Peugeot 5008 (2017 year). Instruction - part 8

111

Ease of use and comfort

Sun visor

Component which protects against sunlight
from the front or the side, also equipped with an
illuminated vanity mirror.

Glove box

F To open the glove box, raise the handle.
The glove box is lit when the lid is opened.

F With the ignition on, raise the concealing

flap; the mirror is illuminated automatically.

This sun visor is also equipped with a ticket
holder.

It houses the front passenger airbag
deactivation switch A.
It also gives access to the housing for scented
air freshener B cartridges.

Never drive with the glove box open when
a passenger is at the front – it may cause
injury during sharp deceleration!

Cigarette lighter/12 V
accessory socket(s)

You can use this socket to connect a telephone
charger, a bottle warmer, etc.
After use, put the cigarette lighter back into
place straight away.

The connection of an electrical device
not approved by PEUGEOT, such as a
USB charger, may adversely affect the
operation of vehicle electrical systems,
causing faults such as poor telephone
reception or interference with displays in
the screens.

F To use the cigarette lighter, press it in

and wait a few seconds until it pops out
automatically.

F To use a 12 V accessory (max power:

120 W), remove the cigarette lighter and
connect a suitable adaptor.

112

Ease of use and comfort

USB port

The USB port also allows a smartphone to be
connected by MirrorLink™ or CarPlay

, so that

certain applications on the smartphone can be
used in the touch screen.

FOCAL

premium Hi-Fi

system

10 speakers incorporating exclusive FOCAL

technologies offer the pleasure of pure and
detailed sound inside the vehicle:
- High fidelity woofer / mid-range speakers:

Polyglass technology delivering balance
and precise sound.

- TNF tweeters: Inverted dome aluminium

technology giving optimum sound
dispersion and very detailed treble.

- Sub-woofer: 200 mm triple coil Power

Flower™ technology for defined and
dynamic reproduction of low frequencies.

- 12-way active amplification – 515 Watts:

Hybrid Class AB / Class D technology
providing breadth and finesse in the high
frequency signals, as well as real power in
the bass.

Wireless charger

This system allows the wireless charging of a
portable device, such as a smartphone, using
the principle of magnetic induction, based on
the Qi 1.1 standard.
The portable device to be charged must be
compatible with the Qi standard, either by
design or by using a compatible holder or shell.
The charging zone is identified by the Qi
symbol.

The USB port allows the connection of a
portable device, such as an iPod

-type digital

audio player, or a USB memory stick.
The USB reader reads your audio files which
are then transferred to the audio system and
played via the vehicle’s loudspeakers.
These files are managed via the steering wheel
controls or from the audio system.

When connected to the USB port,
the portable device can be charged
automatically.
While charging, a message is displayed
if the power consumption of the portable
device exceeds the amperage supplied by
the vehicle.

For more details on the Audio equipment and
telematics, and particularly the USB port,
consult the corresponding section.

Your vehicle is equipped with a high-fidelity
sound system designed by the French brand
FOCAL

, a specialist in acoustics for more

than 35 years and recognised throughout the
world for its patented innovations and its unique
audio signature.

113

Ease of use and comfort

Operation

The charger works with the engine running and
in STOP mode of Stop & Start.
Charging is managed by the smartphone.

For versions with Keyless Entry and Starting,
operation of the charger may be interrupted
when opening a door or switching off the
ignition.

Charging

F First ensure that the charging zone is clear

of other articles.

F Place a portable device in the middle of the

charging zone.

F Once the portable device is detected, the

charge indicator lamp comes on in green.

The system only supports charging one
portable device at a time.

Do not leave any metal objects (coins,
keys, vehicle remote control, etc.) in
the charging area while a device is
being charged – risk of overheating or
interrupting the charging process!

Checking operation

F Charging of the portable device's battery

then starts.

F Once the portable device's battery is fully

charged, the charge indicator lamp goes off.

The state of the charge indicator lamp allows
the operation of the charger to be monitored.

Charge indicator

lamp

Meaning

Off

Engine switched off.
No compatible
portable device
detected.
Charging finished.

Fixed, green

Compatible portable
device detected.
Charging...

Flashing, orange

Foreign object
detected in the
charging zone.
Portable device not
well centred in the
charging zone.

Fixed, orange

Fault with the
portable device's
battery meter.
Temperature of the
portable device's
battery too high.
Charger fault.

114

Ease of use and comfort

If the indicator lamp is lit orange:

Front armrest

Comfort device for the driver and front
passenger.
It includes a refrigerated storage space.

