless connection

first connection.

country.

First activate the smartphone’s Bluetooth^®

Check the Wi-Fi restrictions again when you

USB connection

function.

travel to different locations and set the Wi-Fi

From the system, press "Telephone" to

frequency accordingly.

On connecting the USB cable, the

display the main page.

The regulations of the 5 GHz frequency

CarPlay^® function deactivates the

If the device has already been connected to the

are specific to each country. Refer to the

system's Bluetooth^® mode.

system via Bluetooth^®, select the device settings

regulation in force in your country.

The "CarPlay" function requires the use of

from the list of known devices and choose

a compatible smartphone and compatible

CarPlay^® as the wireless connection mode.

applications.

When using CarPlay^® with 5 GHz

If the device has never been connected to the

frequency activated, there may be

Connect the USB cable.

system before, it will have to be paired (refer to

interference with certain devices (tolls,

the corresponding section).

parking...) resulting in a disconnection. To

The smartphone charges when connected by the

The system detects if the smartphone is

prevent this from happening, it is

USB cable.

compatible with CarPlay^® and offers to connect

recommended to disable the 5 GHz function.

From the system, press "Telephone" to

to it following the pairing process.

display the main page.

Subsequent automatic connection of the

Difficulties in connecting wirelessly your

Press "CarPlay" to display the CarPlay^®

smartphone requires activation of the Bluetooth^®

smartphone may happen, due to:

interface.

on your device.

- Interference with other Wi-Fi networks.

As soon as the connection is established,

CarPlay^® interface may appear

- Interference with certain devices (tolls,

press "CarPlay" to display the CarPlay^®

automatically.

parking) when using Android Auto.

interface.

- An unsuitable configuration of the

Press and hold this steering-mounted

smartphone.

When the USB cable is disconnected

control button and say "Siri" to initiate the

In these cases, it is recommended to connect

and the ignition is switched off then back

smartphone voice commands.

the smartphone with its original cable.

on, the system will not automatically switch to

Radio Media mode; the source must be

Android Auto smartphone

changed manually.

connection

The availability of the application depends on the

country.

209

Touch screen 10" & Bluetooth Radio & Telephone

On the smartphone, download the

Wireless connection

There may be a pause before

Android Auto application.

First activate the smartphone’s Bluetooth^®

applications become available,

function.

depending on the quality of the network.

The "Android Auto" function requires the

Connect a USB cable.

use of a compatible smartphone and

applications.

From the system, press "Telephone" to

Applications

display the main page.

The first connection of Android Auto to

If the device has already been connected to the

the system should be made by USB

Viewing photos

system via Bluetooth^®, select the device settings

cable.

Insert a USB memory stick in the USB port.

from the list of known devices and choose

Android Auto^® as the wireless connection mode.

To protect the system, do not use a USB

USB connection

If the device has never been connected to the

hub.

Connect a USB cable.

system before, it will have to be paired (refer to

The system can read folders and image files in

the corresponding section).

the formats: .tiff; .gif; .jpg/jpeg; .bmp and .png.

The system detects if the smartphone is

The smartphone charges when connected by a

Press Applications to display the main

USB cable.

compatible with Android Auto and offers to

page.

From the system, press "Telephone" to

connect to it following the pairing process.

Press "Photos".

display the main page.

Subsequent automatic connection of the

Press "Android Auto" to start the

smartphone requires activation of the Bluetooth^®

Select a folder.

application in the system.

on your device.

Depending on the smartphone, it may be

As soon as the connection is established,

Select an image to view.

necessary to activate the "Android Auto"

press "Android Auto" to display the

function.

Android Auto interface.

Press this button to display the details of

During the procedure, several screen

Press and hold this steering-mounted

the photo.

pages relating to certain features are

control button and say "OK Google" to

Press the back arrow to go back a level.

displayed.

initiate the smartphone voice commands.

Accept to start and complete the connection.

Access to the different audio sources remains

When connecting a smartphone to the

available in the margin of the Android Auto

Managing messages

system, we recommend enabling

display, using the touch buttons located in the

upper bar.

Press Applications to display the main

Bluetooth^® on the smartphone.

Access to the menus for the system is possible

page.

at any time using the dedicated buttons.

Press "SMS".

210

Touch screen 10" & Bluetooth Radio & Telephone

Select the "SMS” tab.

Move the slider to adjust the brightness of

available connected service, with the exception

the screen and/or the instrument panel

of vehicle location data (e.g. GPS coordinates).

Press this button to select the display

(depending on version).

Some connected services may not

settings for messages.

Press in the shaded area to confirm.

function without the vehicle location data.

Press this button to search and select a

recipient.

Select the "Quick messages” tab.

Privacy Settings

This mode will not be applied to the

emergency call function or to specific

This function allows the user to share, or not

services to which the user has consented

Press this button to select the display

share, data with the offboard.

under the terms of commercial contracts

settings for messages.

The default setting is "No data sharing except

(e.g. Connected alarm).

Press this button to write a new message.

company vehicle".

Confidentiality settings can be accessed via the

"No data sharing except company

Press the bin alongside the selected

"System configuration" menu. You can choose

vehicle"

message to delete it.

between three modes.

This mode does not allow the vehicle to transmit

Press this button alongside the selected

Press "Settings" to display the main

personal data outside the vehicle.

message to display the secondary page.

page.

Press this button to edit and modify the

Press "Configuration" to access the

Connected services will only perform

existing text.

secondary page.

local processing inside the vehicle with

Press this button to write a new message.

Press "System configuration".

limited functions.

Press the bin to delete the message.

Select "Privacy Settings".

This mode will not be applied to the

emergency call function or to specific

"Sharing data and vehicle position"

services to which the user has consented

This mode allows the vehicle to externally

under the terms of commercial contracts

Settings

transmit all the personal data needed for each

(e.g. Connected alarm).

valid available connected service.

Adjusting the brightness

Professional purposes

The personal data required to use the

Press Settings to display the main page.

If the vehicle is used for professional

connected services is sent to the

purposes or under the terms of specific

providers of these services.

Press Brightness.

contracts (e.g. corporate fleet, government

"Only data sharing"

assignment), some privacy modes will not

This mode allows the vehicle to externally

be available for the user on the screen,

transmit all the data needed for each valid

211

Touch screen 10" & Bluetooth Radio & Telephone

depending on the data sharing needs of the

Press the back arrow to confirm.

Setting the time

services.

Press Settings to display the main page.

Modifying system settings

Press "Configuration" to access the

secondary page.

Press Settings to display the main page.

secondary page.

Press "Date and time".

Press "Screen configuration".

Press "Configuration" to access the

Select "Time".

secondary page.

Press "Brightness".

Press this button to set the time using the

Press "System configuration".

Move the slider to adjust the brightness of

virtual keypad.

the screen and/or the instrument panel

Press "OK" to save the time.

Press the "Units" tab to change the units of

(depending on version).

distance, fuel consumption and temperature.

Press the back arrow to confirm.

Press this button to set the time zone.

Press the "Factory settings" tab to restore the

initial settings.

Press "Animation".

Select the display format for the time

Activate or deactivate: “Automatic

Returning the system to factory settings

(12h/24h).

scrolling”.

activates the English language by default

Activate or deactivate summer time (+1

Select "Animated transitions".

(depending on version).

hour).

Press the back arrow to save the settings.

Press the "System info" tab to display the

Press the back arrow to confirm.

versions of the various modules installed in the

system.

The system may not automatically

Press the "Privacy" tab,

Selecting the language

manage the change between winter and

Press Settings to display the main page.

summer time (depending on the country of

Press Settings to display the main page.

sale).

Press "Configuration" to access the

Press "Privacy" to activate or deactivate

secondary page.

Setting the date

the private data mode.

