Peugeot 406 C (2004 year). Instruction - part 6

YOUR 406 COUPE IN DETAIL

Make a careful note of the number on each key. The key number is coded on the label attached to the key.

If the keys are lost, your PEUGEOT dealer can rapidly supply you with new keys.

The high frequency remote control is a sensitive system; do not operate it while it is in your pocket as there is a

possibility that it may unlock your vehicle, without you being aware of it.

The remote control does not operate when the key is in the ignition, even when the ignition is switched off, except for

reprogramming.

Do not operate the deadlocking function if there is anyone inside the vehicle.

Driving with the doors locked may make access to the passenger compartment by the emergency services more difficult

in an emergency.

As a safety precaution (with children on board), remove the ignition key when you leave the vehicle, even for a short time.

Do not repeatedly press the button of your remote control out of range of your vehicle. You run the risk of stopping it from

working and the remote control would have to be reprogrammed.

When purchasing a second-hand vehicle:

- ensure that you are given the confidential card;

- have the key codes memorised by a PEUGEOT dealer, to ensure that the keys in your possession are the only ones

which can start the vehicle.

Do not make any modifications to the electronic engine immobiliser system.

02-02-2004

YOUR 406 COUPE IN DETAIL

Setting

Disarming

Switch the ignition off and get out of

Unlock the vehicle using the remote

the vehicle.

control key

(the direction indicators

Set the alarm within five minutes fol-

flash for two seconds and the red

lowing your exit from the vehicle by

light on the switch goes out).

locking using the remote control (the

Note: if the red warning light flashes,

red light on the switch, visible from

it is a sign that the alarm has been

the outside, flashes every second

triggered during your absence.

and the direction indicators come on

permanently for two seconds).

To stop it, switch on the ignition.

5 seconds later, internal protection is

Note: when the alarm is set, but the

set.

remote control no longer works:

45 seconds later, external protection

☞ unlock the doors using the key

is set.

and open the door; the alarm is

When the alarm is triggered, the

triggered;

THE ALARM SYSTEM*

siren sounds for thirty seconds.

☞ switch the ignition on within ten

This offers two types of protection:

After it has been triggered, the alarm

seconds;

is operational again.

• external , it sounds if a door, the

☞ press the internal protection button 1

bonnet or the boot is opened.

immediately. The alarm is disarmed.

Note: if you wish to lock your vehicle

• internal , it sounds if there is air

without setting the alarm, lock it

movement in the passenger com-

using the lock.

partment

(a broken window or

movement inside the vehicle).

Warning

Note: it also has an anti-tamper

When the alarm is triggered, if a door,

function; if there is an attempt to tam-

the boot or the bonnet are not closed

per with the wires to the siren, the

correctly, the siren sounds for a

control unit or the battery, the siren

moment. Close the vehicle correctly

sounds and the direction indicators

to set the alarm.

light.

* According to destination.

02-02-2004

YOUR 406 COUPE IN DETAIL

To set the alarm to external

To disarm external type

protection only.

protection only

If you want to leave a window partially

☞ see "Disarming" section.

open, or a pet inside the vehicle, you

Note: if you wish to charge or

need to select external protection only:

replace the battery:

• Switch off the ignition.

• Turn on the ignition.

• Within the next ten seconds, press

• You have 10 seconds after turning

the internal protection button

on the ignition to press the internal

until the light comes on.

protection switch

and hold it

• Get out of the vehicle.

down for two seconds.

• Press the locking button on the

• The warning light flashes rapidly

remote control.

for three seconds.

• The doors lock.

• Disconnect the battery.

• The direction indicators light for

• After reconnecting the battery,

two seconds.

lock, then unlock the vehicle using

the remote control.

• The red light on the switch flashes

once a second.

Do not make any modifi-

cations to the alarm sys-

tem, this could cause

faults.

02-02-2004

YOUR 406 COUPE IN DETAIL

To make opening of the

door easier, the window

automatically lowers by a

few centimetres.

It rises and automatically

adjusts itself on closing the door to

ensure perfect sealing.

Before carrying out any work

which involves disconnection

of the battery, lower the win-

THE DOORS

Opening the doors from inside

dows to permit opening and

closing of the doors.

Opening the doors from outside

Locking from the inside

To lock, press button A .

Warning: If the battery is discon-

Locking the front doors locks both

nected, the doors can still be

the front doors and the boot.

opened. However, it is imperative

that the door is not slammed on

closing.

Automatic central locking

Consult your PEUGEOT dealer as

soon as possible.

To activate this function, contact a

PEUGEOT dealer.

The doors and the boot of your vehi-

cle lock automatically while driving

(speed greater than

6 mph

(10km/h)).

