Peugeot 307 Dag (2007.5). Instruction

COMFORT

These child seats can also be used on seats which are not i tted with ISOFIX mountings. In this case, it is essential

that they are secured to the vehicle’s seat by means of the three point seat belt.

Follow the instructions for i tting the child seat indicated in the seat manufacturer’s installation guide.

ISOFIX CHILD SEATS RECOMMENDED BY PEUGEOT AND APPROVED FOR YOUR VEHICLE

ISOFIX KIDDY

ISOFIX RÖMER Duo Plus

Group 0+: from birth to 13 kg

Group 1: from 9 to 18 kg

Installed in the rear facing position.

Installed in the forwards facing position.

Installed in the forwards facing position only.

The body of the child seat must be in
contact with the back of the vehicle’s
front seat.

It is essential that the vehicle’s front
seat is adjusted to the intermediate lon-
gitudinal position.

Secured without the top strap.
Three  child  seat  body  angles:  sitting,
reclining and lying positions.
Adjust  the  vehicle’s  front  seat  so  that
the  child’s  feet  do  not  touch  the  seat
back.

ACCESS

REMOTE CONTROL KEY

The  remote  control  permits  locking,
deadlocking,  unlocking  and  locating
of the vehicle, as well as folding and
unfolding of the exterior mirrors.
The key allows you to switch on the
ignition  and  mechanically  and  inde-
pendently  operate  the  lock  on  the

glove box, the fuel i ller cap, the pas-

senger air bag disarming switch and
the child lock.
From the driver's door, the key allows
you to electrically control the locking,
deadlocking and unlocking of the
doors and boot, as well as the folding
and unfolding of the exterior mirrors.
If one of the doors or the boot is open,
the central locking will not work.

Using the key
 Turn the key in the lock on the

driver's door to lock the vehicle.

This action is coni rmed by i xed

lighting of the direction indicators for
approximately two seconds.
At the same time, the exterior mirrors
fold back.

Unfolding/Folding the key

To unfold or fold the key, i rst press

button A .

Locking

   Using the remote control
       Press  button  B  to lock the vehicle.
      Press  button  B    for  more  than

2 seconds to activate the auto-
matic closing of the windows and
sunroof in addition to locking.

Each action is coni rmed by i xed

lighting of the direction indicators for
approximately two seconds.
At the same time, the exterior mirrors
fold back.

Deadlocking

This renders the exterior and  interior
door controls inoperative.
It  also  disarms  the  interior  central
locking button.

Unlocking

 Press button C to unlock the vehi-

cle.

This is coni rmed by rapid l ashing of

the direction indicators for approxi-
mately two seconds.
At the same time, the exterior mirrors
unfold.

Using the remote control
 Press button B to lock the vehicle

or press button B for more than
2 seconds to activate the auto-
matic closing of the windows and
sunroof in addition to locking.

 Press the button again within

i ve seconds to deadlock the ve-

hicle.

Each action is coni rmed by i xed

lighting of the direction indicators for
approximately two seconds.

ACCESS

ELECTRONIC ENGINE
IMMOBILISER

This locks the engine control system
a few moments after the ignition has
been switched off and therefore pre-
vents  starting  of  the  vehicle  by  any-
one who does not have the key.
The  ignition  key  has  an  electronic
chip which has a special code. When
the ignition is switched on, the code is
recognised and starting is possible.
  If  the  system  does  not  function
correctly,   the  service  warning  light
comes on, accompanied by an audi-
ble signal and a message on the mul-
tifunction display.
In  this  case,  your  vehicle  will  not
start.Contact a PEUGEOT dealer as
soon as possible.
A  heavy  object  attached  to  the  key
(key ring, ...), weighing down on the
shaft  of  the  key  in  the  switch,  may
cause a malfunction.

Battery ref.: CR1620/3 volts.
The information "battery l at" is given

by  displaying  of  the  service  warning
light, accompanied by an audible sig-
nal and a message on the multifunc-
tion display.
To replace the battery, unclip the cas-
ing using a coin at the notch.
If  the  remote  control  does  not  work
after  the  battery  has  been  changed,
re-programme the remote control.

