Peugeot 407 C (2010.5). Instruction

195

SELECTING A STATION

When the current radio station is

displayed on the screen, press the

dial.

The radio source short-cuts menu appears and provides access to

the following short-cuts:

Select the function required and

press the dial to conﬁ rm to gain

access to the corresponding settings.

RDS, if displayed, allows you to continue listening to the same

station by automatic retuning to alternative frequencies. However,

in certain conditions, coverage of an RDS station may not be

assured throughout the entire country as radio stations do not

cover 100 % of the territory. This explains the loss of reception of

the station during a journey.

The external environment (hill, building, tunnel, underground car park...) may

interfere with the reception, including in RDS following mode. This phenomenon

is a normal result of the way in which radio waves are transmitted and does not

in any way indicate a failure of the audio equipment.

RDS - REGIONAL MODE

Press the RADIO button to display

the list of stations received locally

sorted in alphabetical order.

Select the station required by turning

the dial and press to conﬁ rm.

Regional prog.

Radiotext

RDS

While listening to the radio, press one of the

buttons to select the previous or next station on

the list.

Press one of the buttons on the numeric keypad for more than

2 seconds to store the current station.

Press the button on the numeric keypad to recall the stored radio

station.

A long press of one of the buttons starts the

automatic search for a station with a lower or

higher frequency.

RADIO

196

MUSIC MEDIA PLAYERS

CD, MP3/WMA CD
INFORMATION AND ADVICE

In order to be able to play a recorded CDR or CDRW, when

recording it is preferable to select the ISO 9660 level 1, 2 or

Joliet standard.

If the disc is recorded in another format it may not be played

correctly.

It is recommended that the same recording standard is always

used for an individual disc, with as low a speed as possible

(4x maximum) for optimum sound quality.

In the particular case of a multi-session CD, the Joliet standard is

recommended.

The Peugeot Connect Navigation will only play audio ﬁ les with the

extension ".mp3" with a speed of between 8 Kbps and 320 Kbps

and the extension ".wma" with a speed of between 5 Kbps and

384 Kbps.

It also supports the VBR (Variable Bit Rate) mode.

No other type of ﬁ le (.mp4, .m3u...) can be played.

The MP3 format, an abbreviation of MPEG 1, 2 & 2.5 Audio Layer 3

and the WMA format, an abbreviation of Windows Media Audio and

the property of Microsoft, are audio compression standards which

permit the recording of several tens of music ﬁ les on a single disc.

It is advisable to restrict ﬁ le names to 20 characters, without using

special characters (e.g. : " " ? ; ù) to avoid any play or display

problems.

197

SELECTING/PLAYING MUSIC
CD, MP3/WMA CD

The playing and displaying of an MP3/WMA compilation may

depend on the recording programme and/or the settings used.

We recommend the ISO 9660 ﬁ le standard.

Press the MUSIC button.

Select the "Select music" function

and press the dial to conﬁ rm.

Press the up or down button to select

the next/previous folder.

Select the music source required:

CD, MP3/WMA CD. Press the dial to

conﬁ rm. Play begins.

Select music

Press the MUSIC button again or

select the Music Menu function and

press the dial to conﬁ rm.

Press one of the buttons to select a

music track.
Press and hold one of the buttons for

fast forward or rewind play.

Music Menu

The list of tracks or MP3/WMA ﬁ les appears under Music Menu.

MUSIC MEDIA PLAYERS

198

MUSIC MEDIA PLAYERS

Connect the portable device (MP3/

WMA player…) to the audio sockets

(white and red, RCA type) in the glove

box using a JACK/RCA audio cable.

Press the MUSIC button then press

it again or select the Music Menu

function and press the dial to conﬁ rm.

Select the AUX music source and

press the dial to conﬁ rm. Play begins

automatically.

Select the "External device" function

and press the dial to activate it.

External device

The display and management of the controls is on the portable

device.

USING THE EXTERNAL INPUT (AUX)

JACK-RCA AUDIO CABLE NOT SUPPLIED

Music Menu

199

The services available depend on the network, the SIM card and the

compatibility of the Bluetooth telephone used. Check the telephone manual

and with your network provider for details of the services available to you.

A list of mobile telephones with the best level of compatibility is available

from the dealer network.