The door opening controls permit

complete unlocking of the vehicle.

02-02-2004

YOUR 406 COUPE IN DETAIL

Always remove the key

from the ignition when

leaving the vehicle, even

for a short time.

In the event of contact when

operating the sunroof, you must

reverse the movement of the

sunroof. To do this, press the

switch concerned.

When the driver operates the

sunroof, he must ensure that no

one is preventing it from closing

correctly.

SUNROOF

The driver must ensure that pas-

sengers use the sunroof correctly.

• To tilt

Be aware of children when oper-

Press part A of the switch. To

ating the sunroof.

close, press part B of the switch

until the sunroof is completely

closed.

• To open

Press part B of the switch. To

close, press part A of the switch

until the sunroof is completely

closed.

02-02-2004

YOUR 406 COUPE IN DETAIL

BOOT

OPENING THE BONNET

FILLING WITH FUEL

Simultaneous locking or unlocking

From inside: pull the handle on the

Fill with fuel with the engine switched

of the boot and the doors

left-hand side under the fascia.

off.

Turn the key a quarter turn from A to

From outside: lift the catch and

To open the fuel filler flap, firmly pull

raise the bonnet.

the handle on the floor on the left of

The boot is then controlled by the

the driver's seat.

remote control or the driver's door

lock.

Bonnet struts

If you are filling up your tank, do not

continue after the 3rd cut-off of the

These open the bonnet and hold it

Locking the boot only

pump; this could cause your vehicle

open.

to malfunction.

Turn the key a quarter of a turn from

A to C. The boot is then locked,

To close

The capacity of the tank is approx-

whatever the action of the remote

imately 15.4 gallons (70 litres).

control or the driver's door lock.

Lower the bonnet and release it at

the end of its travel. Check that the

To return to simultaneous operation

bonnet is properly locked.

with the doors: turn the key from A to

A filler cap hook is provided on

the inside of the fuel filler flap.

02-02-2004

102

YOUR 406 COUPE IN DETAIL

Dipped/main beam change

Front fog lamps and

rear fog lamp (2nd for-

Pull the stalk towards you.

wards turn of the ring)

Note: with the ignition off, if the

driver's door is open, a buzzer

Note: to switch off the rear fog lamp

sounds if you have left your lights on.

and the front fog lamps, turn the ring

twice backwards.

THE LIGHTS STALK

Front fog lamps and rear fog lamp

Front and rear lights

Rotate the ring B forwards to switch

on and backwards to switch off. The

Selection is by turning ring A.

status is confirmed by the light on the

Direction indicators

(flashers)

instrument panel.

Left: downwards.

Right: upwards.

Lights off

Front fog lamps

(1st for-

wards turn of the ring)

Side lights on

Dipped/main beam

In good or rainy weather,

headlamps

both day and night, the

front fog lamps and the

rear fog lamp are daz-

zling and are prohibited.

Automatic switching

on of lights

Do not forget to switch them off

when they are no longer needed.

02-02-2004

103

YOUR 406 COUPE IN DETAIL

AUTOMATIC SWITCHING ON

Operating check

If the brightness sensor does not

OF THE LIGHTS

function correctly, the system acti-

vates the function

(the lights come

The side lights and dipped beam

Activation

on). The driver is alerted by the

headlamps switch on automatically if

flashing of the ''dipped beam'' warn-

the light is poor, or during continuous

Activation of this function is accom-

ing light on the instrument panel.

operation of the windscreen wipers.

panied by an audible signal and the

They switch off as soon as the light

message "Automatic lighting of

Contact a PEUGEOT dealer to have

becomes bright enough or the wind-

the headlamps activated" on the

the system checked.

screen wipers stop.

multi-function display.

This function is active when the vehi-

Note: Manual operation of the lights

cle is supplied to the customer.

stalk always takes priority

Follow me Home

To disarm or activate the function:

When there is a low level of bright-

☞ Place the key in the accessories

Disarming

ness or at night, if you leave your

position (1st notch),

vehicle, the side lights and the

☞ Press the end of the lights stalk

Disarming of the function is accom-

dipped beam lights may remain on

for more than two seconds.

panied by an audible signal and the

for approximately one minute.

message "Automatic lighting of

This function can only be used if the

Note: in foggy weather, the bright-

the headlamps deactivated" on the

automatic switching on of the lights

ness sensor can detect sufficient

multi-function display.

mode is activated then:

light. Because of this, the lights do

When driving, if this function is

☞ with the key in the accessories

not come on automatically.

switched off when the headlamps

position

(1st notch), flash the

would switch on in automatic mode,

headlamps,

Do not cover the brightness sen-

the lights remain on. It is however

☞ get out of the car and lock it.

sor connected to the rain sensor,

possible to disarm this function and

located on the windscreen behind

switch off the lights by:

the mirror. It is used for automat-

ic switching on of the lights.