Select "Language" to change the

Press Settings to display the main page.

Activate or deactivate:

language.

Press the back arrow to confirm.

Press "Configuration" to access the

- "No sharing (data, vehicle position)".

secondary page.

- "Only data sharing”

– "Data and vehicle position sharing"

212

Touch screen 10" & Bluetooth Radio & Telephone

Press "Date and time".

Difficulties in connecting wirelessly your

► Activate the "RDS" function in the upper bar

smartphone may happen, due to:

to enable the system to check whether there is

Select "Date".

- Interference with other Wi-Fi networks.

a more powerful transmitter in the geographical

Press this button to set the date.

- Interference with certain devices (tolls,

area.

parking) when using Android Auto.

The environment (hills, buildings, tunnels,

Press the back arrow to save the date.

- An unsuitable configuration of the

basement car parks, etc.) is blocking reception,

smartphone.

including in RDS mode.

Select the display format for the date.

In these cases, it is recommended to connect

This is a perfectly normal phenomenon, and is

the smartphone with its original cable.

not indicative of an audio system malfunction.

Press the back arrow again to confirm.

The aerial is missing or has been damaged

The regulations of the 5 GHz frequency

(for example while entering a car wash or

are specific to each country.

underground car park).

Time and date setting is only available if

Refer to the regulation in force in your

► Have the aerial checked by a dealer.

"GPS Synchronisation:" is deactivated.

country.

I cannot find some radio stations in the list of

received stations.

Wifi settings

The name of the radio station changes.

The station is no longer received or its name has

Press Settings to display the main page.

Frequently asked

changed in the list.

questions

► Press the round arrow on the "List" tab on the

Press "Wifi" to access network frequency

"Radio" page.

setting.

The following information groups together the

Some radio stations send other information

Activate or deactivate the 5 GHz Wifi

answers to the most frequently asked questions

in place of their name (the title of the song for

function.

concerning the system.

example).

Android Auto uses the 5 GHz frequency.

The system interprets these details as the station

Radio

CarPlay^® uses the 2,4 and 5 GHz

name.

The reception quality of the tuned radio

frequency.

► Press the round arrow on the "List" tab on the

station gradually deteriorates or the station

"Radio" page.

presets are not working (no sound, 87.5 MHz

When using CarPlay^® with 5 GHz

is displayed, etc.).

frequency activated, there may be

The vehicle is too far from the selected station’s

interference with certain devices (tolls,

transmitter, or no transmitter is present in the

parking...) resulting in a disconnection. To

geographical area.

prevent this from happening, it is

recommended to disable the 5 GHz function.

213

Touch screen 10" & Bluetooth Radio & Telephone

Media

► Check in the telephone settings that it is

► Modify the telephone directory display

"visible to all".

settings.

Playback of my USB memory stick starts only

The Bluetooth telephone is not compatible with

after a very long wait (around 2 to 3 minutes).

the system.

Settings

Some files supplied with the memory stick may

► Check the compatibility of the telephone on

When the treble and bass settings are

greatly slow down access to reading the memory

the Brand's website (services).

changed, the ambience is deselected.

stick (multiplication by 10 of the cataloguing

Android Auto and/or CarPlay do not work.

When the ambience is changed, the treble

time).

Android Auto and CarPlay may not activate if the

and bass settings are reset.

► Delete the files supplied with the memory

USB cables are of poor quality.

Selecting an ambience imposes the treble and

stick and limit the number of sub-folders in the

► Use genuine USB cables to ensure

bass settings, and vice versa.

file structure on the memory stick.

compatibility.

► Modify the treble and bass or ambience

Some characters in information about the

Android Auto and/or CarPlay do not work.

settings to obtain the desired musical ambience.

currently playing media are not displayed

Android Auto and CarPlay are not available in all

When the balance settings are changed, the

correctly.

countries.

distribution is deselected.

The audio system is unable to process certain

► Check the Google Android Auto or Apple

When the distribution setting is changed, the

types of character.

website to see which countries are supported.

balance settings are deselected.

► Use standard characters to name tracks and

The volume of the telephone connected in

Selecting a distribution setting imposes the

folders.

Bluetooth mode is inaudible.

balance settings, and vice versa.

Playback of streaming files does not start.

The volume depends on both the system and the

► Modify the balance setting or the distribution

The connected device does not automatically

telephone.

setting to obtain the desired sound quality.

launch playback.

► Increase the volume of the audio system, to

There is a difference in sound quality

► Start playback from the device.

maximum if required, and increase the volume of

between audio sources.

Track names and playing times are not

the telephone if necessary.

To allow for optimal listening quality, the sound

displayed on the audio streaming screen.

Ambient noise affects the quality of the

settings can be tailored to different audio

The Bluetooth profile does not allow the transfer

telephone call.

sources, which can generate audible differences

of this information.

► Reduce ambient noise (close windows, turn

when changing source.

down ventilation, slow down, etc.).

► Check that the sound settings are appropriate

Telephone

The contacts are not listed in alphabetical

to the sources listened to. Adjust the sound

I cannot connect my Bluetooth telephone.

order.

functions to the middle position.

The telephone's Bluetooth function may be

Some telephones offer display options.

When the engine is off, the system switches

switched off or the device may not be visible.

Depending on the settings chosen, contacts can

off after several minutes of use.

► Check that the telephone has Bluetooth

be transferred in a specific order.

switched on.

214

PEUGEOT Connect Radio

The system’s Open Source Software

Press in the shaded area to go back up a level

PEUGEOT Connect

(OSS) source codes are available at the

or confirm.

Radio

following addresses:

Press the back arrow to go back a level or

https://www.groupe-psa.com/fr/oss/

confirm.

Multimedia audio system -

https://www.groupe-psa.com/en/oss/

The touch screen is of the "capacitive"

Applications - Bluetooth^®

type.

To clean the screen, use a soft, non-abrasive

telephone

First steps

cloth (e.g. spectacles cloth) with no additional

The functions and settings described

With the engine running, a press mutes

product.

vary according to the vehicle version and

the sound.

Do not use sharp objects on the screen.

configuration, as well as the country of sale.

With the ignition off, a press turns the system on.

Do not touch the screen with wet hands.

Increase or decrease the volume using

Certain information is displayed permanently in

For safety reasons and because they

the wheel or the "plus" or "minus" buttons

the upper bar of the touch screen:

require sustained attention by the driver,

(depending on the equipment).

- Air conditioning status information (depending

the following operations must be carried out

Use the buttons on either side of or below the

on version), and direct access to the

with the vehicle stationary and the ignition

touch screen to access the menus, then press

corresponding menu.

on:

the virtual buttons on the touch screen.

- Radio Media and Telephone menu status

- Pairing the smartphone with the system via

Depending on the model, use the "Source" and

information.

Bluetooth.

"Menu" buttons on the left of the touch screen to

- Privacy status information.

- Using the smartphone.

access the menus, then press the virtual buttons

- Access to the touch screen and digital

- Connecting to the CarPlay^® or Android

on the touch screen.

instrument panel settings.

Auto applications (certain applications stop

At all times it is possible to display the rolling

Audio source selection (depending on

displaying when the vehicle is moving).

menus by pressing the screen briefly with three

equipment):

- Changing the system settings and

fingers.

- FM/DAB/AM radio stations (depending on

configuration.

All touch-sensitive areas on the screen are

equipment).

white.

- Telephone connected via Bluetooth and

On pages with multiple tabs at the bottom of the

The system is protected so that it only

Bluetooth multimedia broadcast (streaming).

screen, you can switch between pages either

operates in the vehicle.

- USB Memory stick.

by tapping the tab for the desired page or by

The message Energy economy mode is

- Media player connected via the auxiliary

swiping the pages to the left or right with your

displayed when the system is about to go into

socket (depending on equipment).

finger.

standby.

