Nissan Kicks (2018 year). Instruction

VEHICLE INFORMATION DISPLAY
WARNINGS AND INDICATORS

1. No Key Detected

2. Key Battery Low

3. I-Key

System

Error:

See

Owner’s

Manual

4. Shift to Park

5. Engine start operation (for Continu-

ously

Variable

Transmission

(CVT)

models) (if so equipped)

6. Engine start operation for Intelligent

Key system (if I-Key battery level is low)

7. Release Parking Brake

8. Low Fuel

9. Door/liftgate Open

10. Tire Pressure Low — Add Air (if so

equipped)

11. TPMS Error: See Owner’s Manual (if so

equipped)

12. Alarm - Time for a break? (if so

equipped)

13. Power will turn off to save the battery

14. Power turned off to save the battery

15. Reminder: Turn OFF Headlights

16. Headlight System Error: See Owner’s

Manual

17. Cruise control indicator (if so equipped)

18. Blind Spot Warning (BSW) indicator (if so

equipped)

19. Malfunction (if so equipped)

20. Shipping Mode On Push Storage Fuse

21. CVT Error: See Owner’s Manual (if so

equipped)

22. Steering lock release malfunction indi-

cator (if so equipped)

23. Illumination indicator

24. Transmission Shift Position indicator (if

so equipped)

25. High

Coolant

Temp:

See

Owner’s

Manual

26. Outside Temperature Display

27. Low Outside Temperature

28. Oil and Filter

29. Tire

30. Other

31. Front

Radar

Obstruction

(if

equipped)

32. Side Radar Obstruction (if so equipped)

33. Sport mode indicator (if so equipped)

No Key Detected

This warning appears when the Intelligent
Key is left outside the vehicle with the igni-
tion switch in the ON position. Make sure
the Intelligent Key is inside the vehicle.

For additional information, refer to “NISSAN
Intelligent Key®” in the “Pre-driving checks
and adjustments” section of this manual.

Key Battery Low

This indicator illuminates when the Intelli-
gent Key battery is running out of power.

If this indicator illuminates, replace the bat-
tery with a new one. For additional infor-
mation, refer to “Battery replacement” in
the “Do-it-yourself ” section of this manual.

I-Key System Error: See Owner’s Manual

After the ignition switch is pushed to the
ON position, this light comes on for a period
of time and then turns off.

2-30

Instruments and controls

The I-Key System Error message warns of
a malfunction with the Intelligent Key sys-
tem. If the light comes on while the engine
is stopped, it may be impossible to start
the engine.

If the light comes on while the engine is
running, you can drive the vehicle. However,
in these cases, have the system checked. It
is recommended that you visit a NISSAN
dealer for this service.

Shift to Park

This warning illuminates when the ignition
switch is in the OFF position and the shift
lever is not in the P (Park) position. Also, a
chime sounds when the ignition switch is
in the OFF position.

If this warning illuminates, move the shift
lever to the P (Park) position and start the
engine.

Engine start operation (for Continu-
ously Variable Transmission (CVT) mod-
els) (if so equipped)

This indicator appears when the shift lever
is in the P (Park) position.

This indicator means that the engine will
start by pushing the ignition switch with

the brake pedal depressed. You can start
the engine directly in any position of the
ignition switch.

Engine start operation for Intelligent
Key system (if I-Key battery level is low)

This indicator appears when the battery of
the Intelligent Key is low and when the In-
telligent Key system and the vehicle are not
communicating normally.

If this appears, touch the ignition switch
with the Intelligent Key while depressing
the brake pedal. For additional information,
refer to “NISSAN Intelligent Key® battery dis-
charge” in the “Starting and driving” section
of this manual.

Release Parking Brake

This warning illuminates in the message
area of the vehicle information display
when the parking brake is set and the ve-
hicle is driven.

Low Fuel

This warning illuminates when the fuel level
in the fuel tank is getting low. Refuel as
soon as it is convenient, preferably before
the fuel gauge reaches 0 (Empty). There

will be a small reserve of fuel in the tank
when the fuel gauge needle reaches 0
(Empty).

Door/liftgate Open

This warning illuminates when a door or
the liftgate has been opened.

Tire Pressure Low - Add Air (if so
equipped)

This warning appears when the low tire
pressure warning light in the meter illumi-
nates and low tire pressure is detected. The
warning appears each time the ignition
switch is placed in the ON position as long
as the low tire pressure warning light re-
mains illuminated. If this warning appears,
stop the vehicle and adjust the tire pres-
sures of all four tires to the recommended
COLD tire pressure shown on the Tire and
Loading Information label. For additional
information, refer to “Tire Pressure Monitor-
ing System (TPMS)” in the “Starting and driv-
ing” section of this manual.

