Nissan Juke (2017 year). Instruction

Recent Calls:

The following commands are available under
“Recent Calls”:
. Incoming (Calls)

Speak this command to list the last five
incoming calls to the vehicle. If the call is
from an entry in the phonebook, the name
will be displayed. Otherwise, the phone
number of the incoming call will be dis-
played.
Say “Dial” to call the number or “Send Text”
to send a text message to that number. Say
“Next Entry” or “Previous Entry” to move
through the list of incoming calls.

. Missed (Calls)

Speak this command to list the last five
missed calls to the vehicle. If the call is from
an entry in the phonebook, the name will be
displayed. Otherwise, the phone number of
the missed call will be displayed.
Say “Dial” to call the number or “Send Text”
to send a text message to that number. Say
“Next Entry” or “Previous Entry” to move
through the list of missed calls.

. Outgoing (Calls)

Speak this command to list the last five
outgoing calls from the vehicle. If the call
was to an entry in the phonebook, the name
will be displayed. Otherwise, the phone

number of the outgoing call will be dis-
played.
Say “Dial” to call the number or “Send Text”
to send a text message to that number. Say
“Next Entry” or “Previous Entry” to move
through the list of outgoing calls.

. Redial

Speak this command to call the last number
dialed.

. Call Back

Speak this command to call the number of
the last incoming call to the vehicle.

Show Applications:

Select this command to display list of smart-
phone apps available.

Messaging:

Speak this command to access text messaging
functions. For more information on these com-
mands, see “Text messaging” (P.4-86).

Select Phone:

Speak this command to select a phone to use
from a list of those phones connected to the
vehicle.

Making a call

To make a call from a phone connected to the
vehicle’s Bluetooth

Hands-Free Phone Sys-

tem:

1. Push the

button.

2. The system will prompt you for a command.

Say “Call”.

3. Select one of the available voice commands

to continue:

(A Name)

Speak the name of a phonebook entry to
place a call to that entry. The system will
respond with the name it interpreted from
your command and will prompt you to
confirm that the name is correct. Say
“Yes” to initiate the call or “No” to hear
another name from the phonebook.

List Names

Select this command to call a phone
number that is stored in the phonebook.

Phone Number

Speak this command to place a call by
inputting numbers.

For 7- and 10-digit phone numbers,
speak the numbers. When finished, say
“Dial” to initiate the call. Say “Correction”
at any time in the process to correct a
misspoken or misinterpreted number.

For phone numbers with more digits or
special characters, say “Special Num-

Heater, air conditioner, audio and phone systems

4-85

4-86

Heater, air conditioner, audio and phone systems

ber”, then speak the digits. Up to 24
digits can be entered. Available special
characters are “star”, “pound”, “plus” and
“pause”. When finished, say “Dial” to
initiate the call. Say “Correction” at any
time in the process to correct a mis-
spoken or misinterpreted number or
character.

Redial

Speak this command to dial the number
of the last outgoing call. The system will
display “Redialing (name/number)”. The
name of the phonebook entry will be
displayed if it available, otherwise the
number being redialed will be displayed.

Call Back

Speak this command to dial the number
of the last incoming call. The system will
display “Calling back (name/number)” .
The name of the phonebook entry will be
displayed if it available, otherwise the
number being called back will be dis-
played.

Receiving a call

When a call is received by the phone connected
to the vehicle’s Bluetooth

Hands-Free Phone

System, the call information is displayed on
either the vehicle information display or both the
vehicle information display and the control panel
display.

Push the

button to accept the call. Push the

button to reject the call.

During a call

While a call is active, push the

button to

access additional options. Speak one of the
following commands:
. Send

Speak this command followed by the digits
to enter digits during the phone call.

. Mute On or Mute Off

Speak the command to mute or unmute the
system.

. Transfer Call

Speak this command to transfer the call to
the handset. To transfer the call back from
the handset to the Bluetooth

Hands-Free

Phone System, push the

button and

confirm when prompted.

If supported by the phone, the Bluetooth

Hands-Free Phone System allows for call wait-
ing functionality. If a call is received while
another call is already active, a message will
be displayed on the screen. Push the
button to hold the active call and switch to the
second call. Push the

button to reject the

second call.