Key in ignition

A buzzer sounds on opening the dri-
ver's door, if the key has been left in
the ignition.

mote  control  battery  or  in  the  event
of  a  remote  control  malfunction,  the
remote control must be reinitialised.
      Switch off the ignition.
     Switch the ignition on again.
     Press the remote control locking but-

ton immediately for a few seconds.

 Switch off the ignition and remove

the remote control key from the
ignition lock.

The remote control is now working
again.

Locating your vehicle

Using the key
 Turn the key in the lock on the

driver's door to lock the vehicle.



Turn the key again within i ve

seconds to deadlock the vehicle.

Each action is coni rmed by i xed

lighting of the direction indicators for
approximately two seconds.

When the vehicle is locked,
if unlocking is activated inad-
vertently without a door being
opened within 30 seconds,

the vehicle will lock automatically.
The  folding  and  unfolding  of  the  ex-
terior  mirrors  can  be  deactivated  by
a PEUGEOT dealer.

To locate your vehicle, if
you have locked it, in a
car park:

 press button B , the courtesy lights

come on and the direction indica-

tors l ash for a few seconds.

Changing the remote control
battery

Reprogramming the remote
control

Following disconnection of the vehi-
cle's battery, replacement of the re-

ACCESS

   Make  a  careful  note  of  the
number  on  each  key.  The
key number is coded on the
label attached to the key.

  If the keys are lost, your PEUGEOT
dealer can rapidly supply you with
new keys.
  The  high  frequency  remote  con-
trol  is  a  sensitive  system;  do  not
operate it while it is in your pocket
as there is a possibility that it may
unlock  your  vehicle,  without  you
being aware of it.
  The remote control does not oper-
ate when the key is in the ignition,
even when the ignition is switched
off, except for reprogramming.
  Do  not  operate  the  deadlocking
function  if  there  is  anyone  inside
the vehicle.
  Driving with the doors locked may
make  access  to  the  passenger
compartment  by  the  emergency

services more difi cult in an emer-

gency.
  As  a  safety  precaution  (with  chil-
dren on board), remove the ignition
key  when  you  leave  the  vehicle,
even for a short time.
  Do  not  repeatedly  press  the  but-
ton  of  your  remote  control  out  of
range and out of sight of your ve-
hicle. You run the risk of stopping
it  from  working  and  the  remote
control  would  have  to  be  repro-
grammed.

  When  purchasing  a  second-hand
vehicle:
   -

ensure that you are given the

coni dential card;

have  the  key  codes  memo-
rised  by  a  PEUGEOT  dealer,
to ensure that the keys in your
possession  are  the  only  ones
which can start the vehicle.

Do not make any modii cations to

the electronic engine immobiliser
system.

CONFIDENTIAL CARD

This is given to you on delivery of
your vehicle with the duplicate keys.
It contains the identii cation code

necessary for any work carried out
by a PEUGEOT dealer on the elec-
tronic immobiliser system. This code

is hidden by a i lm, which should be

removed only if necessary.
  Keep  your  card  in  a  safe  place,
never inside the vehicle.
When undertaking a long trip or jour-
ney,  however,  it  is  advisable  to  take
it  with  you  along  with  your  personal
papers.

Do not throw the remote con-
trol batteries away, they con-
tain metals which are harmful
to the environment.

Take them to an approved collection
point.

ACCESS

ELECTRONIC ENGINE
IMMOBILISER

Battery ref.: CR1620/3 volts.
The information "battery l at" is given

Key in ignition

A buzzer sounds on opening the dri-
ver's door, if the key has been left in
the ignition.

ton immediately for a few seconds.

 Switch off the ignition and remove

the remote control key from the
ignition lock.

The remote control is now working
again.

Locating your vehicle

Using the key
 Turn the key in the lock on the

driver's door to lock the vehicle.



