Mitsubishi Outlander PHEV (2019 year). Instruction - part 32

Tyres and wheels

E01100905104

Tyre

215/70R16 100H

225/55R18 98H

Wheel

Size

16x6 1/2J

18x7J

Offset (Inset)

38 mm

NOTE

l

The tyres that can be installed on your vehicle are shown on the driver’s door label, refer to “Tyre inflation pressures” on page 11-10. For details, contact a
MITSUBISHI MOTORS Authorized Service Point.



Fuel consumption

E01102800056

Item

Combined (laden)

Electric consumption

(Wh/km)

Electric range (km)

CO

2

 (g/km)

Fuel consumption

(L/100 km)

NEDC

*1

40

1.8

148

54

*2

WLTC

*3

46

2.0

169

45

*4

*1

: New European Driving Cycle

*2

: All Electric Range

*3

: Worldwide harmonized Light vehicles Test Cycle

*4

: Equivalent All Electric Range

The values are based on UN R101. It varies depending on driving style, road and traffic conditions, ambient temperature, use of air conditioners
and so forth.

Tyres and wheels

12-09

OGGE19E1

Specifications

12

NOTE

l

The results given do not express or imply any guarantee of all the values of the particular vehicle.
The vehicle itself has not been tested and there are inevitably differences between individual vehicles of the same model. In addition, this vehicle may incor-
porate particular modifications. Furthermore, the driver’s style and road and traffic conditions, as well as the extent to which the vehicle has been driven and
the standard of maintenance, will all affect its value.

l

All mentioned values are referring to a new, driven in vehicle.



Capacity

E01101307558

Capacity

12-10

OGGE19E1

Specifications

12

No.

Item

Quantity

Lubricants

1

Engine oil

Oil pan

4.3 litres

Refer to page 11-05.

Oil filter

0.3 litre

2

Brake fluid

As required

Brake fluid DOT3 or DOT4

3

Washer fluid

4.5 litres

—

4

Engine coolant
[includes 0.65 litre in the reserve tank]

Except  for  vehicles  with  elec-
tric heater

6.5 litres

MITSUBISHI MOTORS GENUINE

SUPER LONG LIFE COOLANT PRE-

MIUM or equivalent

*

Vehicles with electric heater

7.5 litres

5

Rear Motor coolant
[includes 1.07 litre in the reserve tank]

6.5 litres

6

Front Motor fluid

2.2 litres

MITSUBISHI MOTORS GENUINE

CVTF-J4

7

Transaxle fluid

Front

3.46 litres

MITSUBISHI MOTORS GENUINE

ATF SPIII

Rear

0.85 litre

*

: Similar high quality ethylene glycol based non-silicate, non-amine, non-nitrate and non-borate coolant with long life hybrid organic acid tech-

nology

CAUTION

l

For the transaxle fluid, use only the MITSUBISHI MOTORS GENUINE ATF.
Use of a different fluid could damage the transaxle.

Capacity

12-11

OGGE19E1

Specifications

12

No.

Item

Quantity

Lubricants

8

Refrigerant (air conditioner)

520 - 560 g

*1

,

495 - 535 g

HFC-134a

*1

, HFO-1234yf

*1

: Vehicles for Ukraine



Capacity

12-12

OGGE19E1

Specifications

12
