Nissan Versa Hatchback (2012 year). Instruction

Random:
Touch the “Random” key to apply a random play
pattern to the iPod

姞. When the random mode is

active, the

icon is displayed to the left of

the song title or album name to denote which
random pattern is applied. To cancel Random
mode, touch the “Random” key until no
icon is displayed.

Repeat:
Touch the “Repeat” key to apply a repeat play
pattern to the iPod

姞. When the repeat mode is

active, the

icon is displayed to the left of

the song title or album name to denote which
repeat pattern is applied. To cancel Repeat
mode, touch the “Repeat” key until no

icon

is displayed.

CD CARE AND CLEANING

● Handle a CD by its edges. Do not bend the

disc. Never touch the surface of the disc.

● Always place the discs in the storage case

when they are not being used.

● To clean a disc, wipe the surface from the

center to the outer edge using a clean, soft
cloth. Do not wipe the disc using a circular
motion.

● Do not use a conventional record cleaner or

alcohol intended for industrial use.

● A new disc may be rough on the inner and

outer edges. Remove the rough edges by
rubbing the inner and outer edges with the
side of a pen or pencil as illustrated.

LHA0049

4-46

Display screen, heater, air conditioner, audio and phone systems

Tuning switch

Phone operation switch

POWER on and SOURCE select
switch

Volume control switch

STEERING WHEEL SWITCH FOR
AUDIO CONTROL (if so equipped)

The audio system can be operated using the
controls on the steering wheel.

POWER on switch

With the ignition switch in the ACC or ON posi-
tion, push the POWER switch to turn the audio
system on.

SOURCE select switch (models
without Navigation System)

Push the SOURCE select switch to change the
mode in the following sequence: PRESET A

→

PRESET B

→ PRESET C → PRESET A.

With a CD inserted and an auxiliary device
plugged in, push the SOURCE select switch to
change the mode in the following sequence: CD

→ AUX → PRESET A → PRESET B → PRESET
C

→ CD.

While in one of the preset radio station banks (A,

B or C), use the tuning switch

select one of the preset radio stations (1–6).

SOURCE select switch (models with
Navigation System)

Push the SOURCE select switch to change the
audio mode in the following sequence: AM/FM

→

→ CD* → USB/AUX* → AM/FM.

* These modes are only available when compat-
ible media storage is inserted into the device.

Volume control switch

Push the volume control switch to increase or
decrease the volume.

Tuning

Memory change (radio):

While in one of the preset radio station banks (A,

B or C), push the tuning switch

for less than 1.5 seconds to change to the next
preset station in memory.

Seek tuning (radio):

Push the tuning switch

for more

than 1.5 seconds to seek the next or previous
radio station.

Next/Previous track (CD):

Push the tuning switch

for less

than 1.5 seconds to return to the beginning of the
present track or skip to the next track. Push
several times to skip back or skip through tracks.

WHA0785

Display screen, heater, air conditioner, audio and phone systems

4-47

ANTENNA

The antenna should be placed in the rearward
position

䊊

for maximum radio reception.

The antenna cannot be shortened, but can be
folded down or removed. When you need to
remove the antenna, turn the antenna rod coun-
terclockwise

䊊

To install the antenna rod, turn the antenna rod
clockwise

䊊

and hand tighten.

CAUTION

● Always properly tighten the antenna

rod during installation or the antenna
rod may break during vehicle operation.

● Be sure that the antenna is removed

before the vehicle enters an automatic
car wash.

● Be sure to fold down the antenna be-

fore the vehicle enters a garage with a
low ceiling.

When installing a CB, ham radio or car phone in
your NISSAN, be sure to observe the following
precautions; otherwise, the new equipment may
adversely affect the engine control system and
other electronic parts.

WARNING

● A cellular telephone should not be used

for any purpose while driving so full
attention may be given to vehicle op-
eration. Some jurisdictions prohibit the
use of cellular telephones while driving.

● If you must make a call while your ve-

hicle is in motion, the hands free cellu-
lar phone operational mode (if so
equipped) is highly recommended. Ex-
ercise extreme caution at all times so
full attention may be given to vehicle
operation.

● If you are unable to devote full attention

to vehicle operation while talking on
the phone, pull off the road to a safe
location and stop your vehicle.

LHA0708

CAR PHONE OR CB RADIO

4-48

Display screen, heater, air conditioner, audio and phone systems

CAUTION

● Keep the antenna as far away as pos-

sible

from

the

electronic

control

modules.