While the second call is active, pushing the
button will allow the same commands that
available during any call as well as two additional
commands:
. Switch Call

Speak this command to hold the second call
and switch back to the original call.

. End Other Call

Speak this command to stay with the
second call and end the original call.

Push the

button to accept the call. Push the

button to reject the call.

Ending a call

To end an active call, push the

button.

Text messaging

WARNING

. Laws in some jurisdictions may

restrict the use of some of the
applications and features, such as
social networking and texting.

. Laws in some jurisdictions may

restrict the use of “Text-to-Speech”.
Check local regulations before
using this feature.

. Use the text messaging feature after

stopping your vehicle in a safe
location. If you have to use the
feature while driving, exercise ex-
treme caution at all times so full
attention may be given to vehicle
operation.

. If you are unable to devote full

attention to vehicle operation while
using the text messaging feature,
pull off the road to a safe location
and stop your vehicle.

NOTE:
. This feature is automatically disabled if

the connected device does not support
the Message Access Profile (MAP). See
the phone’s Owner’s Manual for details
and instructions.

. Many phones may require special per-

mission to enable text messaging.
Check the phone’s screen during Blue-
tooth

pairing. For some phones, you

may need to enable “Notifications” in
the phone’s Bluetooth

menu for text

messages to appear on the vehicle
audio system. See the phone’s Owner’s
Manual for details. Text message inte-
gration requires that the phone support

MAP (Message Access Profile) for both
receiving and sending text messages.
Some phones may not support all text
messaging features. Refer to www.
nissanusa.com/bluetooth or www.
nissan.ca/bluetooth for compatibility
information, as well as your device’s
Owner’s Manual.

The system allows for the sending and receiving
of text messages through the vehicle interface.

Sending a text message:

1. Push the

button.

2. Say “Messaging”.

3. Say “Send Text”.

4. The system will provide a list of available

commands in order to determine the reci-
pient of the text message. Choose from the
following:

(A name)

Number

Incoming Calls

Outgoing Calls

Missed Calls

If “Incoming Calls”, “Outgoing Calls”, or
“Missed Calls” is selected, the following
additional commands will be displayed:

Send Text

For more information about these options,
see “Voice commands” (P.4-84).

5. Once a recipient is chosen, the system

prompts for which message to send. Five
predefined messages are available as well
as three custom messages. To choose one
of the predefined messages, speak one of
the following:

“Driving, can’t text”

“Call me”

“On my way”

“Running late”

“Okay”

To send one of the custom messages, say
“Custom Message”. If more than one cus-
tom message is stored, the system will
prompt for the number of the desired
custom message. For more information on
setting and managing custom text mes-
sages, see “Bluetooth

settings” (P.4-88).

Heater, air conditioner, audio and phone systems

4-87

4-88

Heater, air conditioner, audio and phone systems

Reading a received text message:

1. Push the

button.

2. Say “Messaging”.

3. Say “Read Text”.

The text message, sender and delivery time are
shown on the screen. Use the tuning switch on
the steering wheel to scroll through all text
messages if more than one are available. Push
the

button to exit the text message screen.

Push the

button to access the following

options for replying to the text message:
. Call Back

Speak this command to call the sender of
the text message using the Bluetooth

Hands-Free Phone System.

. Send Text

Speak this command to send a text mes-
sage response to the sender of the text
message.

. Read Text

Speak this command to read the text
message again.

. Previous Text

Speak this command to move to the
previous text message (if available).

. Next Text

Speak this command to move to the next
text message (if available).

NOTE:
. Text messages are only displayed if the

vehicle speed is less than 5 MPH (8
km/h).

. iPhones

can only send text messages

via Siri

Eyes Free.

Making custom messages with Siri

Eyes

Free:

If a connected iPhone

is equipped with Siri

, it

can also be used to create custom messages.
(See “Siri

Eyes Free” (P.4-76).)

