Nissan Versa Note (2019 year). Instruction

After a few driving trips, the

light

should turn off if no other potential emis-
sion control system malfunction exists.
If this indicator light comes on steady for
20 seconds and then blinks for 10 seconds
when the engine is not running, it indicates
that the vehicle is not ready for an emission
control system inspection/maintenance
test. For additional information, refer to
“Readiness

for

Inspection/Maintenance

(I/M) test” in the “Technical and consumer
information” section of this manual.

Operation

The MIL will come on in one of two ways:

∙ MIL on steady — An emission control

system malfunction has been de-
tected. Check the fuel-filler cap. If the
LOOSE FUEL CAP warning message is
displayed in the odometer, and the fuel-
filler cap is loose or missing, tighten or
install the cap and continue to drive the
vehicle. The

light should turn off

after a few driving trips. If the

light

does not turn off after a few driving
trips, have the vehicle inspected. It is
recommended that you visit a NISSAN
dealer for this service. You do not need
to have your vehicle towed to the
dealer.

∙ MIL blinking — An engine misfire has

been detected which may damage the
emission control system. To reduce or
avoid emission control system dam-
age:

– do

not

drive

speeds

above

45 mph (72 km/h);

– avoid hard acceleration or decelera-

tion;

– avoid steep uphill grades;

– if possible, reduce the amount of

cargo being hauled.

The MIL may stop blinking and come on
steady. Have the vehicle inspected. It is rec-
ommended that you visit a NISSAN dealer
for this service. You do not need to have
your vehicle towed to the dealer.

CAUTION

Continued vehicle operation without
having the emission control system
checked and repaired as necessary
could lead to poor driveability, reduced
fuel economy, and possible damage to
the emission control system.

Overdrive OFF indicator

light (if so equipped)

The overdrive OFF indicator light illumi-
nates when the overdrive OFF mode is se-
lected.

For additional information, refer to “Driving
the vehicle” in the “Starting and driving” sec-
tion of this manual.

Security indicator light (if

so equipped)

For vehicles without Intelligent Key: This
light blinks whenever the ignition switch is
placed in the LOCK, OFF or ACC position.

For vehicles with Intelligent Key: This light
blinks when the ignition switch is placed in
the LOCK position with the key removed
from the ignition switch.

The blinking security indicator light indi-
cates that the security systems equipped
on the vehicle are operational.

For additional information, refer to “Security
systems” in this section.

2-22

Instruments and controls

SET indicator light (if so

equipped)

This light comes on while the vehicle speed
is controlled by the cruise control system. If
the light blinks while the engine is running,
it may indicate the cruise control system is
not functioning properly. Have the system
checked. It is recommended that you visit a
NISSAN dealer for this service.

For additional information, refer to “Cruise
control” in the “Starting and driving” section
of this manual.

Side light and headlight

indicator light (green) (if so
equipped)

The side light and headlight indicator light
illuminates when the side light or headlight
position is selected. For additional informa-
tion, refer to “Headlight and turn signal
switch” in this section.

Slip indicator light

This indicator will blink when the Vehicle
Dynamic Control (VDC) system is operat-
ing, thus alerting that the vehicle is nearing
its traction limits. The road surface may be
slippery.

Turn signal/hazard

indicator lights

The appropriate light flashes when the turn
signal switch is activated.

NOTE:

In case of a turn signal light bulb mal-
function, the turn signal will flash at a
higher frequency when the turn signal
switch is activated.

Both lights flash when the hazard switch is
turned on.

For additional information, refer to “Lights”
in the “Do-it-yourself ” section of this
manual.

Vehicle Dynamic Control

(VDC) OFF indicator light

This indicator light comes on when the
VDC OFF switch is pushed to off. This indi-
cates the VDC system is not operating.

Push the VDC OFF switch again or restart
the engine and the system will operate
normally. For additional information, refer
to “Vehicle Dynamic Control (VDC) system”
in the “Starting and driving” section of this
manual.

