Peugeot RCZ (2015 year). Instruction

223

RCZ_en_Chap10b_RT6-2-8_ed01-2015

Configure the filtering and display of TMC messages

TMC (Traffic Message Channel) messages with GPS Navigation provide traffic information in real time.

Press the TRAFFIC button to display the
"

Traffic information" menu.

Select the "

Geographic filter" function

and confirm.

The system offers a choice of:
- "Retain all the messages",
or
- "Retain the messages"

● "Around the vehicle", (confirm

the mileage to modify and select
the distance),

● "On the route".

Confirm "OK" to save the modifications.

We recommend:
- a filter on the route and

- a filter around the vehicle of:

- 12 miles (20 km) in urban areas,
- 30 miles (50 km) on motorways.

TRAFFIC INFORMATION

224

RCZ_en_Chap10b_RT6-2-8_ed01-2015

Principal TMC symbols

Red and yellow triangle: traffic information, for example:

Black and blue triangle: general information, for example:

Weather reports

Modified signage

Risk of explosion

Traffic reports

Narrow carriageway

Road closed

Wind

Slippery surface

Demonstration

Fog

Accident

Danger

Parking

Delay

No entry

Snow / ice

Roadworks

Traffic jam

Receiving TA messages

The TA (Traffic Announcement) function gives priority to TA alert

messages. To operate, this function needs good reception of a

radio station transmitting this type of message. When a traffic report

is transmitted, the current audio source (Radio, CD, USB, ...) is
interrupted automatically to play the TA message. Normal playback
of the audio source resumes at the end of the transmission of
the message.

Press RAdIO to display the menu.

Select "Service announcements" then

confirm.

Activate or deactivate "TA

" then confirm.

The volume setting for TA messages can be adjusted only during the
transmission of this type of alert.

Activate or deactivate the function at any time by pressing
the button.
During a message, press the button to interrupt it.

TRAFFIC INFORMATION

225

RCZ_en_Chap10b_RT6-2-8_ed01-2015

Access to the "TELEPHONE" menu

"Telephone"

"dial"
"directory of contacts"
"Contacts management"
"Phone functions"
"Bluetooth functions"
"Hang up"

Go from the list to the menu (left/right).

List of recent calls sent and
received with the telephone
connected to the system.

Press this button.

To make a call, select a number in the list and confirm "OK"

to start the call.

Connecting a different telephone deletes the list of
recent calls.

No telephone connected.

Telephone connected.

Incoming call.

Outgoing call.

Synchronisation of
contacts in progress.

Telephone call in
progress.

In the top bar of the permanent
display

USING THE TELEPHONE

226

RCZ_en_Chap10b_RT6-2-8_ed01-2015

USING THE TELEPHONE

Pairing a Bluetooth

telephone

First connection

For reasons of safety and because they require prolonged attention

on the part of the driver, the operations for pairing the Bluetooth
mobile telephone to the hands-free system of the audio unit must be
carried out with the vehicle stationary.

In the Bluetooth menu of your telephone, select the
name "PEUGEOT" from the list of devices detected.

Press this button.

Select "Bluetooth functions" and

confirm.

Select "Peripherals search" and

confirm.
The list of peripheral devices detected
is displayed. Wait until the "Connect"
button is available.

You can check the compatibility of your telephone at
www.peugeot.co.uk (services).

Activate the telephone's Bluetooth function
and ensure that it is "visible to all" (telephone

configuration).

Quick procedure from the telephone

Enter a minimum 4 figure code in the telephone and

confirm.

Enter the same code in the system,
select "OK

" and confirm.

Procedure from the system

227

RCZ_en_Chap10b_RT6-2-8_ed01-2015

USING THE TELEPHONE

Select "Connect

" and confirm.

The system offers to connect the
telephone:
-

in "Hands-free mode" (telephone
only),

in "Audio" mode (streaming: playing

music files on the telephone),

or "All" (for selection of both
modes).

Select "OK

" and confirm.

Then accept automatic connection on the telephone to allow the
telephone to reconnect automatically every time the vehicle is
started.

The ability of the system to connect in only one mode depends on
the telephone. The two modes may both connect by default.

The "Hands-free mode" should be used in preference if
"Streaming" is not desired.

The services available depend on the network, the SIM card and the compatibility of the Bluetooth telephone used. Check the telephone
manual and with your network provider for details of the services available to you.