- manually switching off the lights

using the lights stalk,

- switching off the engine.

02-02-2004

104

YOUR 406 COUPE IN DETAIL

Operation

Do not cover the rain

In position 1 or 2, when the vehicle

detector located on the

stops, the windscreen wiper changes

windscreen behind the

to a lower wiping speed, then

interior mirror.

resumes its initial speed when the

When using an automatic car

vehicle starts again.

wash, switch off the ignition or

When the ignition has been

check that the wiper stalk is not in

switched off for more than a

the automatic position.

minute with the stalk in the AUTO

position, it is necesary to reacti-

In winter, it is advisable to wait for

vate this function. To do this, move

the windscreen to completely

the stalk to any position, then move it

clear of ice before operating the

back to the AUTO position.

automatic wipe.

WINDSCREEN WIPER STALK

Front windscreen wipers

Automatic wipe

In the AUTO position, the wiper oper-

Windscreen and headlamp wash

Rapid wipe (heavy rain)

ates automatically and adjusts its

Pull the windscreen wiper stalk

speed to the intensity of the rainfall.

Normal wipe

towards you. The windscreen wash

(moderate rain).

then the windscreen wipers operate

Operating check

for a fixed period.

AUTO Automatic wipe.

Activation

The windscreen wash and headlamp

Off.

wash operate simultaneously for two

Activation of the function is accom-

Single wipe

seconds, only if the headlamps are

panied by the message "Automatic

(press downwards).

on.

wiper activated" on the multi-func-

tion display.

In the event of malfunction in the

AUTO position, the windscreen

wiper will operate in down-grade

mode.

Have the system checked by a

PEUGEOT dealer.

02-02-2004

116

YOUR 406 COUPE IN DETAIL

TRIP COMPUTER

Pressing the button on the end of the wash/wipe stalk enables the following data to

be displayed:

Display B

Display C

– the range

- the current consumption and the range,

- the distance travelled

- the average consumption, the distance travelled and the

average speed calculated over a period "1" ,

- the average consumption

- the average consumption, the distance travelled and the

- the current consumption

average speed calculated over a period "2" .

- the average speed

Periods "1" and "2" are defined by the frequency of the zero

reset. They allow, for instance, daily calculations over period

"1" and monthly calculations over period "2" .

Zero reset

When the required period is displayed, press the stalk for

more than two seconds.

Press the stalk for more than two seconds.

02-02-2004

117

YOUR 406 COUPE IN DETAIL

Range

Average consumption

Distance travelled

The display shows the distance that

This is the ratio between the amount

This shows the distance travelled

can still be covered with the fuel

of fuel consumed and the distance

since the computer was last reset to

remaining in the tank.

travelled since the computer was last

zero.

Note: this figure may rise if there is a

reset to zero.

change in driving style or road sur-

face, causing a significant drop in

After the trip computer has been

current fuel consumption.

reset to zero, the range data

If there are less than 3 litres of fuel in

becomes meaningful only after the

the tank, only three segments will be

vehicle has been in use for a certain

displayed.

period.

If horizontal segments are displayed

instead of figures when driving, con-

tact a PEUGEOT dealer.

Current fuel consumption

Average speed

This gives the fuel consumption

This is obtained by dividing the dis-

recorded during the last two sec-

tance travelled by the period of time

onds. This function is only displayed

the vehicle has been in use (with the

when the vehicle is travelling at more

ignition on), since the computer was

than 12 m.p.h. (20 km/h).

last reset to zero.

02-02-2004

118

YOUR 406 COUPE IN DETAIL

ELECTRIC WINDOWS

Following reconnection of the bat-

tery, in the event of a malfunction,

1 - Driver's electric window switch.

you must reinitialise the driver's elec-

tric window:

You have two options:

- it is essential to close the doors,

- Manual operation:

- open the window completely, then

Press or pull switch 1 gently. The

close it, it will rise in stages of a few

window stops as soon as the

centimetres with each press,

switch is released.

repeat the operation until the win-

dow is completely closed,

- Automatic operation* (driver):

- continue to press the switch for at

Press or pull switch 1 fully.

least one second after reaching

The window opens or closes com-

this position.

pletely when the switch is

released. Pressing the switch

2 - Passenger's electric window

again stops the movement of the

switch.

window.