The VDC light also comes on when you
place the ignition switch in the ON position.
The light will turn off after about 2 seconds
if the system is operational. If the light stays
on or comes on along with the

indi-

cator light while you are driving, have the
VDC system checked. It is recommended
that you visit a NISSAN dealer for this ser-
vice.
While the VDC system is operating, you
might feel a slight vibration or hear the sys-
tem working when starting the vehicle or
accelerating, but this is normal.

AUDIBLE REMINDERS

Brake pad wear warning

The disc brake pads have audible wear
warnings. When a disc brake pad requires
replacement, it makes a high pitched
scraping sound when the vehicle is in mo-
tion, whether or not the brake pedal is de-
pressed. Have the brakes checked as soon
as possible if the warning sound is heard.

Key reminder chime

A chime sounds if the driver’s door is
opened while the key is left in the ignition
switch. Remove the key and take it with you
when leaving the vehicle.

Instruments and controls

2-23

Light reminder chime

With the ignition switch placed in the OFF
position, a chime sounds when the driver’s
door is opened if the headlights or parking
lights are on.

Turn the headlight control switch off before
leaving the vehicle.

NISSAN Intelligent Key® door
buzzer (if so equipped)

The Intelligent Key door buzzer sounds if
any one of the following improper opera-
tions is found.

∙ The ignition switch is not returned to

the LOCK position when locking the
doors.

∙ The Intelligent Key is left inside the ve-

hicle when locking the doors.

∙ The Intelligent Key is taken outside the

vehicle when operating the vehicle.

∙ Any doors are not closed securely when

locking the doors.

When the buzzer sounds, be sure to check
both the vehicle and the Intelligent Key. For
additional information, refer to “NISSAN In-
telligent Key®” in the “Pre-driving checks
and adjustments” section.

Parking brake reminder chime

A chime sounds if the parking brake is set
and the vehicle is driven. The chime will
stop if the parking brake is released or the
vehicle speed returns to zero.

Your vehicle has one type of security system:

∙ NISSAN Vehicle Immobilizer System

NISSAN VEHICLE IMMOBILIZER
SYSTEM

The NISSAN Vehicle Immobilizer System
will not allow the engine to start without
the use of a registered key.

LIC3633

SECURITY SYSTEM (if so equipped)

2-24

Instruments and controls

If the engine fails to start using a registered
key (for example, when interference is
caused by another registered key, an auto-
mated toll road device or automatic pay-
ment device on the key ring), restart the
engine using the following procedures:

1. Leave the ignition switch in the ON po-

sition for approximately 5 seconds.

2. Place the ignition switch in the OFF or

LOCK position and wait approximately
10 seconds.

3. Repeat steps 1 and 2.

4. Restart the engine while holding the

device (which may have caused the in-
terference) separate from the regis-
tered key.

If the no start condition re-occurs, NISSAN
recommends placing the registered key on
a separate key ring to avoid interference
from other devices.

Never leave these keys in the vehicle.

FCC Notice:

For USA:

This device complies with Part 15 of the
FCC Rules. Operation is subject to the fol-
lowing two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference
that may cause undesired operation.

NOTE:

Changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s author-
ity to operate the equipment.

For Canada:

This

device

complies

with

Industry

Canada licence-exempt RSS standard(s).
Operation is subject to the following two
conditions: (1) this device may not cause
interference, and (2) this device must ac-
cept any interference received, including
interference that may cause undesired
operation of the device.

Security indicator light

For vehicles without Intelligent Key: This
light blinks whenever the ignition switch is
placed in the LOCK, OFF or ACC position.

For vehicles with Intelligent Key: This light
blinks when the ignition switch is placed in
the LOCK position with the key removed
from the ignition switch.

This function indicates the NISSAN Vehicle
Immobilizer System is operational.

LIC0474

Instruments and controls

2-25

If the NISSAN Vehicle Immobilizer System is
malfunctioning, the light will remain on
while the ignition switch is placed in the ON
position.

If the light still remains on and/or the
engine will not start, seek service for the
NISSAN Vehicle Immobilizer System as
soon as possible. Please bring all regis-
tered keys that you have. It is recom-
mended that you visit a NISSAN dealer
for this service.

