Nissan 370Z Roadster (2017 year). Instruction

(98,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

2-30

Instruments and controls

Intelligent Key, the door handle request
switch or the mechanical key. (Even if the
door is opened by releasing the door inside
lock knob, the alarm will activate.)

Opening the hood.

How to stop an activated alarm

The alarm will stop by unlocking a door by
pushing the unlock button on the Intelligent Key,
the door handle request switch or using the
mechanical key. The alarm will not stop if the
ignition switch is pushed to the ACC or ON
position.

If the system does not operate as de-
scribed above, it is recommended you have
it checked by a NISSAN dealer.

NISSAN VEHICLE IMMOBILIZER SYS-
TEM

The NISSAN Vehicle Immobilizer System will not
allow the engine to start without the use of the
registered Intelligent Key. Never leave these
keys in the vehicle.

For USA:

This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:

(1) This device may not cause harmful
interference, and (2) this device must

accept any interference received, including
interference that may cause undesired
operation.

Note: Changes or modifications not ex-
pressly approved by the party responsible
for compliance could void the user’s
authority to operate the equipment.

For Canada:

This device complies with Industry Canada
licence-exempt RSS standard(s). Opera-
tion is subject to the following two condi-
tions:

(1) this device may not cause interference,
and (2) this device must accept any inter-
ference, including interference that may
cause undesired operation of the device.

SIC2045

Security indicator light

The security indicator light is located on the
meter panel. It indicates the status of the
NISSAN Vehicle Immobilizer System.

The light blinks after the ignition switch is in the
LOCK, ACC or OFF position. This function
indicates the security systems equipped on the
vehicle are operational.

If the NISSAN Vehicle Immobilizer System is
malfunctioning, this light will remain on while the
ignition switch is in the ON position.

If the light still remains on and/or the
engine will not start, seek service for
NISSAN Vehicle Immobilizer System as

Condition:

(99,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

soon as possible. Please bring all Intelli-
gent Keys that you have. It is recom-
mended you visit a NISSAN dealer for
this service.

WARNING

In freezing temperatures the washer
solution may freeze on the windshield
and obscure your vision which may lead
to an accident. Warm windshield with
the defroster before you wash the
windshield.

CAUTION

Do not operate the washer continu-
ously for more than 30 seconds.

Do not operate the washer if the
reservoir tank is empty.

Do not fill the window washer
reservoir tank with washer fluid
concentrates at full strength. Some
methyl alcohol based washer fluid
concentrates may permanently stain
the grille if spilled while filling the
window washer reservoir tank.

Pre-mix washer fluid concentrates
with water to the manufacturer’s
recommended levels before pouring
the fluid into the window washer

reservoir tank. Do not use the
window washer reservoir tank to
mix the washer fluid concentrate
and water.

Instruments and controls

2-31

WIPER AND WASHER SWITCH

Condition:

(100,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

2-32

Instruments and controls

JVI1012X

The windshield wiper and washer operates
when the ignition switch is in the ON position.

Push the lever down to operate the wiper at the
following speed:

Intermittent — intermittent operation can be
adjusted by turning the knob toward

(Slower) or

(Faster).

When the speed sensing wiper interval function
(for models with navigation system) is turned on,
the intermittent operation speed varies in ac-
cordance with the vehicle speed. (For example,
when the vehicle speed is high, the intermittent
operation speed will be faster.)

Models with navigation system:

Note that the function is set to disabled as the
factory default setting. To turn this function on

and off, see “How to use SETTING button” (P.4-
11).

Low — continuous low speed operation

High — continuous high speed operation

Push the lever up

to have one sweep

operation of the wiper.

Pull the lever toward you

to operate the

washer. Then the wiper will also operate several
times.

Wiper drip wipe system:

The wiper will also operate once about 3
seconds after the washer and wiper are
operated. This operation is to wipe washer fluid
that has dripped on the windshield.

SIC3980

Type A (if so equipped)

SIC3979

Type B (if so equipped)

REAR WINDOW DEFROSTER
SWITCH

Condition:

(101,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

To defog/defrost the rear window glass and
outside mirrors, start the engine and push the
switch

on. The indicator light

will come

on. Push the switch again to turn the defroster
off.