Note:

Always remove the key

from the ignition when

In the case of unwanted opening of

leaving the vehicle, even

the window on closing (for example

for a short time.

in the case of frost) or if the window

In the event of contact when oper-

will not rise, lower it completely and

ating the windows, you must

raise it again immediately, by pulling

reverse the movement of the win-

the switch until the window closes

dow. To do this, press the switch

completely. Continue to press the

concerned.

switch for approximately one second

When the driver operates the

after closing.

passenger window switches, he

must ensure that no one is pre-

venting correct closing of the win-

dow.

The driver must ensure that pas-

sengers use the electric windows

correctly.

Be aware of children when oper-

ating the windows.

* According to country

02-02-2004

119

YOUR 406 COUPE IN DETAIL

The outside of the mirror

on the driver's side is con-

vex (area at edge defined

by dotted line) in order to

eliminate the 'blind spot'.

Objects observed in the driver's

and passenger's mirrors are in

reality closer than they appear.

This must be taken into account to

judge correctly the distance of

vehicles approaching from behind.

REAR WINDOWS

EXTERIOR MIRRORS

To partially open the rear windows,

Electric rear view mirrors

tilt the lever and push it fully to lock

Turn knob 6 to the right or to the left

the windows in the open position.

to select the corresponding mirror.

Move knob 6 in all four directions to

adjust.

When parked, the mirrors can be

folded back manually.

Fold-back electric mirrors

With the ignition on, turn knob 6 to

position A.

02-02-2004

120

YOUR 406 COUPE IN DETAIL

Manual interior mirror

The interior mirror has two positions:

- day (normal),

- night (anti-dazzle).

To change from one to the other,

push or pull the lever on the lower

edge of the mirror.

Automatic day/night interior mirror

This automatically and gradually changes between the day and night positions.

To prevent dazzling, the glass of the mirror darkens automatically depending on

the intensity of the light from behind. It clears as the light (headlamps of follow-

ing vehicles, sunlight) decreases, ensuring maximum visibility.

Operation

Switch on the ignition and press switch 1:

- Indicator light 2 lit (switch pressed): automatic operation.

AREAS FOR TOLL CARDS/

- Indicator light 2 off: automatic system off. The mirror remains at its most clear.

CAR PARK TICKETS

The athermic windscreen has two

Special feature

non-reflective zones located either

side of the base of the interior

To ensure maximum visibility during manoeuvres, the mirror clears automatical-

mirror.

ly when reverse gear is engaged.

They are intended for affixing toll

cards and/or car park tickets.

02-02-2004

121

YOUR 406 COUPE IN DETAIL

HEADLAMP ADJUSTMENT

HAZARD WARNING LIGHTS

STEERING WHEEL HEIGHT

AND DEPTH ADJUSTMENT

Depending on the load in your vehi-

Press the button, the direction indi-

cle, adjusting the beam of the head-

cators flash.

When the vehicle is stationary,

lamps is recommended as follows.

unlock the steering wheel by pulling

They can operate with the ignition

handle A.

1 or 2 people in the front seats.

off.

–

3 people.

Adjust the height and depth of the

steering wheel, then lock it by push-

4 people.

Automatic lighting of hazard

ing handle A down fully.

4 people + maximum

warning lights*

authorised load.

When braking in an emergency,

- Driver + maximum

depending on the force of decelera-

authorised load.

tion, the hazard warning lights come

HORN

on automatically. They switch off

automatically the first time you

Press one of the spokes or

Initial setting is position 0.

accelerate.

the centre of the steering

wheel.

It is also possible to switch them off

by pressing the button.

* According to destination.

02-02-2004

122

YOUR 406 COUPE IN DETAIL

SUN VISOR WITH ILLUMINATED

COURTESY MIRROR

With the ignition on, the mirror is

COURTESY LIGHTS

automatically lit up when the flap is

opened.

1 - Front courtesy light

2 - Rear courtesy light

Permanently on when the ignition key is in the accessories position or

the ignition is on.

Permanently off.

On when the ignition key is removed or when one of the doors is opened.

Coat hook

Press the lower section to extract the

hook from its housing.

3 - Map-reading lights

With the key in the accessories position or the ignition on, turn the knob on the

side required.

02-02-2004

123

YOUR 406 COUPE IN DETAIL

Rear shelf compartment

CENTRE CONSOLE

This is provided for the storage of a

first aid kit.

1- Front ashtray

The catch on the lid is designed to

Press the cover to open the ashtray.

withstand a weight of 9lbs (4 kg) on

To empty it, after opening, push the cover forwards.

impact.

2- Lighter

Push in and wait a few moments until it springs out automatically.

3- Coin storage

4- Cup holder

5- Rear ashtray

Release to empty, by pulling it sharply towards you.

To refit the ashtray, push it into its housing.

Storage compartment

between the rear seats

This also contains a cup holder.

02-02-2004

Content .. 4 5 6 7 ..
