OPTICAL SENSOR

OPTICAL SENSOR

Description

INFOID:0000000009175383

The optical sensor measures ambient light and transmits the optical sensor signal to the BCM.

Component Function Check

INFOID:0000000009175384

1.

CHECK OPTICAL SENSOR SIGNAL TO BCM

CONSULT

1. Turn the ignition switch ON.

2. Select OPTI SEN (DTCT) of BCM (HEAD LAMP) DATA MONITOR item.

3. Turn the lighting switch to AUTO.

*:Outside light varies. The value may be less than the standard value if brightness is weak.

Is the inspection result normal?

YES

>> Optical sensor is normal.

NO

>> Refer to

EXL-124, "Diagnosis Procedure"

.

Diagnosis Procedure

INFOID:0000000009175385

Regarding Wiring Diagram information, refer to

EXL-40, "Wiring Diagram"

.

1.

CHECK OPTICAL SENSOR POWER SUPPLY INPUT

1. Turn ignition switch ON.

2. Turn lighting switch AUTO.

3. Check voltage between optical sensor harness connector and ground.

Is the inspection result normal?

YES

>> GO TO 2.

NO

>> GO TO 4.

2.

CHECK OPTICAL SENSOR GROUND INPUT

Check voltage between optical sensor harness connector and ground.

Is the inspection result normal?

YES

>> GO TO 3.

NO

>> GO TO 6.

3.

CHECK OPTICAL SENSOR SIGNAL OUTPUT

 With illuminating the optical sensor, check voltage between optical sensor harness connector and ground.

Monitor item

Condition

Voltage (Approx.)

OPTI SEN (DTCT)

When outside of vehicle is bright

3.1 V or more *

When outside of vehicle is dark

0.6 V or less

(+)

(

−)

Voltage

(Approx.)

Optical sensor

Connector

Terminal

M15

1

Ground

5 V

(+)

(

−)

Voltage

(Approx.)

Optical sensor

Connector

Terminal

M15

3

Ground

0 V

OPTICAL SENSOR

EXL-125

< DTC/CIRCUIT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

M

A

B

EXL

N

O

P

*: Illuminate the optical sensor. The value may be less than the standard if brightness is weak.

Is the inspection result normal?

YES

>> GO TO 7.

NO

>> Replace the optical sensor. Refer to

EXL-146, "Removal and Installation"

.

4.

CHECK OPTICAL SENSOR OPEN CIRCUIT

1. Turn ignition switch OFF.

2. Disconnect optical sensor connector and BCM connector.

3. Check continuity between optical sensor harness connector and BCM harness connector.

Is the inspection result normal?

YES

>> GO TO 5.

NO

>> Repair or replace the harness or connector.

5.

CHECK OPTICAL SENSOR SHORT CIRCUIT

Check continuity between optical sensor harness connector and ground.

Is the inspection result normal?

YES

>> Replace BCM. Refer to

BCS-80, "Removal and Installation"

.

NO

>> Repair or replace the harness or connector.

6.

CHECK OPTICAL SENSOR GROUND OPEN CIRCUIT

1. Turn ignition switch OFF.

2. Disconnect optical sensor connector and BCM connector.

3. Check continuity between optical sensor harness connector and BCM harness connector.

Is the inspection result normal?

YES

>> Replace BCM. Refer to

BCS-80, "Removal and Installation"

.

NO

>> Repair or replace the harness or connector.

7.

CHECK OPTICAL SENSOR SIGNAL OPEN CIRCUIT

1. Turn ignition switch OFF.

2. Disconnect optical sensor connector and BCM connector.

3. Check continuity between optical sensor harness connector and BCM harness connector.

(+)

(

−)

Condition

Voltage

(Approx.)

Optical sensor

Connector

Terminal

M15

2

Ground

Optical sensor

When illuminating

3.1 V or more *

When shutting off light

0.6 V or less

Optical sensor

BCM

Continuity

Connector

Terminal

Connector

Terminal

M15

1

M18

3

Yes

Optical sensor

Ground

Continuity

Connector

Terminal

M15

1

No

Optical sensor

BCM

Continuity

Connector

Terminal

Connector

Terminal

M15

3

M18

17

Yes

EXL-126

< DTC/CIRCUIT DIAGNOSIS >

OPTICAL SENSOR

Is the inspection result normal?

YES

>> GO TO 8.

NO

>> Repair or replace the harness or connector.

8.

CHECK OPTICAL SENSOR SHORT CIRCUIT

Check continuity between optical sensor harness connector and ground.

Is the inspection result normal?

YES

>> Replace BCM. Refer to

BCS-80, "Removal and Installation"

.

NO

>> Repair or replace the harness or connector.

Optical sensor

BCM

Continuity

Connector

Terminal

Connector

Terminal

M15

2

M18

4

Yes

Optical sensor

Ground

Continuity

Connector

Terminal

M15

2

No

HAZARD SWITCH

EXL-127

< DTC/CIRCUIT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

M

A

B

EXL

N

O

P

HAZARD SWITCH

Component Function Check

INFOID:0000000009175386

1.

CHECK HAZARD SWITCH SIGNAL BY CONSULT

CONSULT DATA MONITOR

1. Turn ignition switch ON.

2. Select HAZARD SW of BCM (FLASHER) DATA MONITOR item.

3. While operating the hazard switch, check the monitor status.

Is the inspection result normal?

YES

>> Hazard switch circuit is normal.

NO

>> Refer to

EXL-127, "Diagnosis Procedure"

.

Diagnosis Procedure

INFOID:0000000009175387

Regarding Wiring Diagram information, refer to

EXL-56, "Wiring Diagram"

.

1.

CHECK HAZARD SWITCH SIGNAL INPUT

1. Turn ignition switch OFF.

2. Disconnect hazard switch harness connector M26.

3. Turn ignition switch ON.

4. Check voltage between hazard switch harness connector M26 and ground.

Is the inspection result normal?

YES

>> GO TO 4.

NO

>> GO TO 2.

2.

CHECK HAZARD SWITCH SIGNAL OPEN CIRCUIT

1. Turn ignition switch OFF.

2. Disconnect BCM harness connector M18.

3. Check continuity between hazard switch harness connector and BCM harness connector.

Is the inspection result normal?

YES

>> GO TO 3.

NO

>> Repair or replace the harness or connector.

Monitor item

Condition

Monitor status

HAZARD SW

Hazard switch

ON

On

OFF

Off

(+)

(

−)

Voltage

(Approx.)

Hazard switch

Connector

Terminal

M26

2

Ground

JPMIA0154GB

Hazard switch

BCM

Continuity

Connector

Terminal

Connector

Terminal

M26

2

M18

36

Yes
