Nissan Note E12. Manual - part 634

TM-94

< SYSTEM DESCRIPTION >

[CVT: RE0F11A]

DIAGNOSIS SYSTEM (TCM)

LINE PRESSURE SEN

(V)

×

Displays the signal voltage of the line pressure sensor.

ATF TEMP SEN

(V)

×

Displays the signal voltage of the CVT fluid temperature
sensor.

G SENSOR

(V)

×

Displays the signal voltage of the G sensor.

VIGN SEN

(V)

×

Displays the battery voltage applied to TCM.

VEHICLE SPEED

(km/h or mph)

×

Displays the vehicle speed recognized by TCM.

INPUT REV

(rpm)

Displays the input shaft speed of CVT recognized by
TCM.

PRI SPEED

(rpm)

×

Displays the primary pulley speed recognized by TCM.

SEC SPEED

(rpm)

Displays the secondary pulley speed recognized by
TCM.

OUTPUT REV

(rpm)

Displays the output shaft speed of CVT recognized by
TCM.

ENG SPEED

(rpm)

×

Displays the engine speed recognized by TCM.

SLIP REV

(rpm)

×

Displays the speed difference between the input shaft
speed of CVT and the engine speed.

TOTAL GEAR RATIO

×

Displays the total CVT gear ratio calculated from input
shaft speed/output shaft speed of CVT.

PULLEY GEAR RATIO

×

Displays the pulley gear ratio calculated from primary
pulley speed/secondary pulley speed.

AUX GEARBOX

Displays the gear position of the auxiliary gearbox recog-
nized by TCM.

G SPEED

(G)

Displays the acceleration and deceleration speed of the
vehicle calculated from vehicle speed change.

ACCEL POSI SEN 1

(deg)

×

×

Displays the estimated throttle position received through
CAN communication.

VENG TRQ

(Nm)

×

Display the engine torque recognized by TCM.

PRI TRQ

(Nm)

Display the input shaft torque of CVT.

TRQ RTO

Display the torque ratio of torque converter.

LINE PRESSURE

(MPa)

×

Displays the secondary pressure (line pressure) calcu-
lated from the signal voltage of the secondary pressure
sensor.

FLUID TEMP

 (

°C or °F)

×

Displays the CVT fluid temperature calculated from the
signal voltage of the CVT fluid temperature sensor.

DSR REV

(rpm)

Displays the target primary pulley speed calculated from
processing of gear shift control.

TRGT GEAR RATIO

Displays the target gear ratio from the input shaft to the
output shaft of CVT calculated from processing of gear
shift control.

TGT PLLY GR RATIO

Displays the target gear ratio of the pulley from process-
ing of gear shift control.

TRGT AUX GEARBOX

Displays the target gear of the auxiliary gearbox calculat-
ed from processing of gear shift control.

LU PRS

(MPa)

Displays the target oil pressure of the torque converter
clutch solenoid valve calculated from oil pressure pro-
cessing of gear shift control.

Monitored item

(Unit)

Monitor item selection

Remarks

MAIN SIG-

NALS

ECU IN-

PUT SIG-

NALS

DIAGNOSIS SYSTEM (TCM)

TM-95

< SYSTEM DESCRIPTION >

[CVT: RE0F11A]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

LINE PRS

(MPa)

Displays the target oil pressure of the line pressure sole-
noid valve calculated from oil pressure processing of
gear shift control.

TRGT PRI PRESSURE

(MPa)

Displays the target oil pressure of the primary pressure
solenoid valve calculated from oil pressure processing of
gear shift control.

TRGT HC/RB PRESS

(MPa)

Displays the target oil pressure of the high clutch & re-
verse brake solenoid valve calculated from oil pressure
processing of gear shift control.

TRGT LB PRESSURE

(MPa)

Displays the target oil pressure of the low brake solenoid
valve calculated from oil pressure processing of gear
shift control.

ISOLT1

(A)

×

Displays the command current from TCM to the torque
converter clutch solenoid valve.

ISOLT2 (A)

×

Displays the command current from TCM to the line
pressure solenoid valve.

PRI SOLENOID

(A)

×

Displays the command current from TCM to the primary
pressure solenoid valve.

HC/RB SOLENOID

(A)

×

Displays the command current from TCM to the high
clutch& reverse brake solenoid valve.

L/B SOLENOID

(A)

×

Displays the command current from TCM to the low
brake solenoid valve.

SOLMON1

(A)

×

×

Monitors the command current from TCM to the torque
converter clutch solenoid valve and displays the moni-
tored value.

SOLMON2

(A)

×

×

Monitors the command current from TCM to the line
pressure solenoid valve and displays the monitored val-
ue.

PRI SOL MON

(A)

×

×

Monitors the command current from TCM to the primary
pressure solenoid valve and displays the monitored val-
ue.

HC/RB SOL MON

(A)

×

×

Monitors the command current from TCM to the high
clutch& reverse brake solenoid valve and displays the
monitored value.

L/B SOL MON

(A)

×

×

Monitors the current command from TCM to the low
brake solenoid valve and displays the monitored value.

D POSITION SW

(On/Off)

×

Displays the operation status of the transmission range
switch (D position).

N POSITION SW

(On/Off)

×

Displays the operation status of the transmission range
switch (N position).

R POSITION SW

(On/Off)

×

Displays the operation status of the transmission range
switch (R position).

P POSITION SW

(On/Off)

×

Displays the operation status of the transmission range
switch (P position).

BRAKESW

(On/Off)

×

×

Displays the reception status of the stop lamp switch sig-
nal received through CAN communication.

L POSITION SW

(On/Off)

×

Displays the operation status of the transmission range
switch (L position).

IDLE SW

(On/Off)

×

×

Displays the reception status of the closed throttle posi-
tion signal received through CAN communication.