216

PEUGEOT Connect Radio

This control is located on the steering wheel or

Radio:

at the end of the lighting control stalk (depending

Select the previous/next preset radio

on equipment).

station.

Short press, smartphone voice commands via

Select the previous/next item in a menu or a list.

the system.

Media:

Increase volume.

Select the previous/next track.

Select the previous/next item in a menu or a list.

Decrease volume.

Radio:

Mute by pressing the volume increase

Short press: display the list of radio

and decrease buttons simultaneously

stations.

(depending on equipment).

In the "Settings" menu, it is possible to

Long press: update the list.

Restore the sound by pressing one of the two

create a profile for an individual or for a

Media:

volume buttons.

group of people with shared interests, and

Short press: display the list of folders.

Media (short press): change the

configure a wide range of settings (radio

Long press: display the available sorting options.

multimedia source.

presets, audio settings, ambiences, etc.).

Change audio source (radio; USB; AUX if

Telephone (short press): start telephone

Settings are applied automatically.

equipment connected; CD; streaming).

call.

Confirm a selection.

Call in progress (short press): access

In very hot conditions, the volume may

telephone menu.

be limited to protect the system. It may

Increase volume.

Telephone (long press): reject an incoming call,

enter standby mode (with the screen and

end call; when no call is in progress, access

sound off) for 5 minutes or more.

Decrease volume.

telephone menu.

The system will resume normal operation

Radio (rotate): automatic search for the

when the temperature in the passenger

Mute/restore sound by simultaneously

previous/next station.

compartment has dropped.

pressing the increase and decrease

Media (rotate): previous/next track, move in a

volume buttons.

list.

Short press: confirm a selection; if nothing

Steering mounted controls

Steering mounted controls -

selected, access to presets.

Radio: display the list of stations.

Type 2

Steering mounted controls -

Media: display the list of tracks.

Radio (press and hold): update the list of

Type 1

stations received.

Voice commands:

217

PEUGEOT Connect Radio

Air conditioning

Press this button to display the details of

Radio

the photo.

Press the back arrow to go back a level.

Selecting a station

Press Radio Media to display the main

Managing messages

page.

18,5

21,5

Press Applications to display the main

Press one of the buttons to perform an

automatic search for radio stations.

page.

Press "SMS".

Move the slider to manually search for

frequencies up or down.

Select the "SMS” tab.

Manage various temperature and air flow

Press this button to select the display

Press the frequency.

settings.

settings for messages.

Enter the FM and AM waveband values

Press this button to search and select a

using the virtual keypad.

recipient.

Applications

Press "OK" to confirm.

Select the "Quick messages” tab.

Viewing photos

Press this button to select the display

Radio reception may be affected by the

Insert a USB memory stick in the USB port.

settings for messages.

use of electrical equipment not approved

Press this button to write a new message.

by the Brand, such as a USB charger

To protect the system, do not use a USB

hub.

connected to the 12 V socket.

Press the bin alongside the selected

The exterior environment (hills, buildings,

The system can read folders and image files in

message to delete it.

tunnels, basement car parks, etc.) may

the formats: .tiff; .gif; .jpg/jpeg; .bmp and .png.

Press this button alongside the selected

block reception, including in RDS mode.

Press Applications to display the main

message to display the secondary page.

This phenomenon is perfectly normal in the

page.

Press this button to edit and modify the

context of radio wave transmission, and

Press "Photos".

existing text.

in no way indicative of an audio system

Press this button to write a new message.

malfunction.

Select a folder.

Press the bin to delete the message.

Select an image to view.

219

PEUGEOT Connect Radio

Changing the waveband

Press in the shaded area to confirm.

Press Radio Media to display the main

page.

Press Radio Media to display the main

Press the "OPTIONS" button to access the

page.

RDS station tracking may not be

secondary page.

Press the "OPTIONS" button to access the

available nationwide, as many radio

Activate/deactivate "TA".

secondary page.

stations do not cover 100 % of the country.

Press "Band" to change waveband.

This explains the loss of reception of the

Press in the shaded area to confirm.

station during a journey.

Press in the shaded area to confirm.

Displaying text information

Audio settings

Presetting a station

The "Radio Text" function displays information

Press Radio Media to display the main

transmitted by the radio station relating to the

page.

Select a radio station or frequency.

station or the currently playing song.

Press the "OPTIONS" button to access the

Make a short press on the star outline. If

Press Radio Media to display the main

secondary page.

the star is solid, the radio station is

page.

Press "Audio settings".

already preset.

Press the "OPTIONS" button to access the

secondary page.

Select the "Tone", "Balance", "Sound",

Select a radio station or frequency.

Activate/deactivate "News".

"Voice" or "Ringtones" tab to configure

Press "Preset".

the sound settings.

Make a long press on one of the buttons

Press in the shaded area to confirm.

Press the back arrow to confirm.

to preset the station.

Activating/Deactivating RDS

In the "Tone" tab, the Ambience, Bass,

Playing TA messages

RDS, if activated, allows you to continue

Medium and Treble sound settings are

listening to the same station by automatically

The TA (Traffic Announcement) function gives

different and independent for each audio

retuning to alternative frequencies.

priority to TA alert messages. To operate, this

source.

Press Radio Media to display the main

function needs good reception of a radio station

In the "Balance” tab, the All passengers,

page.

that transmits this type of message. While traffic

Driver and Front only settings are common

Press the "OPTIONS" button to access the

information is being broadcast, the current

to all sources.

secondary page.

media is automatically interrupted so that the

In the "Sound” tab, activate or deactivate

Activate/deactivate "RDS".

TA message can be heard. Normal play of the

"Volume linked to speed", "Auxiliary input"

previously playing media resumes at the end of

and "Touch tones".

the message.

220

PEUGEOT Connect Radio

The balance/distribution (or spatialisation

When the digital radio signal is poor, the

Media

"FM-DAB Follow-up" enables you to continue

processing to adjust the sound quality

listening to the same station by automatically

USB port

according to the number of passengers in the

switching to the corresponding "FM" analogue

vehicle.

station (if there is one).

Insert the USB memory stick into the USB

Press Radio Media to display the main

port or connect the USB device to the

page.

USB port using a suitable cable (not supplied).

optimises the sound distribution inside

Press the "OPTIONS" button to access the

To protect the system, do not use a USB

the passenger compartment.

secondary page.

hub.

Activate/deactivate "FM-DAB Follow-up".

The system builds playlists (in temporary

Press in the shaded area to confirm.

memory); this operation can take from a

DAB (Digital Audio

few seconds to several minutes at the first

Broadcasting) radio

connection.

If "FM-DAB Follow-up" is activated, there

Reduce the number of non-music files and the

may be a time offset of a few seconds

Terrestrial Digital Radio

number of folders to reduce the waiting time.

when the system switches to "FM" analogue

Playlists are updated whenever the ignition

Digital radio provides higher quality sound.

radio, and in some cases a change in volume.

is switched off or a USB memory stick is

The various "multiplexes/ensembles" offer a

When the digital signal quality is restored, the

connected. The audio system memorises these

choice of radio stations organised in alphabetical

system automatically changes back to "DAB".

lists, which will subsequently load faster if they

order.

have not been changed.

Press Radio Media to display the main

If the "DAB" station being listened to is

page.

not available on "FM", or if "FM-DAB

Auxiliary (AUX) jack socket

Press the "OPTIONS" button to access the

Follow-up" is not activated, the sound will cut

Depending on equipment

secondary page.

out while the digital signal is too weak.

Connect a portable device (MP3 player,

Press "Band" to select "DAB band".

etc.) to the auxiliary jack socket using an

audio cable (not supplied).

