Front head restraints
Height adjustment: slide the head
restraint.
The adjustment is correct when the
upper edge of the head restraint is
at the same height as the top of the
head. This adjustment avoids
excessive movement of the head
rearwards, in cases of rear impact.
Adjustment of angle*: tilt the head
restraint.
To remove the head restraint: posi-
tion it at maximum height, press the
two lugs then remove the head
restraint.
Warning: never drive with the head
restraints removed; they must be in
place and correctly adjusted.
Adjustment of front seats
Forwards/backwards adjustment:
lift control 1, slide the seat, then let go to lock.
Adjustment of seat back:
push control 2 rearwards to obtain the required angle.
Access to rear seats: (3 doors)
raise control 3 or push control 2 towards the front.
Tilt the back of the seat, then pull the seat forward.
The position of the seats is memorised*. To put them back as they were
before, you need only return them to the original position.
The storage compartment for the handbook and Warranty book is located under the
front right-hand seat*.
* According to specification
