Nissan Pathfinder Hybrid (2015 year). Instruction - part 12

CAUTION

● Be sure to carry the Intelligent Key with

you when operating the vehicle.

● Never leave the Intelligent Key in the

vehicle when you leave the vehicle.

The Intelligent Key is always communicating with
the vehicle as it receives radio waves. The Intel-
ligent Key system transmits weak radio waves.
Environmental conditions may interfere with the
operation of the Intelligent Key system under the
following operating conditions:

● When operating near a location where

strong radio waves are transmitted, such as
a TV tower, power station and broadcasting
station.

● When in possession of wireless equipment,

such as a cellular telephone, transceiver,
and CB radio.

● When the Intelligent Key is in contact with or

covered by metallic materials.

● When any type of radio wave remote control

is used nearby.

● When the Intelligent Key is placed near an

electric appliance such as a personal com-
puter.

● When the vehicle is parked near a parking

meter.

In such cases, correct the operating conditions
before using the Intelligent Key function or use
the mechanical key.

Although the life of the battery varies depending
on the operating conditions, the battery’s life is
approximately 2 years. If the battery is dis-
charged, replace it with a new one.

When the Intelligent Key battery is low, an indi-
cator illuminates in the Vehicle Information Dis-
play. For additional information, refer to “Vehicle
Information Display” in the “Instruments and con-
trols” section of this manual.

Since the Intelligent Key is continuously receiving
radio waves, if the key is left near equipment
which transmits strong radio waves, such as sig-
nals from a TV and personal computer, the bat-
tery life may become shorter.

For additional information regarding replacement
of a battery, refer to “Battery replacement” in the
“Maintenance and do-it-yourself” section of this
manual.

As many as 4 Intelligent Keys can be registered
and used with one vehicle. For information about
the purchase and use of additional Intelligent
Keys, contact a NISSAN dealer.

CAUTION

Listed below are conditions or occur-
rences which will damage the Intelligent
Key:

● Do not allow the Intelligent Key, which

contains

electrical

components,

come into contact with water or salt
water. This could affect the system
function.

● Do not drop the Intelligent Key.
● Do not strike the Intelligent Key sharply

against another object.

● Do not change or modify the Intelligent

Key.

● Wetting may damage the Intelligent

Key. If the Intelligent Key gets wet, im-
mediately wipe until it is completely dry.

● Do not place the Intelligent Key for an

extended period in an area where tem-
peratures exceed 140°F (60°C).

● Do not attach the Intelligent Key with a

key holder that contains a magnet.

● Do not place the Intelligent Key near

equipment that produces a magnetic
field, such as a TV, audio equipment and
personal computers.

3-8

Pre-driving checks and adjustments

If an Intelligent Key is lost or stolen, NISSAN
recommends erasing the ID code of that Intelli-
gent Key from the vehicle. This may prevent the
unauthorized use of the Intelligent Key to operate
the vehicle. For information regarding the erasing
procedure, contact a NISSAN dealer.

OPERATING RANGE

The Intelligent Key functions can only be used
when the Intelligent Key is within the specified
operating range from the request switch

䊊

When the Intelligent Key battery is discharged or
strong radio waves are present near the operat-
ing location, the Intelligent Key operating range
becomes narrower, and the Intelligent Key may
not function properly.

The operating range is within 31.5 in (80 cm)
from each request switch

䊊

If the Intelligent Key is too close to the door glass,
handle or rear bumper, the request switches may
not function.

When the Intelligent Key is within the operating
range, it is possible for anyone, even someone
who does not carry the Intelligent Key, to push the
request switch to lock/unlock the doors.

LPD2103

Pre-driving checks and adjustments

3-9

DOOR LOCKS/UNLOCKS
PRECAUTION

● Do not push the door handle request switch

with the Intelligent Key held in your hand as
illustrated. The close distance to the door
handle will cause the Intelligent Key system
to have difficulty recognizing that the Intelli-
gent Key is outside the vehicle.

