Peugeot 407 C Dag (2008 year). Instruction - part 4

ELECTRIC ADJUSTMENT OF
THE HEIGHT AND DEPTH OF
THE STEERING WHEEL

When stationary, adjust the height or

depth of the steering wheel by moving

the control:
 forwards or backwards to adjust

the depth.



up or down to adjust the height.

You can activate or deac-

tivate this function via the

"personalisation-configu-

ration" menu on the multi-

function display.

WELCOME FUNCTION

When the driver's door is opened with

the ignition off, the steering wheel ris-

es to make access to or exit from the

vehicle easier.

MANUAL STEERING WHEEL
HEIGHT AND DEPTH
ADJUSTMENT

When the vehicle is stationary, unlock

the steering wheel by pushing the con-

trol forwards.

Adjust the height and depth of the

steering wheel then lock by pulling the

control fully.

Reinitialisation

Following reconnection of the battery, the

welcome function must be reinitialised:
- move the control in the direction of

the required adjustment,

- release the control,
- move the control again until it

reaches its stop.

This procedure must be carried out for

all four directions.

MANUAL FRONT SEATS

Longitudinal adjustment
Lift the control bar and slide the seat

forwards or backwards.

Driver and passenger seat cushion
height and angle adjustment
Pump up or down to the required position.

Seat back angle adjustment
Without resting your back against the

seat, turn the control to adjust the angle

of the seat back.

Heated seat adjustment
With the engine running, turn the knob.

The temperature of the seat is regu-

lated automatically.
0:

Off.

Low.

Medium.

High.

Driver and passenger seat lumbar
adjustment *
Operate the lever to obtain the required

position.

Access to the rear seats
If necessary, detach the seat belt from

the handle and position it along the

door pillar.
Pull the handle A

upwards and for-

wards to fold the seat back, then move

the seat forward pushing the seat

back.

The driver has a courtesy handle B

to enable him to move the passenger

seat from his seat.

When it is put back in place, the seat

returns to its initial position.

No person or object must pre-

vent the seat from returning to
its initial longitudinal and angle

position.

Depending on your seat's settings, it

is possible that the access to the rear

seats manoeuvre may be limited. In

this case, the seat settings must be

altered ﬁ rst.

The seat must return to this position

for correct locking of the seat back.
Ensure that the seat back returns to its

position correctly and never drive with

the seat back disengaged (free of any

movement).

If the seat back jams on repositioning,

operate the handle A again to release

it and return it to its initial position.

* With electric seat only.

Do not use the seat back an-

gle  adjustment  control  when
using  the  access  to  the  rear
seats  (risk  of  disengaging  of

the seat back with loss of the angle

adjustment function).

Head restraint height and angle
adjustment
To raise or lower the head restraint,

pull it forwards then slide it.
To tilt the head restraint, tilt the lower

part forwards or backwards.
To remove the head restraint, move it

almost to the highest position, lift the

tab using a coin and pull the head re-

straint forwards and upwards at the

same time.

To reﬁ t the head restraint, engage the

stalks in the holes keeping in line with

the seat back.

Front seat active head restraint
This system prevents whiplash.

In the event of a rear impact, the action

of the body on the seat back moves

the head restraint forwards and up-

wards preventing the head from being

thrown backwards.

Front armrest

To change the position of the armrest:
 Lift the handle 1

The armrest folds forwards and up-

wards.

To return to the initial position, push

the armrest backwards and press it to

engage.

The adjustment is correct

when the top of the head re-

straint is level with the top of

the head.

Never drive with the head re-

straints removed; they must be

in place and adjusted correctly.

ELECTRIC FRONT SEATS

Longitudinal adjustment
Push the control forwards or back-

wards to slide the seat.

Driver and passenger seat cushion
height and angle adjustment
Height:

tilt the rear of the control up

or down.
Angle:

tilt the front of the control up

or down.

Seat back angle adjustment
Tilt the control forwards or backwards

to adjust the angle of the seat back.

The electrical functions of the

driver's seat (with the excep-

tion of the access to the rear

seats) are deactivated approxi-

mately one minute after the ignition is

switched off.

To reactivate them, open the door or

switch on the ignition.

Heated seat adjustment
With the engine running, turn the knob.

The temperature of the seat is regu-

lated automatically.
0:

Off.

Low.

Medium.

High.

Driver and passenger seat lumbar
adjustment *
Operate the lever to obtain the required

position.