TPMS Error: See Owner’s Manual (if so
equipped)

This warning appears when there is an er-
ror with your TPMS. If this warning comes

Instruments and controls

2-31

on, have the system checked. It is recom-
mended that you visit a NISSAN dealer for
this service.

Alarm - Time for a break? (if so
equipped)

This indicator appears when the driver en-
ables the Timer Alert function within the
Driving Assistance settings and the se-
lected set time is expired. The time is based
on ignition on time and can be set up to six
hours.

Power will turn off to save the battery

This message appears in the vehicle infor-
mation display after a period of time if the
ignition switch is in the ON position and if
the vehicle is in P (Park). For additional infor-
mation, refer to “Push-button ignition
switch positions” in the “Starting and driv-
ing” section of this manual.

Power turned off to save the battery

This message appears after the ignition
switch is automatically turned off. For addi-
tional information, refer to “Push-button ig-
nition switch positions” in the “Starting and
driving” section of this manual.

Reminder: Turn OFF Headlights

This warning appears when the headlights
are left in the ON position when exiting the
vehicle. Place the headlight switch in the
OFF or AUTO position. For additional infor-
mation, refer to “Headlight and turn signal
switch” in this section.

Headlight System Error: See Owner’s
Manual

This warning illuminates when there is an
error with the system. For additional infor-
mation, refer to “Headlight and turn signal
switch” in this section.

Cruise control indicator (if so equipped)

This indicator shows the cruise control sys-
tem status.

For additional information, refer to “Cruise
control” in the “Starting and driving” section
of this manual.

Blind Spot Warning (BSW) indicator (if
so equipped)

This indicator shows when the BSW system
is engaged.

For additional information, refer to “Blind
Spot Warning (BSW)” in the “Starting and
driving” section of this manual.

Malfunction (if so equipped)

This warning appears when one or more of
the following systems (if so equipped) is
not functioning properly:

∙ Automatic Emergency Braking (AEB)

∙ Blind Spot Warning (BSW)

∙ Rear Cross Traffic Alert (RCTA)

If one or more of these warning appears,
have the system checked. It is recom-
mended that you visit a NISSAN dealer for
this service.

Shipping Mode On Push Storage Fuse

This warning may appear if the extended
storage switch is not pushed in. When this
warning appears, push in the extended
storage switch to turn off the warning. For
additional information, refer to “Extended
storage switch” in this section.

CVT Error: See Owner’s Manual (if so
equipped)

This warning illuminates when there is a
problem with the CVT system. If this warn-
ing comes on, have the system checked. It
is recommended that you visit a NISSAN
dealer for this service.

2-32

Instruments and controls

Steering lock release malfunction indi-
cator (if so equipped)

This indicator appears when the steering
lock cannot be released.

If this indicator appears, push the ignition
switch while lightly turning the steering
wheel right and left.

Illumination indicator

This indicator shows the illumination ad-
justment of the instrument panel. For addi-
tional information, refer to “Instrument
brightness control” in this section.

Transmission Shift Position indicator (if
so equipped)

This indicator shows the transmission shift
position.

High Coolant Temp: See Owner’s Manual

This warning appears when the tempera-
ture of the engine coolant is too high. Stop
the vehicle in a safe location as soon as
possible. Avoid quick starting or abrupt ac-
celeration. When the warning turns off, the
vehicle can be driven.

If the warning appears again soon after it
turns off, have the vehicle checked. It is rec-
ommended that you visit a NISSAN dealer
for this service.

Outside Temperature Display

The outside temperature display appears
in the center region of the vehicle informa-
tion display.

Low Outside Temperature

This warning appears if the outside tem-
perature is below 37°F (3°C). The tempera-
ture can be changed to display in Celsius or
Fahrenheit. For additional information, re-
fer to “Settings” in this section.

Oil and Filter

This indicator appears when the customer
set distance comes for changing the en-
gine oil and filter. You can set or reset the
distance for checking or replacing these
items. For scheduled maintenance items
and intervals, refer to the “Maintenance and
schedules” section of this manual.

Tire

This indicator appears when the customer
set distance is reached for replacing tires.
You can set or reset the distance for replac-
ing tires.