Press in the shaded area to confirm.

This source is only available if "Auxiliary input"

has been selected in the audio settings.

FM-DAB Follow-up

First adjust the volume on the portable device

(to a high level). Then adjust the volume of the

"DAB" does not cover 100 % of the country.

audio system.

Controls are managed via the portable device.

221

PEUGEOT Connect Radio

Selecting the source

classification structured in the form of a

All ".wma" files must be standard WMA 9 files.

library.

The supported sampling rates are 11, 22, 44 and

Press Radio Media to display the main

The default classification used is by artist. To

48 KHz.

page.

modify the classification used, return to the

To avoid reading and display problems, we

Press the "SOURCES" button.

first level of the menu then select the desired

recommend choosing file names less than 20

Select the source.

classification (playlists for example) and

characters long that do not contain any special

confirm to go down through the menu to the

characters (e.g. “ ? . ; ù).

Bluetooth Streaming^®

desired track.

Use only USB memory sticks in FAT32 format

Streaming allows you to listen to the audio feed

(File Allocation Table).

from your smartphone.

The version of software in the audio system may

The Bluetooth profile must be activated.

not be compatible with the generation of the

We recommend using the original USB

First adjust the volume on the portable device

Apple^® player.

cable for the portable device.

(to a high level). Then adjust the volume of the

system.

Information and advice

If play does not start automatically, it may be

The system supports USB mass storage

Telephone

necessary to start the audio playback from the

devices, BlackBerry^® devices or Apple^® players

smartphone.

USB sockets

via the USB ports. The adapter cable is not

Control is from the portable device or by using

supplied.

Depending on equipment, for more information

the system's touch buttons.

Devices are managed using the audio system

on the USB sockets compatible with CarPlay^® or

controls.

Android Auto applications, refer to the "Ease of

Once connected in Streaming mode, the

Other devices, not recognised on connection,

use and comfort" section.

smartphone is considered to be a media

source.

must be connected to the auxiliary socket using

For the list of compatible smartphones,

a jack cable (not supplied) or via Bluetooth

visit the Manufacturer's website in your

streaming, if compatible.

country.

Connecting Apple^® players

To protect the system, do not use a USB

Connect the Apple^® player to the USB socket

hub.

Synchronising a smartphone enables

using a suitable cable (not supplied).

users to display applications that support

Play starts automatically.

The audio system will only play audio files with

the smartphone’s CarPlay^® or Android Auto

Control is via the audio system.

".wav", ".wma", ".aac", ".ogg" and ".mp3" file

technology on the vehicle’s screen. For

extensions, at bit rates between 32 Kbps and

The classifications available are those of

320 Kbps.

the portable device connected (artists/

It also supports VBR (Variable Bit Rate) mode.

albums/genres/playlists/audio books/

No other file types (".mp4", etc.) can be read.

podcasts). It is also possible to use a

222

PEUGEOT Connect Radio

CarPlay^® technology, the CarPlay^® function

Connect the USB cable. The smartphone

Telephone not connected by

must first be activated on the smartphone.

charges when connected by the USB

Bluetooth^®

Unlock the smartphone for the communication

cable.

Connect a USB cable. The smartphone

process between the smartphone and the

From the system, press "Telephone" to

charges when connected by a USB cable.

system to work.

display the main page.

From the system, press "Telephone" to

As principles and standards are constantly

Press the "PHONE" button to go to the

display the main page.

changing, we recommend keeping the

secondary page.

Press "Android Auto" to start the

smartphone's operating system up-to-

Press "CarPlay" to display the CarPlay^®

application in the system.

date, together with the date and time on

interface.

Depending on the smartphone, it may be

the smartphone and the system.

When the USB cable is disconnected

necessary to activate the "Android Auto"

and the ignition is switched off then back

function.

CarPlay^® smartphone

on, the system will not automatically switch to

During the procedure, several screen

Radio Media mode; the source must be

pages relating to certain features are

connection

displayed.

changed manually.

Depending on country.

Accept to start and complete the connection.

The CarPlay^® navigation can be accessed

When connecting a smartphone to the

On connecting the USB cable, the

at any time by pressing the system's

system, we recommend enabling

CarPlay^® function deactivates the

Navigation button.

Bluetooth^® on the smartphone.

system's Bluetooth^® mode.

The "CarPlay" function requires the use of

Android Auto smartphone

Telephone connected by Bluetooth^®

a compatible smartphone and compatible

From the system, press "Telephone" to

applications.

connection

display the main page.

Depending on country.

Connect the USB cable. The smartphone

Press the "PHONE" button to display the

On the smartphone, download the

charges when connected by the USB

secondary page.

Android Auto application.

cable.

Press "Android Auto" to start the

From the system, press Telephone to

The "Android Auto" function requires the

application in the system.

display the CarPlay^® interface.

use of a compatible smartphone and

Access to the different audio sources remains

applications.

available in the margin of the Android Auto

If the smartphone has already connected

display, using the touch buttons located in the

by Bluetooth^®.

upper bar.

Access to the menus for the system is possible

at any time using the dedicated buttons.

223

PEUGEOT Connect Radio

There may be a pause before

In the system, accept the connection request

The profiles compatible with the system

applications become available,

from the telephone.

are: HFP, OPP, PBAP, A2DP, AVRCP,

depending on the quality of the network.

MAP and PAN.

Procedure from the system

Visit the Brand's website for more information

Press Telephone to display the main

Pairing a Bluetooth^®

(compatibility, additional help, etc.).

page.

telephone

Press "Bluetooth search".

Automatic reconnection

The list of detected telephones is

The services available depend on the

On returning to the vehicle, if the last telephone

displayed.

network, the SIM card and the

connected is present again, it is automatically

Select the name of the chosen telephone

compatibility of the Bluetooth devices used.

recognised and within about 30 seconds

in the list.

Consult the telephone user guide and the

after switching on the ignition, the pairing is

service provider to check which services are

Connection sharing

established automatically (Bluetooth activated).

available.

To modify the connection profile:

The system offers to connect the telephone with

Press Telephone to display the main

3 profiles:

The Bluetooth function must be activated

- "Telephone" (hands-free kit, telephone only),

page.

and the telephone configured as "Visible

- “Streaming" (streaming: wireless playing of

Press the "PHONE" button to access the

to all” (in the telphone settings).

audio files on the telephone),

secondary page.

Press "Bluetooth connection" to

- "Mobile internet data".

To complete the pairing, whichever procedure is

display the list of paired devices.

Select one or more profiles.

used (from the telephone or from the system),

Press the "Details" button for a paired

ensure that the code is the same in the system

device.

Press "OK" to confirm.

and in the telephone.

Select one or more profiles.

If the pairing procedure fails, we

Depending on the type of telephone, you may by

Press "OK" to confirm.

recommend deactivating and then

prompted to accept the transfer of contacts and

reactivating the Bluetooth function on the

messages.

telephone.

The ability of the system to connect just

Managing paired telephones

one profile depends on the telephone.

This function lets you connect or disconnect a

Procedure from the telephone

All three profiles may connect by default.

device or delete a pairing.

Select the name of the system in the list

Press Telephone to display the main

of detected devices.

page.

224

PEUGEOT Connect Radio

Press the "PHONE" button to access the

Making a call

secondary page.

Press and hold

Press "Bluetooth connection" to

Using the telephone is not recommended

display the list of paired devices.

while driving.

the steering mounted button.

Press on the name of the telephone

Parking the vehicle.

selected in the list to disconnect it.

Make the call using the steering mounted

Press "Recent calls".

Press again to connect it.

controls.

Select the desired contact from the displayed list.