Access to the rear seats
If necessary, detach the seat belt from

the handle and position it along the

door pillar.
Pull the handle A

upwards and for-

wards to fold the seat back, then move

the seat forward pushing the seat

back.

The driver has a courtesy handle B

to enable him to move the passenger

seat from his seat.

When it is put back in place, the seat

returns to its initial position.

No person or object must pre-

vent the seat from returning to
its initial longitudinal and angle

position.

Depending on your seat's settings, it

is possible that the access to the rear

seats manoeuvre may be limited. In

this case, the seat settings must be

altered ﬁ rst.

The seat must return to this position

for correct locking of the seat back.
Ensure that the seat back returns to its

position correctly and never drive with

the seat back disengaged (free of any

movement).

If the seat back jams on repositioning,

operate the handle A again to release

it and return it to its initial position.

* With electric seat only.

Do not use the seat back an-

gle  adjustment  control  when
using  the  access  to  the  rear
seats  (risk  of  disengaging  of

the seat back with loss of the angle

adjustment function).

Head restraint height and angle
adjustment
To raise or lower the head restraint,

pull it forwards then slide it.
To tilt the head restraint, tilt the lower

part forwards or backwards.
To remove the head restraint, move it

almost to the highest position, lift the

tab using a coin and pull the head re-

straint forwards and upwards at the

same time.

To reﬁ t the head restraint, engage the

stalks in the holes keeping in line with

the seat back.

Front seat active head restraint
This system prevents whiplash.

In the event of a rear impact, the action

of the body on the seat back moves

the head restraint forwards and up-

wards preventing the head from being

thrown backwards.

Front armrest

To change the position of the armrest:
 Lift the handle 1

The armrest folds forwards and up-

wards.

To return to the initial position, push

the armrest backwards and press it to

engage.

The adjustment is correct

when the top of the head re-

straint is level with the top of

the head.

Never drive with the head re-

straints removed; they must be

in place and adjusted correctly.

Memorising driving positions

The electrical adjustments of the driver's
seat, steering wheel and exterior mirrors

are memorised.

Two driving positions can be memo-

rised using buttons M/1and M/2

An audible signal conﬁ rms that a position

has been memorised.

Memorising a new position cancels

the previous one.

Recalling a memorised driving
position

During access to the rear
seats, the memorising and

recalling of the driving posi-

tions are deactivated.

Vehicle moving


Keep button 1 or 2 pressed down

until the bleep indicates that set-

ting of the corresponding memo-

rised position is complete.

REAR HEAD RESTRAINTS

The rear head restraints have a high

position for use and a low position for

storing.

They can also be removed.

To remove them, pull upwards fully

and press the lug.

Never drive with the head re-

straints removed; they must be

in place and adjusted correctly.

Memorising using the controls on
the driver's door
To memorise:


Place the key in the ignition on po-

sition,



Adjust your seat, steering wheel

and mirrors,

 Press button M , then button 1

"ﬁ rst driving position" or button 2

"second driving position" within

four seconds.

Ignition on, vehicle stationary


Brieﬂ y press button 1 or 2 to recall

the corresponding memorised po-

sition. The end of the setting is in-

dicated by a bleep.

After recalling a memorised position

a few times in succession, the func-

tion will be cancelled until the engine

is started.

REAR SEATS

To fold down the rear left seat or the

rear right seat, always start with the

seat, never with the seat back (risk of

damage):


move the front seat(s) forward if

necessary,



place the head restraints in the low

position or remove them if necessary,

Check that the seat belt strap is

positioned correctly at the side of

the seat back,



release the front of the seat cush-

ion 1

by passing your hands under-

neath and lifting at each end A ,

 lift the front of the seat cushion 1 ,
 tilt the seat cushion 1 against the

front seat(s),



pull control 3 forwards to unlock

the seat back 2 ,

 fold down the seat back 2

(left 1/3

or right 2/3).

Note:

the one-piece seat cushion 1

can be removed with care to increase

the volume of the load space.

Squeeze the seat cushion ﬁ xings to

detach them from their fastenings.

When repositioning:


fold up the seat back 2 and lock it

(the red marker of control 3 should

no longer be visible),



fold up the seat 1 ,



reﬁ t the head restraints if they were

removed.

Locking/unlocking the access
to the boot via the rear seats

Your vehicle's boot can be isolated

from the passenger compartment.
The red indicator on the control 3

should no longer be visible. If it is,

push the seat fully.