Depending on the type of telephone, the system will ask you to
accept or not the transfer of your contacts.

On return to the vehicle, the last telephone connected
automatically reconnects, within around 30 seconds after
switching on the ignition (Bluetooth activated and visible).
To modify the automatic connection mode, remove the pairing
and pair the telephone again with the desired mode.

Enter a minimum 4 figure code in the telephone

and confirm.

Enter the same code in the system,
select "OK

" and confirm.

Select the name of the desired
peripheral from the list of devices

detected then confirm.

228

RCZ_en_Chap10b_RT6-2-8_ed01-2015

USING THE TELEPHONE

directory configuration / Synchronisation with the telephone

Press PHONE then select "Contacts
management

" and confirm.

Select "New contact" to enter a new
contact.

Select "Sort by Name/First name" or
"Sort by First name/Name" to choose
the order in which they appear.

Select "delete all contacts" to delete
the contacts saved in the system.

Select "Synchronization options":
-

No synchronization: only the
contacts saved in the system
(always present).

Display telephone contacts: only the
contacts saved in the telephone.

Display SIM card contacts: only the
contacts saved on the SIM card.

Display all phone contacts:
contacts on the SIM card and in the
telephone.

Select "Import all the entries" to import
all the contacts in the telephone and
save them in the system.
Once imported, a contact remains visible
whatever telephone is connected.

Select "Contact mem. status" to see the
number of contacts saved in the system
or imported, and the free memory.

229

RCZ_en_Chap10b_RT6-2-8_ed01-2015

Editing, importing or deleting a contact

Press PHONE then select "directory of
contacts

" and confirm.

Select "Search", then turn the knob to
choose in numerical or alphabetical order
a group of contacts from the entries made

previously, then confirm.
Go to the list of contacts, select the

desired contact then confirm.

Select "Open" to view a contact on the
telephone or modify a contact saved in
the system.

Select "Import" to copy a contact from
the telephone to the system.

Select "delete" to delete a contact
recorded in the system.

USING THE TELEPHONE

Select OK or press the back button to exit
this menu.

Once the contact has been imported, the Bluetooth symbol
disappears, replaced by the telephone symbol which shows that the
contact has been saved in the system.

It is not possible to modify or delete contacts in the telephone or the
SIM card via the Bluetooth connection.

In the "directory of contacts" menu, the import and deletion of
contacts is done one by one.

230

RCZ_en_Chap10b_RT6-2-8_ed01-2015

USING THE TELEPHONE

Press PHONE twice.

Select "dial

" then confirm.

Select "directory of contacts" then

confirm.

Dial the telephone number using the
virtual keypad selecting each number
in turn.
Confirm "OK" to make the call.

Press TEL or twice on PHONE.

Calling a new number

Calling a contact

Select the desired contact and confirm.
If access was via the PHONE button,
select "Call

" and confirm.

Select the number and confirm to start

the call.

Making a call

Use of the telephone is not recommended while driving. We recommended
that you park safely or make use of the steering mounted controls.

231

RCZ_en_Chap10b_RT6-2-8_ed01-2015

USING THE TELEPHONE

Calling a recently entered number

Press TEL, select "Call list" and

confirm,

Select the desired number and confirm.

To erase the calls log, press PHONE twice, select "Phone
functions

" and confirm then select "delete calls log" and confirm.

Ending a call

Press PHONE then select "OK" to end
the call.

Or make a long press on TEL at the
steering mounted controls.

Or make two short presses on TEL at
the steering mounted controls.

Or press the MOdE button, as many
times as necessary, until the telephone
screen is displayed.

Press PHONE to display the calls log.

Press "OK" to display the contextual
menu then select "Hang up

" and confirm.

It is always possible to start a call directly from the telephone; park
the vehicle as a safety measure.

232

RCZ_en_Chap10b_RT6-2-8_ed01-2015

USING THE TELEPHONE

Receiving a call

An incoming call is announced by a ring and a superimposed display
on the screen.

"Yes" to accept the call is selected by
default.
Press "OK" to accept the call.
Select "No

" and confirm to reject the

call.

A short press on TEL accepts an
incoming call.
A long press on TEL rejects an incoming
call.