● After locking with the door handle request

switch, verify the doors are securely locked
by testing them.

● To prevent the Intelligent Key from being left

inside the vehicle, make sure you carry the
Intelligent Key with you and then lock the
doors.

● Do not pull the door handle before pushing

the door handle request switch. The door
will be unlocked but will not open. Release
the door handle once and pull it again to
open the door.

NISSAN INTELLIGENT KEY®
OPERATION

You can lock or unlock the doors without taking
the Intelligent Key out of your pocket or bag.

When you carry the Intelligent Key with you, you
can lock or unlock all doors by pushing the door
handle request switch within the range of opera-
tion.

WPD0375

LPD2104

3-10

Pre-driving checks and adjustments

Locking doors

1. Move the shift lever to the P (Park) position,

place the ignition switch in the LOCK posi-
tion and make sure you carry the Intelligent
Key with you.

2. Close all doors.

3. Push any door handle request switch while

carrying the Intelligent Key with you.

4. All doors and the rear liftgate will lock.

5. The hazard warning lights flash twice and

the outside buzzer sounds once.

NOTE:

● Request switches for all doors and lift-

gate can be deactivated when the I-Key
Door Lock setting is switched to OFF in
the Vehicle Settings of the vehicle in-
formation display. For additional infor-
mation, refer to “Vehicle information
display” in the “Instruments and con-
trols” section of this manual.

● Doors lock with the door handle request

switch while the ignition switch is not in the
LOCK position.

● Doors do not lock by pushing the door

handle request switch while any door is
open. However, doors lock with the me-
chanical key even if any door is open.

● Doors do not lock with the door handle

request switch with the Intelligent Key inside
the vehicle and a beep sounds to warn you.
However, when an Intelligent Key is inside
the vehicle, doors can be locked with an-
other Intelligent Key.

LPD2105

LPD2106

Pre-driving checks and adjustments

3-11

CAUTION

● After locking the doors using the re-

quest switch, make sure that the doors
have been securely locked by operating
the door handles or the rear liftgate
opener switch.

● When locking the doors using the re-

quest switch, make sure to have the
Intelligent Key in your possession be-
fore operating the request switch to
prevent the Intelligent Key from being
left in the vehicle.

● The request switch is operational only

when the Intelligent Key has been de-
tected by the Intelligent Key system.

Lockout protection

To prevent the Intelligent Key from being acci-
dentally locked in the vehicle, lockout protection
is equipped with the Intelligent Key system.

When the driver’s side door is open, the doors
are locked, and then the Intelligent Key is put
inside the vehicle and all the doors are closed;
the lock will automatically unlock and the door
buzzer sounds.

NOTE:

The doors may not lock when the Intelli-
gent Key is in the same hand that is oper-
ating the request switch to lock the door.
Put the Intelligent Key in a purse, pocket or
your other hand.

CAUTION

The lockout protection may not function
under the following conditions:

● When the Intelligent Key is placed on

top of the instrument panel.

● When the Intelligent Key is placed in-

side the glove box or a storage bin.

● When the Intelligent Key is placed in-

side the door pockets.

● When the Intelligent Key is placed in-

side or near metallic materials.

3-12

Pre-driving checks and adjustments

Unlocking doors

1. Carry the Intelligent Key.

2. Push the door handle request switch.

3. The hazard warning lights flash once and the

outside buzzer sounds once.

4. Push the door handle request switch again

within 1 minute to unlock all doors.

For power liftgate opening:

1. Carry the Intelligent Key.

2. Press the power liftgate request switch.

NOTE:

Request switches for all doors and liftgate
can be deactivated when the I-Key Door Lock
setting is switched to OFF in the Vehicle
Settings of the vehicle information display.
For additional information, refer to “Vehicle
information display” in the “Instruments and
controls” section of this manual.