WARNING

The tire replacement indicator is not a
substitute for regular tire checks, includ-
ing tire pressure checks. For additional in-
formation, refer to “Changing wheels and
tires” in the “Do-it-yourself ” section of
this manual. Many factors including tire
inflation, alignment, driving habits and
road conditions affect tire wear and when
tires should be replaced. Setting the tire
replacement indicator for a certain driv-
ing distance does not mean your tires will
last that long. Use the tire replacement
indicator as a guide only and always per-
form regular tire checks. Failure to per-
form regular tire checks, including tire
pressure checks could result in tire failure.
Serious vehicle damage could occur and
may lead to a collision, which could result
in serious personal injury or death.

Other

This indicator appears when the customer
set distance is reached for checking or re-
placing maintenance items other than the
engine oil, oil filter and tires. Other mainte-
nance items can include such things as air
filter or tire rotation. The distance for
checking or replacing the items can be set
or reset.

Instruments and controls

2-33

Front Radar Obstruction (if so
equipped)

This warning appears when there is a radar
obstruction detected. For additional infor-
mation, refer to “Automatic Emergency
Braking (AEB)” in the “Starting and driving”
section of this manual.

Side Radar Obstruction (if so equipped)

This message appears when the Blind
Spot Warning (BSW) or Rear Cross Traffic
Alert (RCTA) systems become unavailable
because a radar blockage is detected. For
additional information, refer to “Blind Spot
Warning (BSW)” or “Rear Cross Traffic Alert
(RCTA)” in the “Starting and driving” section
of this manual.

Sport mode indicator (if so equipped)

A small “S” appears to the right of the Trans-
mission Shift Position indicator in the ve-
hicle information display when the Sport
mode is engaged.

Activate the Sport mode by pressing the
switch on the shift lever while the shift lever
is in the D (Drive) position.

For additional information, refer to “Driving
the vehicle” in the “Starting and driving” sec-
tion of this manual.

Your vehicle may have three types of secu-
rity systems:

∙ Vehicle security system

∙ NISSAN Anti-Theft System

∙ NISSAN Vehicle Immobilizer System

VEHICLE SECURITY SYSTEM

The vehicle security system provides visual
and audible alarm signals if someone
opens the doors or liftgate when the sys-
tem is armed. It is not, however, a motion
detection type system that activates when
a vehicle is moved or when a vibration oc-
curs.

The system helps deter vehicle theft but
cannot prevent it, nor can it prevent the
theft of interior or exterior vehicle compo-
nents in all situations. Always secure your
vehicle even if parking for a brief period.
Never leave your keys in the vehicle, and
always lock the vehicle when unattended.
Be aware of your surroundings, and park in
secure, well-lit areas whenever possible.

Many devices offering additional protec-
tion, such as component locks, identifica-
tion markers, and tracking systems, are
available at auto supply stores and spe-
cialty shops. A NISSAN dealer may also offer
such equipment. Check with your insur-
ance company to see if you may be eligible
for discounts for various theft protection
features.

How to arm the vehicle security
system

1. Close all windows. (The system can be

armed even if the windows are open.)

2. Remove the keys from the vehicle.

3. Close all doors and liftgate. Lock all

doors. The doors can be locked with
the key fob (if so equipped), Intelligent
Key (if so equipped), door handle re-
quest switch, or mechanical key.

LIC3633

SECURITY SYSTEMS (if so equipped)

2-34

Instruments and controls

4. Confirm that the

security indica-

tor light stays on for about 30 seconds.
The vehicle security system is now pre-
armed. The vehicle security system will
automatically shift into the armed
phase. The

security light begins

to flash once every three seconds. If
during the pre-armed phase one of the
following occurs, the system will not
arm:

∙ Any door is unlocked with the key fob (if

so equipped), the Intelligent Key (if so
equipped), mechanical key, or door re-
quest switch.

∙ Ignition switch is placed in the ON posi-

tion.

∙ Even when the driver and/or passen-

gers are in the vehicle, the system will
activate with all the doors, hood and
liftgate

locked

with

the

ignition

switch placed in the LOCK position.
When placing the ignition switch in
the ON position, the system will be
released.

Vehicle security system activation

The vehicle security system will give the
following alarm:

∙ The headlights or turn lamps blink and

the horn sounds intermittently but syn-
chronously.

∙ The alarm automatically turns off after

a period of time. However, the alarm
reactivates if the vehicle is tampered
with again.

The alarm is activated by:

∙ opening any door or the liftgate without

using the key or Intelligent Key (even if
the door is unlocked by releasing the
door inside lock knob).