Insert the ignition key in the lock 4 .

Transporting long objects

In exceptional circumstances , a rear
seat back can be folded without folding
the seat cushion 1

in order to transport

long, light objects (risk of damage to

the seat cushion).

When putting the seat backs

and the seat cushion back in

place, ensure that they are

secured correctly to guaran-

tee your safety and take care not to

trap the seat belts.

When transporting long objects,

do not place a load weighing

more than 30 kg on the rear of

the seat back.

Do not place blunt objects on the rear of

the seat back as this could damage it.

Although one of PEUGEOT's main cri-

teria when designing your vehicle, the

safety of your children also depends

on you.

INSTALLING A CHILD SEAT USING A THREE POINT SEAT BELT

Intermediate longitudinal

position

** The rules for transporting children are

speciﬁ c to each country. Consult the

current legislation in your country.

GENERAL POINTS RELATING
TO CHILD SEATS

"Forwards-facing"

"Rearwards-facing"

For maximum safety, please

follow these precautions:

When a "rearwards-facing"

child seat is installed on the
front passenger seat , it is

essential that the passenger

air bag is disarmed ** . Otherwise, the

child would risk being seriously in-
jured or killed if the air bag were to

inﬂ ate .

- in accordance with European regu-

lations, all children under the age

of 12 or less than one metre ﬁ fty

tall must travel in approved child
seats suited to their weight , on

seats ﬁ tted with a seat belt or ISOFIX

mountings*

- statistically, the safest seats in

your  vehicle  for  the  transpor-
tation  of  children  are  the  rear
seats,

- a child weighing less than 9 kg

must travel in the "rearwards-
facing" position both in the front
and in the rear.

PEUGEOT recommends that children
should travel in the rear seats

of your

vehicle:
- "rearwards-facing" up to the age

of 2,

- "forwards-facing" over the age of 2.

When a "forwards-facing" child seat

is installed on the front passenger
seat , adjust the vehicle's seat to the

intermediate longitudinal position with

the seat back upright and leave the

passenger air bag armed ** .

* According to model.

ADVICE ON CHILD
SEATS

Children under the age of 10 must not

travel in the "forward facing" position

on the front passenger seat, unless

the rear seats are already occupied by

other children, cannot be used or are

absent.

Disarm the passenger air bag * when a

"rear facing" child seat is installed on

the front seat.
Otherwise, the child would risk being

seriously injured or killed if the air bag

were to inﬂ ate.

As a safety precaution, do not leave:

- one or more children alone and un-

supervised in a vehicle,

- a child or an animal in a vehicle

which is exposed to the sun, with

the windows closed,

- the keys within reach of children

inside the vehicle.

To protect young children from the

rays of the sun, ﬁ t side blinds on the

rear windows.

* According to country.

The incorrect installation of a child seat

in a vehicle compromises the child's

protection in the event of an accident.

Remember to fasten the seat belts or

the child seat harness keeping the
slack

in relation to the child's body to

a minimum

, even for short journeys.

For optimum installation of the

"forward facing" child seat, ensure that

the back of the child seat is in contact
with the back of the vehicle's seat and
that the head restraint does not cause

any discomfort.
If the head restraint has to be
removed, ensure that it is stored or

attached securely to prevent it from

being thrown around the vehicle in the

event of sharp braking.

Installing a booster seat
The chest part of the seat belt must

be positioned on the child's shoulder

without touching the neck.

Ensure that the lap part of the seat

belt passes correctly over the child's

thighs.
PEUGEOT recommends the use of

a booster seat which has a back, ﬁ t-

ted with a seat belt guide at shoulder

level.

Passenger air bag OFF

PEUGEOT CHILD SEATS RECOMMENDED BY

PEUGEOT offers a complete range of recommended child seats which are

secured using a three point seat belt :

Group 0: from birth to 10 kg

Group 0+: from birth to 13 kg

"ROMER Baby-Safe Plus"

Installed in the rear-facing position

Groups 1, 2 and 3: from 9 to 36 kg

"KIDDY Life"

For the safety of young children

(from 9 to 18 kg), PEUGEOT recom-

mends use of the restraining cushion.

Groups 2 and 3: from 15 to 36 kg

"RECARO Start''

"KLIPPAN Optima"

From the age of 6 years

(approximately 22 kg),

the booster is used on

its own.

