Nissan Note E12. Manual - part 164

DLK-160

< REMOVAL AND INSTALLATION >

INSIDE KEY ANTENNA

3. Release clips (A) and remove inside key antenna (luggage

room) (1).

INSTALLATION

Installation is in the reverse order of removal.

ALKIA3208ZZ

OUTSIDE KEY ANTENNA

DLK-161

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

OUTSIDE KEY ANTENNA

OUTSIDE HANDLE
OUTSIDE HANDLE : Removal and Installation

INFOID:0000000009567387

REMOVAL

1. Remove outside handle. Refer to

DLK-147, "OUTSIDE HANDLE : Removal and Installation"

.

2. Remove screw (1) and outside handle finisher (1) from outside

handle (2).

3. Remove outside key antenna (outside handle) (1) from outside

handle (2).

INSTALLATION

Installation is in the reverse order of removal.

REAR BUMPER
REAR BUMPER : Removal and Installation

INFOID:0000000009567388

REMOVAL

1. Remove the rear bumper fascia. Refer to

EXT-18, "Removal and Installation"

.

2. Disconnect the harness connector from the outside key antenna (rear bumper)
3. Release clips (A) and remove outside key antenna (rear

bumper) (1).

INSTALLATION

Installation is in the reverse order of removal.

ALKIA3209ZZ

ALKIA3210ZZ

JMKIA7952ZZ

DLK-162

< REMOVAL AND INSTALLATION >

DOOR REQUEST SWITCH

DOOR REQUEST SWITCH

DRIVER SIDE
DRIVER SIDE : Removal and Installation

INFOID:0000000009671358

The door request switch (driver side) is serviced as an assembly with the outside handle. Refer to

DLK-147,

"OUTSIDE HANDLE : Removal and Installation"

.

PASSENGER SIDE
PASSENGER SIDE : Removal and Installation

INFOID:0000000009671359

The door request switch (passenger side) is serviced as an assembly with the outside handle. Refer to

DLK-

147, "OUTSIDE HANDLE : Removal and Installation"

.

BACK DOOR
BACK DOOR : Removal and Installation

INFOID:0000000009671360

REMOVAL

1. Remove back door outer finisher. Refer to

EXT-34, "Removal and Installation"

.

2. Remove screws (A) and back door request switch (1) from back

door outer finisher (2).

INSTALLATION

Installation is in the reverse order of removal.

AWKIA2584ZZ

INTELLIGENT KEY WARNING BUZZER

DLK-163

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

INTELLIGENT KEY WARNING BUZZER

Removal and Installation

INFOID:0000000009567389

REMOVAL

1. Remove front combination lamp (LH). Refer to

EXL-108, "Removal and Installation"

2. Remove bolt (A) and Intelligent Key warning buzzer (1).

INSTALLATION

Installation is in the reverse order of removal.

JMKIA7949ZZ