● Keep the antenna wire more than 8 in

(20 cm) away from the electronic con-
trol system harnesses. Do not route the
antenna wire next to any harness.

● Adjust the antenna standing-wave ratio

as recommended by the manufacturer.

● Connect the ground wire from the CB

radio chassis to the body.

● For details, consult a NISSAN dealer.

WARNING

● Use a phone after stopping your vehicle

in a safe location. If you have to use a
phone while driving, exercise extreme
caution at all times so full attention may
be given to vehicle operation.

● If you are unable to devote full attention

to vehicle operation while talking on
the phone, pull off the road to a safe
location and stop your vehicle.

CAUTION

To avoid discharging the vehicle battery,
use a phone after starting the engine.

BLUETOOTH

姞 HANDS-FREE PHONE

SYSTEM (if so equipped)

Display screen, heater, air conditioner, audio and phone systems

4-49

Your NISSAN is equipped with the Bluetooth

姞

Hands-Free Phone System. If you have a com-
patible Bluetooth

姞 enabled cellular phone, you

can set up the wireless connection between your
cellular phone and the in-vehicle phone module.
With Bluetooth

姞 wireless technology, you can

make or receive a hands-free telephone call with
your cellular phone in the vehicle.

Once your cellular phone is connected to the in-
vehicle phone module, no other phone connecting
procedure is required. Your phone is automatically
connected with the in-vehicle phone module when

the ignition switch is placed in the ON position with
the previously connected cellular phone turned on
and carried in the vehicle.

You can connect up to 5 different Bluetooth

姞

cellular phones to the in-vehicle phone module.
However, you can talk on only one cellular phone
at a time.

Before using the Bluetooth

姞 Hands-Free Phone

System, refer to the following notes.

● Set up the wireless connection between a

cellular phone and the in-vehicle phone
module before using the hands-free phone
system.

● Some Bluetooth姞 enabled cellular phones may

not be recognized by the in-vehicle phone mod-
ule. Please visit www.nissanusa.com/bluetooth
for a recommended phone list and connecting
instructions.

● You will not be able to use a hands-free

phone under the following conditions:

– Your vehicle is outside of the cellular ser-

vice area.

– Your vehicle is in an area where it is

difficult to receive a cellular signal; such
as in a tunnel, in an underground parking
garage, near a tall building or in a moun-
tainous area.

WHA0786

4-50

Display screen, heater, air conditioner, audio and phone systems

– Your cellular phone is locked to prevent it

from being dialed.

● When the radio wave condition is not ideal

or ambient sound is too loud, it may be
difficult to hear the other person’s voice dur-
ing a call.

● Do not place the cellular phone in an area

surrounded by metal or far away from the
in-vehicle phone module to prevent tone
quality degradation and wireless connection
disruption.

● While a cellular phone is connected through

the Bluetooth

姞 wireless connection, the bat-

tery power of the cellular phone may dis-
charge quicker than usual. The Bluetooth

姞

Hands-Free Phone System cannot charge
cellular phones.

● If the hands-free phone system seems to be

malfunctioning, see “Troubleshooting guide”
later in this section. You can also visit
www.nissanusa.com/bluetooth for trouble-
shooting help.

● Some cellular phones or other devices may

cause interference or a buzzing noise to
come from the audio system speakers. Stor-
ing the device in a different location may
reduce or eliminate the noise.

● Refer to the cellular phone Owner’s Manual

regarding the telephone charges, cellular
phone antenna and body, etc.

REGULATORY INFORMATION

FCC Regulatory information

– CAUTION: To maintain compliance with

FCC’s RF exposure guidelines, use only the
supplied antenna. Unauthorized antenna,
modification, or attachments could damage
the transmitter and may violate FCC regula-
tions.

– Operation is subject to the following two con-

ditions:

1. This device may not cause interference and

2. this device must accept any interference,

including interference that may cause unde-
sired operation of the device.

IC Regulatory information

– Operation is subject to the following two con-

ditions: (1) this device may not cause interfer-
ence, and (2) this device must accept any
interference, including interference that may
cause undesired operation of the device.

– This Class B digital apparatus meets all re-

quirements of the Canadian Interference-
Causing Equipment Regulations.

BLUETOOTH

威 is a

trademark owned by
Bluetooth SIG, Inc.
and licensed to
Visteon.