It will automatically turn off in approximately 15
minutes.

CAUTION

When cleaning the inner side of the
rear window, be careful not to
scratch or damage the rear window
defroster.

Do not use the rear window defros-
ter switch while the soft top is being
operated or fully opened. The heat
may damage the top material and/
or components (for Roadster mod-
els).

XENON HEADLIGHTS

WARNING

HIGH VOLTAGE

When xenon headlights are on, they
produce a high voltage. To prevent
an electric shock, never attempt to
modify or disassemble. Always have
your xenon headlights replaced by a
certified service technician.

Xenon headlights provide consider-
ably more light than conventional
headlights. If they are not correctly
aimed, they might temporarily blind
an oncoming driver or the driver
ahead of you and cause a serious
accident. If headlights are not aimed
correctly, it is recommended you
immediately take your vehicle to a
NISSAN dealer and have the head-
lights adjusted correctly.

When the xenon headlight is initially turned on,
its brightness or color varies slightly. However,
the color and brightness will soon stabilize.

The life of xenon headlights will be
shortened by frequent on-off opera-

tion. It is generally desirable not to turn
off the headlights for short intervals
(for example, when the vehicle stops at
a traffic signal).

If the xenon headlight bulb is close to
burning out, the brightness will drasti-
cally decrease, the light will start
blinking, or the color of the light will
become reddish. If one or more of the
above signs appear, it is recommended
you visit a NISSAN dealer.

Instruments and controls

2-33

HEADLIGHT AND TURN SIGNAL
SWITCH

Condition:

(102,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

2-34

Instruments and controls

SIC3994

HEADLIGHT SWITCH

Lighting

Turn the switch to the

position:

The front parking, side marker, tail, license plate,
instrument lights and daytime running lights will
come on.

Turn the switch to the

position:

Headlights will come on and all the other lights
remain on. However, the daytime running lights
will turn off.

SIC3995

Autolight system

The autolight system allows the headlights to be
set so they turn on and off automatically.

To set the autolight system:

1. Make sure the headlight switch is in the

AUTO position

2. Push the ignition switch to the ON position.

3. The autolight system automatically turns the

headlights on and off.

To turn the autolight system off, turn the switch
to the OFF,

position.

The autolight system can turn on the headlights
automatically when it is dark and turn off the

headlights when it is light.

If the ignition switch is pushed to the OFF
position and one of the doors is opened and this
condition is continued, the headlights remain on
for 5 minutes.

Automatic headlights off delay:

You can keep the headlights on for 45 seconds
after you push the ignition switch to OFF and
open any door then close all the doors.

Models with navigation system:

You can adjust the period of the automatic
headlights off delay from 0 seconds (OFF) to
180 seconds. The factory default setting is 45
seconds.

For automatic headlights off delay setting, see
“Light Off Delay” (P.4-15).

Condition:

(103,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

SIC3784A

Be sure not to put anything on top of the
photo sensor

located on the top of the

instrument panel. The photo sensor con-
trols the autolight; if it is covered, the
photo sensor reacts as if it is dark and the
headlights will illuminate.

SIC3996

Headlight beam select

To select the low beam, put the lever in the
neutral position as shown.

To select the high beam, push the lever forward
while the switch is in the

position. Pull it

back to select the low beam.

Pulling the lever toward you will flash the
headlight high beam even when the headlight
switch is in the OFF position.

Battery saver system

A chime will sound when the driver side door is
opened with the light switch in the

position and the ignition switch in the ACC, OFF
or LOCK position.

When the headlight switch is in the

position while the ignition switch is in the ON
position, the lights will automatically turn off after
a period of time when the ignition switch has
been pushed to the OFF position.

When the headlight switch remains in the
or

position after the lights automatically turn

off, the lights will turn on when the ignition
switch is pushed to the ON position.

CAUTION

When you turn on the headlight
switch again after the lights auto-
matically turn off, the lights will not
turn off automatically. Be sure to
turn the light switch to the OFF
position when you leave the vehicle
for extended periods of time, other-
wise the battery will be discharged.

