M = Metallic, S = Solid, 2S = Solid and Clear, 2 P = 2-coat Pearl, 3P = 3-coat pearl, P = Pearl, Black is solvent based, all others are water
based, t = TMAC clear coat

ALKIA2740ZZ

Component

Color code

CAL

HAE

K23

K50

KH3

NAH

RBG

QAA

Description

Brown

Gold

Silver

Gray

Black

Red

Blue

White

Paint type

Hard clear coat

Door mirror

Body color

CAL

HAE

K23

K50

KH3

NAH

RBG

QAA

Front grille

Chromium Plate

Cr2P

Front bumper fascia

Body color

CAL

HAE

K23

K50

KH3

NAH

RBG

QAA

Side guard molding

Chromium Plate

Cr2P

Door outside handle

Chromium Plate

Cr2P

Sill molding

Black

KH3

Rear bumper fascia

Body color

CAL

HAE

K23

K50

KH3

NAH

RBG

QAA

Back door outer finisher

Chromium Plate

Cr2P

Rear spoiler

Body color

CAL

HAE

K23

K50

KH3

NAH

RBG

QAA

Roof side molding

Black KH3

KH3

PRECAUTIONS

BRM-3

< PRECAUTION >

BRM

PRECAUTION

PRECAUTIONS

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"

INFOID:0000000009176364

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along

with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain

types of collision. Information necessary to service the system safely is included in the SR and SB section of

this Service Manual.

WARNING:

• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in

the event of a collision which would result in air bag inflation, all maintenance must be performed by

an authorized NISSAN/INFINITI dealer.

• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal

injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag

Module, see the SR section.

• Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this

Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-

ness connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNING:

• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-

tion ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a

hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing

serious injury.

• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the

battery and wait at least three minutes before performing any service.

BRM-4

< PRECAUTION >

HANDLING PRECAUTIONS FOR PLASTICS

HANDLING PRECAUTIONS FOR PLASTICS

Precautions For Plastics

INFOID:0000000009176365

1. When repairing and painting a portion of the body adjacent to plastic parts, consider their characteristics

(influence of heat and solvent) and remove them if necessary or take suitable measures to protect them.

2. Plastic parts should be repaired and painted using methods suiting the materials

characteristics.

Abbre-

viation

Material name

Heat resisting

temperature

°C (°F)

Resistance to gasoline and

solvents

Other cautions

Polyethylene

60(140)

Gasoline and most solvents are
harmless if applied for a very
short time (wipe up quickly).

Flammable

PVC

Poly Vinyl Chloride

80(176)

Same as above.

Poison gas is emitted
when burned.

EPM/
EPDM

Ethylene Propylene (Diene) co-
polymer

80(176)

Same as above.

Flammable

TPO/
TPR

Thermoplastic Olefine/
Thermoplastic rubber

80(176)

Same as above.

Flammable

Polypropylene

90(194)

Same as above.

Flammable, avoid bat-
tery acid.

Unsaturated Polyester

90(194)

Same as above.

Flammable

Polystyrene

80(176)

Avoid solvents.

Flammable

ABS

Acrylonitrile Butadiene Styrene

80(176)

Avoid gasoline and solvents.

—

PMMA

Poly Methyl Methacrylate

85(185)

Same as above.

—

EVAC

Ethylene Vinyl Acetate

90(194)

Same as above.

—

ASA

Acrylonitrile Styrene Acrylate

100(222)

Same as above.

Flammable

PPE

Poly Phenylene Ether

110(230)

Same as above.

—

Polycarbonate

120(248)

Same as above.

—

PAR

Polyarylate

180(356)

Same as above.

—

PUR

Polyurethane

90(194)

Same as above.

—

PPC

Polypropylene Composite

115 (239)

Same as above

Flammable

POM

Poly Oxymethylene

120(248)

Same as above.

Avoid battery acid.

PBT+
PC

Poly Butylene Terephthalate +
Polycarbonate

120(248)

Same as above.

Flammable

Polyamide (Nylon)

140(284)

Same as above.

Avoid immersing in wa-
ter.

PBT

Poly Butylene Terephthalate

140(284)

Same as above.

—

PET

Polyester

180(356)

Same as above.

—

PEI

Polyetherimide

200(392)

Same as above.

—
