54

Seats, restraints

Depending on vehicle, there is a

warning on the airbag label located on

the front passenger sun visor. Refer

to "Airbag system" for further

information 3 48.

The front passenger airbag system

can be deactivated via the settings

menu in the Driver Information Centre

3

 91.

Deactivate the front passenger airbag

system as follows:

1. Press SETq once to access the

settings menu.

2. Scroll through the menu options

using R or S until Pass bag (in

Standard version)

- or -
Passenger bag (in Multifunction

version)
is displayed.

3. Press SETq to access this menu

option.

4. Press R or S to switch from Pass

bag On to Pass bag off (Standard

version)
- or -
from Passenger bag On to

Passenger bag Off (Multifunction

version).

5. Press SETq to confirm selection.

Depending on version, a

message requesting confirmation

also appears in the display.

6. Press R or S to select Yes.
7. Press SETq briefly to confirm

deactivation and automatically

return to the previous display

screen.

Front passenger seat airbags are

deactivated and will not inflate in the

event of a collision. Control indicator

* illuminates continuously in the roof

console. A child restraint system can

be installed in accordance with the

Child restraint installation locations

tables 3 58.

Seats, restraints

55

9 Danger

Deactivate passenger airbag only

in combination with the use of a

child restraint system, subject to

the instructions and restrictions in

the table 3 58.
Otherwise, there is a risk of fatal

injury for a person occupying a

seat with a deactivated front

passenger airbag.

As long as the control indicator * is

not illuminated, the front passenger

airbag system will inflate in the event

of a collision.
If control indicators * and v are

illuminated at the same time, there is

a system failure. The status of the

system is not discernible, therefore

no person is allowed to occupy the

front passenger seat. Contact a

workshop immediately.
Change status only when the vehicle

is stopped with the ignition off. Status

remains until the next change.
Control indicator v for airbag and belt

tensioners 3 83.

Control indicator * for airbag

deactivation 3 84.
Reactivating front passenger airbag

system - see Driver Information

Centre 3 91.

Child restraints

Child restraint systems

9 Danger

If using a rear-facing child restraint

system on the front passenger

seat, the airbag system for the

front passenger seat must be

deactivated. This also applies to

certain forward-facing child

restraint systems as indicated in

the table 3 58.

Airbag deactivation 3 53.
Airbag label 3 48.
We recommend a child restraint

system which is tailored specifically to

the vehicle. For further information,

contact your workshop.
When a child restraint system is being

used, pay attention to the following

usage and installation instructions

and also those supplied with the child

restraint system.

56

Seats, restraints

Always comply with local or national

regulations. In some countries, the

use of child restraint systems is

forbidden on certain seats.
Child restraint systems can be

fastened with:

● Three-point seat belt
● ISOFIX brackets
● Top-tether

Three-point seat belt

Child restraint systems can be

fastened by using a three-point seat

belt 3 46.
Depending on the size of the used

child restraint systems and the model

variant, child restraint systems can be

attached to certain 2nd row seats

3

 58.

ISOFIX brackets

ISOFIX mounting brackets are

indicated by ISOFIX labels on the

backrest.

Fasten vehicle-approved ISOFIX

child restraint systems to the ISOFIX

mounting brackets.
When using ISOFIX mounting

brackets for seat mounting,

universally approved child restraint

systems for ISOFIX may be used.
A Top-Tether strap must be used in

addition to the ISOFIX mounting

brackets.
Permissible mounting location

positions for ISOFIX  child restraint

systems are marked in the tables by

<

, IL and IUF.

Top-tether anchors

Top-tether anchors are located on the

back of the seat.

In addition to the ISOFIX mounting

brackets, fasten the Top-tether strap

to the Top-tether anchors.
ISOFIX child restraint systems of

universal category positions are

marked in the table by IUF 3 58.

Selecting the right system

The rear seats are the most

convenient location to fasten a child

restraint system.

