P0011 IVT CONTROL EC-143 < DTC/CIRCUIT DIAGNOSIS > [HR16DE] C D E F G H I J K L M A EC N P O CAUTION: Always drive at a safe speed. 2. Check 1st trip DTC. With GST Follow the procedure “With CONSULT” above. YES >> Proceed to NO >> INSPECTION END Diagnosis Procedure INFOID:0000000009022503 1. CHECK OIL PRESSURE WARNING LAMP 1. Start engine. 2. Check oil pressure warning lamp and confirm it is not illumi- nated. Is oil pressure warning lamp illuminated? YES >> Proceed to NO >> GO TO 2. 2. CHECK INTAKE VALVE TIMING CONTROL SOLENOID VALVE EC-144, "Component Inspection" Is the inspection result normal? YES >> GO TO 3. NO >> Replace intake valve timing control solenoid valve. Refer to . 3. CHECK CRANKSHAFT POSITION SENSOR (POS) EC-226, "Component Inspection" Is the inspection result normal? YES >> GO TO 4. NO >> Replace crankshaft position sensor (POS). Refer to 4. CHECK CAMSHAFT POSITION SENSOR (PHASE) EC-230, "Component Inspection" Is the inspection result normal? YES >> GO TO 5. NO >> Replace camshaft position sensor (PHASE). Refer to . 5. CHECK CAMSHAFT (INTAKE) Check the following. ENG SPEED 1,200 - 3,175 rpm (A constant rotation is maintained.) COOLAN TEMP/S More than 60 °C (140°F) Shift lever 1st or 2nd position Driving location uphill Driving vehicle uphill PBIA8559J |