If a door handle is pulled while unlocking the
doors, that door may not be unlocked. Returning
the door handle to its original position will unlock
the door. If the door does not unlock after return-
ing the door handle, push the door handle re-
quest switch to unlock the door.

All doors will be locked automatically unless one
of the following operations is performed within
1 minute after pushing the request switch.

● Opening any door.
● Pushing the ignition switch.

The interior light timer illuminates for a period of
time when a door is unlocked and the room light
switch is in the DOOR position.

The interior light can be turned off without waiting
by performing one of the following operations:

● Placing the ignition switch in the ON posi-

tion.

● Locking the doors with the remote control.
● Switching the room light switch to the OFF

position.

● Switching the Auto Room Lamp to the OFF

position in Vehicle Settings of the vehicle
information display. For additional informa-
tion, refer to “Vehicle information display” in
the “Instruments and controls” section of this
manual.

LPD2105

LPD2106

Pre-driving checks and adjustments

3-13

HOW TO USE THE REMOTE
KEYLESS ENTRY FUNCTION

The remote keyless entry function can operate all
door locks using the remote keyless function of
the Intelligent Key. The remote keyless function
can operate at a distance of 33 ft (10 m) away
from the vehicle. The operating distance de-
pends upon the conditions around the vehicle.

The remote keyless entry function will not func-
tion under the following conditions:

● When the Intelligent Key is not within the

operational range.

● When the doors or the rear liftgate are open

or not closed securely.

● When the Intelligent Key battery is dis-

charged.

CAUTION

When locking the doors using the Intelli-
gent Key, be sure not to leave the key in
the vehicle.

Locking doors

1. Place the ignition switch in the LOCK posi-

tion.

2. Close all doors.

3. Press the

button on the Intelligent

Key.

4. The hazard warning lights flash twice and

the horn beeps once.

5. All doors will be locked.

CAUTION

After locking the doors using the Intelli-
gent Key, be sure that the doors have been
securely locked by operating the door
handles.

WPD0359

3-14

Pre-driving checks and adjustments

Unlocking doors

1. Press the

button on the Intelligent

Key.

2. The hazard warning lights flash once.

3. Press the

button again within 5 sec-

onds to unlock all doors.

NOTE:

The unlocking operation can be changed in
Selective door unlock in the Vehicle Set-
tings of the vehicle information display. For
additional information, refer to “Vehicle in-
formation display” in the “Instruments and
controls” section of this manual.

All doors will be locked automatically unless one
of the following operations is performed within
1 minute after pressing the

button:

● Opening any doors.
● Pushing the ignition switch.

The interior light illuminates for a period of time
when a door is unlocked and the room light
switch is in the DOOR position.

The light can be turned off without waiting by
performing one of the following operations:

● Placing the ignition switch in the ON posi-

tion.

● Locking the doors with the Intelligent Key.
● Switching the room light switch to the OFF

position.

● Switching the Auto Room Lamp to the OFF

position in Vehicle Settings of the vehicle
information display. For additional informa-
tion, refer to “Vehicle information display” in
the “Instruments and controls” section of this
manual.

Opening windows

The Intelligent Key allows you to simultaneously
open windows equipped with automatic opera-
tion.

● To open the windows, press the

but-

ton on the Intelligent Key for longer than
3 seconds after all doors are unlocked.

The door windows will open while pressing
the

button on the Intelligent Key.

The door windows cannot be closed by
using the Intelligent Key.

WPD0360

Pre-driving checks and adjustments

3-15

Releasing the rear liftgate (if so
equipped)

The rear liftgate can be opened and closed by
performing the following:

● Press the

button for longer than

0.5 seconds to open the rear liftgate.

● Press the

button again for longer than

0.5 seconds to close the rear liftgate.

When the

button is pressed during the

open or close process the liftgate will reverse.

Using the panic alarm

If you are near your vehicle and feel threatened,
you may activate the panic alarm to call attention
by pressing and holding the

button on the

Intelligent Key for longer than 0.5 seconds.