It is always possible to make a call

Deleting a telephone

Calling a new number

directly from the telephone; as a safety

Press the basket at the top right of the

Press Telephone to display the main

measure, first park the vehicle.

screen to display a basket alongside the

page.

telephone chosen.

Enter the phone number using the digital

Press the basket alongside the telephone

Setting the ringtone

keypad.

chosen to delete it.

Press Telephone to display the main

Press "Call" to start the call.

page.

Receiving a call

Press the "OPTIONS" button to access the

An incoming call is announced by a ring and a

secondary page.

Calling a contact

superimposed display in the screen.

Press "Ring volume" to display the

Press Telephone to display the main

Make a short press on the steering

volume bar.

page.

mounted PHONE button to accept an

Press the arrows or move the slider to set

Or press and hold

incoming call.

the ring volume.

And

the steering mounted PHONE button.

Make a long press

Settings

Press "Contacts".

on the steering mounted PHONE button

Select the desired contact from the displayed list.

to reject the call.

Configuring profiles

Press "Call".

Press Settings to display the main page.

Press "End call".

Press "Profiles".

Calling a recently used

number

Select "Profile 1", "Profile 2", "Profile 3” or

Press Telephone to display the main

"Common profile".

page.

225

PEUGEOT Connect Radio

Press this button to enter a name for the

Press the "Factory settings" tab to restore the

Press the back arrow to confirm.

profile using the virtual keypad.

initial settings.

Press "OK" to save.

Press "Animation".

Returning the system to factory settings

Activate or deactivate: “Automatic

activates the English language by default

Press the back arrow to confirm.

scrolling”.

(depending on version).

Select "Animated transitions".

Press this button to activate the profile.

Press the "System info" tab to display the

versions of the various modules installed in the

Press the back arrow to confirm.

Press the back arrow again to confirm.

system.

Press the "Privacy" tab,

Press this button to reset the selected

Selecting the language

profile.

Press Settings to display the main page.

Adjusting the brightness

Press "Privacy" to activate or deactivate

Press "Configuration" to access the

Press Settings to display the main page.

the private data mode.

secondary page.

Activate or deactivate:

Select "Language" to change the

Press Brightness.

language.

- "No sharing (data, vehicle position)".

Press the back arrow to confirm.

Move the slider to adjust the brightness of

- "Only data sharing”

the screen and/or the instrument panel

- "Data and vehicle position sharing"

(depending on version).

Press the back arrow to confirm.

Setting the time

Press in the shaded area to confirm.

Press Settings to display the main page.

Press "Configuration" to access the

Modifying system settings

Press "Configuration" to access the

secondary page.

Press Settings to display the main page.

secondary page.

Press "Date and time".

Press "Screen configuration".

Press "Configuration" to access the

Select "Time".

secondary page.

Press "Brightness".

Press this button to set the time using the

Press "System configuration".

Move the slider to adjust the brightness of

virtual keypad.

the screen and/or the instrument panel

Press "OK" to save the time.

Press the "Units" tab to change the units of

(depending on version).

distance, fuel consumption and temperature.

226

PEUGEOT Connect Radio

Press this button to set the time zone.

Time and date setting is only available if

I cannot find some radio stations in the list of

"GPS Synchronisation:" is deactivated.

received stations.

Select the display format for the time

The name of the radio station changes.

(12h/24h).

The station is no longer received or its name has

Activate or deactivate summer time (+1

Frequently asked

changed in the list.

hour).

► Press the round arrow on the "List" tab on the

questions

Activate or deactivate GPS

"Radio" page.

synchronisation (UTC).

The following information groups together the

Some radio stations send other information

Press the back arrow to save the settings.

answers to the most frequently asked questions

in place of their name (the title of the song for

concerning the system.

example).

The system interprets these details as the station

The system may not automatically

Radio

name.

manage the change between winter and

The reception quality of the tuned radio

► Press the round arrow on the "List" tab on the

summer time (depending on the country of

station gradually deteriorates or the station

"Radio" page.

sale).

presets are not working (no sound, 87.5 MHz

Media

is displayed, etc.).

Setting the date

The vehicle is too far from the selected station’s

Playback of my USB memory stick starts only

Press Settings to display the main page.

transmitter, or no transmitter is present in the

after a very long wait (around 2 to 3 minutes).

geographical area.

Some files supplied with the memory stick may

Press "Configuration" to access the

► Activate the "RDS" function in the upper bar

greatly slow down access to reading the memory

secondary page.

to enable the system to check whether there is

stick (multiplication by 10 of the cataloguing

Press "Date and time".

a more powerful transmitter in the geographical

time).

area.

► Delete the files supplied with the memory

The environment (hills, buildings, tunnels,

stick and limit the number of sub-folders in the

Select "Date".

Press this button to set the date.

basement car parks, etc.) is blocking reception,

file structure on the memory stick.

including in RDS mode.

Some characters in information about the

Press the back arrow to save the date.

This is a perfectly normal phenomenon, and is

currently playing media are not displayed

not indicative of an audio system malfunction.

correctly.

Select the display format for the date.

The aerial is missing or has been damaged

The audio system is unable to process certain

(for example while entering a car wash or

types of character.

Press the back arrow again to confirm.

underground car park).

► Use standard characters to name tracks and

► Have the aerial checked by a dealer.

folders.

Playback of streaming files does not start.

227

PEUGEOT Connect Radio

The connected device does not automatically

The volume depends on both the system and the

► Modify the balance setting or the distribution

launch playback.

telephone.

setting to obtain the desired sound quality.

► Start playback from the device.

► Increase the volume of the audio system, to

There is a difference in sound quality

Track names and playing times are not

maximum if required, and increase the volume of

between audio sources.

displayed on the audio streaming screen.

the telephone if necessary.

To allow for optimal listening quality, the sound

The Bluetooth profile does not allow the transfer

Ambient noise affects the quality of the

settings can be tailored to different audio

of this information.

telephone call.

sources, which can generate audible differences

► Reduce ambient noise (close windows, turn

when changing source.

Telephone

down ventilation, slow down, etc.).

► Check that the sound settings are appropriate

I cannot connect my Bluetooth telephone.

The contacts are not listed in alphabetical

to the sources listened to. Adjust the sound

The telephone's Bluetooth function may be

order.

functions to the middle position.

switched off or the device may not be visible.

Some telephones offer display options.

When the engine is off, the system switches

► Check that the telephone has Bluetooth

Depending on the settings chosen, contacts can

off after several minutes of use.

switched on.

be transferred in a specific order.

When the engine is switched off, the system's

► Check in the telephone settings that it is

► Modify the telephone directory display

operating time depends on the state of charge of

"visible to all".

settings.

the battery.

The Bluetooth telephone is not compatible with

The switch-off is normal: the system

the system.

Settings

automatically goes into energy economy mode

► Check the compatibility of the telephone on

When the treble and bass settings are

and switches off to maintain an adequate charge

the Brand's website (services).

changed, the ambience is deselected.

in the battery.

Android Auto and/or CarPlay do not work.

When the ambience is changed, the treble

► Start the vehicle’s engine to increase the

Android Auto and CarPlay may not activate if the

and bass settings are reset.

charge of the battery.

USB cables are of poor quality.

Selecting an ambience imposes the treble and

► Use genuine USB cables to ensure

bass settings, and vice versa.

compatibility.

► Modify the treble and bass or ambience

Android Auto and/or CarPlay do not work.

settings to obtain the desired musical ambience.

Android Auto and CarPlay are not available in all

When the balance settings are changed, the

countries.

distribution is deselected.

► Check the Google Android Auto or Apple

When the distribution setting is changed, the

website to see which countries are supported.

balance settings are deselected.

The volume of the telephone connected in

Selecting a distribution setting imposes the

Bluetooth mode is inaudible.

balance settings, and vice versa.