USING THE SYSTEM

The NISSAN Voice Recognition system allows
hands-free operation of the Bluetooth

姞 Phone

System.

If the vehicle is in motion, some commands may
not be available so full attention may be given to
vehicle operation.

Initialization

When the ignition switch is placed in the ON
position, NISSAN Voice Recognition is initialized,
which takes a few seconds. If the

button is

pressed before the initialization completes, the
system will announce “Hands-free phone system
not ready” and will not react to voice commands.

Display screen, heater, air conditioner, audio and phone systems

4-51

Operating tips

To get the best performance out of the NISSAN
Voice Recognition system, observe the following:

● Keep the interior of the vehicle as quiet as

possible. Close the windows to eliminate
surrounding noises (traffic noises, vibration
sounds, etc.), which may prevent the system
from recognizing voice commands correctly.

● Wait until the tone sounds before speaking a

command. Otherwise, the command will not
be received properly.

● Start speaking a command within 5 seconds

after the tone sounds.

● Speak in a natural voice without pausing

between words.

Giving voice commands

To operate NISSAN Voice Recognition, press
and release the

button located on the

steering wheel. After the tone sounds, speak a
command.

The command given is picked up by the micro-
phone, and voice feedback is given when the
command is accepted.

● If you need to hear the available commands

for the current menu again, say “Help” and
the system will repeat them.

● If a command is not recognized, the system

announces, “Command not recognized.
Please try again.” Repeat the command in a
clear voice.

● If you want to go back to the previous com-

mand, you can say “Go back” or “Correc-
tion” any time the system is waiting for a
response.

● You can cancel a command when the sys-

tem is waiting for a response by saying,
“Cancel” or “Quit.” The system announces
“Cancel” and ends the VR session. You can
also press and hold the

button on the

steering wheel for 5 seconds at any time to
end the VR session. Whenever the VR ses-
sion is cancelled, a double beep is played to
indicate you have exited the system.

● If you want to adjust the volume of the voice

feedback, press the volume control switches
(+ or -) on the steering wheel while being
provided with feedback. You can also use
the radio volume control knob.

● In most cases you can interrupt the voice

feedback to speak the next command by
pressing the

button on the steering

wheel.

● To use the system faster, you may speak the

second level commands with the main menu
command on the main menu. For example,
press the

button and after the tone

say, “Call Redial.”

NOTE:

The combined command of Call and (a
Name) cannot be used.

How to say numbers

NISSAN Voice Recognition requires a certain
way to speak numbers in voice commands. Refer
to the following rules and examples.

● Either “zero” or “oh” can be used for “0”.

Example: 1-800-662-6200

– “One eight oh oh six six two six two oh

oh”, or

– “One eight zero zero six six two six two oh

oh”

4-52

Display screen, heater, air conditioner, audio and phone systems

● Words can be used for the first 4 digits

places only.

Example: 1-800-662-6200

– “One eight hundred six six two six two oh

oh”,

– NOT “One eight hundred six six two sixty

two hundred,” and

– NOT “One eight oh oh six six two sixty two

hundred”

● Numbers can be spoken in small groups.

The system will prompt you to continue en-
tering digits, if desired.

Example: 1-800-662-6200

– “One eight zero zero”

The system repeats the numbers and
prompts you to enter more.

– “six six two”

The system repeats the numbers and
prompts you to enter more.

– “six two zero zero”

● Say “pound” for “#”. Say “star” for “*” (avail-

able when using the “Special Number” com-
mand and the “Send” command during a
call).

See “List of voice commands” and “Special
number” in this section for more information.

Example: 1-555-1212 *123

– “One five five five one two one two star

one two three”

● Say “plus” for “+” (available only when using

the “Special Number” command).

● Say “pause” for a 2-second pause (available

only when storing a phone book number).

NOTE:

For best results, say phone numbers as
single digits.

The voice command “Help” is available at any
time. Please use the “Help” command to get
information on how to use the system.

CONTROL BUTTONS

The control buttons for the Bluetooth

姞 Hands-

Free Phone System are located on the steering
wheel.

PHONE/SEND

Press the

button to initiate a

VR session or answer an incoming
call.

WHA0787

Display screen, heater, air conditioner, audio and phone systems

4-53

You can also use the

button

to interrupt the system feedback
and give a command at once. See
“List of voice commands” and
“During a call” in this section for
more information.