Never leave the light switch on
when the engine is not running for
extended periods of time even if the

Instruments and controls

2-35

Condition:

(104,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

2-36

Instruments and controls

headlights turn off automatically.

Daytime running light system

The daytime running lights automatically illumi-
nate when the engine is started with the parking
brake released. The daytime running lights
operate with the headlight switch in the OFF
position or in the

position. Turn the head-

light switch to the

position for full illumina-

tion when driving at night. However, the daytime
running lights will turn off.

If the parking brake is applied before the engine
is started, the daytime running lights do not
illuminate. The daytime running lights illuminate
once the parking brake is released. The daytime
running lights will remain on until the ignition
switch is pushed to the OFF position.

WARNING

When the daytime running light system
is active, tail lights on your vehicle are
not on. It is necessary at dusk to turn on
your headlights. Failure to do so could
cause an accident injuring yourself and
others.

SIC3981

Instrument brightness control

The instrument brightness control operates
when the headlight control switch is in the

or AUTO position (with the autolights

activated).

Push the upper

or lower

switch to

brighten or dim the instrument panel lights when
driving at night.

SIC3997

TURN SIGNAL SWITCH

Turn signal

Move the lever up or down to signal the turning
direction. When the turn is completed, the turn
signals cancel automatically.

Lane change signal

Move the lever up or down until the turn signal
begins to flash, but the lever does not latch, to
signal a lane change. Hold the lever until the lane
change is completed.

Move the lever up or down until the turn signal
begins to flash, but the lever does not latch, and
release the lever. The turn signal will automati-
cally flash three times.

Condition:

(105,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

Choose the appropriate method to signal a lane
change based on road and traffic conditions.

SIC4066

FOG LIGHT SWITCH (if so equipped)

To turn on the rear fog light, turn the headlight
switch to the

position, then turn the fog light

switch to the

position.

The switch returns to the OFF position auto-
matically, and the rear fog light will illuminate.

Make sure the indicator light on the instrument
panel illuminates.

To turn off the rear fog light, turn the fog light
switch to the

position again.

Make sure the indicator light on the instrument
panel turns off.

SIC3982

To sound the horn, push the center pad area of
the steering wheel.

WARNING

Do not disassemble the horn. Doing so
could affect proper operation of the
supplemental front air bag system.
Tampering with the supplemental front
air bag system may result in serious
personal injury.

Instruments and controls

2-37

HORN

Condition:

(106,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

2-38

Instruments and controls

WARNING

Do not use or allow occupants to use
the seat heater if you or the occupants
cannot monitor elevated seat tempera-
tures or have an inability to feel pain in
those body parts in contact with the
seat. Use of the seat heater by such
people could result in serious injury.

CAUTION

The battery could run down if the
seat heater is operated while the
engine is not running.

Do not use the seat heater for
extended periods or when no one
is using the seat.

Do not put anything on the seat
which insulates heat, such as a
blanket, cushion, seat cover, etc.
Otherwise, the seat may become
overheated.

Do not place anything hard or heavy
on the seat or pierce it with a pin or
similar object. This may result in

damage to the heater.

Any liquid spilled on the heated seat
should be removed immediately
with a dry cloth.

When cleaning the seat, never use
gasoline, thinner, or any similar
materials.

If any malfunctions are found or the
heated seat does not operate, turn
the switch off and have the system
checked. It is recommended you
visit a NISSAN dealer for this ser-
vice.

SIC2770

The front seats are warmed by built-in heaters.
The switches located on the center console can
be operated independently of each other.

1. Start the engine.

2. Select the desired heat range.

For high heat, push the HI side of the

switch

For low heat, push the LO side of the

switch

The indicator light

will illuminate

when the heater is on.

3. To turn off the heater, return the switch to

the level position. Make sure that the
indicator light turns off.

HEATED SEATS (if so equipped)

Condition:

(107,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

The heater is controlled by a thermostat,
automatically turning the heater on and off.
The indicator light will remain on as long as
the switch is on.

When the vehicle’s interior is warmed, or
before you leave the vehicle, be sure to turn
off the switch.