228

PEUGEOT Connect Nav

The system is protected so that it only

All of the touch areas of the screen are white.

PEUGEOT Connect Nav

operates in the vehicle.

Press the back arrow to go back a level.

The message Energy economy mode is

Press "OK" to confirm.

GPS navigation -

displayed when the system is about to go into

The touch screen is of the "capacitive"

Applications - Multimedia

standby.

type.

audio system - Bluetooth^®

To clean the screen, use a soft, non-abrasive

System and map updates can be

cloth (e.g. spectacles cloth) with no additional

telephone

downloaded from the Brand's website.

product.

The update procedure is also available there.

The functions and settings described

Do not use sharp objects on the screen.

vary according to the vehicle version and

Do not touch the screen with wet hands.

configuration, as well as the country of sale.

The system’s Open Source Software

(OSS) source codes are available at the

Certain information is displayed permanently

following addresses:

in the side bars or in the upper bar of the touch

For safety reasons and because they

https://www.groupe-psa.com/fr/oss/

screen (depending on equipment):

require sustained attention by the driver,

https://www.groupe-psa.com/en/oss/

- Air conditioning status information (depending

the following operations must be carried out

on version), and direct access to the

with the vehicle stationary and the ignition

corresponding menu.

on:

- Go directly to the audio source selection

- Pairing the smartphone with the system via

First steps

option, to view the list of radio stations (or list of

Bluetooth.

With the engine running, a press mutes

titles depending on the source).

- Using the smartphone.

the sound.

- Go to the "Notifications" of messages, emails,

- Connecting to the CarPlay^® or Android

With the ignition off, a press turns the system on.

map updates and, depending on the services,

Auto applications (certain applications stop

Increase or decrease the volume using

the navigation notifications.

displaying when the vehicle is moving).

the wheel or the "plus" or "minus" buttons

- Go to the settings for the touch screen and the

- Watching a video (the video stops when the

(depending on the equipment).

digital instrument panel.

vehicle starts to move again).

Use the menu buttons on either side of or below

Audio source selection (depending on

- Changing the system settings and

the touch screen for access to the menus, then

equipment):

configuration.

press the virtual buttons in the touch screen.

- FM/DAB/AM radio stations (depending on

Depending on the model, use the "Source" or

equipment).

AM and DAB radio are not available on

"Menu" buttons to access the rolling menus, then

- Telephone connected via Bluetooth and

Hybrid vehicles.

press the virtual buttons in the touch screen.

Bluetooth multimedia broadcast (streaming).

Display the rolling menus at any time by pressing

- USB memory stick.

the screen briefly with three fingers.

229

PEUGEOT Connect Nav

- Media player connected via the auxiliary

Media: display the list of tracks.

Steering mounted controls

socket (depending on equipment).

Radio (press and hold): update the list of

Voice control:

- Video (depending on equipment).

detected stations.

This control is located on the steering

wheel or at the end of the lighting control stalk

(depending on equipment).

Menus

Short press, system voice control.

Long press, voice commands from smartphone

Connected navigation

or CarPlay^®, Android Auto via the system.

Increase volume.

Decrease volume.

Mute by pressing the volume increase

and decrease buttons simultaneously

In the "Settings" menu, it is possible to

(depending on equipment).

create a profile for an individual or for a

Restore the sound by pressing one of the two

group of people with shared interests, and

volume buttons.

configure a wide range of settings (radio

Media (short press): change the

presets, audio settings, navigation history,

multimedia source.

Enter navigation settings and choose a

favourite contacts, etc.). Settings are applied

Telephone (short press): start telephone

destination.

automatically.

call.

Use real-time services, depending on equipment.

Call in progress (short press): access

telephone menu.

In very hot conditions, the volume may

Telephone (long press): reject an incoming call,

be limited to protect the system. It may

end call; when no call is in progress, access

enter standby mode (with the screen and

telephone menu.

sound off) for 5 minutes or more.

Radio (rotate): automatic search for the

The system will resume normal operation

previous/next station.

when the temperature in the passenger

Media (rotate): previous/next track, move

compartment has dropped.

through a list.

Short press: confirm a selection; if nothing

selected, access presets.

Radio: display the list of stations.

230

PEUGEOT Connect Nav

Example of a "voice command" for the radio and

Voice commands

media:

"Play artist Madonna"

Steering wheel-mounted

Example of a "voice command" for the

controls

telephone:

Voice commands:

"Call David Miller"

Voice commands can be issued from any

The voice commands, with a choice of 17

screen page after a short press on the "Voice

languages (Arabic, Brazilian, Czech,

commands" button located on the steering

Danish, Dutch, English, Farsi, French,

wheel or at the end of the lighting control stalk

German, Italian, Norwegian, Polish,

A number of commands are available when a

(depending on equipment), as long as there is no

Portuguese, Russian, Spanish, Swedish,

menu is selected.

telephone call in progress.

Turkish), are made using the language

To ensure that voice commands are

previously chosen and set in the system.

always recognised by the system, please

For some voice commands, there are

follow these recommendations:

alternative synonyms.

- use natural language in a normal tone

Example: Guide to / Navigate to / Go to / ...

without breaking up words or raising your

The voice commands in Arabic for: "Navigate

voice.

to address" and "Display POI in the city", are

- always wait for the "beep" (audible signal)

not available.

before speaking.

- for best results, closing the windows and

Information - Using the

sunroof is recommended, to avoid extraneous

Press the Push To Talk button and tell me

interference (depending on version).

system

what you'd like after the tone. Remember

- before issuing a voice command, ask any

When voice commands are activated, by

you can interrupt me at any time by pressing this

other passengers to refrain from speaking.

briefly pressing the button, help is

button. If you press it again while I'm waiting for

displayed on the touch screen, offering various

you to speak, it'll end the conversation. If you

menus and enabling voice-based interaction with

need to start over, say "cancel". If you want to

First steps

the system.

undo something, say "undo". And to get

Example of a "voice command" for

information and tips at any time, just say "help".

navigation:

If you ask to me do something and there's some

"Navigate to address 11 regent street,

information missing that I need, I'll give you

London"

some examples or take you through it step by

232

PEUGEOT Connect Nav

step. There's more information available in

To plan a route, say "navigate to" followed by the

distance" or "arrival time". To learn more

"novice" mode. You can set the dialogue mode to

address, the contact name or an intersection. For

commands, try saying "help with navigation".

"expert" when you feel comfortable.

example, "navigate to address 11 Regent Street,

Voice commands

London", "navigate to contact, John Miller",

Global voice commands

or "navigate to intersection of Regent Street,

Show POI ''hotel'' at the destination

Voice commands

London". You can specify if it's a preferred

Show nearby POI petrol station

address, or a Point of Interest. For example, say

Navigate to POI Heathrow Airport in London

Set dialogue mode as novice - expert

"navigate to preferred address, Tennis club", or

Navigate to POI petrol station along the route

Select user 1 / Select profile John

"navigate to POI Heathrow Airport in London".

Help messages

Increase temperature

Or, you can just say, "navigate home". To see

Decrease temperature

Points of Interest on a map, you can say things

To see points of interest on a map, you can

Help messages

like "show POI hotels in Banbury". For more

say things like "show hotels in Banbury", "show

information say "help with points of interest" or

nearby parking", "show hotel at the destination"

There are lots of topics I can help you with.

"help with route guidance".

or "show petrol station along the route". If you

You can say: "help with phone", "help with

To choose a destination, say something like

prefer to navigate directly to a point of interest,

navigation", "help with media" or "help with

"navigate to line three" or "select line two". If you

you can say "navigate to nearby petrol station".

radio". For an overview on how to use voice

can't find the destination but the street's right,

If you feel you are not being well understood,

controls, you can say "help with voice controls".

say for example "select the street in line three".

try to say the word "POI" in front of the point

Say "yes" if I got that right. Otherwise, say "no"

To move around a displayed list, you can say

of interest. For example say "navigate to POI

and we'll start that again.

