ADP-28
< SYSTEM DESCRIPTION >
DIAGNOSIS SYSTEM (DRIVER SEAT CONTROL UNIT)
WORK SUPPORT
SLIDE PULSE
—
–
×
Value (32768) when battery connections are standard. If it
moves backward, the value increases. If it moves forward,
the value decreases.
RECLN PULSE
—
–
×
Value (32768) when battery connections are standard. If it
moves backward, the value increases. If it moves forward,
the value decreases.
LIFT FR PULSE
—
–
×
Value (32768) when battery connections are standard. If it
moves DOWN, the value increases. If it moves UP, the val-
ue decreases.
LIFT RR PULSE
—
–
×
Value (32768) when battery connections are standard. If it
moves DOWN, the value increases. If it moves UP, the val-
ue decreases.
MIR/SEN RH U–D
“V”
–
×
Voltage input from door mirror sensor (passenger side) up/
down is displayed.
MIR/SEN RH R–L
“V”
–
×
Voltage input from door mirror sensor (passenger side) left/
right is displayed.
MIR/SEN LH U–D
“V”
–
×
Voltage input from door mirror sensor (driver side) up/down
is displayed.
MIR/SEN LH R–L
“V”
–
×
Voltage input from door mirror sensor (driver side) left/right
is displayed.
TILT PULSE
—
–
×
Value (32768) when battery connections are standard. If it
moves DOWN, the value increases. If it moves UP, the val-
ue decreases.
TELESCO PULSE
—
–
×
Value (32768) when battery connections are standard. If it
moves backward, the value increases. If it moves forward,
the value decreases.
Monitor Item
Unit
Main
Signals
Selection
From
Menu
Contents
Work item
Content
Item
EXIT SEAT SLIDE SETTING
Entry/exit assist (seat) can be selected:
ON (operated) – OFF (not operated)
ON
OFF
EXIT TILT SETTING
Entry/exit assist (steering column) can be selected:
ON (operated) – OFF (not operated)
ON
OFF
SEAT SLIDE VOLUME SET
The amount of seat sliding for entry/exit assist can be selected
from 3 items.
40 mm (1.6 in)
80 mm (3.1 in)
150 mm (6 in)