The panic alarm and headlights will stay on for a
period of time.

The panic alarm stops when:

● It has run for a period of time, or
● Any button is pressed on the Intelligent Key.
● The request switch on the driver or passen-

ger door is pushed and the Intelligent Key is
in range of the door handle.

Linking the key fob to automatic drive
positioner memory (if so equipped)

If the vehicle is equipped with automatic drive
positioner, the key fob can be linked to a memory
setting.

For additional information, refer to “Automatic
drive positioner” in this section.

WPD0414

WPD0415

3-16

Pre-driving checks and adjustments

Answer back horn feature

If desired, the answer back horn feature can be
deactivated using the Intelligent Key. When de-
activated and the LOCK

button is

pushed, the hazard indicator lights flash twice.
When the UNLOCK

button is pushed, nei-

ther the hazard indicator lights nor the horn op-
erates.

NOTE:

If you change the answer back horn and
light flash feature with the Intelligent Key,
the vehicle information display screen will
show the current mode after the ignition
switch has been cycled from the OFF to the
ON position. The vehicle information dis-
play screen can also be used to change the
answer back horn mode. For additional in-
formation, refer to “Answer back horn” in
the “Instruments and controls” section of
this manual.

To deactivate: Press and hold the
and

buttons for at least 2 seconds.

The hazard warning lights will flash 3 times to
confirm that the answer back horn feature has
been deactivated.

To activate: Press and hold the
and

buttons for at least 2 seconds once

more.

The hazard warning lights will flash once and the
horn will sound once to confirm that the horn
beep feature has been reactivated.

Deactivating the horn beep feature does not si-
lence the horn if the alarm is triggered.

WARNING SIGNALS

To help prevent the vehicle from moving unex-
pectedly by erroneous operation of the Intelligent
Key or to help prevent the vehicle from being
stolen, a chime or buzzer sounds from inside and
outside the vehicle and a warning is displayed in
the instrument panel.

When a chime or beep sounds or a warning is
displayed, be sure to check the vehicle and the
Intelligent Key.

For additional information, refer to the “Trouble-
shooting guide” in this section and “Vehicle infor-
mation display” in the “Instruments and controls”
section of this manual.

WPD0362

Pre-driving checks and adjustments

3-17

TROUBLESHOOTING GUIDE

Verify the location of all Intelligent Keys that are
programmed for the vehicle. If another Intelligent
Key is in range or inside the vehicle, the vehicle
system may respond differently than expected.

Symptom

Possible Cause

Remedy

When stopping the engine

The Shift to Park warning appears on the
display and the inside warning chime
sounds continuously.

The shift lever is not in the P (Park) position.

Move the shift lever to the P (Park) position.

When shifting the shift lever to the P (Park)
position

The Push ignition to OFF warning appears
in the display.

The ignition switch is in the ACC or ON
position.

Place the ignition switch in the OFF
position.

When opening the driver’s door to get out
of the vehicle

The Door Open warning appears on the
display and the inside warning chime
sounds continuously.

The ignition switch is in the ACC or ON
position.

Place the ignition switch in the OFF
position.

When closing the door after getting out of
the vehicle

The No Key Detected warning appears on
the display, the outside chime sounds 3
times and the inside warning chime sounds
for approximately 3 seconds.

The ignition switch is in the ACC or ON
position.

Place the ignition switch in the OFF
position.

The Shift to Park warning appears on the
display and the outside chime sounds
continuously.

The ignition switch is in the ACC position
and the shift lever is not in the P (Park)
position.

Move the shift lever to the P (Park) position
and place the ignition switch in the OFF
position.

When closing the door with the inside lock
knob turned to LOCK

The outside chime sounds for approximately
3 seconds and all the doors unlock.

The Intelligent Key is inside the vehicle.

Carry the Intelligent Key with you.