SWITCH OPERATION

WARNING

In freezing temperatures the washer
solution may freeze on the windshield
and obscure your vision which may lead
to an accident. Warm the windshield
with the defroster before you wash the
windshield.

CAUTION

∙ Do not operate the washer continu-

ously for more than 30 seconds.

∙ Do not operate the washer if the res-

ervoir is empty.

∙ Do not fill the windshield-washer fluid

reservoir with washer fluid concen-
trates at full strength. Some methyl
alcohol based washer fluid concen-
trates may permanently stain the
grille

spilled

while

filling

the

windshield-washer fluid reservoir.

∙ Pre-mix windshield-washer fluid con-

centrates with water to the manufac-
turer’s recommended levels before
pouring the fluid into the windshield-
washer fluid reservoir. Do not use the
windshield-washer fluid reservoir to
mix the windshield-washer fluid con-
centrate and water.

LIC3028

WIPER AND WASHER SWITCH

2-26

Instruments and controls

The windshield wiper and washer operates
when the ignition switch is in the ON posi-
tion.

Push the lever down to operate the wiper
at the following speed:

䊊

Intermittent (INT) — intermittent op-
eration

can

adjusted

(if

equipped) by turning the knob toward

䊊

(Slower) or

䊊

(Faster).

䊊

Low (LO) — continuous low speed op-
eration

䊊

High (HI) — continuous high speed op-
eration

Push the lever up

䊊

to have one sweep

operation (MIST) of the wiper.

Pull the lever toward you

䊊

to operate the

washer. The wiper will also operate several
times.

REAR SWITCH OPERATION

The rear window wiper and washer oper-
ate when the ignition switch is placed in the
ON position.

Turn the switch clockwise from the OFF
position to operate the wiper.

䊊

Intermittent (INT) – intermittent opera-
tion (not adjustable)

䊊

ON – continuous low speed operation

Push the switch forward

䊊

to operate the

washer. The wiper will also operate several
times.

WARNING

In freezing temperatures the washer
solution may freeze on the window and
obscure your vision. Warm the rear win-
dow with the defroster before you wash
the rear window.

CAUTION

∙ Do not operate the washer continu-

ously for more than 30 seconds.

∙ Do not operate the washer if the

windshield-washer fluid reservoir is
empty.

∙ Do not fill the windshield-washer fluid

reservoir

with

windshield-washer

fluid concentrates at full strength.
Some

methyl

alcohol

based

windshield-washer

fluid

concen-

trates may permanently stain the
grille

spilled

while

filling

the

windshield-washer fluid reservoir.

LIC3101

Instruments and controls

2-27

∙ Pre-mix windshield-washer fluid con-

To defrost the rear window glass and out-
side mirrors (if so equipped), start the en-
gine and push the rear window defroster
switch on. The rear window defroster indi-
cator light on the switch comes on. Push
the switch again to turn the defroster off.

The rear window defroster automatically
turns off after approximately 15 minutes.

CAUTION

When cleaning the inner side of the rear
window, be careful not to scratch or
damage the rear window defroster.

HEADLIGHT CONTROL SWITCH

Lighting

䊊

Rotate the switch to the

position,

and the front parking, tail, license plate,
and instrument panel lights will come
on.

䊊

Rotate the switch to the

position,

and the headlights will come on and all
the other lights remain on.

LIC2116

Type A (if so equipped)

LIC2127

REAR WINDOW AND OUTSIDE
MIRROR (if so equipped)
DEFROSTER SWITCH

HEADLIGHT AND TURN SIGNAL
SWITCH

2-28

Instruments and controls

CAUTION

Use the headlights with the engine run-
ning to avoid discharging the vehicle
battery.

Headlight beam select

䊊

To select the high beam function, en-
gage the headlights, then push the le-
ver forward. The high beam lights
come on and the

indicator light

illuminates (blue). For additional infor-
mation, refer to “Headlight control
switch” in this section.

䊊

Pull the lever back to return to the low
beam.

䊊

Pulling and releasing the lever flashes
the headlight high beams on and off,
the headlights need not be on for this
function.