Bluetooth

settings

To access and adjust the settings for the
Bluetooth

Hands-Free Phone System:

1. Push the ENTER/SETTING button.

2. Use the TUNE·FOLDER or TUNE·SCROLL

knob to select “Bluetooth” and then push
the ENTER/SETTING button:

Bluetooth

Select “ON” or “OFF” to turn the
vehicle’s Bluetooth

system on or off.

Add Phone

To connect a phone to the system, see
“Initialization” (P.4-83).

Delete Phone

Select to delete a phone from the
displayed list. The system will ask to
confirm before deleting the phone.

Replace Phone

Select to replace a phone from the
displayed list. When a selection is made,
the system will ask to confirm before
proceeding. The recorded phonebook for
the phone being deleted will be saved as
long as the new phone’s phonebook is
the same as the old phone’s phonebook.

Select Phone

Select to connect to a previously con-
nected phone from the displayed list.

Phonebook Download

Select to turn on or off the automatic
download of a connected phone’s pho-
nebook.

Siri

Select the

PHONE SEND button

operation for Siri

Eyes Free function

from “Short Press” and “Long Press” (if
available). (see “Siri

Eyes Free” (P.4-

76).)

“Siri” is displayed only when a Siri

Eyes

Free enabled iPhone

is connected to

the vehicle.

Show Incoming Calls

Select “Driver Only” to have incoming
call information displayed only in the
vehicle information display. Select “Both”
to have incoming call information dis-
played in both the vehicle information
display and the center display screen

Text Message

Select to turn on or off the vehicle’s text
messaging feature.

New Text Sound

Select to adjust the volume of the sound
that plays when a new text is received by
a phone connected to the Bluetooth

Hands-Free Phone System. The setting
all the way to the left indicates that the
new text sound will be muted.

Show Incoming Text

Select “Driver Only” to have incoming
text messages displayed only in the
vehicle information display. Select “Both”
to have incoming text messages dis-
played in both the vehicle information
display and the center display screen.
Select “None” to have no display of
incoming text messages.

Edit Custom Messages

Select to set a custom message that will
be available with the standard options
when sending a text message. To set a
custom message, send a text message to
your own phone number while the phone
is connected to the system. Three
custom messages can be set. Custom
messages can only be set while the
vehicle is stationary.

Auto Reply

Select to turn on or off the Auto Reply
function. When enabled, the vehicle will
automatically send a predefined text

message to the sender when a text
message is received while driving.

Auto Reply Message

Select to choose the message that is
sent when the Auto Reply function is
enabled. Choose from “I’m Driving” or
one of the three custom messages
stored in the system.

Vehicle Signature On/Off

Select to choose whether or not the
vehicle signature is added to outgoing
text messages from the vehicle. This
message cannot be changed or custo-
mized.

WARNING

. Use a phone after stopping your

vehicle in a safe location. If you
have to use a phone while driving,
exercise extreme caution at all
times so full attention may be given
to vehicle operation.

. If you are unable to devote full

attention to vehicle operation while
talking on the phone, pull off the
road to a safe location and stop
your vehicle.

CAUTION

To avoid discharging the vehicle bat-
tery, use a phone after starting the
engine.

Heater, air conditioner, audio and phone systems

4-89

Bluetooth

HANDS-FREE PHONE

SYSTEM (models with navigation
system)

4-90

Heater, air conditioner, audio and phone systems

SAA3446

Volume control switch

í/+

PHONE SEND

button

PHONE END

button

Microphone

The phone

button is located on the control

panel can also use to control the Bluetooth

Hands-Free Phone System. (See “Control but-
tons and functions (models with navigation
system)” (P.4-3).)

Your vehicle is equipped with the Bluetooth

Hands-Free Phone System. If you have a
compatible Bluetooth

enabled cellular phone,

you can set up the wireless connection between
your cellular phone and the in-vehicle phone
module. With Bluetooth

wireless technology,

you can make or receive a hands-free telephone
call with your cellular phone in the vehicle.

Once your cellular phone is connected to the in-
vehicle phone module, no other phone connect-
ing procedure is required. Your phone is
automatically connected with the in-vehicle
phone module when the ignition switch is
placed in the ON position with the connected
cellular phone turned on and carried in the
vehicle.