"next page" or "previous page". You can undo

restaurant at the destination".

your last action and start over by saying "undo",

To choose a POI, say something like "select

"Navigation" voice

or say "cancel" to cancel the current action.

line 2". If you've searched for a Point of Interest

Voice commands

and don't see the one you're after, you can filter

commands

further by saying something like "select POI in

Voice commands

Tell me the remaining distance

line 2", or "select the city in line 3". You can also

Tell me the remaining time

scroll through the list by saying "next page" or

Navigate home

Tell me the arrival time

"previous page".

Navigate to work

Stop route guidance

Navigate to preferred address, Tennis club

Depending on the country, give

Help messages

Navigate to contact, John Miller

destination (address) instructions in the

Navigate to address 11 regent street, London

language configured for the system.

You can say "stop" or "resume route guidance".

Help messages

To get information about your current route, you

can say "tell me the remaining time", "remaining

233

PEUGEOT Connect Nav

"Radio Media" voice

Voice commands

Media voice commands are available

only with a USB connection.

commands

What's playing?

Voice commands

Help messages

"Telephone" voice

Turn on source radio - Streaming Bluetooth

To choose what you'd like to play, start by saying

commands

- …

"play" and then the item. For example, say "play

Help messages

If there is no telephone connected by

song Hey Jude", "play line 3" or "select line 2".

Bluetooth, a voice message announces:

You can undo your last action and start over

You can select an audio source by saying "turn

by saying "undo", or say "cancel" to cancel the

"Please first connect a telephone", and the

on source" followed by the device name. For

voice session is closed.

current action.

example, "turn on source, Streaming Bluetooth",

Voice commands

or "turn on source, radio". Use the command

"play" to specify the type of music you'd like to

Play song Hey Jude

Call David Miller*

hear. You can choose between "song", "artist",

Play artist Madonna

Call voicemail*

or "album". Just say something like "play artist,

Play album Thriller

Display calls*

Madonna", "play song, Hey Jude", or "play

Help messages

album, Thriller".

Voice commands

I'm not sure what you'd like to play. Please say

To make a phone call, say "call" followed by

"play" and then a song title, an album title, or

the contact name, for example: "Call David

Tune to channel BBC Radio 2

an artist name. For example, say "play song

Miller". You can also include the phone type, for

Tune to 98.5 FM

Hey Jude", "play artist Madonna" or "play

example: "Call David Miller at home". To make

Tune to preset number five

album Thriller". To select a line number from the

a call by number, say "dial" followed by the

Help messages

display, say "select line two". To move around

phone number, for example, "Dial 107776 835

a displayed list, you can say "next page" or

417". You can check your voicemail by saying

You can pick a radio station by saying "tune to"

"previous page". You can undo your last action

"call voicemail". To send a text, say "send quick

and the station name or frequency. For example

and start over by saying "undo", or say "cancel"

message to", followed by the contact, and then

"tune to channel Talksport" or "tune to 98.5

to cancel the current action.

the name of the quick message you'd like to

FM". To listen to a preset radio station, say for

send. For example, "send quick message to

example "tune to preset number five".

* This function is available only if the telephone connected to the system supports downloading of contacts and recent calls and the corresponding

download has been performed.

234

PEUGEOT Connect Nav

David Miller, I'll be late". To display the list of

From the list of quick messages, say the name of

Bill Carter, I'll be late". Check the phone menu

calls, say "display calls". For more information on

the one you'd like to send. To move around the

for the names of the supported messages.

SMS, you can say "help with texting".

list you can say "go to start", "go to end", "next

The system only sends pre-recorded

To choose a contact, say something like "select

page" or "previous page". You can undo your last

"Quick messages".

line three". To move around the list say "next

action and start over by saying "undo", or say

page" or "previous page". You can undo your last

"cancel" to cancel the current action.

action and start over by saying "undo", or say

Voice commands

Navigation

"cancel" to cancel the current action.

Send SMS to John Miller, I'm just arriving

"Text message" voice

Send SMS to David Miller at the office, don't

Choice of a destination

wait for me

commands

Help messages

To a new destination

If there is no telephone connected by

Intuitive method:

Bluetooth, a voice message announces:

Please say "call" or "send quick message to",

Press Navigation to display the main

"Please first connect a telephone", and the

and then select a line from the list. To move

page.

voice session is closed.

around a list shown on the display, you can

Press "Search…".

say "go to start", "go to end", "next page" or

The "Text messages" voice commands

"previous page". You can undo your last action

Enter an address or the key words for the

function allows you to dictate and send

and start over by saying "undo", or say "cancel"

destination.

an SMS.

to cancel the current action.

Press "OK" to select the "Guidance

Dictate the text, taking care to pause briefly

Voice commands

criteria".

between each word.

When you have finished, the voice recognition

Listen to most recent message*

Guided method:

system will automatically generate an SMS.

Help messages

In order to be able to use the navigation,

Voice commands

you must enter the "City", the "Street"

To hear your last message, you can say "listen to

(suggestions are displayed automatically

most recent message". When you want to send

when you begin typing), then enter the

Send quick message to Bill Carter, I'll be late

a text, there's a set of quick messages ready for

Help messages

you to use. Just use the quick message name

"Number" using the virtual keypad, or select

and say something like "send quick message to

* This function is available only if the telephone connected to the system supports downloading of contacts and recent calls and the corresponding

download has been performed.

235

PEUGEOT Connect Nav

an address from the "Contact" list or the

To a recent destination

To a contact

address "History".

Press Navigation to display the main

page.

If you do not confirm the number, the

Press the "MENU" button to access the

navigation system will show one end of

secondary page.

the street.

Select "My destinations".

Press the "MENU" button to access the

Select the "Recent” tab.

Select the "Contact” tab.

secondary page.

Select the address chosen in the list to display

Select a contact in the list to start guided

Select "Enter address".

the "Guidance criteria”.

navigation.

Press "OK" to start guided navigation.

Then

To points of interest (POI)

Select the "Country".

Guided method:

Select "Position" to see the point of

Points of interest (POI) are listed in different

Select the keyboard “language”.

arrival on the map.

categories.

Press Navigation to display the main

Change the keyboard "type" according to

To "Home" or "My work"

page.

the selected "language": ABCDE;

Press Navigation to display the main

Press the "MENU" button to access the

AZERTY; QWERTY or QWERTZ.

page.

secondary page.

Enter the "City", the "Street" and the

Press the "MENU" button to access the

Select "Points of interest".

"Number", and confirm by pressing on

the displayed suggestions.

secondary page.

Select "My destinations".

Select the "Travel", "leisure",

Press "OK" to select the "Guidance

"Commercial", "Public" or "Geographic”

criteria".

tab.

And/or

Select the "Preferred” tab.

Select "Home".

Select "See on map" to choose the

Select "Search" to enter the name and

"Guidance criteria".

address of a POI.

Press "OK" to start guided navigation.

Select "My work".

Press "OK" to calculate the route.

Zoom in/out using the touch buttons or

with two fingers on the screen.

Intuitive method:

Select a preset favourite destination.

236

PEUGEOT Connect Nav

You can only select this method of

To a point on the map

A marker is displayed in the middle of the

using the service if a network connection

screen, with the "Latitude" and

Press Navigation to display the main

is active; this may be either a "network

"Longitude" coordinates.

page.

connection provided by the vehicle", if you

Choose the type of coordinates:

Explore the map by sliding a finger on the

use the Peugeot Connect Packs solution, or

DMS for: Degrees, Minutes, Seconds.

screen.

else a "network connection provided by the

DD for: Degrees, Decimals.