Battery saver system

If the ignition switch is placed in the OFF
position while the headlight switch is in

the

position, the headlights

will turn off after a period of time.

CAUTION

Even though the battery saver feature
automatically turns off the headlights
after a period of time, you should turn
the headlight switch to the OFF position
when the engine is not running to avoid
discharging the vehicle battery.

DAYTIME RUNNING LIGHTS (DRL)
SYSTEM (Canada only)

The daytime running lights automatically
illuminate when the engine is started with
the parking brake released. The daytime
running lights operate with the headlight
switch in the OFF position or in the
position. Turn the headlight switch to
the

position for full illumination when

driving at night.

Type B (if so equipped)

WIC1509

LIC2128

Instruments and controls

2-29

If the parking brake is applied before the
engine is started, the daytime running
lights do not illuminate. The daytime run-
ning lights illuminate when the parking
brake is released. The daytime running
lights will remain on until the ignition switch
is placed in the OFF position or the head-
light switch is turned to the

position.

WARNING

When the daytime running light system
is active, tail lights on your vehicle are
not on. It is necessary at dusk to turn on
your headlights. Failure to do so could
cause an accident injuring yourself and
others.

INSTRUMENT BRIGHTNESS
CONTROL

The instrument brightness control oper-
ates when the vehicle is in the ON position.

Type A (if so equipped):

Press the control

䊊

to adjust the bright-

ness of instrument panel lights when driv-
ing at night.

Type B (if so equipped):

Turn the knob

䊊

left continuously for illu-

mination to decrease and turn the knob
right continuously for illumination to in-
crease.

Type A (if so equipped)

LIC2137

Type B (if so equipped)

LIC2769

2-30

Instruments and controls

TURN SIGNAL SWITCH

Turn signal

䊊

Move the lever up or down to signal the
turning direction. When the turn is
completed, the turn signal cancels au-
tomatically.

Lane change signal

䊊

Move the lever up or down until the
turn signal begins to flash, but the lever
does not latch, to signal a lane change.
Hold the lever until the lane change is
completed.
Move the lever up or down until the
turn signal begins to flash, but the lever
does not latch, and release the lever.
The turn signal will automatically flash
three times.

Choose the appropriate method to signal
a lane change based on road and traffic
conditions.

FOG LIGHT SWITCH (if so
equipped)

To turn the fog lights on, turn the headlight
switch to the

position, then turn the

fog light switch to the

position.

To turn the fog lights off, turn the fog light
switch to the OFF position.

The headlights must be on and the low
beams selected for the fog lights to oper-
ate. The fog lights automatically turn off
when the high beam headlights are se-
lected.

WIC1512

WIC1513

Instruments and controls

2-31

To sound the horn, push near the horn
icon(s) on the steering wheel.

WARNING

Do not disassemble the horn. Doing so
could affect proper operation of the
supplemental front air bag system.
Tampering with the supplemental front
air bag system may result in serious
personal injury.

WARNING

Do not use or allow occupants to use
the seat heater if you or the occupants
cannot monitor elevated seat tempera-
tures or have an inability to feel pain in
body parts in contact with the seat. Use
of the seat heater by such people could
result in serious injury.

Type A (if so equipped)

LIC2419

Type B (if so equipped)

LIC1389

LIC3037

HORN

HEATED SEAT SWITCHES (if so
equipped)

2-32

Instruments and controls

CAUTION

∙ The battery could run down if the seat

heater is operated while the engine is
not running.

∙ Do not use the seat heater for ex-

tended periods or when no one is us-
ing the seat.

∙ Do not put anything on the seat which

insulates heat, such as a blanket,
cushion or seat cover, etc. Otherwise,
the seat may become overheated.

∙ Do not place anything hard or heavy

on the seat or pierce it with a pin or
similar object. This may result in dam-
age to the heater.

∙ Any liquid spilled on the heated seat

should be removed immediately with
a dry cloth.

∙ When cleaning the seat, never use

gasoline, benzine, thinner, or any
similar materials.

∙ If any malfunctions are found or the

heated seat does not operate, turn
the switch off and have the system
checked. It is recommended that you
visit a NISSAN dealer for this service.