How to stop an activated alarm

The alarm stops only by unlocking a door
or the liftgate with the key fob (if so
equipped), pressing the

button on

the Intelligent Key (if so equipped), or push-
ing the request switch on the driver’s or
passenger’s door with the Intelligent Key (if
so equipped) in range of the door handle.

NISSAN ANTI-THEFT SYSTEM
(NATS) (if so equipped)

The NISSAN Anti-Theft System will not al-
low the engine to start without the use of a
registered NATS key.

If the engine does not start using the reg-
istered NATS key, it may be due to interfer-
ence caused by:

∙ Another NATS key

∙ Automated toll road device

∙ Automated payment device

∙ Other devices that transmit similar sig-

nals

Start the engine using the following proce-
dure:

1. Remove any items that may be causing

the interference away from the NATS
key.

2. Leave the ignition switch in the ON po-

sition for approximately 5 seconds.

3. Place the ignition switch in the OFF or

LOCK position and wait approximately
10 seconds.

4. Repeat steps 2 and 3 again.

5. Start the engine.

Instruments and controls

2-35

6. Repeat the steps above until all pos-

sible interferences are eliminated.

If this procedure allows the engine to start,
NISSAN recommends placing the regis-
tered NATS key separate from other de-
vices to avoid interference.

NISSAN VEHICLE IMMOBILIZER
SYSTEM (if so equipped)

The NISSAN Vehicle Immobilizer System
will not allow the engine to start without
the use of a registered key.

If the engine fails to start using a registered
key (for example, when interference is
caused by another registered key, an auto-
mated toll road device or automatic pay-
ment device on the key ring), restart the
engine using the following procedures:

1. Leave the ignition switch in the ON po-

sition for approximately 5 seconds.

2. Turn the ignition switch to the OFF or

LOCK position, and wait approximately
10 seconds.

3. Repeat steps 1 and 2.

4. Restart the engine while holding the

device (which may have caused the in-
terference) separate from the regis-
tered key.

If the no start condition re-occurs, NISSAN
recommends placing the registered key on
a separate key ring to avoid interference
from other devices.

FCC Notice:

For USA:

This device complies with Part 15 of the
FCC Rules. Operation is subject to the fol-
lowing two conditions; (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference
that may cause undesired operation of
the device.

NOTE:

Changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s author-
ity to operate the equipment.

For Canada:

This

device

complies

with

Industry

Canada licence-exempt RSS standard(s).
Operation is subject to the following two
conditions: (1) this device may not cause
interference, and (2) this device must ac-
cept any interference, including interfer-
ence that may cause undesired opera-
tion of the device.

2-36

Instruments and controls

Security indicator light (if so
equipped)

The security indicator light blinks whenever
the ignition switch is placed in the OFF or
LOCK position.

This function indicates the NISSAN Anti-
Theft System (NATS) is operational.

If the NATS is malfunctioning, the light will
remain on while the ignition switch is
placed in the ON position.

If the light still remains on and/or the
engine will not start, seek service for the
NATS as soon as possible. Please bring all
registered keys that you have. It is rec-
ommended that you visit a NISSAN
dealer for this service.

SWITCH OPERATION

WARNING

In freezing temperatures the washer
solution may freeze on the windshield
and obscure your vision which may lead
to an accident. Warm the windshield
with the defroster before you wash the
windshield.

LIC0474

LIC2661

WIPER AND WASHER SWITCH

Instruments and controls

2-37

CAUTION

∙ Do not operate the washer continu-

ously for more than 30 seconds.

∙ Do not operate the washer if the

windshield-washer fluid reservoir is
empty.

∙ Do not fill the windshield-washer fluid

reservoir

with

windshield-washer

fluid concentrates at full strength.
Some

methyl

alcohol

based

windshield-washer

fluid

concen-

trates may permanently stain the
grille

spilled

while

filling

the

windshield-washer fluid reservoir.

∙ Pre-mix windshield-washer fluid con-

centrates with water to the manufac-
turer’s recommended levels before
pouring the fluid into the windshield-
washer fluid reservoir. Do not use the
windshield-washer fluid reservoir to
mix the windshield-washer fluid con-
centrate and water.

NOTE:

If the windshield wiper operation is in-
terrupted by snow or ice, the wiper may
stop moving to protect its motor. If this
occurs, turn the wiper switch to the OFF
position and remove the snow or ice that
is on and around the wiper arms. In ap-
proximately 1 minute, turn the switch on
again to operate the wiper.