When pushing the door handle request
switch or the LOCK button on the Intelli-
gent Key to lock the door

The outside chime sounds for approximately
2 seconds.

The Intelligent Key is inside the vehicle.

Carry the Intelligent Key with you.

3-18

Pre-driving checks and adjustments

Symptom

Possible Cause

Remedy

When pushing the ignition switch to start
the engine

The Intelligent Key battery indicator appears
on the display.

The battery charge is low.

Replace the battery with a new one. For
additional information, refer to “Battery re-
placement” in the “Maintenance and do-it-
yourself” section of this manual.

The No Key Detected warning appears on
the display, the outside chime sounds 3
times and the inside warning chime sounds
for approximately 3 seconds.

The Intelligent Key is not in the vehicle.

Carry the Intelligent Key with you.

When pushing the ignition switch

The Intelligent Key system warning light in
the meter illuminates in yellow.

It warns of a malfunction with the Intelligent
Key system.

Contact a NISSAN dealer.

Pre-driving checks and adjustments

3-19

The

button will be on the NISSAN Intelli-

gent Key® if the vehicle has remote engine start.
This feature allows the engine to start from out-
side the vehicle.

The following features may be affected when the
remote start feature is used:

● Vehicles with manual or automatic climate

control systems will default to the last used
heating or cooling mode.

● Vehicles equipped with heated seats may

have this feature come on during a remote
start. For additional information, refer to
“Heated seats” in the “Instruments and con-
trols” section.

Laws in some local communities may restrict the
use of remote starters. For example, some laws
require a person using remote start to have the
vehicle in view. Check local regulations for any
requirements.

Other conditions may affect the function of the
Remote Engine Start feature. For additional infor-
mation, refer to “Conditions the remote start will
not work” in this section.

Other conditions can affect the performance of
the Intelligent Key transmitter. For additional in-
formation, refer to “NISSAN Intelligent Key®” in
this section.

REMOTE ENGINE START
OPERATING RANGE

The remote engine start function can only be
used when the Intelligent Key is within the speci-
fied operating range from the vehicle.

The remote engine start operating range is ap-
proximately 197 ft (60 m) from the vehicle.

REMOTE STARTING THE VEHICLE

To use the remote start feature to start the engine
perform the following:

1. Aim the Intelligent Key at the vehicle.

2. Press the

LOCK button to lock all doors.

3. Within 5 seconds press and hold the

remote start button until the turn signal lights
flash and the tail lamps turn on. If the vehicle
is not within view press and hold the
remote start button for at least 2 seconds.

The following events will occur when the engine
starts:

● The parking lights will turn on and remain on

as long as the engine is running.

● The doors will be locked and the climate

control system may come on.

● The engine will continue to run for 10 min-

utes. Repeat the steps to extend the time for
an additional ten minutes. For additional in-
formation, refer to “Extending engine run
time” in this section.

Depress and hold the brake then press the push-
button ignition switch to the ON position before
driving. For additional information, refer to “Driv-
ing the vehicle” in the “Starting and driving” sec-
tion of this manual.

LPD2272

REMOTE ENGINE START (if so
equipped)

3-20

Pre-driving checks and adjustments

EXTENDING ENGINE RUN TIME

The remote start feature can be extended one
time by performing the steps listed in “Remote
starting the vehicle” in this section. Run time will
be calculated as follows:

● The first 10 minute run time will start when

the remote start function is performed.

● The second 10 minutes will start immedi-

ately when the remote start function is per-
formed again. For example, if the engine has
been running for 5 minutes, and 10 minutes
are added, the engine will run for a total of
15 minutes.

● Extending engine run time will bring you to

the 2 remote start limit.

A maximum of 2 remote starts, or a single start
with an extension, are allowed between ignition
cycles.

The ignition switch must be cycled to the ON
position and then back to the OFF position be-
fore the remote start procedure can be used
again.