The front seats are warmed by built-in
heaters.

1. Start the engine.

2. Select the switch that corresponds to

the seat you wish to heat, the switches
are located on the center console.
Push the LO or HI position of the switch,
as desired. The indicator light on the
switch will illuminate.

The heater is controlled by a thermo-
stat, automatically turning the heater
on and off. The indicator light will re-
main on as long as the switch is on.

3. When the seat is warmed or before you

leave the vehicle, be sure to turn the
switch off.

The vehicle should be driven with the VDC
system on for most driving conditions.

If the vehicle is stuck in mud or snow, the
VDC system reduces the engine output to
reduce wheel spin. The engine speed will
be reduced even if the accelerator is de-
pressed to the floor. If maximum engine
power is needed to free a stuck vehicle,
turn the VDC system off.

To turn off the VDC system, push the VDC
OFF switch. The

indicator will come

on.

LIC3344

VEHICLE DYNAMIC CONTROL (VDC)
OFF SWITCH

Instruments and controls

2-33

Push the VDC OFF switch again or restart
the engine to turn on the system. For addi-
tional information, refer to “Vehicle Dy-
namic Control (VDC) system” in the “Start-
ing and driving” section of this manual.

The power outlets are for powering electri-
cal accessories such as cellular tele-
phones. The outlets are rated at 12 volt,
120W (10A) maximum.

CAUTION

∙ The outlet and plug may be hot during

or immediately after use.

∙ Only certain power outlets are de-

signed for use with a cigarette lighter
unit. Do not use any other power out-
let for an accessory lighter. It is rec-
ommended that you visit a NISSAN
dealer for additional information

∙ Do not use with accessories that ex-

ceed a 12 volt, 120W (10A) power draw.

Instrument panel

LIC3609

Console (if so equipped)

LIC3610

POWER OUTLETS

2-34

Instruments and controls

∙ Do not use double adapters or more

than one electrical accessory.

∙ Use power outlets with the engine

running to avoid discharging the ve-
hicle battery.

∙ Avoid using power outlets when the

air conditioner, headlights or rear win-
dow defroster is on.

∙ Before inserting or disconnecting a

plug, be sure the electrical accessory
being used is turned off.

∙ Push the plug in as far as it will go. If

good contact is not made, the plug
may overheat or the internal tem-
perature fuse may open.

∙ When not in use, be sure to close the

cap. Do not allow water or any other
liquid to contact the outlet.

FRONT-DOOR POCKETS

SEATBACK POCKET

The seatback pocket is located on the
back of the front passenger seat. The
pocket can be used to store maps.

LIC2157

LIC2782

STORAGE

Instruments and controls

2-35

WARNING

To ensure proper operation of the pas-
senger’s NISSAN Advanced Air Bag Sys-
tem,

please

observe

the

following

items:

∙ Do not allow a passenger in the rear

seat to push or pull on the seatback
pocket or head restraint/headrest.

∙ Do not place heavy loads heavier than

9.1 lbs. (4 kg) on the seatback, head
restraint/headrest, or in the seatback
pocket.

STORAGE TRAY

WARNING

Do not place sharp objects in the trays
to help prevent injury in an accident or
sudden stop.

GLOVE BOX

Open the glove box by pulling the handle.

Use pocket on glove box lid

䊊

to store and

hide small objects.

WARNING

Keep glove box lid closed while driving
to help prevent injury in an accident or a
sudden stop.

LIC2742

LIC3613

2-36

Instruments and controls

UPPER GLOVE BOX

Open the upper glove box by pulling the
handle.

WARNING

Keep glove box lid closed while driving
to help prevent injury in an accident or a
sudden stop.

CUP HOLDERS

WARNING

Avoid abrupt starting and braking
when the cup holder is being used to
prevent spilling the drink. If the liquid is
hot, it can scald you or your passenger.

CAUTION

Use only soft cups in the cup holder.
Hard objects can injure you in an
accident.

LIC2532

Front

LIC3611

Instruments and controls

2-37

Nissan Versa Note (2019 year). Instruction - part 7
