Switching off the side lights
switches off the rear fog lamp or
returns to the front fog lamps only
position if the vehicle is fitted with
them.
Horn
Press the end of the stalk.
Dipped/main beam.
Light off.
Rear fog lamp lit.
Lights off.
Front fog lamps.
Front and rear fog lamps.
Lights off.
Side light on.
In both clear and rainy
weather, in daylight and
at night, the rear fog
lamp dazzles and is the-
refore prohibited.
Do not forget to switch it off as
soon as it is no longer needed.
LIGHTS STALK
Front lights
Selection is by turning ring A.
Changing between dipped/main
beam:
Pull the stalk fully towards you.
When your vehicle is equipped with
long range light* these operate
simultaneously with the main beam.
To flash the headlamps:
Flick the stalk towards you and
release it.
N.B.: If the lights are left on when
you switch off the engine and open
a front door, a buzzer will sound.
Direction indicators (flashers)
Left, downwards.
Right, upwards.
Fog lamps
Operation is by turning ring B. The
position is shown by the warning
lamps on the fascia.
It operates with the dipped/main
beam headlamps.
These operate with the side lights,
dipped and main beam headlamps.
These operate with the side lights,
dipped and main beam headlamps.
Rear
Front and rear
Y OU R 1 0 6 I N DETAI L
62
A
B
A
B
