BACK DOOR WINDOW GLASS
GW-29
< REMOVAL AND INSTALLATION >
C
D
E
F
G
H
I
J
L
M
A
B
GW
N
O
P
5. Remove back door glass (1) using a suitable tool (3).
(2): Back door assembly
• Apply protective tape around the back door window glass to
protect the painted surface from damage.
• If the back door window glass is to be reused, mark the body
and the glass with mating marks.
WARNING:
When cutting the back door window glass from the vehicle,
always wear safety glasses and heavy gloves to help pre-
vent glass splinters from entering your eyes or cutting your
hands.
CAUTION:
• Be careful not to scratch the back door window glass when removing.
• Do not set or stand glass on its edge. Small chips may develop into cracks.
• Apply a protective tape around the back door window glass to protect the painted surface from
damage.
6. Use an inflatable pump bag (3) to assist with removing the back
door window glass (2).
(1): Back Door Assembly
7. Remove the back door window glass (1) from the back door
assembly (2).
INSTALLATION
Installation is in the reverse order of removal.
• Use a genuine NISSAN Urethane Adhesive Kit (if available) or equivalent and follow the instructions fur-
nished with it.
• Adhesive shall be continuously applied to assure watertightness. Glass installation shall be finished within
five minutes after applying the adhesive.
• While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out
by passenger compartment air pressure when a door is closed.
• The molding must be installed securely so that it is in position and leaves no gap.
• Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely
cured (preferably 24 hours). Curing time varies with temperature and humidity.
WARNING:
• Keep heat and open flames away as primers and adhesive are flammable.
• The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid
contact with the skin and eyes.
• Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled.
If affected by vapor inhalation, immediately move to an area with fresh air.
• Driving the vehicle before the urethane adhesive has completely cured may affect the performance
of the windshield in case of an accident.
CAUTION:
ALKIA2351ZZ
ALKIA2352ZZ
ALKIA2948ZZ