Turn the key again within i ve

seconds to deadlock the vehicle.

Each action is coni rmed by i xed

lighting of the direction indicators for
approximately two seconds.

When the vehicle is locked,
if unlocking is activated inad-
vertently without a door being
opened within 30 seconds,

the vehicle will lock automatically.
The  folding  and  unfolding  of  the  ex-
terior  mirrors  can  be  deactivated  by
a PEUGEOT dealer.

To locate your vehicle, if
you have locked it, in a
car park:

 press button B , the courtesy lights

come on and the direction indica-

tors l ash for a few seconds.

Changing the remote control
battery

Reprogramming the remote
control

Following disconnection of the vehi-
cle's battery, replacement of the re-

ACCESS

   Make  a  careful  note  of  the
number  on  each  key.  The
key number is coded on the
label attached to the key.

services more difi cult in an emer-

  When  purchasing  a  second-hand
vehicle:
   -

ensure that you are given the

coni dential card;

have  the  key  codes  memo-
rised  by  a  PEUGEOT  dealer,
to ensure that the keys in your
possession  are  the  only  ones
which can start the vehicle.

Do not make any modii cations to

the electronic engine immobiliser
system.

CONFIDENTIAL CARD

This is given to you on delivery of
your vehicle with the duplicate keys.
It contains the identii cation code

necessary for any work carried out
by a PEUGEOT dealer on the elec-
tronic immobiliser system. This code

is hidden by a i lm, which should be

Do not throw the remote con-
trol batteries away, they con-
tain metals which are harmful
to the environment.

Take them to an approved collection
point.

ACCESS

   Make  a  careful  note  of  the
number  on  each  key.  The
key number is coded on the
label attached to the key.

services more difi cult in an emer-

  When  purchasing  a  second-hand
vehicle:
   -

ensure that you are given the

coni dential card;

have  the  key  codes  memo-
rised  by  a  PEUGEOT  dealer,
to ensure that the keys in your
possession  are  the  only  ones
which can start the vehicle.

Do not make any modii cations to

the electronic engine immobiliser
system.

CONFIDENTIAL CARD

This is given to you on delivery of
your vehicle with the duplicate keys.
It contains the identii cation code

necessary for any work carried out
by a PEUGEOT dealer on the elec-
tronic immobiliser system. This code

is hidden by a i lm, which should be

Do not throw the remote con-
trol batteries away, they con-
tain metals which are harmful
to the environment.

Take them to an approved collection
point.

ACCESS

ALARM

This provides two types of protection:
-

exterior protection: it sounds if
a door, the boot or the bonnet is
opened.

interior  protection:   it  sounds  if
the volume inside the passenger
compartment  changes  (breaking
of  a  window  or  a  movement  in-
side the vehicle).

 In the next ten seconds, press

button A until the indicator light is
on continuously,

 Get out of the vehicle,
 Set the alarm by locking or dead-

locking using the remote control
(button A

indicator light l ashes

once a second).

In  order  for  the  alarm  to  be  set  in
this mode, these operations must be
carried  out  each  time  the  ignition  is
switched off.

Setting the alarm

 Switch off the ignition and get out

of the vehicle.

 Set the alarm, by locking or dead-

locking using the remote control
(button A

indicator light l ashes

once per second).

  Note :  if  you  wish  to  lock  your  vehi-
cle without setting the alarm, use the
door lock.
When  the  alarm  is  triggered,  the  si-
ren  sounds  and  the  direction  indica-

tor lights l ash for thirty seconds.
After triggering, the alarm remains
set.

Disarming

Unlock  the  vehicle  with  the  remote
control  key  (button   A   indicator  light
goes out).
  Note:  if the alarm has been triggered
while you were away from your vehicle,

the rapid l ashing of the indicator light

will stop when you switch on the
ignition.

Failure of the remote control

 Unlock the doors with the key and

open the door. The alarm is trig-
gered.

 Switch on the ignition. The alarm

is disarmed.

