Peugeot 207 CC Dag (2010 year). Instruction

167

* The services available depend on the network, the SIM card and the compatibility of the Bluetooth
telephone used. Check the telephone manual and with your network provider for details of the
services available to you. A list of mobile telephones with the best level of compatibility is available
from the dealer network.

BLUETOOTH TELEPHONE

CONNECTING A TELEPHONE

For reasons of safety and because they require prolong

rolonged attention

on the part of the driver, the operations for pairing the B

the Bluetooth

mobile telephone to the hands-free system of the Peugeot Connect

Navigation must be carried out with the vehicle stationary. The

ignition must be on.

Activate the telephone's Bluetooth function.
The last telephone connected is reconnected

automatically.

Enter the authentication code on the
telephone. The code to be entered is
displayed on the screen.

To change the telephone connected,
press the PHONE button, then select
Phone Menu and press the dial to

conﬁ rm.

Once the telephone has been connected, Peugeot Con

t Connect

Navigation can synchronise the address book and the c

the call list. This

synchronisation may take a few minutes * .

Select "Connect phone". Select the

telephone and press to conﬁ rm.

The list of telephones connected previously (4 maximum) appears

on the multifunction screen. Select the telephone required for a new

on the multifunction screen. Select the telephone required for a new
connection.

Press the PHONE button.

For a ﬁ rst connection, select
"Search phone" and press the dial to

conﬁ rm. Then select the name of the
telephone.

SEARCH PHONE

CONNECT PHONE

168

end the call in progress.

Select the "Yes" tab to accept or "No"

to refuse and conﬁ rm by pressing the
dial.

RECEIVING A CALL

MAKING A CALL

An incoming call is announced by a ring and a superimposed display

on the multifunction screen.

YES

To hang up, press the PHONE button
or press the dial and select "End call"

then conﬁ rm by pressing the dial.

END CALL

Press the PHONE button.

Select "Dial number", then dial the

telephone number using the virtual
keypad.

Select the "Phone" Menu function and

press the dial to conﬁ rm.

The list of the last 20 calls made and received in the vehicle appears

under "Phone" Menu. You can select a number and press the dial to

make the call.

It is also possible to select a number from the address book. You can

select "Dial from address book". The Peugeot Connect Navigation

select "Dial from address book". The Peugeot Connect Navigation
can record up to 4 000 entries.

Press the end of the steering mounted control for more than two

Press the end of the steering mounted control for more than two
seconds to gain access to the address book.

"PHONE" MENU

DIAL NUMBER

To delete a number, press the PHONE button then press and hold on

a call number to display a list of actions including:
Delete entry
Delete list

BLUETOOTH TELEPHONE

169

CONFIGURATION

SETTING THE DATE AND TIME

The SETUP function gives access to the following options: System language, Date & Time, Display
(Brightness, Colour, Map colour), Vehicle, Units, System.

Select the "Date format" function and

press the dial to conﬁ rm.

Conﬁ rm the format required using the dial.

Pressing the SET UP button for more than 2 seconds gives access

Pressing the SET UP button for more than 2 seconds gives access
to:

Conﬁ rm the format required using
the dial.

Select the "Time format" function and

press the dial to conﬁ rm.

DESCRIPTION OF THE UNIT

GPS COVERAGE

DEMO MODE

Set the parameters one by one using

the direction arrows and conﬁ rm by

means of the dial.

Select the "Set date & time" function

and press the dial to conﬁ rm.

These settings must be re-entered if the battery has been

These settings must be re-entered if the battery has been
disconnected.

Press the SET UP button.

SET DATE & TIME

Select the "Date & Time" function and

press the dial to conﬁ rm.

DATE & TIME

170

TRIP COMPUTER/VEHICLE PARAMETERS

TRIP COMPUTER

Press the MAIN button or press

the MODE button several times in

succession until the trip computer is
displayed.

- The "vehicle" tab:
The range, the current fuel

consumption and the distance

remaining.

- The "1" (trip 1) tab with:
The average speed, the average

fuel consumption and the distance
travelled calculated over route "1".

- The "2" (trip 2) tab with the same

functions for a second route.

Range: displays the distance which can travelled with the remaining

displays the distance which can travelled with the remaining

fuel detected in the tank, based on the average fuel consumption

over the last few miles (kilometres).

This displayed value may vary signiﬁ cantly following a change in the

This displayed value may vary signiﬁ cantly following a change in the
vehicle speed or the relief of the route.

When the range falls below 20 miles (30 km), dashes are displayed.

After ﬁ lling with at least 5 litres of fuel, the range is recalculated and

is displayed when it exceeds 60 miles (100 km).
If, whilst driving, dashes are displayed continuously in p

ly in place of the

digits, contact a PEUGEOT dealer.