CANCELING A REMOTE START

To cancel a remote start, perform one of the
following:

● Aim the Intelligent Key at the vehicle and

press

until the parking lights turn off.

● Turn on the hazard warning flashers.
● Cycle the ignition switch ON and then OFF.
● The extended engine run time has expired.
● The first 10 minute timer has expired.
● The engine hood has been opened.
● The shift lever is moved out of park.
● The alarm sounds due to illegal entry into the

vehicle.

● The ignition switch is pushed without an

Intelligent Key in the vehicle.

● The ignition switch is pushed with an Intelli-

gent Key in the vehicle but the brake pedal is
not depressed.

CONDITIONS THE REMOTE START
WILL NOT WORK

The remote start will not operate if any of the
following conditions are present:

● The ignition switch is placed in the ON po-

sition.

● The hood is not securely closed.
● The hazard warning lights are on.
● The engine is still running. The engine must

be completely stopped. Wait at least 6 sec-
onds if the engine goes from running to off.
This is not applicable when extending en-
gine run time.

● The remote start button

is not pressed

and held for at least 2 seconds.

● The remote start button

is not pressed

and held within 5 seconds of pressing the
lock button.

● The brake is pressed.
● The doors are not closed and locked.
● The trunk or back door is open.
● The I–Key Indicator Light

remains

solid in the vehicle information display.

Pre-driving checks and adjustments

3-21

● The alarm sounds due to illegal entry into the

vehicle.

● Two remote vehicle starts, or a single remote

start with an extension, have already been
used.

● The vehicle is not in P (Park).
● There is a detected registered key already

inside of the vehicle.

● The Remote Start function has been

switched to the OFF position in Vehicle Set-
tings of the vehicle information display. For
additional information, refer to “Vehicle infor-
mation display” in the “Instruments and con-
trols” section of this manual.

The remote engine start may display a warning or
indicator in the vehicle information display. For
additional information and an explanation of the
warning or indicator, refer to “Vehicle information
display” in the “Instruments and controls” section
of this manual.

䊊

Pull the hood lock release handle located
below the driver side instrument panel. The
hood will spring up slightly.

䊊

Push the lever at the front of the hood to the
side as illustrated with your fingertips and
raise the hood.

When closing the hood, lower it slowly and make
sure it locks into place.

WARNING

● Make sure the hood is completely

closed and latched before driving. Fail-
ure to do so could cause the hood to fly
open and result in an accident.

● If you see steam or smoke coming from

the engine compartment, to avoid injury
do not open the hood.

LPD2107

HOOD

3-22

Pre-driving checks and adjustments

WARNING

● Always be sure the liftgate has been

closed securely to prevent it from open-
ing while driving.

● Do not drive with the liftgate open. This

could allow dangerous exhaust gases
to be drawn into the vehicle. For addi-
tional information, refer to “Exhaust
gas (carbon monoxide)” in the “Starting
and driving” section of this manual.

● Do not leave children unattended inside

the vehicle. They could unknowingly ac-
tivate switches or controls. Unattended
children could become involved in seri-
ous accidents.

● Always be sure that hands and feet are

clear of the door frame to avoid injury
while closing the liftgate.

OPERATING THE MANUAL
LIFTGATE (if so equipped)

The power door lock system allows you to lock or
unlock all doors including the liftgate simultane-
ously.

To open the liftgate, press the request switch

䊊

and pull up on the handle.

To close, lower and push the liftgate down se-
curely.

OPERATING THE POWER LIFTGATE
(if so equipped)

WARNING

● Make sure that all passengers have

their hands, etc., inside the vehicle be-
fore closing the liftgate.

● Do not leave children unattended inside

the vehicle. They could unknowingly ac-
tivate switches or controls. Unattended
children could become involved in seri-
ous accidents.

LPD2274

LIFTGATE

Pre-driving checks and adjustments

3-23

Content .. 10 11 12 13 ..