Opening

Storage

Closing

Scented air freshener

A complete air freshener system for the
passenger compartment. It is supplied by a
three-fragrance cartridge.
This system operates only with the engine
running.

Activation / Settings

Activation and adjustment of settings is done in
the touch screen:
- either directly in the Applications menu,
- or by personalising an ambience for the

i-Cockpit Amplify function.

In the Applications menu:

- remove the portable device, then replace it

in the middle of the charging zone.

or
- remove the portable device and try again in

a quarter of an hour.

If the problem persists, have the system
checked by a PEUGEOT dealer or a qualified
workshop.

F Press the lever beneath the cover.
The cover opens in two parts.

The small removable tray can be installed in
front of or behind the storage space.
A ventilation nozzle circulates fresh air.

F Fold the two parts of the cover back.

Select "Scented air freshener",

F select a fragrance from the three offered,
F select a delivery intensity to activate the

system,

or
F select "OFF" to deactivate it.
The modifications are taken into account
immediately.

115

Ease of use and comfort

The scented air freshener is also
managed by the i-Cockpit Amplify
function.

For more information on the i-Cockpit Amplify
function, refer to the corresponding section.

Changing the cartridge

Access to the cartridge is in the glove box.

F Ignition on, pull the tab 1 in the direction of

the arrow to release the used cartridge.

F Remove the used cartridge 2 from its

housing.

The air freshener stops working with the
cartridge removed.

F Remove the two seals from the new

cartridge.

F Insert the new cartridge into its housing

observing the direction of fitment.

The air freshener is ready to operate again.

Recommendations

Do not discard the original cartridge, which
serves as a blanking plug if the air freshener is
not used.
Retain the cartridge sealing caps which serve
as packaging if the cartridge is not used.
Replacement cartridges are available from
PEUGEOT dealers or from the brand's internet
website.

As a safety measure:
- use only the cartridges designed for

the system,

- do not try to fit or remove a cartridge

when driving,

- do not try to refill or dismantle the

cartridges.

Keep cartridges out of the reach of
children or pets.
Do not allow the fluid in the cartridge to
come into contact with the skin or eyes.
In the event of ingestion of the fluid in the
cartridge, consult a doctor, showing them
the product packaging or label.

116

Ease of use and comfort

Removing

To remove the mat on the driver's side:
F  move the seat as far back as possible,
F  unclip the fixings,
F  remove the mat.

Refitting

To avoid any risk of jamming of the pedals:
- only use mats which are suited to the

fixings already present in the vehicle;
these fixings must be used,

- never place one mat on top of another.
The use of mats not approved by
PEUGEOT may interfere with access to
the pedals and hinder the operation of the
cruise control / speed limiter.
The mats approved by PEUGEOT have
two fixings located below the seat.

Mats

Fitting

When fitting the mat for the first time, on the
driver's side use only the fixings provided in the
wallet attached.
The other mats are simply placed on the
carpet.

To refit the mat on the driver's side:
F  position the mat correctly,
F  reattach the fixings by pressing,
F  check that the mat is secured correctly.

Courtesy lamps

Front courtesy lamp

Front map reading lamps

Rear courtesy lamp

Rear map reading lamps

117

Ease of use and comfort

Front and rear courtesy lamps

In this position, the courtesy
lamp comes on gradually:

-  when the vehicle is unlocked,
-  when the key is removed from the ignition,
-  when opening a door,
-  when the remote control locking button is

activated, in order to locate your vehicle.

It switches off gradually:

-  when the vehicle is locked,
-  when the ignition is switched on,
-  30 seconds after the last door is closed.

Permanently off.

Permanent lighting.

In "permanent lighting" mode, the lighting time
varies according to the circumstances:

- when the ignition is off, approximately ten

minutes,

- in energy saving mode, approximately thirty

seconds,

- with the engine running, unlimited.

When the front courtesy lamp is in the
"permanent lighting" position, the rear
courtesy lamp also comes on, except if it
is in the "permanently off" position.
To switch off the rear courtesy lamp, put it
in the "permanently off" position.

Front and rear map reading
lamps

Take care not to put anything in contact
with the courtesy lamps.

F With the ignition on, press the

corresponding switch.

Interior ambient lighting

The dimmed passenger compartment lighting
improves visibility in the vehicle when the light
is poor.

At night, the interior ambient lighting comes on
automatically when the sidelamps are switched
on.