Seats, restraints

57

Children should travel facing

rearwards in the vehicle as long as

possible. This makes sure that the

child's backbone, which is still very

weak, is under less strain in the event

of an accident.
Suitable are restraint systems that

comply with valid UN ECE

regulations. Check local laws and

regulations for mandatory use of child

restraint systems.
Ensure that the child restraint system

to be installed is compatible with the

vehicle type.
Ensure that the mounting location of

the child restraint system within the

vehicle is correct, see following

tables.
Allow children to enter and exit the

vehicle only on the side facing away

from the traffic.
When the child restraint system is not

in use, secure the seat with a seat belt

or remove it from the vehicle.

Note

Do not affix anything on the child

restraint systems and do not cover

them with any other materials.

A child restraint system which has

been subjected to stress in an

accident must be replaced.

Child locks 3 25.

58

Seats, restraints

Child restraint installation locations

Permissible options for fitting a child restraint system

Weight and age class

Front passenger seat

Second row

Third row

activated airbag deactivated airbag outboard seat centre seat

Group 0: up to 10 kg
or approx. 10 months

X

U

1

U, <

U

X

Group 0+: up to 13 kg
or approx. two years

X

U

1

U, <

U

X

Group I: 9 to 18 kg
or approx. eight months to four years

X

U

1

U, <

U

X

Group II: 15 to 25 kg
or approx. three to seven years

X

X

U

U

X

Group III: 22 to 36 kg
or approx. six to 12 years

X

X

U

U

X

1

: When securing with a three-point seat belt, move seat to uppermost position and ensure that the seat belt runs

forwards from the upper anchorage point. Adjust seat backrest as far as necessary to a vertical position to ensure

that the belt is tight on the buckle side.

<

: Vehicle seat available with ISOFIX attachments. When attaching using ISOFIX, only the ISOFIX child restraint

systems permitted for the vehicle may be used.

U : Universal suitability in conjunction with three-point seat belt.

X : No child restraint system permitted in this weight class.

Seats, restraints

59

Permissible options for fitting an ISOFIX child restraint system

Weight class

Size class Fixture

On front

passenger seat

On outboard

seats in the

second row

On centre

seat in the

second row

On the

seats in the

third row

Group 0: up to 10 kg
or approx. 10 months

E

ISO/R1 X

IL

X

X

Group 0+: up to 13 kg
or approx. two years

E

ISO/R1 X

IL

X

X

D

ISO/R2 X

IL

X

X

C

ISO/R3 X

IL

1)

X

X

Group I: 9 to 18 kg
or approx. eight months to four years

D

ISO/R2 X

IL

X

X

C

ISO/R3 X

IL

1)

X

X

B

ISO/F2 X

IUF

X

X

B1

ISO/F2X X

IUF

X

X

A

ISO/F3 X

IUF

X

X

1)

The ISOFIX child seat can be installed by lifting the head restraint all the way up.

IL : Suitable for particular ISOFIX restraint systems of the 'specific-vehicle', 'restricted' or 'semi-universal' categories.

The ISOFIX restraint system must be approved for the specific vehicle type.

IUF : Suitable for ISOFIX forward-facing child restraint systems of universal category approved for use in this weight class.

X

: No ISOFIX child restraint system approved in this weight class.

60

Seats, restraints

ISOFIX size class and seat device

A – ISO/F3

: forward-facing child restraint system for children of maximum size in the weight class 9 to 18 kg

B – ISO/F2

: forward-facing child restraint system for smaller children in the weight class 9 to 18 kg

B1 – ISO/F2X : forward-facing child restraint system for smaller children in the weight class 9 to 18 kg

C – ISO/R3

: rear-facing child restraint system for children of maximum size in the weight class up to 18 kg

D – ISO/R2

: rear-facing child restraint system for smaller children in the weight class up to 18 kg

E – ISO/R1

: rear-facing child restraint system for young children in the weight class up to 13 kg

Storage

61

Storage

Storage compartments ................ 61

Instrument panel storage ........... 61

Glovebox ................................... 62

Cupholders ................................ 62

Front storage ............................. 62

Overhead console ..................... 62

Underseat storage ..................... 63

Load compartment ....................... 63

Rear storage .............................. 63

Load compartment cover ........... 64

Lashing eyes ............................. 66

Load compartment grille ............ 67

Roof rack system ......................... 68

Roof rack ................................... 68

Loading information ..................... 68

Storage compartments

9 Warning

Do not store heavy or sharp

objects in the storage

compartments. Otherwise vehicle

occupants could be injured by

objects being thrown around in the

event of hard braking, a sudden

change in direction or an accident.