Select the destination by pressing on the map.

user" via a smartphone,

Press this button to start guided

Tap the screen to place a marker and

In both cases, the system is automatically

navigation.

display the sub-menu.

connected to the Internet, if network coverage

Press this button to start guided

permits.

Press this button to save the displayed

navigation.

address.

Press Navigation to display the main

Press this button to save the displayed

page.

Press this button to enter the "Latitude"

address.

Press the "MENU" button to access the

value using the virtual keypad.

secondary page.

A long press on a point opens a list of

And

Select "Search".

nearby POIs.

Press this button to enter the "Longitude"

value using the virtual keypad.

Press on the mode shown in the bottom right of

the screen (On-Board or Connected) to change

To GPS coordinates

TMC (Traffic Message

the "Database".

Press Navigation to display the main

Channel)

Select the "Database" in "On-Board"

page.

mode (integrated into the map), or in

Explore the map by sliding a finger on the

Available in some countries.

"Connected" mode (connected to the Internet).

screen.

TMC (Traffic Message Channel) messages

Press the back arrow to confirm.

Touch the screen with a finger to go to the next

are based on a European standard for traffic

image.

information broadcasting via the RDS system on

Enter an address or the key words for the

Press this button to display the world

FM radio, sending traffic information in real time.

destination (POI).

map.

The TMC information is then displayed on a GPS

Press "OK" to start the search.

Using the grid, select the desired country or

Navigation system map and taken into account

region by zooming.

straight away when routes are calculated, to

Select the "On the route", "Around the

Press this button to display or enter the

avoid accidents, traffic jams and closed roads.

vehicle" or "At destination" tab to refine

GPS coordinates.

Danger zone alerts may or may not be

your search.

displayed, depending on the applicable

Select the desired address to calculate the route.

237

PEUGEOT Connect Nav

legislation and subscription to the

update the smartphone operating system

Select the "Secured", "Not secured" or

corresponding service.

as well as the date and time on the

"Stored” tab.

smartphone and system, to ensure that the

Select a network.

communication process between the

Connected navigation

smartphone and the system functions

Using the virtual keypad, enter the "Key"

correctly.

network Wi-Fi and the "Password".

Press "OK" to establish a connection

Connected navigation

USB connection

between the smartphone and the

Connect the USB cable.

connection

vehicle’s system.

The smartphone charges when

Depending on version, vehicle trim level and

connected by the USB cable.

Usage restrictions:

subscription to online services and options.

Bluetooth connection

With CarPlay^®, connection sharing is only

Activate the Bluetooth function on the

available with a Wi-Fi connection.

Network connection provided by the

telephone and ensure that it is visible to

The quality of services depends on the quality

vehicle

all (see the "Connect-App" section).

of the network connection.

With the Peugeot Connect Packs

Wi-Fi connection

solution, the system is automatically

Select a Wi-Fi network detected by the

connected to the Internet and connected

Authorize sending

system and connect to it.

services, and does not require the user to

information

provide a connection via their smartphone.

This function is only available if it has

Press Settings to display the main page.

been activated either via the

"Notifications" or via the "Applications" menu.

Network connection provided by the

Press the "OPTIONS" button to access the

Press "Notifications".

secondary page.

user

Select "System configuration".

Select Wi-Fi to activate it.

Select the "Private mode" tab.

For the list of compatible smartphones,

Press Connect-App to display the main

visit the Brand's website in your country.

page.

Press "Notifications".

Activate and enter settings for sharing the

Press the "OPTIONS" button to access the

smartphone connection.

secondary page.

Press "Private mode".

Select "Wi-Fi network connection".

As processes and standards are

THEN

constantly changing, we recommend you

238

PEUGEOT Connect Nav

Activate or deactivate:

- "Give an audible warning".

Press Navigation to display the main

- "Advise proximity of POI 1".

page.

- "No data sharing except for company

- "Advise proximity of POI 2".

Press the "Declare a new danger zone"

vehicles".

Press “OK” to confirm your selection.

button located in the side bars or the

- "Only data sharing"

upper bar of the touch screen (depending on

- "Sharing data and vehicle position"

equipment).

The "Notifications", located in the upper

Select the "Type” option to select the type

bar, can be accessed at any time.

Settings specific to

of "Danger area".

Select the "Speed" option and enter it

connected navigation

Danger zone alerts may or may not be

using the virtual keypad.

Press Navigation to display the main

displayed, depending on the applicable

Press "OK" to save and send the

page.

legislation and subscription to the

information.

Press the "MENU" button to access the

corresponding service.

secondary page.

Displaying fuel information

Select "Settings".

When "TOMTOM TRAFFIC” appears, the

Press Navigation to display the main

services are available.

page.

Select the "Map” tab.

The services offered with connected

Press this button to display the list of

navigation are as follows.

services.

Activate or deactivate:

A Connected Services pack:

Press "POI on map" to display the list

- "Allow declaration of danger zones".

- Weather,

of points of interest.

- "Guidance to final destination on foot".

- Filling stations,

Press one of the buttons to search for

These settings must be configured for each

- Car park,

"Stations".

profile.

- Traffic,

Activate/deactivate "Stations".

Press “OK” to confirm your selection.

- POI local search.

A Danger area pack (optional).

Press this button to display a secondary

Select the "Alerts” tab.

page.

Select the "Settings” tab.

Activate or deactivate:

Declaration: "Risk areas

alert"

Select the desired fuel.

- "Advise of car park nearby".

- "Filling station alert".

To send information about danger zones,

Press "OK" to save.

- “Risk areas alert" then press the warning icon

select the option:Allow declaration of

(triangle) to configure the alerts.

danger zones

239

PEUGEOT Connect Nav

Displaying charging station

Press this button to display basic

As principles and standards are constantly

information.

changing, we recommend keeping the

details

Press this button to display detailed

smartphone's operating system up-to-

Press Navigation to display the main

weather information.

date, together with the date and time on

page.

the smartphone and the system.

The temperature displayed at 6 a.m. will

Press this button to display the list of

be the maximum temperature for the day.

services.

The temperature displayed at 6 p.m. will be

Connectivity

Press "POI on map" to display the list

the minimum temperature for the night.

of points of interest.

Press Applications to display the main

Press one of the buttons to search for

page.

"Stations".

Press "Connectivity" to access the CarPlay^® or

Activate/deactivate "Stations".

Applications

Android Auto functions.

USB sockets

Press this button to display a secondary

CarPlay^® smartphone

page.

Depending on equipment, for more information

connection

Select the "Settings" tab.

on the USB sockets compatible with CarPlay^® or

Depending on country.

Android Auto applications, refer to the "Ease of

Select the desired connector type.

use and comfort" section.

On connecting the USB cable, the

CarPlay^® function deactivates the

For the list of compatible smartphones,

Press "OK" to save.

system's Bluetooth^® mode.

visit the Manufacturer's website in your

The "CarPlay" function requires the use of

country.

a compatible smartphone and compatible

Displaying weather

applications.

Synchronising a smartphone enables

information

users to display applications that support

Connect the USB cable. The smartphone

Press Navigation to display the main

the smartphone’s CarPlay^® or Android Auto

charges when connected by the USB

page.

technology on the vehicle’s screen. For

cable.

Press this button to display the list of

CarPlay^® technology, the CarPlay^® function

Press "Telephone" to display the

services.

must first be activated on the smartphone.

CarPlay^® interface.

Select "View map".

Unlock the smartphone for the communication

process between the smartphone and the

Connect the USB cable. The smartphone

Select "Weather".

system to work.

charges when connected by the USB

cable.

240

Peugeot 208 (2024 year). Manual in english - page 3