118

Ease of use and comfort

The ambient lighting switches off automatically
when the sidelamps are switched off.

The interior ambient lighting can
be activated or deactivated and its
brightness adjusted in the Vehicle /
Driving menu of the touch screen.

The interior ambient lighting is also
managed by the i-Cockpit Amplify
function.
For more information on the
i-Cockpit Amplify function, refer
to the corresponding section.

Rear fittings

230 V / 50 Hz power socket

In the event of a fault, the green warning lamp
flashes.
Have it checked by a PEUGEOT dealer or a
qualified workshop.

Connect only one device at a time to
the socket (no extension or multi-way
connector).
Connect only devices with class II
insulation (shown on the device).
Do not use a device with a metal case
(electric shaver, etc.).

Depending on the version, the ambient lighting
includes:
- two LEDs located in the front courtesy lamp,
- a light source in the storage compartment at

the front of the centre console,

- a light source for each of the front footwells,
- illuminated guides on the front door panels

and on the sides of the centre console,

- illuminated bezels for the front cup holders,
- a light source for each of the front door

pockets,

- illuminated rails along the panoramic

sunroof blind.

It is located at the back of the centre console
beneath a protective cover.
This socket (max. power: 150 W) operates with
the engine running, as well as in STOP mode of
Stop & Start.
F  Raise the protective cover.
F  Check that the green indicator lamp is on.
F  Connect your multimedia or other electrical

device (telephone charger, laptop computer,
CD-DVD player, bottle warmer, etc.).

As a safety measure, when electrical
consumption is high and when required by
the vehicle's electrical system (particular
weather conditions, electrical overload,
etc.), the current supply to the socket will
be cut off; the green indicator lamp goes
off.

119

Ease of use and comfort

12 V accessory socket

F To connect a 12 V accessory (max power:

120 W), lift the cover and connect a suitable
adaptor.

"Aircraft" type tables

Side blinds

Always guide the blind slowly using the
tab, both up and down.

F To use the table, lower it fully until it locks in

the low position.

F To store it, raise the table, passing the point

of resistance, to the high position.

On the passenger side, do not forget to
fold it before placing the backrest in the
table position.
For more information on the Front seats
and in particular setting the "table"
position for the backrest, refer to the
corresponding section.

Do not place hard or heavy objects on the
table.
They could become dangerous projectiles
in the event of emergency braking or
impact.

Fitted to the windows in row 2, they protect the
passenger compartment from the sun's rays.
F Pull the central tab to unroll the blind.
F Position the blind's clip on the hook.

120

Ease of use and comfort

Depending on version, the storage boxes are
fitted in the floor, at the foot of the side seats on
the second row.
On the left side, it may also contain the
temporary puncture repair kit.
To open them, lift the cover by the notch.

Storage boxes

Boot fittings

Load space cover

12 V accessory socket (maximum
power: 120 Watts)

Boot lamp

Luggage retaining strap

Storage brackets of the load space
cover

Armrest with cup holder and storage

Open storage compartment

Concertina floor

Stowing rings

121

Ease of use and comfort

Load space cover

In 5-seat configuration, it is installed behind
the second row seats, with the third row seats
stored folded away.
In 7-seat configuration, it is stored behind the
third row seats.

Installation

Removal

F Remove the guides of the roller from the

rails in pillars B.

F Guide the roller as it reels in.
F Unlock the roller by pressing one of the

handles located at the ends of the roller
bracket.

F Position the left and right ends of the roller

in cut-outs A, with the mobile flap at the
front.

F Pull out the roller until it reaches the boot

pillars.

F Insert the guides of the roller into the rails in

pillars B.

Storage behind the 3

row seats

F Make sure that the 3

row seats are folded

away.

F Fold the first two concertina boards.
F Position the roller in the space located

above the armrest, side by side, tilting it
slightly.

F Slide the roller to the stop position, until it

reaches the notches arranged at the back of
the boot, with the two hinges facing down.

F Unfold the third row seats.
The folded concertina boards can be placed in
the horizontal or upright position.

To fold the 3

row seats with the roller stored at

the back, it is necessary to raise the concertina
boards in order to give access to the seat
unlocking controls (red straps).

When sharp deceleration occurs, objects
placed on the load space cover can turn
into projectiles.

122

Ease of use and comfort

High load retaining net

It offers protection to the occupants when
very sharp braking occurs.

Behind the front seats

Once fitted, the net does not prevent
tipping of the backrests.