Incorrect operation

When  the  ignition  is  switched  on,  if
button  A  lights for ten seconds, there
is a fault in the siren connection.
Contact a PEUGEOT dealer to have
the system checked.

If  the  alarm  has  been  trig-
gered  ten  times  in  succes-
sion,  on  the  eleventh  time  it
becomes inactive.

If button A

indicator light l ashes rap-

idly,  the  alarm  has  been  triggered
while  you  were  away  from  your  ve-
hicle.
45 seconds following pressing of the
locking button on the remote control,
the  alarm  is  set,  regardless  of  the
status of the doors or boot.
When  washing  your  vehicle,  to  pre-
vent triggering of the alarm:
   -

lock the doors using the key,

or
-

set the exterior alarm only

To set the alarm with exterior
protection only

If, while you are away from the vehi-
cle, you wish to leave a window par-
tially open or a pet inside the vehicle,
you should choose exterior protec-
tion only.
 Switch off the ignition,

Automatic activation *

The alarm is activated automatically
two minutes after the last closure of a
door or the boot.
In order to avoid accidental triggering
of the alarm when a door or the boot

is opened, it is essential to i rst press

the unlocking button on the remote
control.

* According to country.

ACCESS

1. Driver's electric

window switch.

2. Passenger's electric

window switch.

3. Rear right electric

window switch.

4. Rear left electric

window switch.

5. Disarming of the rear electric

window switches (child lock) .

You have two options:

   Automatic operation :
Press  or  pull  the  switch  fully      :  the
window  opens  or  closes  completely
when  the  switch  is  released.  Pres-
sing  the  switch  again  stops  the  mo-
vement of the window.
  Note:  approximately 45 seconds fol-
lowing  removal  of  the  ignition  key,
none of the windows can be opened
or closed. The ignition must be swit-
ched  on  again  to  open  or  close  the
windows.

Always remove the key from
the ignition when leaving
the vehicle, even for a short
time.

In the event of contact during opera-
tion of the windows, you must rever-
se  the  movement  of  the  window.  To
do this, press the switch concerned.
When  the  driver  operates  the  pas-
senger  electric  window  switches,  he
must  ensure  that  no  one  is  preven-
ting correct closing of the windows.
The driver must ensure that the pas-
sengers use the electric windows cor-
rectly.
Be aware of children when operating
the windows.

Reinitialisation of the
windows

Following reconnection of the battery
or in the event of a malfunction :
-

release the switch and pull it
again until it closes completely,

hold the switch for approximately
one second after closing,

press the switch to lower the win-
dow automatically,

when  the  window  has  reached
the low position, press the switch
again  for  approximately  one  se-
cond.

  The  safety  auto-reverse  function
is  not  active  during  these  opera-
tions.

   Manual operation:
Press or pull the switch gently  .
The  window  stops  as  soon  as  the
switch is released.

ELECTRIC WINDOWS

   Safety auto-reverse
When  the  window  rises  and  meets
an  obstacle,  it  stops  and  partially
lowers again.

   Disarming the rear window
controls
For the safety of your children, press
switch   5   to  prevent  operation  of  the
rear windows irrespective of their po-
sition.
When the button is pressed down, di-
sarming is active. When the button is
raised, disarming is deactivated.

  Note:
In  the  event  of  unwanted  opening
of  the  window  on  closing  (for  exam-
ple  in  the  presence  of  frost),  press
the  switch  until  it  opens  completely,
then  pull  it  immediately  until  it  clo-
ses.  Continue  to  hold  the  switch  for
approximately  one  second  after  the
window has closed.
  The safety auto-reverse function is
not active during these operations.

ACCESS

   Opening the doors from
inside
The  door  opening  control  permits
complete unlocking of the vehicle.
  Note:   the  door  opening  switches
do  not  function  when  the  vehicle  is
deadlocked.

Pressing button  A  permits locking or
unlocking of the vehicle.
The  red  warning  light  on  the  button
comes on when the vehicle is locked
and switches off when it is unlocked.
  Note:  if the vehicle is locked or dead-
locked from outside, the red warning

light l ashes and button A does not

function. In this case, use the key or
the remote control for unlocking.