Instrument panel storage

Storage compartments are located on

both sides of the instrument panel.

Document holder

Pull the rear of the document holder

upwards from the instrument panel

and rest in tilted position.
To fold away, lower the document

holder back into the instrument panel,

pressing down until it engages

audibly.

62

Storage

Glovebox

Pull lever to open the glovebox cover.
Depending on version, the glovebox

may be lockable using the ignition

key.
The glovebox should be closed whilst

driving.

Cupholders

Cupholders are located in the console

between the front seats.
The cupholders can also be used to

hold the portable ashtray unit 3 76.

Front storage

Storage compartments are located in

the front door pockets.
Coat hooks are located on the cabin

bulkhead (where fitted).

Overhead console

Store only lightweight items such as

paperwork or maps in the overhead

console.

Storage

63

Underseat storage

Pull the loop on the seat cushion to

gain access to the storage area.

Load compartment

Rear storage

Storage compartments are located in

the rear door pockets and in the load

compartment sidewalls.

Roof bars

Do not exceed the maximum load

(which includes the weight of the

bars) of 25 kg. Always distribute the

load evenly on the roof bars. The load

must not obstruct complete closure of

the doors.
Retighten the fastening screws on the

four brackets periodically.

Caution

Do not use elastic lashings, e.g.

bungee cord. We recommend the

use of webbing straps.

Roof bars are designed to be fitted in

a specific position. Proper fastening

of the roof bars cannot be guaranteed

if refitted in another position.

No materials (e.g. rubber, plastic)

should be placed between the feet of

the bars and the vehicle body, to

ensure proper fastening.

9 Warning

The use of roof bars may affect

steering and vehicle handling.

Removal

To remove the roof bars when not in

use:

64

Storage

1. On one side of the vehicle, rotate

handle below first roof bar

(located beneath the bracket) to

loosen, then slide handle inwards

towards centre of vehicle.

2. Repeat above step for the other

side of the vehicle.

3. Push up roof bar to release from

bracket on both sides and remove

roof bar completely.

4. Repeat above steps for the

second roof bar.

5. Unfasten screws on the four

brackets to remove the brackets

from the vehicle body.

Load compartment cover

Extendable load compartment

cover

Do not place any heavy or sharp-

edged objects on the extendable load

compartment cover.

Closing

Pull the cover towards the rear using

the handle and engage it in the

retainers at the sides.

Opening

Remove load compartment cover

from the retainers at the sides. Hold

the cover and guide it until it is fully

rolled up.

Storage

65

Removing

Open the load compartment cover.
Pull the release lever and lift cover

from retainers.

Installing

Insert either side of the load

compartment cover in the recess, pull

the release lever. Insert the load

compartment cover and engage.

Rear parcel shelf

The rear parcel shelf consists of two

parts - a front part and rear part. The

front part can be opened or closed,

allowing for greater flexibility in the

load compartment.
Do not place any excessively heavy

or sharp-edged objects on the rear

parcel shelf.

9 Warning

Always make sure that the load in

the vehicle is securely stowed.

Otherwise objects can be thrown

around inside the vehicle and

cause personal injury or damage

to the load or car.

The rear parcel shelf can be installed

in two positions, i.e. the upper

position

66

Storage

or the lower position. In the lower

position, the maximum load

permissible is 70 kg.

Removing

If the rear seats are in the folded

position, remove the parcel shelf and

store it horizontally between the back

of the front seats and the folded rear

seats.

Caution

For safety reasons, do not place

loads on the folded rear seats.