Behind the rear seats

This removable net allows the entire loading
volume to be used up to the roof:
- behind the front seats (1

row) when the

rear seats are folded down,

- behind the rear seats (2

row) when the

load space cover is removed.

F Fold down the rear seats.
F Insert the ends of the bar, one after the

other, into the fixing points of the roof.

F Attach the net straps to the lower rings,

located on the outer slides of the front
seats.

F Pull on the straps to stretch the net.

F Remove the load space cover.
F Insert the ends of the bar, one after the

other, into the fixing points of the roof.

F Attach the straps of the net to the lower

rings, located on each side trim of the boot.

F Pull on the straps to stretch the net.

123

Ease of use and comfort

12 V accessory socket

Boot lighting

F To connect a 12 V accessory (max power:

120 W), remove the cap and connect an
appropriate adaptor.

F Switch on the ignition.

This comes on automatically when the boot is
opened and goes off automatically when the
boot is closed.

The lighting time varies according to the
circumstances:
- when the ignition is off, approximately

ten minutes,

- in energy economy mode,

approximately thirty seconds,

- with the engine running, unlimited.

124

Lighting and visibility

Exterior lighting control
stalk

Main lighting

Selection of main lighting mode

F Turn ring A to align the desired symbol with

the marking.

Automatic illumination of headlamps.
Daytime running lamps / Dipped
beam / Main beam.

Sidelamps only.

Dipped or main beam headlamps.

"Highway function"
On versions fitted with "Full LED"
technology headlamps, the range of the
dipped beam headlamps is automatically
increased once the speed of the vehicle is
above 70 mph (110 km/h).

Without AUTO lighting

With AUTO lighting

Headlamp dipping

F Pull stalk B towards you to switch between

dipped and main beam headlamps or to
activate automatic headlamp dipping.

In the lighting off and sidelamps modes, the
driver can switch on the main beam headlamps
temporarily ("headlamp flash") by maintaining a
pull on the stalk.

Displays

Illumination of the corresponding indicator
lamp in the instrument panel confirms that the
lighting selected is on.

Lighting off (ignition off) /
Daytime running lamps (engine
running).

A fault with a lamp is signalled by
the permanent illumination of this
warning lamp, accompanied by the
display of a message and an audible
signal.

125

Lighting and visibility

Foglamps

In clear weather or rain, during the day or
at night, it is prohibited to switch on the
front or rear foglamps. In these situations,
the power of their beams may dazzle other
drivers. They should only be used in fog
or snow.
In these weather conditions, it is your
responsibility to switch on the foglamps
and dipped beam headlamps manually as
the sunshine sensor may detect sufficient
light.
Switch off the foglamps when they are no
longer necessary.

Rear foglamps

The main or dipped beam headlamps
must be on.

Rotate and release ring C:
F forwards to switch on the rear foglamps.
F backwards to switch them off.

Front and rear foglamps

The sidelamps or dipped or main beam
headlamps must be on.

Rotate and release ring C:
F once forwards to switch on the front

foglamps,

F forwards a second time to switch on the rear

foglamps.

F once backwards to switch off the rear

foglamps,

F backwards a second time to switch off the

front foglamps.

126

Lighting and visibility

Switching off the lamps when the
ignition is switched off
On switching off the ignition, all of the
lamps turn off immediately, except for
dipped beam if automatic guide-me-home
lighting is activated.

Switching on the lamps after the
ignition is switched off
To reactivate the lighting control, rotate
ring A to the 0 position – lamps off, then to
the desired position.
On opening the driver's door a temporary
audible signal warns the driver that the
lighting is on.
They will go off automatically after a
period of time that depends on the state of
charge in battery (entering energy-saving
mode).

In some weather conditions (e.g. low
temperature or humidity), the presence
of misting on the internal surface of the
glass of the headlamps and rear lamps is
normal; it disappears after the lamps have
been on for a few minutes.

Travelling abroad
If using your vehicle in a country that
drives on the other side of the road, the
headlamps must be adjusted to avoid
dazzling oncoming drivers.
Contact a PEUGEOT dealer or a qualified
workshop.

Daytime running lamps/
sidelamps

The LEDs of these lamps light up automatically
when the engine starts, at the front and back of
the vehicle.

They provide the following functions:
- Daytime running lamps (lighting control

stalk at position "0" or "AUTO" with
adequate light level).

- Sidelamps (lighting control stalk at position

"AUTO" with low light levels or "Sidelamps
only" or "Dipped/main beam headlamps").

Content .. 6 7 8 9 ..