BLUETOOTH TELEPHONE

CONNECTING A TELEPHONE

For reasons of safety and because they require prolonged attention

on the part of the driver, the operations for pairing the Bluetooth

mobile telephone to the hands-free system of the Peugeot Connect

Navigation must be carried out with the vehicle stationary. The

ignition must be on.

Activate the telephone's Bluetooth function.

The last telephone connected is reconnected

automatically.

Enter the authentication code on the telephone.

The code to be entered is displayed on the

screen.

To change the telephone connected,

press the PHONE button, then select

Phone Menu and press the dial to

conﬁ rm.

Once the telephone has been connected, Peugeot Connect

Navigation can synchronise the address book and the call list. This

synchronisation may take a few minutes * .

Select "Connect phone". Select the

telephone and press to conﬁ rm.

The list of telephones connected previously (4 maximum) appears

on the multifunction screen. Select the telephone required for a new

connection.

Press the PHONE button.

For a ﬁ rst connection, select

"Search phone" and press the dial to

conﬁ rm. Then select the name of the

telephone.

Search phone

Connect phone

200

Select the "Yes" tab to accept or "No"

to refuse and conﬁ rm by pressing

the dial.

RECEIVING A CALL

MAKING A CALL

An incoming call is announced by a ring and a superimposed

display on the multifunction screen.

Yes

To hang up, press the PHONE button

or press the dial and select "End call"

then conﬁ rm by pressing the dial.

End call

Press the PHONE button.

Select "Dial number", then dial the

telephone number using the virtual

keypad.

Select the Phone Menu function and

press the dial to conﬁ rm.

The list of the last 20 calls made and received in the vehicle

appears under Phone Menu. You can select a number and press

the dial to make the call.

It is also possible to select a number from the address book.

You can select "Dial from address book". The Peugeot Connect

Navigation can record up to 4 000 entries.

Press the end of the steering mounted control for more than

two seconds to gain access to the address book.

Phone Menu

Dial number

To delete a number, press the PHONE button then press and hold

on a call number to display a list of actions including:

Delete entry

Delete list

BLUETOOTH TELEPHONE

Press the end of the steering mounted control to

accept the call or end the call in progress.

201

CONFIGURATION

SETTING THE DATE AND TIME

The SETUP function gives access to the following options: System

language, Date & Time, Display (Brightness, Colour, Map colour), Vehicle,

Units, System.

Adjust the settings one by one using

the direction arrows and conﬁ rm by

means of the dial.

Select the "Date format" function and

press the dial to conﬁ rm.

Select the "Set date & time" function

and press the dial to conﬁ rm.

Conﬁ rm the format required using the dial.

Pressing the SET UP button for more than 2 seconds gives

access to:

These settings must be entered again if the battery has been

disconnected.

Press the SET UP button.

Conﬁ rm the format required using

the dial.

Select the "Time format" function and

press the dial to conﬁ rm.

Set date & time

Select the "Date & Time" function

and press the dial to conﬁ rm.

Demo mode

GPS coverage

Description of the unit

Date & Time

202

TRIP COMPUTER/VEHICLE PARAMETERS

TRIP COMPUTER

Press the MODE button several

times in succession until the trip

computer is displayed.

Range:

displays the distance which can travelled with the

remaining fuel detected in the tank, based on the average fuel

consumption over the last few miles (kilometres).

This displayed value may vary signiﬁ cantly following a change in

the vehicle speed or the relief of the route.

When the range falls below 20 miles (30 km), dashes are

displayed. After ﬁ lling with at least 5 litres of fuel, the range is

recalculated and is displayed when it exceeds 60 miles (100 km).

If, whilst driving, dashes are displayed continuously in place of the

digits, contact a PEUGEOT dealer.

Each press of the button at the end of the wiper stalk displays the

different trip computer information in succession, according to the

screen.

A FEW DEFINITIONS

- The "vehicle" tab:

The range, the current fuel

consumption and the distance

remaining.

- The "1" (trip 1) tab with:

The average speed, the average

fuel consumption and the

distance travelled calculated

over route "1".

- The "2" (trip 2) tab with the same

functions for a second route.

Current fuel consumption:

only calculated and displayed above

20 mph (30 km/h).
Average fuel consumption:

this is the average fuel consumption

since the last trip computer zero reset.