You can register up to 5 different Bluetooth

cellular phones to the in-vehicle phone module.
However, you can talk on only one cellular phone
at a time.

NISSAN Voice Recognition system supports the
phone commands, so dialing a phone number
using your voice is possible. For more details,
see “NISSAN Voice Recognition System (mod-
els with navigation system)” (P.4-96).

Before using the Bluetooth

Hands-Free Phone

System, refer to the following notes.
. Set up the wireless connection between a

cellular phone and the in-vehicle phone
module before using the Hands-Free Phone
System.

. Some Bluetooth

enabled cellular phones

may not be recognized by the in-vehicle
phone module. Please visit www.nissanusa.
com/bluetooth for a recommended phone

list and connecting.

. You will not be able to use a hands-free

phone under the following conditions:
— Your vehicle is outside of the cellular

service area.

— Your vehicle is in an area where it is

difficult to receive cellular signal; such as
in a tunnel, in an underground parking
garage, near a tall building or in a
mountainous area.

— Your cellular phone is locked to prevent it

from being dialed.

. When the radio wave condition is not ideal

or ambient sound is too loud, it may be
difficult to hear the other person’s voice
during a call.

. Immediately after the ignition switch is

placed in the ON position, it may be
impossible to receive a call for a short
period of time.

. Do not place the cellular phone in an area

surrounded by metal or far away from the in-
vehicle phone module to prevent tone quality
degradation and wireless connection dis-
ruption.

. While a cellular phone is connected through

the Bluetooth

wireless connection, the

battery power of the cellular phone may
discharge quicker than usual. The Blue-

tooth

Hands-Free Phone System cannot

charge cellular phones.

. If the Hands-Free Phone System seems to

be malfunctioning, visit www.nissanusa.
com/bluetooth for troubleshooting help.

. Some cellular phones or other devices may

cause interference or a buzzing noise to
come from the audio system speakers.
Storing the device in a different location
may reduce or eliminate the noise.

. Refer to the cellular phone Owner’s Manual

regarding the telephone charges, cellular
phone antenna and body, etc.

. The signal strength display on the monitor

will not coincide with the signal strength
display of some cellular phones.

REGULATORY INFORMATION

FCC Regulatory information

– CAUTION: To maintain compliance with
FCC’s RF exposure guidelines, use only the
supplied antenna. Unauthorized antenna, mod-
ification, or attachments could damage the
transmitter and may violate FCC regulations.

– Operation is subject to the following two
conditions:

1. This device may not cause interference and

2. This device must accept any interference,

including interference that may cause un-

desired operation of the device.

IC Regulatory information

– Operation is subject to the following two
conditions: (1) this device may not cause
interference, and (2) this device must accept
any interference, including interference that may
cause undesired operation of the device.

– This Class B digital apparatus meets all
requirements of the Canadian Interference-
Causing Equipment Regulations.

Bluetooth

is a trademark

owned by Bluetooth SIG, Inc.
and licensed to Robert Bosch
GmbH.

VOICE COMMAND

You can use voice commands to operate various
Bluetooth

Hands-Free Phone System features

using the NISSAN Voice Recognition system.
For more details, see “NISSAN Voice Recogni-
tion System (models with navigation system)”
(P.4-96).

Voice Prompt Interrupt

While using the voice recognition system, the
system voice can be interrupted to allow the
user to speak commands. While the system is
speaking, push the

button on the steering

wheel. The system voice will stop and a tone will
be heard. After the tone, speak desired com-

mand (displayed on the touch-screen).

One Shot Call

To use the system faster, you may speak the
second level commands with the main menu
command on the main menu. For example, push
the

button and after the tone say, “Call

Redial”.

Heater, air conditioner, audio and phone systems

4-91

4-92

Heater, air conditioner, audio and phone systems

JVH0735X

CONNECTING PROCEDURE

NOTE:

The connecting procedure must be per-
formed when the vehicle is stationary. If
the vehicle starts moving during the pro-
cedure, the procedure will be cancelled.

1. Push the

button on the control panel.