233

RCZ_en_Chap10b_RT6-2-8_ed01-2015

Options during a call*

During a call, press the MOdE button
several times to select display of the
telephone screen, then press "OK" to
open the contextual menu.

Select "Private mode

" and confirm to

take the call on the handset.
Or select "Hands-free mode" and

confirm to take the call via the vehicle's

speakers.

Select "Put call on hold

" and confirm to

put the current call on hold.
Or select "Resume the call" and

confirm to resume the call on hold.

Select "dTMF ring tones" to use the
numerical keypad, so as to navigate
through the menu of an interactive vocal
server.

Select "Hang up" to end the call.

* Depending on the compatibility of the phone and your service plan.

It is possible to hold a 3-way conference
call by making 2 calls in succession*.
Select "Conference mode call" in
the contextual menu accessible using
this button.

Or make a short press on this button.

USING THE TELEPHONE

234

RCZ_en_Chap10b_RT6-2-8_ed01-2015

Press PHONE twice.

Select "List of the paired peripherals"

and confirm.

It is possible to:
- "Connect" or "disconnect" the

selected telephone,

delete the pairing of the selected
telephone.

It is also possible to select all pairings.

Managing paired telephones

Changing the ringtone

Press PHONE twice.

Select "Phone functions

" and confirm.

Select "Ring options

" and confirm.

You can adjust the volume and the type
of ringtone.

Select "Bluetooth functions".

Select "OK

" and confirm to save

the changes.

USING THE TELEPHONE

235

RCZ_en_Chap10b_RT6-2-8_ed01-2015

"FM / dAB / AM"

"Change waveband" ("FM /
dAB / AM")
"Options" ("TA, RdS, dAB/FM
station tracking")
"Audio settings" (see this
section)
"Update radio list"

Alphabetical list of stations
received.

Press 5 or 6 or use the rotary control to select the
previous or next station in the list.

Go from the list to the menu (left/right).

Press RAdIO.

RAdIO

Access to the "RAdIO" menu

236

RCZ_en_Chap10b_RT6-2-8_ed01-2015

By alphabetical list
Press RAdIO, select the station of your

choice and confirm.

By automatic frequency search
Press 7 or 8 for the automatic search

for a lower or higher radio frequency.
Or turn the thumb wheel at the steering
mounted controls.

By manual frequency search
Press 5 or 6 to adjust the radio

frequency step by step.

Selecting a station

The external environment (hill, building, tunnel, underground car park...) may interfere with the reception, including in RDS station tracking mode.
This phenomenon is a normal result of the way in which radio waves are transmitted and does not in any way indicate a fault with the audio system.

The quality of reception is represented by the number of

active waves in this symbol.

Press RAdIO or OK to display the
contextual menu.

Changing waveband

Select "Change waveband".

Select "FM / dAB / AM

" and confirm.

RAdIO

237

RCZ_en_Chap10b_RT6-2-8_ed01-2015

Press the button on the numerical keypad to recall a
preset station.
Or press then turn the thumb wheel at the steering
mounted controls.

Presetting a station

After selecting a station, press one of the buttons on the
numerical keypad for 2 seconds to preset the current
station.
An audible signal confirms that the station has been preset.

Press RAdIO.

Activate / deactivate RdS

RDS, if activated, allows you to continue listening to the same

station by automatic retuning to alternative frequencies. However,

in certain conditions, coverage of an RDS station may not be
assured throughout the entire country as radio stations do not
cover 100 % of the territory. This explains the loss of reception of
the station during a journey.

Select "Guidance options" then

confirm.

Activate or deactivate "RdS" then

confirm.

RAdIO

238

RCZ_en_Chap10b_RT6-2-8_ed01-2015

RAdIO

Display of options:
if active but not available, the display
will be greyed out,
if active and available, the display will
be empty.

Display the name and number of
the multiplex service being used.

Preset stations, buttons 1 to 6.
Short press: select the preset radio
station.
Long press: preset a radio station.

Display of "Radiotext" for the
current station.

Display of the "DAB" or "DAB
(FM)" band.

Display of the name of
the current station.

Represents the signal strength
for the band being listened to.

If the "DAB" radio station being
listened to is not available on
"FM", the "DAB FM" option is
greyed out.

Any thumbnail broadcast by the
station.
The "Video mode" allows the
display to be enlarged.

Peugeot RCZ (2015 year). Instruction - part 15