Distance travelled:

calculated since the last trip computer

zero reset.
Distance remaining to the destination:

calculated with reference

to the ﬁ nal destination, entered by the user. If guidance is activated,

the navigation system calculates it as a current value.

Average speed:

this is the average speed calculated since the last

trip computer zero reset (ignition on).

RADIO

203

SCREEN MENU MAP

"Traffic" Menu

Messages on route

Only warnings on route

All warning messages

All messages

Within 2 miles (3 km)

Geo. Filter

Within 3 miles (5 km)

Within 6 miles (10 km)

Within 30 miles (50 km)

Within 60 miles (100 km)

"Music" Menu

Select music

Sound settings

Balance/Fader

Bass/Treble

Linear

Equalizer

Classic

Jazz

Rock/Pop

Techno

Vocal

Loudness

Speed dependent volume

Reset sound settings

"Radio" Menu

Waveband

Linear

Manual tune

Sound settings

Balance/Fader

Bass/Treble

Equalizer

MAIN FUNCTION

OPTION A

option A1

option A2

OPTION B...

204

Abort guidance/Resume guidance

Destination input

Geo position

Map

Stopovers

Add stopover

Navigate HOME

Choose from address book

Rearrange route

Choose from last destinations

Replace stopover

Delete stopover

Recalculate

Fast route

Short route

Optimized route

POI search

POI nearby

Route options

Route type

Short route

Fast route

"Navigation" Menu

City

Street

Enter new address

Country

Navigate HOME

City district

House number

Start route guidance

Postal code

Save to address book

Intersection

Address input

POI near destination

POI in city

POI in country

POI near route

Choose from address book

Choose from last destinations

TMC station information

Loudness

Speed dependent volume

Reset sound settings

Classic

Jazz

Rock/Pop

Techno

Vocal

205

Avoid ferries

Recalculate

Settings

Navi volume

POI categories on Map

Set parameters for risk areas

Display on map

Visual alert

Sound alert

Dial from address book

"Phone" Menu

Search phone

Call lists

Connect phone

Select ring tone

Phone/Ring tone volume

Phones connected

Enter mailbox number

Settings

Disconnect phone

Rename phone

Delete pairing

Delete all pairings

Show details

"SETUP" menu

System language *

English

Español

Deutsch

Italiano

Français

Nederlands

Polski

Portuguese

Date & Time *

Set date & time

Date format

Time format

Avoid motorways

Route dynamics

Trafﬁ c independent

Semi-dynamic

Avoidance criteria

Avoid toll roads

Optimized route

* Available according to model.

206

* Available according to model.

Dark blue

Map colour

Night mode for map

Units

Day mode for map

Vehicle *

Vehicle information

Alert log

Status of functions

Temperature

Celsius

Fahrenheit

Metric/Imperial

Kilometres (Consumption: l/100)

Kilometres (Consumption: km/l)

Miles (Consumption: MPG)

System

Auto. Day/Night for map

Factory reset

Software version

Automatic scrolling

Colour

Pop titanium

Toffee

Blue steel

Technogrey

Display

Brightness

FREQUENTLY ASKED QUESTIONS

QUESTION

ANSWER

SOLUTION

There is a difference in

sound quality between

the different audio

sources (radio, CD...).

For optimum sound quality, the audio settings (Volume, Bass, Treble,

Ambience, Loudness) can be adapted to the different sound sources,

which may result in audible differences when changing source (radio,

CD...).

Check that the audio settings (Volume, Bass,

Treble, Ambience, Loudness) are adapted to

the sources listened to. It is advisable to set

the AUDIO functions (Bass, Treble, Front-Rear

Balance, Left-Right Balance) to the middle

position, select the Linear musical ambience and

set the loudness correction to the "Active" position

in CD mode or to the "Inactive" position in radio

mode.

The CD is ejected

automatically or is not

played by the player.

The CD is inserted upside down, is unplayable, does not contain any

audio data or contains an audio format which the player cannot play.

The CD is protected by an anti-pirating protection system which is not

recognised by the audio equipment.

- Check that the CD is inserted in the player the

right way up.

- Check the condition of the CD: the CD cannot

be played if it is too damaged.

