FRONT FOG LAMP
EXL-115
< REMOVAL AND INSTALLATION >
C
D
E
F
G
H
I
J
K
M
A
B
EXL
N
O
P
FRONT FOG LAMP
Bulb Replacement
INFOID:0000000001572915
1.
Remove front portion of fender protector. Refer to
EXT-20, "Removal and Installation of Front Fender Pro-
2.
Disconnect fog lamp connector.
3.
Turn the bulb counterclockwise to remove it.
CAUTION:
• Do not touch the glass of bulb directly by hand. Keep
grease and other oily substances away from it. Do not
touch bulb by hand while it is lit or right after being turned
off. Burning may result.
• Do not leave bulb out of fog lamp reflector for a long time
because dust, moisture smoke, etc. may affect the perfor-
mance of fog lamp. When replacing bulb, be sure to
replace it with new one.
Removal and Installation
INFOID:0000000001572914
FRONT FOG LAMP
The fog lamp is a semi-sealed beam type which uses a replaceable halogen bulb.
CAUTION:
• Do not leave fog lamp assembly without bulb for a long period of time. Dust, moisture, smoke, etc.
entering the fog lamp body may affect the performance. Remove the bulb from the headlamp assem-
bly just before replacement bulb is installed.
• Grasp only the plastic base when handling the bulb. Never touch the glass envelope. Touching the
glass could significantly affect the bulb life and/or fog lamp performance.
Removal
1.
Remove front portion of fender protector. Refer to
EXT-20, "Removal and Installation of Front Fender Pro-
2.
Disconnect fog lamp connector.
3.
Remove fog lamp screws and pull fog lamp rearward out of front
bumper.
Installation
Installation is in the reverse order of removal.
LKIA0573E
LKIA0574E