LOCATION OF CHILD SEATS ATTACHED USING THE SEAT BELT

In accordance with European regulations, this table indicates the options for installing child seats secured using a seat belt

and universally approved in accordance with the weight of the child and the seat in the vehicle.

group 0: from birth to 10 kg.

b: consult the legislation in force in

your country before installing your

child on this seat.

c: vehicle seat in the intermediate

longitudinal position.

U: seat suitable for the installation of a

universally approved child seat se-

cured using a seat belt, "rear facing"

and/or "forward facing".

Installation of the L1

(RÖMER

Baby-Safe Plus) child seat on

the rear seats of your vehicle

is not recommended.

Weight of the child and indicative age

Seat

Under 13 kg

(groups 0 (a) and 0+)

Up to 1 year approx

From 9 to 18 kg

(group 1)

1 to 3 years approx

From 15 to 25 kg

(group 2)

3 to 6 years approx

From 22 to 36 kg

(group 3)

6 to 10 years approx

Front passenger

seat (b)

U(c)

Rear seats

ADVICE ON CHILD
SEATS

Children under the age of 10 must not

travel in the "forward facing" position

on the front passenger seat, unless

the rear seats are already occupied by

other children, cannot be used or are

absent.

Disarm the passenger air bag * when a

"rear facing" child seat is installed on

the front seat.
Otherwise, the child would risk being

seriously injured or killed if the air bag

were to inﬂ ate.

As a safety precaution, do not leave:

- one or more children alone and un-

supervised in a vehicle,

- a child or an animal in a vehicle

which is exposed to the sun, with

the windows closed,

- the keys within reach of children

inside the vehicle.

To protect young children from the

rays of the sun, ﬁ t side blinds on the

rear windows.

* According to country.

The incorrect installation of a child seat

in a vehicle compromises the child's

protection in the event of an accident.

Remember to fasten the seat belts or

the child seat harness keeping the
slack

in relation to the child's body to

a minimum

, even for short journeys.

For optimum installation of the

"forward facing" child seat, ensure that

the back of the child seat is in contact
with the back of the vehicle's seat and
that the head restraint does not cause

any discomfort.
If the head restraint has to be
removed, ensure that it is stored or

attached securely to prevent it from

being thrown around the vehicle in the

event of sharp braking.

Installing a booster seat
The chest part of the seat belt must

be positioned on the child's shoulder

without touching the neck.

Ensure that the lap part of the seat

belt passes correctly over the child's

thighs.
PEUGEOT recommends the use of

a booster seat which has a back, ﬁ t-

ted with a seat belt guide at shoulder

level.

"ISOFIX" MOUNTINGS

Your vehicle has been approved in accor-

dance with the new ISOFIX regulation

The seats * , represented below, are ﬁ tted

with regulation ISOFIX mountings:

These are three rings for each seat:

This ISOFIX mounting system guaran-

tees you fast, reliable and safe ﬁ tting

of the child seat in your vehicle.
The ISOFIX child seats

are ﬁ tted with

two locks which are secured easily on

these lower rings A

Some also have an upper strap which

is attached to the upper ring B .

- two lower rings A , located between

the vehicle seat back and cushion,

indicated by a label,

* According to version.

- an upper ring B , referred to as the

TOP TETHER

, indicated by a label.

To attach this strap, raise the

vehicle seat's head restraint

then pass the hook between

its rods. Then ﬁ x the hook on

the upper ring B and tighten the upper

strap.

The incorrect installation of a

child seat in a vehicle compro-

mises the child's protection in

the event of an accident.

For information regarding the ISOFIX

child seats which can be installed in your

vehicle, consult the summary table for

the location of the ISOFIX child seats.

ISOFIX CHILD SEAT RECOMMENDED BY PEUGEOT AND APPROVED FOR YOUR VEHICLE

This child seat can also be used on seats which are not ﬁ tted with ISOFIX mountings.

In this case, it must be attached to the vehicle seat using the three point seat belt.

Follow the instructions for ﬁ tting the child seat given in the seat manufacturer's installation guide.

ISOFIX RÖMER Duo Plus

(size category B1 )

Group 1: from 9 to 18 kg

Installed in the forward facing position.

Fitted with an upper strap to be secured on the ISOFIX upper ring,

referred to as the TOP TETHER.

Three seat body angles: sitting, reclining, lying.

Content .. 2 3 4 5 ..