2. Touch the “Settings” key.

3. Touch the “Phone & Bluetooth” key.

4. Touch the “Connect New Device” key.

5. Initiate the connecting process from the

handset. The system will display the mes-
sage: “Is PIN XXXXXX displayed on your
Bluetooth device?”. If the PIN is displayed

on your Bluetooth

device, select “Yes” to

complete the pairing process.

For more information, see the Bluetooth

device’s Owner’s Manual.

VEHICLE PHONEBOOK

To access the vehicle phonebook:

1. Push the

button on the control panel.

2. Touch the “Phonebook” key.

3. Choose the desired entry from the displayed

list.

4. The number of the entry will be displayed on

the screen. Touch the number to initiate
dialing.

NOTE:

To scroll quickly through the list, touch the
“A-Z” key in the upper right corner of the
screen. Turn the TUNE knob to choose a
letter or number and then push AUDIO
button. The list will move to the first entry
that begins with that number or letter.

MAKING A CALL

To make a call, follow the procedure below:

1. Push the

button on the control panel.

The “Phone” screen will appear on the
display.

2. Select one of the following options to make

a call:

. “Phonebook”: Select the name from an entry

stored in the vehicle phonebook.

. “Call Lists”: Select the name from the

incoming, outgoing or missed.

. “Redial”: Dial the last outgoing call from the

vehicle.

. “

”: Input the phone number manually

using a keypad displayed on the screen. For
information on how to use the touch-screen,
see “Control buttons and functions (models
with navigation system)” (P.4-3).

RECEIVING A CALL

When a call is placed to the connected phone,
the display will change to phone mode.

To accept the incoming call:
. Push the

button on the steering wheel.

. Touch the green phone icon on the screen.
To reject the incoming call:
. Push the

button on the steering wheel.

. Touch the red phone icon on the screen.

DURING A CALL

While a call is active, the following options are
available on the screen:
. “Handset”

Select this option to switch control of the
phone call over to the handset.

. “Mute Mic.”

Select this option to mute the microphone.
Select again to unmute the microphone.

. Red phone (

) icon

Select to end the phone call.

ENDING A CALL

To end a phone call, select the red phone (

)

icon on the screen or push the

button on

the steering wheel.

TEXT MESSAGING

WARNING

. Laws in some jurisdictions may

restrict the use of some of the
applications and features, such as
social networking and texting.

. Laws in some jurisdictions may

restrict the use of “Text-to-Speech”.
Check local regulations before
using this feature.

. Use the text messaging feature after

stopping your vehicle in a safe
location. If you have to use the
feature while driving, exercise ex-
treme caution at all times so full
attention may be given to vehicle
operation.

. If you are unable to devote full

attention to vehicle operation while
using the text messaging feature,
pull off the road to a safe location
and stop your vehicle.

NOTE:

Many phones may require special permis-
sion to enable text messaging. Check the
phone’s screen during Bluetooth

pairing.

For some phones, you may need to enable
“Notifications” in the phone’s Bluetooth

menu for text messages to appear on the
vehicle audio system. See the phone’s
Owner’s Manual for details. Text message
integration requires that the phone sup-
port MAP (Message Access Profile) for
both receiving and sending text messages.
Some phones may not support all text
messaging features. Refer to www.nissa-
nusa.com/bluetooth or www.nissan.ca/
bluetooth for compatibility information,

as well as your device’s Owner’s Manual.

The system allows for the sending and receiving
of text messages through the vehicle interface.

Sending a text message

1. Push the

button on the steering wheel.

2. Say “Phone” after the tone.

3. Say “Send Text” after the tone.

4. The system will provide a list of available

commands in order to determine the reci-
pient of the text message. Choose from the
following:

To (a name)

Enter Number

Missed Calls

Incoming Calls

Outgoing Calls

For more information about these options,
see “Voice command” (P.4-91).

5. Once a recipient is chosen, the system

prompts for which message to send. Nine
predefined messages are available as well
as three custom messages. To choose one
of the predefined messages, speak one of
the following after the tone:

“Driving, can’t text”

“Call me”

Heater, air conditioner, audio and phone systems

4-93

4-94

Heater, air conditioner, audio and phone systems

“On my way”

“Running late”

“Okay”

“Yes”

“No”

“Where are you?”