The windshield wiper and washer operates
when the ignition switch is in the ON posi-
tion.

Push the lever down to operate the wiper
at the following speed:

䊊

Intermittent — intermittent operation
can be adjusted by turning the knob
toward

䊊

(Faster) or

䊊

(Slower). Also,

the intermittent operation speed var-
ies in accordance with the vehicle
speed (if so equipped). (For example,
when the vehicle speed is high, the in-
termittent operation speed will be
faster.)

䊊

Low — continuous low speed opera-
tion

䊊

High — continuous high speed opera-
tion

Push the lever up

䊊

to have one sweep

operation (MIST) of the wiper.

Pull the lever toward you

䊊

to operate the

washer. The wiper will also operate several
times.

NOTE:

The Wiper with Speed feature may be
disabled. For additional information, re-
fer to “Vehicle information display” in
this section.

2-38

Instruments and controls

REAR SWITCH OPERATION

WARNING

In freezing temperatures the washer
solution may freeze on the rear window
and obscure your vision which may lead
to an accident. Warm the rear window
with the defroster before you wash the
rear window.

CAUTION

∙ Do not operate the washer continu-

ously for more than 30 seconds.

∙ Do not operate the washer if the

windshield-washer fluid reservoir is
empty.

∙ Do not fill the windshield-washer fluid

reservoir

with

windshield-washer

fluid concentrates at full strength.
Some

methyl

alcohol

based

windshield-washer

fluid

concen-

trates may permanently stain the
grille

spilled

while

filling

the

windshield-washer fluid reservoir.

∙ Pre-mix windshield-washer fluid con-

NOTE:

If the rear window wiper operation is in-
terrupted by snow, etc., the wiper may
stop moving to protect its motor. If this
occurs, turn the wiper switch to OFF and
remove the snow, etc. on and around the
wiper arms. After about 1 minute, turn
the switch on again to operate the wiper.

The rear window wiper and washer oper-
ate when the ignition switch is in the ON
position. Turn the switch clockwise from
the OFF position to operate the wiper.

䊊

Intermittent — intermittent operation
(not adjustable)

䊊

Low — continuous low speed opera-
tion

Push the switch forward

䊊

to operate the

washer. The wiper will also operate several
times.

If the windshield wipers are on and the ve-
hicle is placed in R (Reverse) the rear wiper
will automatically turn on while the vehicle
remains in R (Reverse).

LIC2662

Instruments and controls

2-39

NOTE:

The Reverse Link feature may be dis-
abled. For additional information, refer
to “Vehicle information display” in this
section.

To defrost the rear window glass (if so
equipped), start the engine and push the
rear window defroster switch on. The rear
window defroster indicator light on the
switch comes on. Push the switch again to
turn the defroster off.

To defrost the outside mirrors (if so
equipped), start the engine and push the
outside mirror defroster switch on. The
outside mirror defroster indicator light on
the switch comes on. Push the switch
again to turn the defroster off.

The rear window/outside mirror defroster
(if so equipped) automatically turns off af-
ter approximately 15 minutes.

CAUTION

When cleaning the inner side of the rear
window, be careful not to scratch or
damage the rear window defroster.

Type A (if so equipped)

LIC3600

Type B (if so equipped)

LIC3570

REAR WINDOW AND/OR OUTSIDE
MIRROR DEFROSTER SWITCH (if so
equipped)

2-40

Instruments and controls

HEADLIGHT CONTROL SWITCH

Lighting

䊊

Rotate the switch to the

position,

and the side, tail, license plate, and in-
strument panel lights will come on.

䊊

Rotate the switch to the

position,

and the headlights will come on and all
the other lights remain on.

CAUTION

Use the headlights with the engine run-
ning to avoid discharging the vehicle
battery.

Type A (if so equipped)

LIC2634

Type B (if so equipped)

LIC4008

Type C (if so equipped)

LIC4007

HEADLIGHT AND TURN SIGNAL
SWITCH

Instruments and controls

2-41

Autolight system (if so equipped)

The autolight system allows the headlights
to turn on and off automatically. The auto-
light system can:

∙ Turn on the headlights, front parking,

tail, license plate and instrument panel
lights automatically when it is dark.

∙ Turn off all the lights when it is light.

∙ Keep all the lights on for a period of time

after you place the ignition switch in the
OFF position and all doors are closed.