PHONE/END
While the voice recognition system
is active, press and hold the
button for 5 seconds to quit the
voice recognition system at any
time.

TUNING SWITCH
While using the voice recognition
system, tilt the tuning switch up or
down to manually control the
phone system.

GETTING STARTED

The following procedures will help you get
started using the Bluetooth

姞 Hands-Free Phone

System with NISSAN Voice Recognition. For ad-
ditional command options, refer to “List of voice
commands” in this section.

Choosing a language

You can interact with the Bluetooth

姞 Hands-Free

Phone System using English, Spanish or French.

To change the language, perform the following.

1. Press and hold the

button for more

than 5 seconds.

2. The

system

announces:

“Press

the

PHONE/SEND (

) button for the

hands-free phone system to enter the voice
adaptation mode or press the PHONE/END
(

) button to select a different lan-

guage.”

3. Press the

button.

For information on voice adaptation, see
“Voice adaptation (VA) mode” in this section.

4. The system announces the current language

and gives you the option to change the lan-
guage to Spanish (in Spanish) or French (in
French). To select the current language,
press the PHONE/SEND (

) button. To

select a different language, tilt the tuning

switch (

) up or down.

NOTE:

You must press the

button within 5

seconds to change the language.

5. If you decide not to change the language, do

not press either button. After 5 seconds, the
VR session will end, and the language will
not be changed.

Connecting procedure

NOTE:

The connecting procedure must be per-
formed when the vehicle is stationary. If the
vehicle starts moving during the procedure,
the procedure will be cancelled.

Main Menu

“Connect phone”

䊊

“Add phone”

䊊

Initiate from handset

䊊

Name phone

䊊

1. Press the

button on the steering

wheel. The system announces the available
commands.

2. Say: “Connect phone”

䊊

. The system ac-

knowledges the command and announces
the next set of available commands.

4-54

Display screen, heater, air conditioner, audio and phone systems

3. Say: “Add phone”

䊊

. The system acknowl-

edges the command and asks you to initiate
connecting from the phone handset

䊊

The connecting procedure of the cellular
phone varies according to each cellular
phone model. See the cellular phone Own-
er’s Manual for details. You can also visit
www.nissanusa.com/bluetooth for instruc-
tions on connecting NISSAN recommended
cellular phones.

When prompted for a Passkey code, enter
“1234” from the handset. The Passkey code
“1234” has been assigned by NISSAN and
cannot be changed.

4. The system asks you to say a name for the

phone

䊊

If the name is too long or too short, the
system tells you, then prompts you for a
name again.

Also, if more than one phone is connected
and the name sounds too much like a name
already used, the system tells you, then
prompts you for a name again.

Making a call by entering a phone
number

Main Menu

“Call”

䊊

“Phone Number”

䊊

Speak the digits

䊊

“Dial”

䊊

1. Press the

button on the steering

wheel. A tone will sound.

2. Say: “Call”

䊊

. The system acknowledges

the command and announces the next set of
available commands.

3. Say “Phone Number”

䊊

. The system ac-

knowledges the command and announces
the next set of available commands.

Say: “Special Number” to dial more than 10
digits or any special characters.

4. Say the number you wish to call starting with

the area code in single digit format

䊊

. If the

system has trouble recognizing the correct
phone number, try entering the number in
the following groups: 3-digit area code,
3-digit prefix and the last 4-digits. For ex-
ample, 555-121-3354 can be said as “five
five five” as the 1st group, then “one two
one” as the 2nd group, and “three three five

four” as the 3rd group. For dialing more than
10 digits or any special characters, say
“Special Number”. See “How to say num-
bers” in this section for more information.

5. When you have finished speaking the phone

number, the system repeats it back and an-
nounces the available commands.

6. Say: “Dial”

䊊

. The system acknowledges

the command and makes the call.

For additional command options, see “List of
voice commands” in this section.

Receiving a call

When you hear the ring tone, press the
button on the steering wheel.

Once the call has ended, press the

button

on the steering wheel.

NOTE:

If you do not wish to take the call when you
hear the ring tone, press the

button

on the steering wheel.

For additional command options, see “List of
voice commands” later in this section.

Display screen, heater, air conditioner, audio and phone systems

4-55

LIST OF VOICE COMMANDS

Main Menu

“Call”

“Phonebook”

“Recent Calls”

“Connect Phone”

When you press and release the

button on

the steering wheel, you can choose from the
commands on the Main Menu. The following
pages describe these commands and the com-
mands in each sub-menu.