“When?”

To send one of the custom messages, say
“Custom Messages”. If more than one
custom message is stored, the system will
prompt for the number of the desired
custom message. For more information on
setting and managing custom text mes-
sages, see “Phone settings” (P.4-96).

Reading a received text message

1. Push the

button on the steering wheel.

2. Say “Phone” after the tone.

3. Say “Read Text” after the tone.

The text message, sender and delivery time are
shown on the screen. Use the tuning switch to
scroll through all text messages if more than one
are available. Push the

button to exit the text

message screen. Push the

button to

access the following options for replying to the
text message:
. Call Back

Speak this command to call the sender of
the text message using the Bluetooth

Hands-Free Phone System.

. Send Text

Speak this command to send a text mes-
sage response to the sender of the text
message.

. Read Text

Speak this command to read the text
message again.

. Previous Text

Speak this command to move to the
previous text message (if available).

. Next Text

Speak this command to move to the next
text message (if available).

NOTE:
. Text messages are only displayed if the

vehicle speed is less than 5 MPH (8
km/h).

. iPhones

can only send text messages

via Siri

Eyes Free.

Making custom messages with Siri

Eyes Free

If a connected iPhone

is equipped with Siri

, it

can also be used to create custom messages.
(See “Siri

Eyes Free” (P.4-76).)

JVH0750X

Bluetooth

SETTINGS

To access the phone settings:

1. Push the

button.

2. Touch the “Settings” key.

3. Touch the “Phone & Bluetooth” key.

Menu Item

Result

Phone Settings

For detailed information, see “Phone settings” (P.4-96).

Connect New Device

Touch to connect a new Bluetooth

device to the Bluetooth

Hands-Free Phone System.

Select Connected Device

Touch to choose a Bluetooth

device from a list of those devices connected to the Bluetooth

Hands-Free Phone System.

Replace Connected Device

Touch to replace a Bluetooth

device from a list of those devices connected to the Bluetooth

Hands-Free Phone System.

Delete Connected Device

Touch to delete a Bluetooth

device from a list of those devices connected to the Bluetooth

Hands-Free Phone System.

Bluetooth

Touch to toggle Bluetooth

on and off.

Heater, air conditioner, audio and phone systems

4-95

4-96

Heater, air conditioner, audio and phone systems

PHONE SETTINGS

To access the phone settings:

1. Push the

button.

2. Touch the “Settings” key.

3. Touch the “Phone & Bluetooth” key.

4. Touch the “Phone Settings” key and adjust

the following settings as desired:

. Sort Phonebook By:

Touch “First Name” or “Last Name” to
choose how phonebook entries are alpha-
betically displayed on the screen.

. Use Phonebook From:

Touch “Handset” to use the phone’s phone-
book. Select “SIM” to use the phonebook on
the SIM card. Touch “Both” to use both
sources.

. Download Phonebook Now:

Touch to download the phonebook to the
vehicle from the chosen source.

. Record Name for Phonebook Entry:

Touch to record a name for a phonebook
entry for use with the NISSAN Voice
Recognition System.

. Phone Notifications for:

Touch “Driver” to have phone notifications
shown in the vehicle information display.
Touch “Both” to have phone notifications

shown in both the vehicle information dis-
play and the center display screen.

. Text Messaging:

Touch to toggle the text message function-
ality on or off.

. Show Incoming Text for:

Touch “Driver” to have incoming text notifi-
cations shown in the vehicle information
display. Touch “Both” to have text notifica-
tions shown in both the vehicle information
display and the center display screen. Touch
“Off” to turn off all text notifications.

. Auto Reply:

Touch to toggle the auto reply functionality
on or off.

. Auto Reply Message:

Touch to indicate preferred message to be
sent when “Auto Reply” function is acti-
vated.

. Use Vehicle’s Signature:

Touch to toggle on or off the addition of the
vehicle signature to outgoing messages

. Custom Text Messages:

Touch this option to select a custom
message to edit. There are 4 customer
message slots available.