THE DOORS

Opening the doors from
outside

To  partially  open  the  rear  windows,
tilt  the  lever  and  push  it  fully  to  lock
the windows in the open position.

REAR WINDOWS

Locking/Unlocking from the
inside

ACCESS

   Opening the doors from
inside
The  door  opening  control  permits
complete unlocking of the vehicle.
  Note:   the  door  opening  switches
do  not  function  when  the  vehicle  is
deadlocked.

light l ashes and button A does not

function. In this case, use the key or
the remote control for unlocking.

THE DOORS

Opening the doors from
outside

To  partially  open  the  rear  windows,
tilt  the  lever  and  push  it  fully  to  lock
the windows in the open position.

REAR WINDOWS

Locking/Unlocking from the
inside

ACCESS

   To switch on
Press and hold button  A .
Activation  of  the  function  is  accom-
panied  by  a  message  on  the  multi-
function display.

   Automatic central
locking of the doors
The  doors  can  lock  automatically
when  you  are  driving  (at  a  speed  of
more than 6 mph (10 km/h)).
Above 6 mph (10 km/h), press button
A

briel y to unlock the doors tempo-

rarily.
You can activate or deactivate this
function .

   To switch off
Press and hold button  A .
Deactivation  of  the  function  is  ac-
companied  by  a  message  on  the
multifunction display.

"Door open" alert

If a door has not been closed properly:
-

when  the  engine  is  running ,
  you are warned by a diagram and
a  message  on  the  multifunction
display for a few seconds,

when  the  vehicle  is  moving
   (speed  above  6  mph  (10  km/h)),
the  service  warning  light  comes
on.  This  is  accompanied  by  an
audible signal, a message and a
diagram on the multifunction dis-
play for a few seconds.

This prevents either of the rear doors
being opened from inside.
 Turn the switch on each rear door

a quarter of a turn using the ignition
key.

Child safety

  Notes:
   If  one  of  the  doors  is  open,  locking
from the inside and automatic central
locking are not possible.
If the boot is open, automatic central
locking of the doors is active.

ACCESS

   To switch on
Press and hold button  A .
Activation  of  the  function  is  accom-
panied  by  a  message  on  the  multi-
function display.

   Automatic central
locking of the doors
The  doors  can  lock  automatically
when  you  are  driving  (at  a  speed  of
more than 6 mph (10 km/h)).
Above 6 mph (10 km/h), press button
A

briel y to unlock the doors tempo-

rarily.
You can activate or deactivate this
function .

   To switch off
Press and hold button  A .
Deactivation  of  the  function  is  ac-
companied  by  a  message  on  the
multifunction display.

"Door open" alert

If a door has not been closed properly:
-

when  the  engine  is  running ,
  you are warned by a diagram and
a  message  on  the  multifunction
display for a few seconds,

This prevents either of the rear doors
being opened from inside.
 Turn the switch on each rear door

a quarter of a turn using the ignition
key.

Child safety

  Notes:
   If  one  of  the  doors  is  open,  locking
from the inside and automatic central
locking are not possible.
If the boot is open, automatic central
locking of the doors is active.

ACCESS

   Simultaneous locking or
unlocking of the tailgate
and the doors
The  tailgate  is  locked  or  unlocked
by  the  remote  control  or  the  driver's
door lock.
To  open,  pull  handle   A   and  lift  the
tailgate.
  Note:   the  tailgate  locks  automati-
cally  when  the  vehicle  is  being  dri-
ven at 6 mph (10 km/h), even if the
automatic  central  locking  is  deac-
tivated.  It  unlocks  when  one  of  the
doors is opened or when the central
locking button is pressed (speed be-
low 6 mph (10 km/h)).

TAILGATE

Saloon

This enables the tailgate to be un-
locked in the event of a central locking
fault.
 Fold back the rear seats to gain

access to the lock from inside the
boot.