Remember to wait for the tone before
speaking.

After the main menu, you can say “Help” to hear
the list of commands currently available any time
the system is waiting for a response.

If you want to end an action without completing it,
you can say “Cancel” or “Quit” at any time the
system is waiting for a response. The system will
end the VR session. Whenever the VR session is
cancelled, a double beep is played to indicate
you have exited the system.

If you want to go back to the previous command,
you can say “Go back” or “Correction” any time
the system is waiting for a response.

“Call”

Main Menu

“Call”

(Speak name)

䊊

“Phone Number”

(Speak Digits)

䊊

“Special Number”

䊊

“Redial”

䊊

“Call Back”

䊊

(Speak name)

䊊

If you have stored entries in the phonebook, you
can dial a number associated with a name and
location.

See “Phonebook” in this section to learn how to
store entries.

When prompted by the system, say the name of
the phone book entry you wish to call. The system
acknowledges the name.

If there are multiple locations associated with the
name, the system asks you to choose the loca-
tion.

Once you have confirmed the name and location,
the system begins the call.

(Speak Digits)

䊊

When prompted by the system, say the number
you wish to call. Refer to “How to say numbers”
and “Making a call by entering a phone number”
in this section for more details.

“Special Number”

䊊

For dialing more than 10 digits or any special
characters, say “Special Number”. When the
system acknowledges the command, the system
will prompt you to speak the number.

“Redial”

䊊

Use the Redial command to call the last number
that was dialed.

The system acknowledges the command, re-
peats the number and begins dialing.

If a redial number does not exist, the system
announces, “There is no number to redial” and
ends the VR session.

“Call Back”

䊊

Use the Call Back command to dial the number of
the last incoming call within the vehicle.

The system acknowledges the command, re-
peats the number and begins dialing.

4-56

Display screen, heater, air conditioner, audio and phone systems

If a call back number does not exist, the system
announces, “There is no number to call back” and
ends the VR session.

During a call

During a call there are several command options
available. Press the

button on the steering

wheel to mute the receiving voice and enter com-
mands.

● “Help” — The system announces the avail-

able commands.

● “Go back/Correction” — The system an-

nounces “Go back,” ends the VR session
and returns to the call.

● “Cancel/Quit” — The system announces

“Cancel,” ends the VR session and returns
to the call.

● “Send/Enter/Call/Dial” — Use the Send

command to enter numbers, “*” or “#” during
a call. For example, if you were directed to
dial an extension by an automated system:

Say: “Send one two three four.”

The system acknowledges the command
and sends the tones associated with the
numbers. The system then ends the VR ses-
sion and returns to the call. Say “star” for “*”,
Say “pound” for “#”.

● “Transfer call” — Use the Transfer Call com-

mand to transfer the call from the Bluetooth

姞

Hands-Free Phone System to the cellular
phone when privacy is desired.

The system announces, “Transfer call. Call
transferred to privacy mode.” The system
then ends the VR session.

To reconnect the call from the cellular phone
to the Bluetooth

姞 Hands-Free System,

press the

button.

● “Mute” — Use the Mute command to mute

your voice so the other party cannot hear it.
Use the mute command again to unmute
your voice.

NOTE:

If a call is ended or the cellular phone
network connection is lost while the Mute
feature is on, the Mute feature will be reset
to “off” for the next call so the other party
can hear your voice.

“Phonebook” (phones without
automatic phonebook download
function)

NOTE:

The “Transfer Entry” command is not avail-
able when the vehicle is moving.

Main Menu

“Phonebook”

“Transfer Entry”

䊊

“Delete Entry”

䊊

“List Names”

䊊

For phones that do not support automatic down-
load of the phonebook (PBAP Bluetooth

姞 pro-

file), the “Phonebook” command is used to manu-
ally add entries to the vehicle phonebook.

The phonebook stores up to 40 names for each
phone connected to the system.

NOTE:

Each phone has its own separate phone-
book. You cannot access Phone A’s phone-
book if you are currently connected with
Phone B.

Display screen, heater, air conditioner, audio and phone systems

4-57

“Transfer Entry”

䊊

Use the Transfer Entry command to store a new
name in the system.

When prompted by the system, say the name you
would like to give the new entry.