The NISSAN Voice Recognition system allows
hands-free operation of the systems equipped
on this vehicle, such as the phone and naviga-
tion systems.

To operate NISSAN Voice Recognition, push the

button located on the steering wheel.

When prompted, speak the command for the
system you wish to activate. The command given
is picked up by the microphone and performed
when it is properly recognized. NISSAN Voice
Recognition will provide a voice response as
well as a message in the center display to inform
you of the command results.

NISSAN VOICE RECOGNITION
SYSTEM (models with navigation
system)

USING THE SYSTEM

Initialization

When the ignition switch is in the ON position,
NISSAN Voice Recognition is initialized, which
takes a few seconds. When completed, the
system is ready to accept voice commands. If
the

button is pushed before the initialization

completes, the system will announce: “Voice
Recognition System not ready. Please wait.”

SAA3385

Giving voice commands

1. Push the

button.

2. The system announces: “Please say a

category like phone or a command like
points of interest followed by a brand name”.
A list of available commands is then spoken
by the system.

3. After the tone sounds and the face icon on

the display changes, speak a command.
Available commands are discussed in this
section.

4. Voice and display feedback are provided

when the command is accepted.

. If the command is not recognized, the

system announces: “Command not recog-
nized”. Repeat the command in a clear
voice.

. If you want to cancel the command or go

back to the previous menu of commands,
push the

button. The system will

announce: “Cancelling voice recognition”
or “Go back” depending on the current
menu level.

. Push the BACK button on the control panel

to move back through the menus displayed
on the screen.

. If you want to adjust the volume of the voice

feedback, use the volume control switches
on the steering wheel or the volume knob on
the control panel.

. The voice command screen can also be

accessed using the control panel display:

1. Push the

button.

2. Touch the “Voice Commands” key.

Operating tips

To get the best performance out of NISSAN
Voice Recognition, observe the following:
. Keep the interior of the vehicle as quiet as

possible. Close the windows to eliminate the
surrounding noises (traffic noises, vibration
sounds, etc.), which may prevent the system

Heater, air conditioner, audio and phone systems

4-97

4-98

Heater, air conditioner, audio and phone systems

from recognizing the voice commands cor-
rectly.

. Wait until a tone sounds before speaking a

command. Otherwise, the command will not
be received properly.

. Start speaking a command within 3.5

seconds after the tone sounds.

. Speak in a natural voice without pausing

between words.

JVH0865X

SYSTEM FEATURES

NISSAN Voice Recognition can activate the
following systems:
. Bluetooth

Hands-Free Phone System

. Navigation
. Audio
. Information
. My Apps
For additional information on the navigation
system, see the separate Navigation System
Owner’s Manual.

How to say numbers

NISSAN Voice Recognition requires a certain
way to speak numbers in voice commands.
Refer to the following examples.

General rule: Either “zero” or “oh” can be used
for “0”.

Phone numbers:

Speak phone numbers according to the follow-
ing example. For 1-800-662-6200, say dial
number and then speak the phone number in
any of the following formats:
. “one eight oh oh six six two six two oh oh”
. “one eight hundred six six two six two oh oh”
. “one eight zero zero six six two six two oh

oh”

For the best voice recognition phone dialing
results, say phone numbers as single digits.
Also, full numbers can only be spoken for “800”.
For example, you cannot say 555-6000 as “five
five five six thousand”.

Bluetooth

HANDS-FREE PHONE

SYSTEM VOICE COMMANDS

To access the Bluetooth

Hands-Free Phone

System voice commands:

1. Push the

button.

2. Say “Call” and then a name in the vehicle

phonebook to call that entry. Otherwise, say

“Phone” to access various phone com-
mands.

If the Bluetooth

has been set to “Off”, the

system announces: “Bluetooth

is off. Would

you like to turn Bluetooth

on?”

If no phone is connected to the system and the
vehicle is stationary, the system announces:
“There is no phone connected. Would you like to
connect a phone now?” Say “Yes” to connect a
phone. All further Bluetooth

Hands-Free Phone

System voice commands are only available if a
phone is connected.