SPORT MODE SW

(On/Off)

×

×

Displays the reception status of the overdrive control
switch signal received through CAN communication.

Monitored item

(Unit)

Monitor item selection

Remarks

MAIN SIG-

NALS

ECU IN-

PUT SIG-

NALS

TM-96

< SYSTEM DESCRIPTION >

[CVT: RE0F11A]

DIAGNOSIS SYSTEM (TCM)

STRDWNSW

(On/Off)

×

• Displays the operation status of the paddle shifter

(down switch).

• It is displayed although not equipped.

STRUPSW

(On/Off)

×

• Displays the operation status of the paddle shifter (up

switch).

• It is displayed although not equipped.

DOWNLVR

(On/Off)

×

• Displays the operation status of the selector lever

(down switch).

• It is displayed although not equipped.

UPLVR

(On/Off)

×

• Displays the operation status of the selector lever (up

switch).

• It is displayed although not equipped.

NONMMODE

(On/Off)

×

• Displays if the selector lever position is not at the man-

ual shift gate.

• It is displayed although not equipped.

MMODE

(On/Off)

×

• Displays if the selector lever position is at the manual

shift gate.

• It is displayed although not equipped.

INDLRNG

(On/Off)

Displays the transmission status of the shift position (L
position) signal transmitted through CAN communica-
tion.

INDDRNG

(On/Off)

Displays the transmission status of the shift position (D
position) signal transmitted through CAN communica-
tion.

INGNRNG

(On/Off)

Displays the transmission status of the shift position (N
position) signal transmitted through CAN communica-
tion.

INGRRNG

(On/Off)

Displays the transmission status of the shift position (R
position) signal transmitted through CAN communica-
tion.

INGPRNG

(On/Off)

Displays the transmission status of the shift position (P
position) signal transmitted through CAN communica-
tion.

CVT LAMP

(On/Off)

Displays the transmission status of the OD OFF indicator
lamp signal transmitted through CAN communication.

SPORT MODE IND

(On/Off)

Displays the transmission status of the OD OFF indicator
lamp signal transmitted through CAN communication.

MMODE IND

(On/Off)

• Displays the transmission status of the manual mode

signal transmitted through CAN communication.

• It is displayed although not equipped.

VDC ON

(On/Off)

×

• Displays the reception status of the VDC (ESP) oper-

ation signal received through CAN communication.

• It is displayed although not equipped.

TCS ON

(On/Off)

×

• Displays the reception status of the TCS operation sig-

nal received through CAN communication.

• It is displayed although not equipped.

ABS FAIL SIGNAL

(On/Off)

×

Displays the reception status of the ABS malfunction sig-
nal received through CAN communication.

ABS ON

(On/Off)

×

Displays the reception status of the ABS operation signal
received through CAN communication.

4WD FAIL SIGNAL

(On/Off)

×

• Displays the reception status of the 4WD malfunction

signal received through CAN communication.

• It is displayed although not equipped.

Monitored item

(Unit)

Monitor item selection

Remarks

MAIN SIG-

NALS

ECU IN-

PUT SIG-

NALS

DIAGNOSIS SYSTEM (TCM)

TM-97

< SYSTEM DESCRIPTION >

[CVT: RE0F11A]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

WORK SUPPORT

*: “Clutch point learning” can be selected, but do not use it.

Engine brake adjustment

Check the degradation level of the CVT fluid.

4WD OPERATION SIG

(On/Off)

×

• Displays the reception status of the 4WD operation

signal received through CAN communication.

• It is displayed although not equipped.

4WD-TCS SIGNAL

(On/Off)

×

• Displays the reception status of the engine torque

down request signal received through CAN communi-
cation.

• It is displayed although not equipped.

RANGE

×

Displays the gear position recognized by TCM.

M GEAR POS

×

Display the target gear of manual mode

G SEN SLOPE

 (%)

Displays the gradient angle calculated from the G sensor
signal voltage.

ENGBRKLVL

(On/Off)

Displays the setting of “ENGINE BRAKE ADJ” in “Work
Support”.

PVIGN VOLT

(V)

×

Displays the backup voltage of TCM.

TRGT AUX GR RATIO

Displays the target gear ratio of the auxiliary gearbox cal-
culated from processing of gear shift control.

G SEN CALIBRATION

(YET/DONE)

Displays the status of “G SENSOR CALIBRATION” in
“Work Support”.

N IDLE STATUS

(On/Off)

Displays idle neutral status.

CVT-B

• Displays CVT fluid temperature count.
• This monitor item does not use.

CVT-A

• Displays CVT fluid temperature count.
• This monitor item does not use.

Monitored item

(Unit)

Monitor item selection

Remarks

MAIN SIG-

NALS

ECU IN-

PUT SIG-

NALS

Item name

Description

ENGINE BRAKE ADJ.

Although there is no malfunction on the transaxle and the CVT system, if a customer
make a complaint like “I do not feel comfortable with automatic operation of the engine
brake on downhill”, the engine brake may be cancelled with “engine brake adjust-
ment”.

CONFORM CVTF DETERIORTN

Check the degradation level of the CVT fluid under severe conditions.

G SENSOR CALIBRATION

Compensate the G sensor.

ERASE CALIBRATION DATA

Erase the calibration data memorized by TCM.

ERASE LEARNING VALUE

Erase the learning value memorized by TCM.

ERASE MEMORY DATA

Perform “erasing of the calibration data” and “erasing of the learned value” at the same
time.

CLUTCH POINT LEARNING*

Allow learning of the clutch engagement point of the auxiliary gearbox for TCM.

ENGINE BRAKE LEVEL
ON

: Turn ON the engine brake control.

OFF

: Turn OFF the engine brake control.

CVTF degradation level data