To remove, lift the front part of the

parcel shelf by releasing it from the

front retainers (1) on both sides.
Lift the rear part of the parcel shelf by

releasing it from the rear retainers (2

and 3) on both sides.

Installing

Refit the parcel shelf by engaging in

front and rear retainers on both sides.

Lashing eyes

Van

Lashing eyes are mounted in the load

compartment to enable cargo to be

secured against slippage using

lashing straps or a luggage floor net.

Combo Tour

The number and location of the

lashing eyes varies depending on the

vehicle.

Storage

67

The maximum force applied to the

lashing eyes should not exceed

500 daN/5 kN/5000 N.
Depending on country, the maximum

force may be shown on a label.

Note

Specifications on the label always

have priority over those given in this

manual.

Loading information 3 68.

Load compartment grille

Depending on version, the load

compartment area can be increased

by opening the load compartment

partition on the front passenger side

(where fitted).

● Fold down the front passenger

seat. Refer to "Seat folding"

3

 38.

● From inside the load

compartment, release the pin (1)

on the rear of the partition to

unlock, then swing open the

partition door over the folded

front passenger seat.

● Insert the pin in the slot (2) on the

backrest of the folded front

passenger seat to lock in

position.

9 Warning

The load compartment partition

must always be locked in either

position during driving. Otherwise

vehicle occupants could be injured

by the partition in the event of hard

braking, a sudden change in

direction or an accident.

Ladder bulkhead

Depending on version, a ladder

bulkhead is fixed behind the driver's

seat or behind the rear seats to

protect seat occupants from

unsecured objects in the load

compartment.

68

Storage

Roof rack system

Roof rack

For safety reasons and to avoid

damage to the roof, the vehicle

approved roof rack system is

recommended. Contact a workshop

for further information.
Follow the installation instructions

and remove the roof rack when not in

use.

Mounting roof rack

To fasten a roof rack, insert the

mounting bolts in the holes indicated

in the illustration.

Note

Roof racks are not permitted on high

roof variants (H2).
Vehicle dimensions 3 188.

Loading information

● Heavy objects in the load

compartment should be evenly

distributed and placed as far

forward as possible. If objects

can be stacked, the heavier

objects should be placed at the

bottom.

● Secure objects with lashing

straps attached to lashing eyes

3

 66.

● Secure loose objects in load

compartment to prevent them

from sliding.

● When transporting objects in the

load compartment, the backrests

of the rear seats must not be tilted

forwards or folded down.

● Do not allow the load to protrude

above the upper edge of the

backrests.

● Do not place any objects on the

extendable load compartment

cover 3 64 or the instrument

panel, and do not cover the

sensor on top of the instrument

panel 3 109.

Storage

69

● The load must not obstruct the

operation of the pedals, parking

brake and gear selector lever, or

hinder the freedom of movement

of the driver. Do not place any

unsecured objects in the interior.

● Do not drive with an open load

compartment.

9 Warning

Always make sure that the load in

the vehicle is securely stowed.

Otherwise objects can be thrown

around inside the vehicle and

cause personal injury or damage

to the load or vehicle.

● The payload is the difference

between the permitted gross

vehicle weight (see identification

plate 3 181) and the EC kerb

weight.
To calculate the payload, enter

the data for your vehicle in the

weights table at the front of this

manual.
The EC kerb weight includes

weights for the driver (68 kg),

luggage (7 kg) and all fluids (fuel

tank 90% full).
Optional equipment and

accessories increase the kerb

weight.

● Driving with a roof load increases

the sensitivity of the vehicle to

cross-winds and has a

detrimental effect on vehicle

handling due to the vehicle's

higher centre of gravity.

Distribute the load evenly and

secure it properly with retaining

straps. Adjust the tyre pressure

and vehicle speed according to

the load conditions. Check and

retighten the straps frequently.
Do not drive faster than

120 km/h.
The permissible roof load (which

includes the weight of the roof

rack) is 100 kg. The roof load is

the combined weight of the roof

rack and the load.