If a phone is connected and Bluetooth

is set to

“On”, the following voice commands are avail-
able:
. Call (a name)

Speak the name of the contact in which you
are trying to call. System will confirm correct
contact. Say “Dial” to initiate dialing.

. Dial Number

Allows for up to 24 digits to be dialed. After
the number is entered, say “Dial” to initiate
dialing. Say “Correction” to correct the
number entered. Say “Go Back” to return
to the main menu.

. List Phonebook

Starting with the first alphabetical entry in
the vehicle phonebook, the system prompts

for an additional command. Say “Dial” to call
the number of the phonebook entry. Say
“Send Text” to send a text message to the
number of the phonebook entry. Say “Next
Entry” to skip to the next alphabetical entry
in the vehicle phonebook, where the same
options will then be available.

. Recent Calls

The system prompts for an additional
command. Say “Missed Calls”, “Incoming
Calls” or “Outgoing Calls” to display a list of
such calls on the screen.
Speak the number of the entry displayed on
the screen to dial that number or say “Next
Page” to view entries on the next page (if
available).

. Redial

Redials the last called number.

. Read Text

Reads an incoming text message. For more
information about text messaging with the
Bluetooth

Hands-Free Phone System, see

“Bluetooth

Hands-Free Phone System

(models with navigation system)” (P.4-89).

. Send Text

Sends a text message. For more information
about text messaging with the Bluetooth

Hands-Free Phone System, see “Bluetooth

Hands-Free Phone System (models with

navigation system)” (P.4-89).

. Select Phone

The system replies “Please use manual
controls to continue”. Use manual controls
to change the active phone from among the
listed phones connected to the vehicle.

For more information about the Bluetooth

Hands-Free Phone System, see “Bluetooth

Hands-Free Phone System (models with navi-
gation system)” (P.4-89).

NAVIGATION SYSTEM VOICE COM-
MANDS

The following voice commands are available for
the Navigation System:
. Street Address (address)
. Points of Interest (name)
. POI by Category
. Home
. Address Book
. Previous Destinations
. Enter Address in Steps
. Cancel Route
For more information about these commands,
see the separate Navigation System Owner’s
Manual.

Heater, air conditioner, audio and phone systems

4-99

4-100

Heater, air conditioner, audio and phone systems

AUDIO SYSTEM VOICE COMMANDS

To access the audio system voice commands:

1. Push the

button.

2. Say “Audio”.

3. Speak a command from the following

available commands:

. Play (AM, FM, etc.)

Allows user to select radio band

. Tune AM (number)

Allows user to tune directly to a desired AM
frequency

. Tune FM (number)

Allows user to tune directly to a desired FM
frequency

. SXM channel (number)

Allows user to tune directly to a desired
SXM station (if so equipped)

. CD Track (number)

Allows user to select track to be played

. Play Song (name)

Allows user to select song name to be
played

. Play Artist (name)

Allows user to select artist to be played

. Play Album (name)

Allows user to select album name to be
played

For more information about the audio system,
see “FM-AM-SAT radio with Compact Disc (CD)
player (Type B)” (P.4-62).

INFORMATION VOICE COMMANDS

The following voice commands are available for
the information functions of the Navigation
System:
. Traffic
. Fuel Prices
. Stocks
. Movie Listings
. Current Weather
. Weather Map
. 5 — day Forecast
. 6 — hour Forecast
For more information about these commands,
see the separate Navigation System Owner’s
Manual.

MY APPS VOICE COMMANDS

Many Apps can be accessed using this voice
command. See “NissanConnect

App smart-

phone integration” (P.4-75).

HELP VOICE COMMANDS

The following voice commands can be spoken
to have the system provide instructions and tips
for using the NISSAN Voice Recognition sys-
tem.
. List Commands
. What Can I Say?
. General Help
. Quit
. Exit

TROUBLESHOOTING GUIDE

The system should respond correctly to all voice
commands without difficulty. If problems are
encountered, follow the solutions given in this
guide for the appropriate error. Where the
solutions are listed by number, try each solution
in turn, starting with number one, until the
problem is resolved.

Nissan Juke (2017 year). Instruction - part 16