Current fuel consumption: only calculated and display

displayed above

20 mph (30 km/h).
Average fuel consumption: this is the average fuel consumption

this is the average fuel consumption

since the last trip computer zero reset.
Distance travelled: calculated since the last trip computer zero

calculated since the last trip computer zero

reset.

Distance remaining to the destination: calculated wit

ed with reference

to the ﬁ nal destination, entered by the user. If guidance is activated,

the navigation system calculates it as a current value.
Average speed: this is the average speed calculated s

ated since the last

trip computer zero reset (ignition on).

Each press of the button at the end of the wiper stalk di

talk displays the

different trip computer information in succession, according to the

different trip computer information in succession, according to the
screen.

A FEW DEFINITIONS

171

"RADIO" MENU

MAIN FUNCTION

CHOICE A

choice A1

choice A2

CHOICE B...

SCREEN MENU MAP

"MUSIC" MENU

"TRAFFIC" MENU

MESSAGES ON ROUTE

ONLY WARNINGS ON ROUTE

ALL WARNING MESSAGES

ALL MESSAGES

GEO. FILTER

Within 2 miles (3 km)

Within 3 miles (5 km)

Within 6 miles (10 km)

Within 30 miles (50 km)

Within 60 miles (100 km)

SELECT MUSIC

SOUND SETTINGS

Balance/Fader

Bass/Treble

Equalizer

Linear

Classic

Jazz

Rock/Pop

Techno

Vocal

Loudness

Speed dependent volume

Reset sound settings

WAVEBAND

MANUAL TUNE

SOUND SETTINGS

Balance/Fader

Bass/Treble

Equalizer

Linear

Classic

Jazz

Rock/Pop

Techno

Vocal

Loudness

Speed dependent volume

Reset sound settings

172

ROUTE OPTIONS

Route type

Fast route

Short route

Optimized route

Route dynamics

Trafﬁ c independent

Semi-dynamic

Avoidance criteria

Avoid motorways

Avoid toll roads

Avoid ferries

Recalculate

STOPOVERS

Add stopover

Address input

Navigate HOME

Choose from address book

Choose from last destinations

Rearrange route

Replace stopover

Delete stopover

Recalculate

Fast route

Short route

Optimized route

"NAVIGATION" MENU

ABORT GUIDANCE/RESUME GUIDANCE

POI SEARCH

POI nearby

POI near destination

POI in city

POI in country

POI near route

SETTINGS

Navi volume

POI categories on Map

Set parameters for risk areas

Display on map

Visual alert

Sound alert

DESTINATION INPUT

Address input

Country

City

Street

House number

Start route guidance

Postal code

Save to address book

Intersection

City district

Geo position

Map

Navigate HOME

Choose from address book

Choose from last destinations

TMC station information

173

"PHONE" MENU

"SETUP" MENU

DIAL NUMBER

SETTINGS

Select ring tone

Phone/Ring tone volume

Enter mailbox number

SYSTEM LANGUAGE *

Deutsch

English

Español

Français

Italiano

Nederlands

Polski

Portuguese

DATE & TIME *

Set date & time

Date format

Time format

Dark blue

Map colour

Day mode for map

Night mode for map

Auto. Day/Night for map

VEHICLE *

Vehicle information

Alert log

Status of functions

DISPLAY

Brightness

Colour

Pop titanium

Toffee

Blue steel

Technogrey

UNITS

Temperature

Celsius

Fahrenheit

Metric/Imperial

Kilometres (Consumption: l/100)

Kilometres (Consumption: km/l)

Miles (Consumption: MPG)

SYSTEM

Factory reset

Software version

Automatic scrolling

DIAL FROM ADDRESS BOOK

CALL LISTS

CONNECT PHONE

Search phone

Phones connected

Disconnect phone

Rename phone

Delete pairing

Delete all pairings

Show details

* Available according to model.

174

sound quality between
the different audio

sources (radio, CD...).

Check that the audio settings (Volume, Bass,

Treble, Ambience, Loudness) are adapted to
the sources listened to. It is advisable to set

the AUDIO functions (Bass, Treble, Front-Rear

Balance, Left-Right Balance) to the middle

position, select the Linear musical ambience
and set the loudness correction to the "Active"

position in CD mode or to the "Inactive" position

in radio mode.

For optimum sound quality, the audio settings (Volume, Bass, Treble,

Ambience, Loudness) can be adapted to the different sound sources,

which may result in audible differences when changing source (radio,

CD...).

The CD is ejected

automatically or is not
played by the player.

- Check that the CD is inserted in the player the

right way up.