- Check the content in the case of a recorded

CD: consult the advice in the Audio section.

- The audio equipment's CD player does not

play DVDs.

- Because of their quality level, certain

writeable CDs will not be played by the audio

system.

The CD player sound is

poor.

The CD used is scratched or of poor quality.

Insert good quality CDs and store them in suitable

conditions.

The audio equipment settings (bass, treble, ambiences) are unsuitable.

Set the treble or bass level to 0, without selecting

an ambience.

208

QUESTION

ANSWER

SOLUTION

The stored stations do

not function (no sound,

87.5 Mhz is displayed...).

An incorrect waveband is selected.

Press the BAND AST button to return to the

waveband (AM, FM1, FM2, FMAST) on which the

stations are stored.

The quality of reception

of the radio station

listened to gradually

deteriorates or the stored

stations do not function

(no sound, 87.5 Mhz is

displayed...).

The vehicle is too far from the transmitter used by the station listened

to or there is no transmitter in the geographical area through which the

vehicle is travelling.

Activate the RDS function to enable the system

to check whether there is a more powerful

transmitter in the geographical area.

The environment (hills, buildings, tunnels, basement car parks...) block

reception, including in RDS mode.

This phenomenon is normal and does not indicate

a failure of the audio equipment.

The aerial is absent or has been damaged (for example when going

through a car wash or into an underground car park).

Have the aerial checked by a PEUGEOT dealer.

Sound cut-outs of 1 to

2 seconds in radio mode.

During this brief sound cut-out, the RDS searches for any frequency

permitting better reception of the station.

Deactivate the RDS function if the phenomenon is

too frequent and always on the same route.

With the engine off,

the audio equipment

switches off after a few

minutes of use.

When the engine is switched off, the audio equipment operating time

depends on the battery charge.

The switch-off is normal: the audio equipment switches to economy mode

and switches off to prevent discharging of the vehicle's battery.

Start the vehicle's engine to increase the battery

charge.

209

QUESTION

ANSWER

SOLUTION

TA is selected. However,

certain trafﬁ c jams

along the route are not

indicated in real time.

On starting, it is several minutes before the system begins to receive the

trafﬁ c information.

Wait until the trafﬁ c information is being received

correctly (displaying of the trafﬁ c information

symbols on the map).

In certain countries, only major routes (motorways...) are listed for the

trafﬁ c information.

This phenomenon is normal. The system is

dependent on the trafﬁ c information available.

I receive a speed camera

alert for a camera which

is not on my route.

The system announces all speed cameras located in a conical zone

forward of the vehicle. It may detect speed cameras on nearby or parallel

roads.

Zoom the map to view the exact position of the

speed camera.

The audible speed

camera alert is not

working.

Audible alerts are not active.

Activate audible alerts in Navigation Menu,

Settings, Set parameters for risk areas.

The alert volume level is set to minimum.

Increase the speed camera alert volume.

The altitude is not

displayed.

On starting, the initialisation of the GPS may take up to 3 minutes to

receive more than 3 satellites correctly.

Wait until the system has started up completely.

Check that there is a GPS coverage of at least

3 satellites (long press on the SETUP button, then

select GPS coverage).

Depending on the geographical environment (tunnel...) or the weather,

the conditions of reception of the GPS signal may vary.

This phenomenon is normal. The system is

dependent on the conditions of reception of the

GPS signal.

The route is not

calculated successfully.

The exclusion criteria may conﬂ ict with the current location (exclusion of

toll roads on a motorway with tolls).

Check the exclusion criteria.

210

QUESTION

ANSWER

SOLUTION

There is a long waiting

time after inserting a CD.

When a new medium is inserted, the system reads a certain amount of

data (directory, title, artist, etc.). This may take a few seconds.

This phenomenon is normal.

I cannot connect my

Bluetooth telephone.

The telephone's Bluetooth function may be deactivated or the equipment

may not be visible.

- Check that your telephone's Bluetooth

function is activated.

- Check that your telephone is visible.

A telephone connected

by Bluetooth is inaudible.

The volume level depends on both the system and the telephone.

Increase the Peugeot Connect Navigation volume

setting, possibly to maximum, and increase the

telephone volume level if necessary.

Peugeot 407 C (2010.5). Instruction - part 14