SIC2771

The climate controlled seat warms up or cools
down the front seats by blowing warm or cool air
from the surface of the seat. The switches
located on the center console can be operated
independently of each other.

The surface temperature of the climate con-
trolled seats is automatically controlled at an
optimum temperature. However, adjust the
temperature using the control knob if the seats
are too hot or cold.

1. Start the engine.

2. Turn the control knob

to the heat side

or to the cool side

. The indicator

light

on the control knob will illuminate.

3. Adjust the desired amount of the air using

the control knob

4. When the vehicle’s interior is warmed or

cooled, and/or before you leave the vehicle,
be sure to turn the control knob to the OFF
position (center). The indicator light

the control knob goes off at the OFF
position.

The climate controlled seat has air filters. If
the climate controlled seat is not functioning
properly, it may indicate the air filters may be
clogged. To check the air filters for the
climate controlled seat, it is recommended
you visit a NISSAN dealer.

WARNING

Do not use or allow occupants to use
the climate controlled seat if you or the
occupants cannot monitor seat tem-
peratures or have an inability to feel
pain in those body parts in contact with
the seat. Use of the climate controlled
seats by such people could result in
serious injury.

Instruments and controls

2-39

CLIMATE CONTROLLED SEATS (if
so equipped)

Condition:

(108,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

2-40

Instruments and controls

CAUTION

Do not place objects in front of the
intake inlets located behind and
under the front seat. Doing so could
cause improper operation or inter-
ruption of the operation.

The battery could run down if the
climate controlled seat is operated
while the engine is not running.

Do not use the climate controlled
seat for extended periods or when
no one is using the seat.

Do not put anything on the seat
which insulates heat, such as a
blanket, cushion, seat cover, etc.
Otherwise, the seat may become
overheated.

Do not place anything hard or heavy
on the seat or pierce it with a pin or
similar object. This may result in
damage to the climate controlled
seat.

Any liquid spilled on the seat should
be removed immediately with a dry
cloth.

The climate controlled seat has air
filters. Do not operate the climate
controlled seat without the air fil-
ters. This may result in damage to
the system.

When cleaning the seat, never use
gasoline, thinner, or any similar
materials.

If any malfunctions are found or the
climate controlled seat does not
operate, turn the switch off and
have the system checked. It is
recommended you visit a NISSAN
dealer for this service.

SSD1161

The vehicle should be driven with the Vehicle
Dynamic Control (VDC) system on for most
driving conditions.

If the vehicle is stuck in mud or snow, the VDC
system reduces the engine output to reduce
wheel spin. The engine speed will be reduced
even if the accelerator is depressed to the floor.
If maximum engine power is needed to free a
stuck vehicle, turn the VDC system off.

To turn off the VDC system, push the VDC OFF
switch. The

indicator light will illuminate.

Push the VDC OFF switch again or restart the
engine to turn on the system. (See “Vehicle
Dynamic Control (VDC) system” (P.5-29).)

VEHICLE DYNAMIC CONTROL (VDC)
OFF SWITCH

Condition:

(109,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

SIC3984

Center console

SIC3985

Lower glove box

The power outlet is located in the center console
and on the lower glove box.

CAUTION

The outlet and plug may be hot
during or immediately after use.

Do not use with accessories that
exceed a 12 volt, 120W (10A) power
draw. Do not use double adapters or
more than one electrical accessory.

Use power outlet with the engine
running to avoid discharging the
vehicle battery.

Avoid using power outlet when the
air conditioner, headlights or rear
window defroster is on.

This power outlet is not designed
for use with a cigarette lighter unit.

Push the plug in as far as it will go.
If good contact is not made, the plug
may overheat or the internal tem-
perature fuse may blow.

Before inserting or disconnecting a
plug, be sure the electrical acces-
sory being used is turned OFF.

When not in use, be sure to close
the cap. Do not allow water or any
liquid to contact the outlet.

Instruments and controls

2-41

POWER OUTLET

Condition:

(110,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

2-42

Instruments and controls

SIC3987

INSTRUMENT POCKET (except for na-
vigation system equipped models)

To open the lid, push the knob up

To close, push the lid down.