To turn on the autolight system:

1. Turn the headlight switch to the AUTO

position

䊊

2. Place the ignition switch in the ON po-

sition.

3. The autolight system automatically

turns the headlights on and off.

Initially, if the ignition switch is turned off
and a door is opened and left open, the
headlights remain on for a period of time. If
another door is opened while the head-
lights are on, then the timer is reset.

To turn the autolight system off, turn the

switch to the OFF,

, or

position.

NOTE:

Autolight activation sensitivity and the
time delay for autolight shutoff may be
able to be adjusted. For additional infor-
mation, refer to “Vehicle information dis-
play” in this section.

Be sure you do not put anything on top
of the autolight sensor located in the top
side

䊊

of the instrument panel. The au-

tolight sensor controls the autolight; if it
is covered, the autolight sensor reacts as
if it is dark out and the headlights will
illuminate. If this occurs while parked
with the engine off and the ignition
switch placed in the ON position, your
vehicle’s battery could become dis-
charged.

LIC2636

LIC4006

2-42

Instruments and controls

Headlight beam select

䊊

To select the high beam function, push
the lever forward while the low beams
are on. The high beam lights come on
and the

indicator light illumi-

nates.

䊊

Pull the lever back to return to the low
beam.

䊊

Pulling and releasing the lever flashes
the headlight high beams on and off.
The low beams do not need to be on
for this to function.

Battery saver system

The battery saver system automatically
turns off the ignition after a period of time
when the ignition switch is left in the ON
position.

The battery saver system automatically
turns off the following lights after a period
of time when the ignition switch is placed in
the OFF position:

∙ Headlights, when the headlight switch

is in the

position

∙ Interior lights, when left in the ON posi-

tion

CAUTION

Even though the battery saver feature
automatically turns off the headlights
after a period of time, you should turn
the headlight switch to the OFF position
when the engine is not running to avoid
discharging the vehicle battery.

DAYTIME RUNNING LIGHTS (DRL)
SYSTEM (if so equipped)

The Daytime Running Lights (DRL) portion
of the fog light assembly automatically illu-
minates when the engine is started with
the parking brake released. The DRL oper-
ate with the headlight switch in the OFF
position. Turn the headlight switch to
the

position for full illumination when

driving at night. (The DRL will turn off.)
If the parking brake is applied before the
engine is started, the DRL do not illuminate.
The DRL illuminate once the parking brake
is released. The DRL will remain on until the
ignition switch is placed in the OFF position.

It is necessary at dusk to turn the headlight
switch on for interior controls and switches
to illuminate, as those remain off while the
switch is in the OFF position.

WARNING

When the DRL system is active, tail
lights on your vehicle are not on. It is
necessary at dusk to turn on your head-
lights. Failure to do so could cause an
accident injuring yourself and others.

LIC2637

Instruments and controls

2-43

INSTRUMENT BRIGHTNESS
CONTROL

Turn the control knob

䊊

to adjust the

brightness of instrument panel lights.

TURN SIGNAL SWITCH

Turn signal

䊊

Move the lever up or down to signal the
turning direction. When the turn is
completed, the turn signal cancels au-
tomatically.

Lane change signal

䊊

To signal a lane change, move the lever
up or down until the turn signal begins
to flash, but the lever does not latch.

The turn signal will automatically flash
three times.

NOTE:

The 3 flash pass lane change signal may
be able to be disabled. For additional in-
formation, refer to “Vehicle information
display” in this section.

LIC3579

LIC2638

2-44

Instruments and controls

FOG LIGHT SWITCH (if so
equipped)

To turn the fog lights on, turn the headlight

switch to the

position, then

turn the fog light switch to the

posi-

tion.
To turn the fog lights on with the headlight
switch in the AUTO position, the headlights
must be on, then turn the fog light switch to
the

position.

To turn the fog lights off, turn the fog light
switch to the OFF position.

To sound the horn, push near the horn icon
on the steering wheel.

WARNING

Do not disassemble the horn. Doing so
could affect proper operation of the
supplemental front air bag system.
Tampering with the supplemental front
air bag system may result in serious
personal injury.

WARNING

Do not use or allow occupants to use
the seat heater if you or the occupants
cannot monitor elevated seat tempera-
tures or have an inability to feel pain in
body parts that contact the seat. Use of
the seat heater by such people could
result in serious injury.

LIC2639

LIC3568

LIC3973

HORN

HEATED SEAT SWITCHES (if so
equipped)

Instruments and controls

2-45

Nissan Kicks (2018 year). Instruction - part 8