 Insert a small screwdriver into

hole B of the lock to unlock the
tailgate.

Estate

"Tailgate open" warning
If the tailgate is not properly closed:
-

with the engine running , you
are warned by a diagram and a
message on the multifunction dis-
play for a few seconds,

when  the  vehicle  is  moving
(speed  above  6  mph  (10 km/h)),
the  service  warning  light  comes
on. It is accompanied by an audi-
ble signal, a diagram and a mes-
sage on the multi-function display
for a few seconds.

Tailgate release

ACCESS

   Notes:
After  reconnecting  the  battery,  in  the
event of a malfunction, you must reini-
tialise the safety auto-reverse:
   -

place the control in the maximum
partial opening position (3rd notch
to the right),

wait until the roof is in the maxi-
mum partially open position,

press the control for at least one
second.

In the event of unwanted opening of
the  roof  on  closing  (for  example,  in
the presence of ice), and immediate-
ly after the roof stops:
   -

move the control to the "O" posi-
tion and press the control imme-
diately,

continue to press the control until
the roof is fully closed.

  The  safety  auto-reverse  function
is  not  active  during  these  opera-
tions.

To partially open the roof: Turn
the switch to the right (three pos-
sible settings).

To open the roof completely:
Turn the switch to the left (six
possible settings).

To close it completely: Turn the
switch back to position "O" .

Safety  auto-reverse:   When  the
sunroof  is  closing  and  meets  an
obstacle,  it  stops  then  partially
opens again.

The sunroof shutter is manual.

Always  remove  the  key  from
the  ignition  when  leaving  the
vehicle, even for a short time.
In  the  event  of  contact  dur-

ing  operation  of  the  roof,  you  must
reverse the movement of the roof. To
do this, press the switch concerned.
When  the  driver  operates  the  roof
switch,  he  must  ensure  that  no  one
is  preventing  correct  closing  of  the
roof.
The driver must ensure that the pas-
sengers use the sunroof correctly.
Be aware of children when operating
the roof.

SUNROOF

ACCESS

The engine must be switched off

when i lling with fuel.


Open the fuel i ller l ap.

 Insert the key then turn it to the

left.

 Remove the cap and hang it on

the hook located on the inside of

the l ap.

A label afi xed to the inside of the fuel

i ller l ap indicates which type of fuel

to use.
When you i ll your tank, do not conti-

nue after the third cut-off of the pump.
This could cause your vehicle to mal-
function.
  The  capacity  of  the  tank  is  ap-
proximately 60 litres.
   

After i lling the tank, lock the cap

and close the fuel i ller l ap.

Low fuel level

When the minimum
fuel level in the tank is
reached, this warning
light comes on on the
instrument panel.

You can still drive approximately
30 miles (50 km).

   Operating fault
With the ignition on, if the fuel gauge
needle  remains  in  or  returns  to  the
rest position (below zero), this indica-
tes a malfunction of the fuel gauge.
Contact a PEUGEOT dealer.

FILLING WITH FUEL

1.6 litre 16V BioFlex engine

Your  BioFlex  vehicle  is  an  adapta-
ble  vehicle.  It  has  been  designed  to
run  equally  well  on  unleaded  petrol
(RON  95  or  RON  98)  or  ethanol  (in
Europe,  this  is  a  mixture  containing
85% ethanol and 15% unleaded pe-
trol, referred to as E85).
So, irrespective of the quantity of fuel
remaining  in  your  tank  and  regar-
dless  of  the  type  of  fuel  (unleaded
petrol,  E85  or  a  mixture  of  the  two),

you can i ll your tank at any time with

unleaded petrol (RON 95 or RON 98)
or ethanol E85.
This vehicle will run on unleaded pe-
trol only without experiencing any
problems.

In wintry conditions, starting
the engine from cold may so-

metimes prove difi cult. Du-

ring these very cold periods,

it is advisable to favour unleaded
petrol to guarantee optimum starting
conditions.

Peugeot 307 Dag (2007.5). Instruction - part 5