For example, say: “Mary.”

If the name is too long or too short, the system
tells you, then prompts you for a name again.

Also, if the name sounds too much like a name
already stored, the system tells you, then prompts
you for a name again.

The system will ask you to transfer a phone
number stored in the cellular phone’s memory.

Enter a phone number by voice command:

For example, say: “five five five one two one two.”
See “How to say numbers” in this section for
more information.

To transfer a phone number stored in the cellular
phone’s memory:

Say “Transfer entry.” The system acknowledges
the command and asks you to initiate the transfer
from the phone handset. The new contact phone
number will be transferred from the cellular
phone via the Bluetooth

姞 communication link.

The transfer procedure varies according to each
cellular phone. See the cellular phone Owner’s

Manual

for

details.

You

can

also

visit

www.nissanusa.com/bluetooth for instructions
on transferring phone numbers from NISSAN
recommended cellular phones.

The system repeats the number and prompts you
for the next command. When you have finished
entering numbers or transferring an entry, choose
“Store.”

The system confirms the name, location and
number.

“Delete Entry”

䊊

Use the Delete Entry command to erase one
entry from the phonebook. After the system rec-
ognizes the command, speak the name to delete
or say “List Names” to choose an entry.

“List Names”

䊊

Use the List Names command to hear all the
names in the phonebook.

The system recites the phonebook entries but
does not include the actual phone numbers.
When the playback of the list is complete, the
system goes back to the main menu.

You can stop the playback of the list at any time
by pressing the

button on the steering

wheel. The system ends the VR session.

“Phonebook” (phones with automatic
phonebook download function)

NOTE:

The “Transfer Entry” command is not avail-
able when the vehicle is moving.

Main Menu

“Phonebook”

Speak a Name

“List Names”

䊊

“Record Name”

䊊

For phones that support automatic download of the
phonebook (PBAP Bluetooth

姞 profile), the “Phone-

book” command is used to manage entries in the
vehicle phonebook. You can say the name of an
entry at this menu to initiate dialing of that entry.

The phonebook stores up to 1000 names for
each phone connected to the system.

When a phone is connected to the system, the
phonebook is automatically downloaded to the
vehicle. This feature allows you to access your
phonebook from the Bluetooth

姞 system and call

contacts by name. You can record a custom
voice tag for contact names that the system has
difficulty recognizing. For more information see
“Record name” in this section.

4-58

Display screen, heater, air conditioner, audio and phone systems

NOTE:

Each phone has its own separate phone-
book. You cannot access Phone A’s phone-
book if you are currently connected with
Phone B.

“List Names”

䊊

Use the List Names command to hear all the
names and locations in the phone book.

The system recites the phone book entries but
does not include the actual phone numbers.
When the playback of the list is complete, the
system goes back to the main menu.

You can stop the playback of the list at any time
by pressing the

button on the steering

wheel. The system ends the VR session. See the
“Record name” command in this section for infor-
mation about recording custom voice tags for list
entries that the system has difficulty pronounc-
ing.

“Record Name”

䊊

The system allows you to record custom voice
tags for contact names in the phonebook that the
vehicle has difficulty recognizing. This feature can
also be used to record voice tags to directly dial
an entry with multiple numbers. Up to 40 voice
tags can be recorded to the system.

“Recent Calls”

Main Menu

“Recent Calls”

“Outgoing”

䊊

“Incoming”

䊊

“Missed”

䊊

Use the Recent Calls command to access out-
going, incoming or missed calls.

“Outgoing”

䊊

Use the Outgoing command to list the outgoing
calls made from the vehicle.

“Incoming”

䊊

Use the Incoming command to list the incoming
calls made to the vehicle.

“Missed”

䊊

Use the Missed command to list the calls made to
the vehicle that were not answered.

“Connect Phone”

NOTE:

The Add Phone command is not available
when the vehicle is moving.

Main Menu

“Connect Phone”

“Add Phone”

䊊

“Select Phone”

䊊

“Delete Phone”

䊊

“Turn Bluetooth OFF”

䊊

Use the Connect Phone commands to manage
the phones connecting to the vehicle or to enable
the Bluetooth

姞 function on the vehicle.

“Add Phone”

䊊

Use the Add Phone command to add a phone to
the vehicle. See “Connecting procedure” in this
section for more information.