- Check the condition of the CD: the CD cannot

be played if it is too damaged.

- Check the content in the case of a recorded

CD: consult the advice in the Audio section.

- The audio equipment's CD player does not

play DVDs.

- Because of their quality level, certain writeable

CDs will not be played by the audio system.

The CD is inserted upside down, is unplayable, does not contain any audio

data or contains an audio format which the player cannot play.

The CD is protected by an anti-pirating protection system which is not

recognised by the audio equipment.

The CD player sound
is poor.

Insert good quality CDs and store them in
suitable conditions.

The CD used is scratched or of poor quality.

The audio equipment settings (bass, treble, ambiences) are unsuitable.

Set the treble or bass level to 0, without selecting

an ambience.

QUESTION

SOLUTION

ANSWER

FREQUENTLY ASKED QUESTIONS

175

SOLUTION

ANSWER

The quality of reception
of the radio station
listened to gradually
deteriorates or the
stored stations do

not function (no
sound, 87.5 Mhz is

displayed...).

The vehicle is too far from the transmitter used by the station listened to or

there is no transmitter in the geographical area through which the vehicle
is travelling.

The environment (hills, buildings, tunnels, basement car parks...) block

reception, including in RDS mode.

The aerial is absent or has been damaged (for example when going

through a car wash or into an underground car park).

Activate the RDS function to enable the system

to check whether there is a more powerful

transmitter in the geographical area.

This phenomenon is normal and does not

indicate a failure of the audio equipment.

Have the aerial checked by a PEUGEOT dealer.

Sound cut-outs of 1

to 2 seconds in radio

mode.

During this brief sound cut-out, the RDS searches for any frequency

permitting better reception of the station.

Deactivate the RDS function if the phenomenon

is too frequent and always on the same route.

With the engine off,

the audio equipment
switches off after a few

minutes of use.

When the engine is switched off, the audio equipment operating time
depends on the battery charge.

The switch-off is normal: the audio equipment switches to economy mode
and switches off to prevent discharging of the vehicle's battery.

Start the vehicle's engine to increase the battery
charge.

The stored stations do

not function (no sound,

87.5 Mhz is displayed...)

An incorrect waveband is selected.

Press the BAND AST button to return to the

waveband (AM, FM1, FM2, FMAST) on which the
stations are stored.

176

QUESTION

SOLUTION

ANSWER

The TA box is ticked.

However, certain trafﬁ c

jams along the route
are not indicated in real

time.

On starting, it is several minutes before the system begins to receive the

trafﬁ c information.

Wait until the trafﬁ c information is being received

correctly (displaying of the trafﬁ c information

symbols on the map).

In certain countries, only major routes (motorways...) are listed for the

trafﬁ c information.

The time taken to
calculate a route

sometimes seems
longer than usual.

This phenomenon is normal. The system is

dependent on the trafﬁ c information available.

The performance of the system may slow down temporarily if a CD is

being copied onto the Jukebox at the same time as a route is being
calculated.

Wait until the CD has been copied or stop the
copying before starting the guidance function.

I receive a speed

camera alert for a

camera which is not on

my route.

The system announces all speed cameras located in a conical zone

forward of the vehicle. It may detect speed cameras on nearby or parallel
roads.

Zoom the map to view the exact position of the

speed camera.

The audible speed

camera alert is not
working.

Audible alerts are not active.

The altitude is not
displayed.

On starting, the initialisation of the GPS may take up to 3 minutes to

receive more than 3 satellites correctly.

Wait until the system has started up completely.
Check that there is a GPS coverage of at least

3 satellites (long press on the SETUP button,

then select GPS coverage).

Depending on the geographical environment (tunnel...) or the weather, the

conditions of reception of the GPS signal may vary.

This phenomenon is normal. The system is
dependent on the conditions of reception of the
GPS signal.

The route is not
calculated successfully.

The exclusion criteria may conﬂ ict with the current location (exclusion of

toll roads on a motorway with tolls).

Check the exclusion criteria.

The alert volume level is set to minimum.

Activate audible alerts in Navigation Menu,

Settings, Set parameters for risk areas.
Increase the speed camera alert volume.

177

There is a long waiting

time after inserting a CD.

When a new medium is inserted, the system reads a certain amount of

data (directory, title, artist, etc.).

This may take a few seconds.

This phenomenon is normal.

I cannot connect my
Bluetooth telephone.

A telephone connected
by Bluetooth is
inaudible.

The telephone's Bluetooth function may be deactivated or the equipment

may not be visible.

The volume level depends on both the system and the telephone.

- Check that your telephone's Bluetooth function

is activated.

- Check that your telephone is visible.