WARNING

Keep the pocket lid closed while driving
to help prevent injury in an accident or a
sudden stop.

CUP HOLDERS

CAUTION

Avoid abrupt starting and braking
when the cup holder is being used
to prevent spilling the drink. If the
liquid is hot, it can scald you or your
passenger.

Use only soft cups in the cup holder.
Hard objects can injure you in an
accident.

SIC4071

A cup holder is located on the center console.

STORAGE

Condition:

(111,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

SIC3988

Soft bottle holder

CAUTION

Do not use bottle holder for any
other objects that could be thrown
about in the vehicle and possibly
injure people during sudden braking
or an accident.

Do not use bottle holder for open
liquid containers.

SIC3999

GLOVE BOX

WARNING

Keep glove box lid closed while driving
to help prevent injury in an accident or a
sudden stop.

To open the glove box, pull the handle

To close, push the lid in until the lock latches.

To lock

/unlock

the glove box, use the

mechanical key. For the mechanical key usage,
see “Keys” (P.3-2).

SIC4070

CONSOLE BOX

To open the console box, push the button

and pull up the lid.

To close, push the lid down until latched.

Instruments and controls

2-43

Condition:

(112,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

2-44

Instruments and controls

SIC3989

REAR PARCEL BOX

The rear parcel box is located behind the right-
side seat.

To open the rear parcel box, pull the upper part
of the lid to position

To remove the rear parcel box, pull the lid to
position

with a greater force until it

unlatches. And then, pull the rear parcel box to
direction

To install, make sure the two hinges of the rear
parcel box engaged with the holders, then
perform the steps above in the reverse order.

WARNING

Keep the rear parcel box lid closed
while driving to help prevent injury in an
accident or a sudden stop.

SIC4026

CARGO COVER (if so equipped)

The cargo cover keeps the contents in the cargo
area hidden from the outside.

To use the cargo cover, pull it out and hang both
sides on the hooks

located on the inside of

the rear hatch.

Condition:

(113,1)

[ Edit: 2016/ 2/ 22

Model: 2017MY NISSAN 370Z(Z34) OM17E00Z34U0 ]

SIC3990

To remove the cargo cover unit, stow the cover
and pull the holder

to the opposite side.

WARNING

Never put anything on the cargo
cover, no matter how small. Any
object on it could cause an injury
in an accident or sudden stop.

Do not leave the cargo cover in the
vehicle with it disengaged from the
holder.

Properly secure all cargo with ropes
or straps to help prevent it from

sliding or shifting. Do not place
cargo higher than the seatbacks. In
a sudden stop or collision, unse-
cured cargo could cause personal
injury.

Properly secure cargo and do not
allow it to contact the top tether
strap when it is attached to the top
tether anchor. Cargo that is not
properly secured or cargo that con-
tacts the top tether strap may da-
mage the top tether strap during a
collision. If the cargo cover contacts
the top tether strap when it is
attached to the top tether anchor,
remove the cargo cover from the
vehicle or secure it on the cargo
floor below its attachment location.
If the cargo cover is not removed, it
may damage the top tether strap
during a collision. Your child could
be seriously injured or killed in a
collision if the child restraint top
tether strap is damaged.

POWER WINDOWS

WARNING

Make sure that all passengers have
their hands, etc. inside the vehicle
while it is in motion and before
closing the windows. Use the win-
dow lock switch to prevent unex-
pected use of the power windows.

To help avoid risk of injury or death
through unintended operation of
the vehicle and or its systems,
including entrapment in windows
or inadvertent door lock activation,
do not leave children, people who
require the assistance of others or
pets unattended in your vehicle.
Additionally, the temperature inside
a closed vehicle on a warm day can
quickly become high enough to
cause a significant risk of injury or
death to people and pets.

The power windows operate when the ignition
switch is in the ON position or for about 45
seconds after the ignition switch is pushed to
the OFF position. If the driver’s or front
passenger’s door is opened during this period

Instruments and controls

2-45

WINDOWS

Condition:

Nissan 370Z Roadster (2017 year). Instruction - part 7