“Select Phone”

䊊

Use the Select Phone command to select from a
list of phones connected to the vehicle. The sys-
tem will list the names assigned to each phone
and then prompt you for the phone you wish to
select. Only one phone can be active at a time.

Display screen, heater, air conditioner, audio and phone systems

4-59

“Delete Phone”

䊊

Use the Delete Phone command to delete a
phone that is connected to the vehicle. The sys-
tem will list the names assigned to each phone
and then prompt you for the phone you wish to
delete. Deleting a phone from the vehicle will also
delete that phonebook for that phone.

“Turn Bluetooth OFF”

䊊

Use the Turn Bluetooth OFF command to prevent
a wireless connection to your phone.

VOICE ADAPTATION (VA) MODE

Voice Adaptation allows up to two out-of-dialect
users to train the system to improve recognition
accuracy. By repeating a number of commands,
the users can create a voice model of their own
voice that is stored in the system. The system is
capable of storing a different voice adaptation
model for each connected phone.

Training procedure

The procedure for training a voice is as follows.

1. Position the vehicle in a reasonably quiet

outdoor location.

2. Sit in the driver’s seat with the engine run-

ning, the parking brake on, and the transmis-
sion in P (Park).

3. Press and hold the

button for more

than 5 seconds.

4. The

system

announces:

“Press

the

PHONE/SEND (

) button for the

hands-free phone system to enter the voice
adaptation mode or press the PHONE/END
(

) button to select a different lan-

guage.”

5. Press the

button.

For information on selecting a different lan-
guage, see “Choosing a language” in this
section.

6. Voice memory A or memory B is selected

automatically. If both memory locations are
already in use, the system will prompt you to
overwrite one. Follow the instructions pro-
vided by the system.

7. When preparation is complete and you are

ready to begin, press the

button.

8. The VA mode will be explained. Follow the

instructions provided by the system.

9. When training is finished, the system will tell

you an adequate number of phrases have
been recorded.

10. The system will announce that voice adap-

tation has been completed and the system is
ready.

The VA mode will stop if:

● The

button is pressed for more than 5

seconds in VA mode.

● The vehicle begins moving during VA mode.
● The ignition switch is placed in the OFF or

LOCK position.

Training phrases

During the VA mode, the system instructs the
trainer to say the following phrases. (The system
will prompt you for each phrase.)

● phonebook transfer entry
● dial three oh four two nine
● delete call back number
● incoming
● transfer entry
● eight pause nine three two pause seven
● delete all entries
● call seven two four zero nine
● phonebook delete entry

4-60

Display screen, heater, air conditioner, audio and phone systems

● next entry
● dial star two one seven oh
● yes
● no
● select
● missed
● dial eight five six nine two
● Bluetooth on
● outgoing
● call three one nine oh two
● nine seven pause pause three oh eight
● cancel
● call back number
● call star two zero nine five
● delete phone
● dial eight three zero five one
● record name
● four three pause two nine pause zero
● delete redial number
● phonebook list names

● call eight oh five four one
● correction
● connect phone
● dial seven four oh one eight
● previous entry
● delete
● dial nine seven two six six
● call seven six three oh one
● go back
● call five six two eight zero
● dial six six four three seven

MANUAL CONTROL

While using the voice recognition system, it is
possible to select menu options by using the
steering wheel controls instead of speaking voice
commands. The manual control mode does not
allow dialing a phone number by digits. The user
may select an entry from the Phonebook or Re-
cent Calls lists. To re-activate voice recognition,
exit the manual control mode by pressing and
holding the PHONE/END (

) button. At that

time, pressing the PHONE/SEND (

) button

will start the Hands Free Phone System.

Operating tips

● To enter manual control mode, start the

voice recognition system and tilt the tuning
(

) switch up or down. The system will

speak

⬙Showing Manual Options⬙ when

manual controls are initially activated.

● To browse the menu options, tilt the tuning

(

) switch up or down. The system will

always speak the current menu option. De-
pending on the audio display, it will also
show the current menu option.

● To select the current menu option, press the

PHONE/SEND (

) button.

● To go back to the previous menu, press the

PHONE/END (

) button. If the current

menu is the Main Menu, pressing the
PHONE/END (

) button will exit the

Phone system.

● To exit the manual control mode, press and

hold the PHONE/END (

) button for 5

seconds.

Display screen, heater, air conditioner, audio and phone systems

4-61

Nissan Versa Hatchback (2012 year). Instruction - part 12