Increase the Peugeot Connect Navigation volume

setting, possibly to maximum, and increase the

telephone volume level if necessary.

QUESTION

SOLUTION

ANSWER

179

Peugeot Connect Sound

CONTENTS

01 First steps

02 Steering mounted controls p.

03 Main menu

04 Audio

05 Peugeot Connect USB

06 Bluetooth

07 Conﬁ guration

08 Trip computer

09 Screen menu map

Frequently asked questions

Your Peugeot Connect Sound is coded in such a way that
it will only operate in your vehicle. If it is to be installed
in another vehicle, contact your PEUGEOT dealer for

conﬁ guration of the system.

For safety reasons, the driver must carry out operations
which require prolonged attention while the vehicle is
stationary.
When the engine is switched off and to prevent

discharging of the battery, the audio equipment may

switch off after a few minutes.

AUDIO EQUIPMENT/BLUETOOTH

t Connect Sound

Connect Sound

180

181

182

183

186

189

191

192

193

195

180

01 FIRST STEPS

1.    On/Off and volume adjustment.
2.    CD eject.
3.    Selection of the display on the screen from the following

modes:

Audio (AUDIO), Trip Computer (TRIP) and Telephone (TEL)

functions.

4. Selection of source:

radio, audio CD/MP3 CD, USB, Jack connection, Streaming.

5. Selection of FM1, FM2, FMast and AM wavebands.
6. Setting audio options: front/rear balance, left/right balance,

loudness, sound ambience.

7. Display the list of local stations, of the tracks on the CD or of

the MP3 folders.

8. Abandon current operation.
9. TA (Trafﬁ c Announcement) function on/off.

Long press: access to the PTY (Types of radio programme)

mode.

10. Conﬁ rmation.
11. Automatic search for a lower/higher frequency.

Selection of previous/next CD, MP3 or USB track.

12. Selection of a lower/higher radio frequency.

Selection of the previous/next MP3 folder.

Selection of the previous/next USB equipment folder/genre/

artist/playlist.

13. Display the general menu.
14. Buttons 1 to 6:

Selection of a stored radio station.

Long press: store a station.

15. The DARK button changes the display on the screen to

improve driving comfort at night.

1st press: lighting the upper band only.

2nd press: display of a black screen.

3rd press: return to the standard display.

181

RADIO: selection of the previous stored
station.

USB: selection of the previous genre/artist/

directory from the classiﬁ cation list.

Selection of the previous item on a menu.

RADIO: automatic search for a higher frequency.

CD/MP3/USB: selection of the next track.

CD/USB: continuous press: fast forwards play.

Selection of the previous item.

RADIO: automatic search for a lower frequency.

CD/MP3/USB: selection of the previous track.

CD/USB: continuous press: fast reverse.

Selection of the next item.

Volume increase.

Volume decrease.

STEERING MOUNTED CONTROLS

Mute: press the volume
increase and decrease

buttons simultaneously.

The sound is restored by
pressing one of the two

volume buttons.

- Change of sound source.

- Conﬁ rmation of a selection.
- Pick up/Hang up the

telephone.

- Press for more than 2 seconds:

access to the telephone menu.

RADIO: selection of the next stored station.

USB: selection of the next genre/artist/

directory from the classiﬁ cation list.

Selection of the next item on a menu.

183

04 AUDIO

Press the SOURCE button several

times in succession and select the
radio.

Press the BAND AST button to select

a waveband: FM1, FM2, FMast, AM.

Brieﬂ y press one of the buttons to

carry out an automatic search of the
radio stations.

Press one of the buttons to carry out a

manual search of the radio stations.

Press the LIST REFRESH button to
display the list of stations received

locally (30 stations maximum).

To update this list, press for more than
two seconds.

Select ACTIVATE FREQUENCY

FOLLOWING (RDS) then press OK.

RDS appears on the display.

Select the FM WAVEBAND

PREFERENCES function then

press OK.

Select AUDIO FUNCTIONS then

press OK.

Press the MENU button.

FM WAVEBAND PREFERENCES

ACTIVATE FREQUENCY FOLLOWING (RDS)

The external environment (hills, buildings, tunnels, basement car parks) may block reception, including
in RDS mode. This is a normal effect of the way in which radio waves are transmitted and does not
indicate any failure of the audio equipment.

RDS

The RDS, if displayed, enables you to continue listening to the same

station by automatic retuning to alternative frequencies. However, in

certain conditions, coverage of an RDS station may not be assured
throughout the country as radio stations do not cover 100 % of the

territory. This explains the loss of reception of the station during a journey.

RADIO

SELECTING A STATION

Peugeot 207 CC Dag (2010 year). Instruction - part 12
